olympia electronics BS-530/1/WP User manual

GENERAL
This device is a sounder for fire detection
panels that offer a strong sound that
covers many square metres. It features
two inputs (N1, N2) for the production of
two different sounds.
This device can co-operate with any fire
detection panel (BSR-2104, BSR-2114,
BS-1632, BS-1634, BS-1636, BS-636).
Installation and Connection
1. First, remove the retaining screw, place
a flat blade screwdriver in the holes of the
plastic hooks and remove the plastic cover
(Image 1 on page 2).
2. Use the supplied mounting parts to install
the siren’s base on the wall. Place the
plastic plugs and fasten the screws to the
mounting holes.
3. Insert the included sealing rings around
the respective recesses (image 2,3 page 2).
4. Place the caps and make a hole in the
center using a small screwdriver. Pass
through the caps the cables to connect the
device.
5. The (+N1 or the +N2) terminal block is
connected to the (+) output of Alarm-1 or
Alarm-2 of the panel and the (-) of the
terminal block is connected to the (-) output
of Alarm-1 or Alarm-2 of the panel.
Accordingly connect in parallel all the
sirens. (The maximum number of sirens
depends on the type of the panel).
6. To select various sound effects use the
dipswitch 1, 2 and 3 and choose the
diserable sound effect, according to tables 2
and 3 on page 3.
7. On the last siren of the line, we must
connect in parallel with its power cables,
the terminal resistor that was removed
from the alarm contacts of the panel.
8. Refit the plastic cover until the plastic
hooks are securely attached (step 1) and
fasten the retaining screw (torque
0.6Nm).
9. Test the device after installation.
ΒS-530/1/WP
High Quality European based Manufacturers
WATERPROOF SOUNDER FOR FIRE DETECTION PANEL
921530005_09_004
Page 1 from 4
Thank you for your trust in our products.
Olympia Electronics - European manufacturer.
TECHNICAL CHARACTERISTICS
21-28V DC
1.2W
IP 65
EN 54-3:2001 +A1:2002 +A2:2006
o
0 to 60 C
Up to 95%
230gr.
141 x 141 x 95 mm
OPERATION VOLTAGE
MAXIMUM CONSUMPTION
MAXIMUM SOUND OUTPUT in1m
ΤYPE OF APPLICATION ENVIRONMENT
MOUNTING
OPERATION TEMPERATURE RANGE
RELATIVE HUMIDITY
EXTERNAL DIMENSIONS
TYPICAL WEIGHT
GUARANTEE
DEGREES OF COVER PROTECTION
PRODUCED IN ACCORDANCE WITH
CONSTRUCTION MATERIAL
2 years
Bayblend FR3010, transparent polycarbonate
Τype B
Wall
94dB (sound effect 1)

TO FIRE
DETECTION
PANE
921530005_09_004
Page 2 from 4
NOTE!!! After finishing the installation, place the
SEAL sticker as shown in the picture.
1
11
Image 1 Image 2
2D i p s w i t c h s i r e n
selections
Image 3
2 2
3
4 4
+N1 +N2
1 2 3
56
ON
3
2

0 91 21
94 22
90 22
87 31
91 29
82 27 92 24
83 27
1
2
3
4
5
6
7
Sound effect
TABLE 2
Tone in accordance to:
Fire Detection Panel connection to +N1
dB mA
11
ONON
22 33
11 11 11 11 11 1
ONON ONON ON ONON ONON ON
22 22 22 22 22 2
33 33 33 33 33 3
11
ONON
22 33
11 11 11 11 11
ONON ONON ON ONON ONON
22 22 22 22 22
33 33 33 33 33
1
ON
2 3
DSW Nr
970Hz continuous BS5839-1:2002 - ‘’evacuate’’ BS5839 Part 1 1988
BS5839-1:2002 - ‘’alert’’ BS5839 Part 1 1988 BS5839-1:2002 - DIN -Tone DIN33404 Part 3 BS5839-1:2002 NEN2575 (Netherlands) ISO8201 High Frequency ISO8201 Low tone - US Temporal Tone LF ISO8201 High tone - US Temporal Tone HF
970Hz (1sec ON - 1 sec OFF) From 1200Hz to 500Hz in 1 sec From 500Hz to 1200Hz in 3.5 sec - 0.5 sec OFF 800Hz - 970Hz alternate at 1Hz Intermittent 2850Hz (0.5 sec ON - 0.5 sec OFF) 970Hz (0.5 sec ON 970 Hz OFF x3 times +1.5 sec OFF) 2850Hz (0.5 sec ON 2850 Hz OFF x3 times +1.5 sec OFF)
TABLE 3
Tone in accordance to:
BS5839-1:2002 - ‘’evacuate’’ BS5839 Part 1 1988 BS5839-1:2002 - ‘’alert’’ BS5839 Part 1 1988 BS5839-1:2002 - DIN -Tone DIN33404 Part 3 BS5839-1:2002 NEN2575 (Netherlands) ISO8201 High Frequency ISO8201 Low tone - US Temporal Tone LF ISO8201 High tone - US Temporal Tone HF
0
91 21
94 22
90 22
87 31
91 29
82 27 92 24
83 27
1
2
3
4
5
6
7
Sound effect
Fire Detection Panel connection to +N2
dB mA
1
ON
2 3
1
ON
2 3
DSW Nr
970Hz continuous 970Hz (1 sec ON - 1 sec OFF) From 1200Hz to 500Hz in 1 sec From 500Hz to 1200Hz in 3.5 sec - 0.5 sec OFF 800Hz - 970Hz alternate at 1Hz Intermittent 2850Hz (0.5 sec ON - 0.5 sec OFF) 970Hz (0.5 sec ON 970 Hz OFF x3 times +1.5 sec OFF) 2850Hz (0.5 sec ON 2850 Hz OFF x3 times +1.5 sec OFF)
921530005_09_004
Page 3 from 4

921530005_09_004
Page 4 from 4
WARRANTY
Olympia Electronics guarantees the quality, condition and operation of the goods. The period of
warranty is specified in the official catalogue of Olympia Electronics and also in the technical leaflet,
which accompanies each product. This warranty ceases to exist if the buyer does not follow the
technical instructions included in official documents given by Olympia Electronics or if the buyer
modifies the goods provided or has any repairs or re-setting done by a third party, unless Olympia
Electronics has fully agreed to them in writing. Products that have been damaged can be returned to
the premises of our company for repair or replacement, as long as the warranty period is valid.
Olympia Electronics reserves the right to repair or to replace the returned goods and to or not charge
the buyer depending on the reason of defection. Olympia Electronics reserves the right to charge or
not the buyer the transportation cost.
HEAD OFFICE
72nd km. Ο.N.R. Thessaloniki-Κaterini
P.C. 60061 Greece
www.olympia-electronics.gr
[email protected]
0848-CPR-023 16
EN 54-3:2001 +A1:2002 +A2:2006
BS-530/1/WP
WATERPROOF SOUNDER 0848
KOLINDROS PIERIAS
60061 GREECE
Certification
The waterproof sounder BS-530/1/WP is certified from H.E.E.Q.A.C. Also H.E.E.Q.A.C.
controls the production under CPR number:
