Olympus USPM-RU-W Series User manual

PV8344F4E013
I
Optical Measuring Instrument
Operation Manual
USPM-RU-W series
USPM-W-B
Before use
Thank you for your purchasing our NIR Micro Spectrophotometer.
To use this product safely and satisfactorily benefit from doing so, please take the time to
carefully read this Operation Manual before using the product.
Keep this manual handy when using the product, and store it close to the unit for future
reference. Page 9 of this manual contains the warranty. Fill in the necessary items, and
store it in a safe place.

PV8344F4E013
II
Contents
Preface ····································································1
Cautions, Ratings and Graphic Symbols ···························2
For Safe Use·····························································4
Product Features ····················································· 11
1. Confirming the Package Contents ························· 12
2. Names and Functions of
Parts and their Specifications ······························· 14
3. Installation and Connection ·································· 19
4. How to Use······················································· 26
5. Precautions for Storage······································· 41
6. Troubleshooting················································· 44
7. Compliance with Regulations ······························· 46
Appendix································································ 47
䞉Principles of measurement
䞉Precautions for safe use of the lighting device (lamp house)
(Check list for inspection of the lighting device (lamp house))
䞉Precautions for proper use of the power cord

PV8344F4E013
1
Preface
Usage environment
Use the unit in an environment that conforms to the specification on the usage
environment.
Refer to 2.3 Product specification for the usage environment conditions.
How to carry
For how to carry the unit, refer to 3.1 To transfer and install the main unit.
How to clean
For how to clean the unit, refer to 5.2 (2) Cleaning.
About the lamp house
Though heavily dependent on the usage conditions (ambient temperature and
humidity, supply voltage, period of lighting, etc.), the useful life of the lighting device
(lamp house) * assumes either short one of for approximately eight years䠄In the case
of the use of approximately eight hours a day䠅or approximately 20,000 hours .
*The above statement does not guarantee freedom from failures or repair at no 㻌
charge during the service life.
* Depending on the usage conditions, there is a possibility of aging degradation in a
shorter period.
Inspect the lamp house according to Appendix: Checklist for inspection of the
lighting device (lamp house) until the lamp house reaches the end of its useful life.
Should any unexpected incident occur (e.g., smoke) during use, turn off the power
immediately and contact the sales representative where you purchased the unit or our
sales department. Regular inspection is recommended, in order to achieve safe use
and reduce downtime.
About the reference sample
The reference data once a year is recommended to be updated because 45reference
sample and the high reflection reference sample give the mirror court. Please contact
the shop or our business window of store purchased when you update it.
About the personal computer (hereinafter "computer")
We (Olympus) will take no responsibility for any and all damage arising out of the use
or malfunction of the unit, including, but not limited to, any damage to the data stored
in your personal computer(s). Please make a backup copy of your computer system
and keep it in a safe place. (Olympus does not provide any backup support.)
We assure the quality of the unit when it is shipped from our factory. No malfunction
or disability due to any change in the environment settings of the computer (e.g., any
change in the BIOS) or the installation of other applications, are covered by the
quality assurance of Olympus.
When there is only a small amount of free space in the computer’s hard disk drive
this may make the data processing take longer or even cause errors. Delete
unneeded data files regularly. For how to delete data files, refer to the operating
system manual.
NEVER delete or rename any folders already included on the hard disk drive of the
computer in the configuration at shipment. Otherwise, the software may become no
longer usable.

PV8344F4E013
2
Cautions, Ratings and Graphic Symbols
[Safety symbols]
An NIR micro spectrophotometer has labels with the following marks.
Handle it carefully, keeping the meanings of the marks in mind.
[Locations of the warning labels and rating labels]
Warning labels and rating labels are indicated in the places shown in the figure. If any
one of them is missing or any warning label becomes dirty or starts to peel, contact your
supplier or our sales department for a replacement.
Symbols
Description
Don not touch with your hand.
There is a risk of
burns.㻌
Indicates any unspecified danger. Follow the precaution
described
next to this mark.
The main switch is turned ON.
The main switch is turned OFF.
U
Warning Plate
Indicates precautions about
replacement of lamps.
U
Rating Label
Indicates the input rating
and its
Serial No.
This product corresponds to RISK GROUP2 in the UV range (200
-400nm) based on IEC62471-2.
In addition, this product corresponds to RISK GROUP1 in the blue light range
(300-700nm).

PV8344F4E013
3
[Symbols on the box]
The box has the following symbols:
Indicates th
is side up.
Indicates the
box should be protected from rain.
Indicates the
items inside are fragile and the box should be handled
with
care.
Indicates the compatibility with China RoHS.

PV8344F4E013
4
For Safe Use
The purpose of the unit
This unit is designed to measure the spectroscopic characteristics, such as reflectance
and transmittance. Do not use it for any other purpose.
About this Operation Manual
This Operation Manual contains essential information for the safe and effective use of the
unit. Before use, please read this Operation Manual and the manuals of the devices used
in combination with the unit. Take care to understand the contents and always follow their
instructions.
Safety cannot be ensured when the unit is used in any manner not covered in this
Operation Manual.
Keep this Operation Manual and the manuals of the associated devices in a place where
you can access them easily. If you have any questions on the content of this Operation
Manual, please contact the sales representative where you purchased the unit or the
sales department at Olympus.
NEVER repair or modify the unit
NEVER disassemble or modify the unit except to replace consumables. Otherwise, there
is a risk of injury, damage to equipment, and inability to secure the proper functioning of
the unit. Take measures according to section "6. Troubleshooting" if a repair is
considered necessary. When you cannot fix a problem, send the unit for repair to the
supplier where you purchased it or to the Olympus sales department.
Warnings in this document
This document uses the following symbols and terms in the manner as described below.
These symbols and terms are classified into several safety levels. To use the unit safely
and properly, make sure that you thoroughly understand the contents of the symbols and
terms.
Failure to follow these precautions may result in serious injury or
death.
Failure to follow these precautions may result in injury or material
damage to
this Product or peripheral devices.

PV8344F4E013
5
Symbols denoting prohibition (prohibited actions)
Symbols denoting obligation (mandatory actions)
Symbols denoting caution
General precautions on handling
Strictly adhere to the following precautions when handling this unit. Please observe the
precautions provided in the subsequent chapters.
Do not place the unit in a location subject to lamp smoke, vapor,
moisture, or excessive dust!
Doing so may cause a fire or electrical shock. Do not place the unit in a
location that is exposed to direct sunlight, or in a location that is subject to
extreme variations in temperature, such as near heating equipment or
thermal equipment. Do not place the unit in a location subject to moisture or
excessive dust.
Do not put water or foreign objects inside the unit!
Doing so may cause a fire or electrical shock hazard. When water or any
foreign object gets inside the unit, turn off the power and unplug the power
cord immediately, and then contact to supplier where you purchased it or the
Olympus sales department.
Failure to follow these precautions may result in
serious injury or
death.

PV8344F4E013
6
Do not disassemble or modify the unit!
Disassembly or modifying the unit for a reason other than replacement of
consumables may cause fire, electric shock hazard or injury. If an
abnormality occurs, such as unusual odor or noise, immediately turn off the
power, remove the power plug from the wall outlet, and contact our sales
representatives or our sales department for repair. For your own safety,
never attempt to perform repairs on your own.
Do not cover the vents!
There are vents for heat dissipation on the front and the side of the
photometric head.
Be careful not to cover the vents.
Install the unit at least 10 cm away from a wall!
Since the lamp house gets hot when the lamp is illuminated, place the unit
at a point at least 10 cm away from any walls. Operating the unit near a wall
may cause fire.
Do not touch the lamp house or put anything on it!
Do not touch the top of the lamp house that becomes hot when the lamp is
illuminated. Do not put anything on the lamp house. There is the danger of
burns or fire.
Do not place the plastic cover on the lamp house until it has cooled!
Since the lamp house gets hot when lamp is illuminated, do not place the
plastic cover on it until the lamp house has cooled. Otherwise, there is a risk
of fire.
UDo not watch the light of the halogen lamp directly!
UDo not watch the light of the halogen lamp directly.
Eyes might be damaged

PV8344F4E013
7
Use the prescribed power supply
Use the prescribed power supply in this operation manual. If any power
supply other than that prescribed in this manual is used, the safety
performance of the product cannot be guaranteed, and fire may result.
Use the supplied power cord and cable.
Be sure to use the supplied power cord and cable.
Use of any power cord or cable other than that supplied may cause a failure
such as the generation of noise or a malfunction due to external noise. The
supplied power cord and cable cannot be used with other equipment. For
products for which the power cord is not supplied, review Precautions for
proper use of the power cord before selecting an appropriate power cord.
Do not operate the unit with wet hands!
Operating the unit or removing/inserting the power plug with wet hands may
cause electrical shock.
Ground the unit securely!
Connect the earth terminal of a three-terminal outlet to the ground for safety.
Imperfect grounding may cause electric shocks.
About the warning labels
On the lamp house, which gets very hot, warning labels are affixed (See
page 2). Follow the instructions on the labels. If a warning label gets dirty or
starts to peel, contact the supplier where you purchased the unit or our sales
department for replacements.
Replacement of fuses
Before replacing a fuse, turn off the power and unplug the power cord, to
prevent an electrical shock.
Do not use the unit for any purpose other than the intended!
This device is intended to measure spectroscopic characteristics, such as
reflectance and transmittance. Do not use any other purpose than the
intended.

PV8344F4E013
8
Do not place the unit in an unstable location!
If the unit is placed on an unstable stand, on an incline, or on a rigid floor, it
may be knocked over or fall down, resulting in injury.
Fully check the strength and incline of the installation location.
Do not attempt to replace a lamp just after turning it off!
The lamp is hot just after the light is turned off. Wait until the lamp cools
before replacing it. Otherwise there is a risk of burns.
Pay attention when adjusting focus!
In adjusting focus, pay close attention to the location of the objective lens so
that it does not touch a sample.
Measure a room-temperature sample!
Measure a room-temperature sample. A high-temperature sample may
cause heat deformation of or damage to the stage.
Failure to follow these precautions may result in injury or material
damage to
this Product or peripheral devices.

PV8344F4E013
9
Warranty
(1) Warranty Card
***** Warranty Card *****
(Product Name) NIR Micro Spectrophotometer(Model Name) USPM-W-B
SerialNo.
*TheusermustentertheserialNo.
Customer Information
Name
Address
Phone Number
(Warranty Period) One year from the date of purchase or after 2000 hours of use,
whichever comes first.
(Date of Purchase) _________________________________________
(Vendor) _________________________________________
(2) Warranty Conditions
This warranty guarantees free repair for the following conditions.
[Free Repair]
1) Olympus Corporation will repair, free of charge, any problem caused by a
manufacturing defect, provided that the problem occurred while correctly using
the product in compliance with the provisions of the manual during the warranty
period.
2) We do not warrant any failure due to other causes (ex. peripheral devices or the
environment of the installation site).
3) Regardless of the warranty period, there will be a charge to repair the following:
Defect or damage due to the incorrect use of the device.
Defect or damage due to acts of God (lightening or flood, etc.) or other
unforeseeable accidents.
Defect or damage due to apparatuses other than this device.
Defect or damage to a part or component that is repaired or modified by an
individual other than Olympus service personnel, or defect or damage due
to such repair or modification.
Defect or damage to a product whose serial number has been deliberately
changed or removed.
Defect or damage to an expandable items.
4) For details on how to have defects repaired in Japan or overseas, contact the
service department at Olympus Corporation. Contact the support division given
in the attachment.

PV8344F4E013
10
* The warranty card guarantees any free-of-charge repair under the terms and conditions
specified in this document. The warranty is not intended to restrict the right of the
customer. Even after the warranty period, the service department at Olympus will gladly
welcome any questions. Contact the support division given in the attachment.
Although we went to great effort to confirm the accuracy of the contents of this
document, if you feel that certain points are unclear, or find any mistakes or
omissions, please contact the service department at Olympus Corporation. Contact
the support division given in the attachment.
Regardless of the preceding provision, we will take no responsibility for the impact of
the approved outcome.

PV8344F4E013
11
Product Features
The Product has the following features:
Wideband measurement
The unit is able to measure the spectroscopic characteristics within the wide wavelength
range of 380 nm to 1,050 nm.
Measurement in a minute area
The unit is able to measure the surface reflectance of a minute area (φ70 μm (φ17 μm
with an optional x40 objective lens)) in a sphere or a micro-optical part.
Measurement of thin plates
The product is able to measure plates of thickness of 1 mm (0.15 mm with an optional
x40 objective lens).
Reflectivity measurement㻌of㻌Part around lens
The reflectivity measurement in the part around the lens becomes easy in using optional
rotation stage.
*The measurement that is optional and provides for permeability, 45-degree reflectivity
measurement of the incidence, and the polarizing direction can be done.
This device is intended to measure spectroscopic characteristics,
such as reflectance and transmittance. Do not u
se it for anything
other than the intended purpose.

PV8344F4E013
12
1. Confirming the Package Contents
Check the package to confirm the main unit and all accessories are included in accord
with the table shown below. Also, check that no part has been damaged in transit. If you
find anything missing or discover a component has been damaged, or have any
questions, please contact your sales representative or our sales department before
attempting to use anything in the package.
1.
NIR Micro Spectrophotometer: USPM-W-B Operation Manual
2. Spectral Analysis Software: USPM
-SA Operation Manual
3. Spectral Analysis Software: USPM
-SA Installation Instructions
4. Main unit
5. controller supply unit
6. Lamp house
7. x10 objective lens
8. x20 objective lens
9. x40 object ive lens
䈜10. BK7 reference sample
䈜11. Wavelength calibration sample
12. USB cables
13. Lamp cable
14. IO cable
15. Application software
CD-ROM
16. Protection key
䈜We can provide you with our document (for a fee)
describing the calibration of BK7 refer
ence sample and
Wavelength
calibration sample, if necessary. Please
contact the supplier where you purchased the unit or our
sales department.

PV8344F4E013
13
䈜It is a reference sample for the high reflectivity sample. Reference data CD is attached.
The reference data once a year is recommended to be updated because the high
reflectivity reference sample give the mirror court. Please contact the shop or our
business window of store purchased when you update it.
Item
Num.
Description
1
NIR Micro Spectrophotometer USPM-W-B Operation Manual
1
This document
2
Spectral Analysis Software USPM-SA Operation Manual
1
3
Spectral Analysis Software USPM-SA Installation Instructions
1
4
Main unit
1
5
Controller supply unit
1
6
Lamp house
1
7
x10 objective lens
Model: USPM-OBL10
1
8
x20 objective lens
Model: USPM-OBL20
1
9
x40 objective lens
Model: USPM-OBL40
1
Optional
10
BK7 reference sample
1
Reference
11
Wavelength calibration sample
1
Reference of wavelength
calibration
12
USB cables
2
1.5 m
13
Lamp cable
1
1.5 m
14
IO cable
1
1.5 m
15
Application software CD-ROM
1
Including drivers
16
Protection key
1
17
Halogen lamps (for the unit only)
5
4 spares
18
Fuses: Rated voltage/current: 250 V AC, 3.15 A
Size: φ5.2 mm u20 mm
Time delay fuse ,high breaking capacity type
3
2 spares
19
Caps for the revolver
5
20
Hexagon wrench
1
For Work installation board㻌
detaching
21
Rotation stage (with two M3 u18 screws)
1
Optional
22
High-reflectivity reference sample (with data CD)
1
Optional
20. Hexagon wrench
21. Rotation stage
䈜22. High-reflectivity reference sample
19. Caps for the revolver
17. Halogen lamps
18. Fuses
A computer and its power cord are prepared separately.
Use the computer properly in accordance with its manuals.
Do not install
any other applications than those specified.
Such unauthorized applications may cause a system failure.

PV8344F4E013
14
2. Names and Functions of Parts and
their Specifications
2.1. The names and functions of each part in the unit
The functions and the operations of each part in the unit are presented below:
1. Lamp connector
Supplies power to the lamp house. It is connected to the controller supply unit via the
lamp cable.
2. Lamp house
Accommodates a halogen lamp. For details, refer to “3. Installation and Connection”.
3. Photometric head
Contains the optical system for spectrophotometry.
4. IO connector
Supplies control power. It is connected to the controller supply unit via the IO cable.
Front view of the main unit
Rear view of the main unit
2. Lamp
house
3.
Photometric head
4.
IO connector
5.
USB connector
6. Revolver
7. Object
ive lens
8. Focus adjuster
9. Shift
stage
1. Lamp connector

PV8344F4E013
15
5. (Two) USB connectors
Transmit video signals and control signals. Each of them is connected to the computer
via a USB cable.
6. Revolver
An objective lens is placed on it. For detail, refer to “3. Installation and Connection”.
7. Objective lenses
Choose and place one of them on the revolver according to the application.
8. Focus adjuster
Moves the photometric head and an objective lens in the vertical direction. The load
adjuster is available for adjusting the load on the motion of focus.
9. Shift stage
The coarse tuning knob and the fine tuning knob are used to adjust the position of the
sample on the stage in the horizontal direction (forward or backward, or right or left).
Coarse tuning knob
Fine tuning knob
Load adjuster
Fine tuning knob
Coarse tuning knob
All the object lenses are for use in the unit only. Do
not
use any of them in other
devices.

PV8344F4E013
16
2.2. The names and functions of the items on the controller supply unit
The functions and operating methods are shown below:
1. Power switch
Turn on or off the power of the controller supply unit.
2. Power indicator
Light on when power is on and off when power is off.
3. Lamp 1 switch / Lamp 2 switch
Supplies power to the lamp house or switches the power destination. Turning on a
switch supplies power through the corresponding connector (Lamp 1 or Lamp 2
connector) to illuminate the halogen lamp.
4. Lamp 1 connector / Lamp 2 connector
Each connector supplies power to the corresponding lamp house.
Connect a LAMP cable to each connector. (DC 12V )
5. IO connector
Supplies control voltage to the unit. Connect an IO cable. (DC 12V )
6. Power inlet
Connect the power cord here to supply power to the controller supply unit. The
component is equipped with a fuse. For details on replacing the fuse, refer to 3.4
Installation and replacement of fuses.
Front view of the controller supply unit
Rear view of the controller supply unit
2. Power indicator
4. Lamp 1
connector
Lamp 2 c
onnector
5. IO connector
6. Power inlet
3. Lam
p 1 switch
Lamp 2 switch
1. Power switch
Lamp 2 switch and connector are used wi
th an optional unit
(Transmittance measurement set, 45
-degree measurement set).
Always use the supplied cable.
With any other cables, there is a risk of malfunction due to internal or external
noise. The supplied cables may not be used for any other devices.

PV8344F4E013
17
2.3. Product specification
Item
Specification
Name
NIR Micro Spectrophotometer
Model
USPM-W-B
Wavelength range
380 nm - 1,050 nm
Display resolution
of wavelength
About 1 nm
(Wavelength resolution About 5 nm )
Repeatability
With 10x
/20x objective lens
±0.02[%] or less (430 nm - 1,010 nm),
±0.2[%] or less (in other ranges)
With 40x object
ive lens
±0.05[%] or less (430 nm - 950 nm),
±0.5[%] or less (in other ranges)
Analysis of film thickness
±1[%] or less
Halogen lamps
Custom halogen lamps supplied by Life Elex: JC12V 55W (*Average life: 700 h)
*
Average life is the time when half of test samples are burned out.
In short, the time at which the survival rate reaches 50%.
Objective lenses
Model
USPM-OBL10
USPM-OBL20
USPM-OBL40
Magnification
10x
20x
40x
NA
0.12
0.24
0.24
Range (Spot dia.)
70 μm
35 μm
17.5 μm
Distance
14.3 mm
4.2 mm
2.2 mm
curvature radius of
sample
±5mm䡚
±1mm䡚
±1mm䡚
Thickness of sample
1.0mm䡚
0.5mm䡚
0.2mm䡚
Shift stage
Size of mounting: 200(W) u200(D) mm; Load: 3 kg
Operating range: (XY) ±40 mm, (Z) 125 mm
Rotation stage
䠄OPTIONAL
䠅
Sample that can be loaded䠖
Diameter
㻌φ5~60mm,
surface of flange
㻌1~10mm,㻌
Height
㻌MAX10mm㻌
Load
㻌䠖㻌150g
Operating range
㻌䠖㻌
±90°
Weight
Main unit: Approx. 26 kg (excluding computer)
Controller supply unit: Approx. 6.7 kg
Dimension
The body: 360(W) u446(D) u606(H)
Controller supply unit: 250(W) u270(D) u125(H)
Power
specification
Input: 100–240 V AC 110 VA 50/60 Hz
Fuse: Rated voltage/curr
ent: 250 V AC, 3.15 A
Size:φ5.2 mm u20 mm
㻌㻌㻌Time lag ,high breaking capacity type Number:2
Computer and
monitor
Computer
- CPU:
Intel CPU 2.0 GHz or better, PC/AT–compatible machine
- Chipset: Made by
Intel Corporation (recommendation)
- Memory: 4
GB or greater is recommended
- HDD
: more than 40 GB
- Supported OS:
Windows®10 Professional (64-bit version)
- An optical drive that can read a CD
-ROM (external types can also be used)
- USB
2.0 u3 ports or greater
- EMC: Class B
Monitor
- Resolution: 1024 u768 or greater㻌㻌㻌㻌㻌㻌㻌- EMC: Class B
Usage
environment
Indoor use
Altitude: up to 2,000 m

PV8344F4E013
18
Temperature: 15ºC - 30ºC
Humidity: 15%
- 60% RH (non-condensing)
Voltage fluctuation:
±10%
Contamination: 2 (IEC60664
-1)
Installation Category (Overvoltage Category): II (IEC60664-1)
