Omer B17.70 CL4-3 Guide
Caratteristiche - Features
Manuale d’uso, manutezione e parti di ricambio Parte 2
Use, maintenance and spare parts manual Part 2
Gebrauchsanweisung, Instandhaltungsrichtlinien und Ersatzteile Teil 2
Manuel d’utilisation, entretien et pièces de rechange Partie 2
Manual de uso, mantenimiento y repuestos Part 2
Manual de utiliza o, manuten o e partes sobresselentes Parte 2çã çã
Handleiding voor gebruik, onderhoud en reservedelslite Deel 2
Brugsanvisning, vedligeholdelse og reservedelslite Del 2
32÷70
160
5÷8,3 bar
70÷120 psi
1,40
3,5
572x91x286
86,7 dB(A)
97,9 dB(A)
2
<2,5 m/s
B17.70 CL4-3
1841750-3_B1770CL4-3_4 201217 IV
Via Foresto 42 - 31058 SUSEGANA TV ITALY Tel.0438455318 Fax 0438/455530 E-mail: omer@omer.it www.omer.it
omers.p.a.
Tecnika carakthristika
Diastaseis se mm
Dvnatothta gemistera, svndeteres
Piesh leitovrgias atm.
Katanalosh aera l/xtvphma
Baros kg
Dvnatothta gemistera , svndeteres
Akoustikh piesh sth qesh ceiristou
Akoustikh iscu
Mesos oros metrhshs kradasmon
sth xeirolabh
Dati tecnici Donnèes techniques Dados tècnicos
Technical data Datos tècnicos Technischengegevens
Technische daten Tekniske data
Misure impiegabili mm Mesures utilisable mm Medidas que se podem utilizar mm
Usable lenghts mm Medidas que se pueden amplear mm Te gebruiken engtes in mm
Gebrauchliche Längen mm Brugbare laengder i mm
Capacità caricatore n° punti Capacitè chargeur n° de points Capacitade carregador n° pontos
Magazine capacity No. of fasteners Capacidad cargador n° puntos Capaciteit magazijn in aantal spijkers
Magazinkapazität Nägel Kapacitet af magasin antal klemmme
Pressione d’esercizio Pression de fonctionnement Pressao de trabalho
Working pressure Presiòn de trabajo Werkdruk
Betriebsdruck Arbejds tryk bar
Consumo aria litri/colpo Consommation air litre/coup Consumo ar litro/golpe
Air consumption litres/shot Consumo aire-litros/golpe Luchtverbruik liter/schot
Luftverbrauch Liter/Schlag Luftforbrug liter/skud
Peso kg Poids kg Peso kg
Weight kg Peso kg Gewicht in kg
Gewicht kg Vaegt kg
Dimensioni (AxBxH) mm Dimension mm Dimencoes mm
Dimensions mm Dimensiones mm Afmetingen in mm
Große mm Dimensioner mm
EN 12549 :1999 ISO 11201 :1995
Pressione sonora in pos. operatore Pression acoustique près de l’opérateur Intensidade sonora perto do operador
Sound pressure at the workstation Presiòn sonora en posición encargado Geluidssterkte op de werkplek
Lärmintensität am Arbeitsplatz Lydstyrke på operatorposten
EN 12549 :1999 ISO 3744 :1994
Potenza sonora emessa Puissance acoustique émise Potência sonora emitida
Emitted sound power Potencia sonora emitida Uitgestraalde geluidssterkte
Ausgestrahlte Lärmintensität Udsendt lydstryrke
EN 28662 :1992 ISO 5349 :1986 ISO 8662 -11
Valore medio ponderato di vibrazione Valeur moyenne pondèrèe de vibration Valor medio ponderado de vibracao
sull’impugnatura mesurèe sur la poignèe medida no punho
Weighted mean value of vibration Valor medio ponderado de vibracion Gewogen gemiddelde vibratiewaarde
on the grip medida en la empunadura
Mitteler Vibrationswert, am Griff Middelvaerdi af vibrationer pa
Gemessen handtaget
®
TupoV karfiou
cod. 1841750-3
Tipo di punto
Type of fastener
Befestigungselement
Type d’agrafe
Tipo de punto
Tipo de ponto
Type nietjes
Tilspændingstype
32 1-1/4"
70 2-3/4"
Brads 17
1,6x2,2
Head width: .137”
Gauge: 14
3,5
Schema di collegamento - Connecting diagram
5 ÷ 8,3 bar
A
RP
D02D0107.50 07.40 07.30 07.25
Dotazioni - Equipment - Ausrüstung - Équipements - Equipamiento - Parecomena Equipamento - Uitrusting - Udstyr
Top loading
Caricamento Superiore
4 strip capacity magazine
Capacità 4 barrette
Remote fire valve NC
Comando a distanza NC
Collegamento per valvola 3/2 NC
Connection for valve 3/2 NC
Parti di ricambio - Spare parts - Ersatzteile - Pièces de rechange - Piezas de repuesto
- Partes sobresselentes - Tabel te raadplegen - ReservedeleAntallaktika
B17.70 CL4-3
cod. 1841750-3
30.82.1
21.80.29
26.83
01.49
02.40.1
22.82
44.80
92.73
01.56.2
44.82
44.73
40.83
01.37
00.54
25.81
86.80
06.25.2
02.48
17.27
28.81
21.83
06.20
09.16
00.14
51.83
00.21
00.09
00.12
53.83
09.21
54.83
91.73
00.14
10.55
50.83
55.83
10.55
Apply Loctite 243
01.51
03.20
17.30.5
03.31
18.04
03.00
50.83.3
52.80
32.85
00.48
80.80.00
06.20
00.37
01.75
27.82
UPGRADE NUMBER
INDICE DI MODIFICA
NIVEAU DE MODIFICATION
INDICADOR DE MODIFICA
0000000
SERIAL NUMBER
MATRICOLA
MATRICULE
MATRICULA
73.71.2
04.10
04.14
68.80
61.83
04.16.5
64.83 43.16.4
05.12
05.16.2
90.80.29
80.80.29 93.47.2
03.12.2
86.17.3
70.80.29
91.00
05.00
60.83
Indice di modifica
Upgrade number
B17.70 CL4-3 44464086
cod. 1841750-3
Parti di ricambio - Spare parts - Ersatzteile - Pièces de rechange - Piezas de repuesto
- Partes sobresselentes - Tabel te raadplegen - ReservedeleAntallaktika
05.35
09.15
05.25
67.80.1
71.87
06.00.1
06.25
Cod. Descrizione Description
00.09 O-Ring O-Ring
00.12 O-Ring O-Ring
00.14 O-Ring O-Ring
00.21 O-Ring O-Ring
00.37 O-Ring O-Ring
00.48 O-Ring O-Ring
00.54 O-Ring O-Ring
01.37 O-Ring O-Ring
01.49 O-Ring O-Ring
01.51 O-Ring O-Ring
01.56.2 O-Ring O-Ring
01.75 O-Ring O-Ring
02.40.1 Guarnizione Gasket
02.48 O-Ring O-Ring
03.00 Dado Nut
03.12.1 Vite Screw
03.20 Vite Screw
03.31 Vite Screw
04.10 Vite Screw
04.14 Vite Screw
04.16.5 Vite Screw
05.00 Dado Nut
05.12 Vite Screw
05.16.2 Vite Screw
05.25 Vite Screw
05.35 Vite Screw
06.00.1 Dado Nut
06.20 Vite Screw
06.25.2 Vite Screw
06.35 Vite Screw
07.25 Chiave esagonale Hex. bar wrench
07.30 Chiave esagonale Hex. bar wrench
07.40 Chiave esagonale Hex. bar wrench
07.50 Chiave esagonale Hex. bar wrench
09.15 Rondella Washer
09.16 Rondella Washer
09.21 Anello elastico Elastic ring
10.55 O-Ring O-Ring
17.27 Tappo Inlet cap
17.30.5 Attacco Connection
18.04 Pistoncino Piston
21.83 Corpo Body
22.82 Testa Head
25.81 Deflettore Deflector
26.83 Cilindro Cylinder
27.82 Anello cilindro Cylinder ring
28.81 Guarnizione testa Head gasket
30.82.1 Pistone Piston
32.85 Ammortizzatore Bumper
40.83 Valvola completa Valve ass’y
43.16.4 Rondella Washer
44.73 Guarnizione cilindro Cylinder gasket
44.80 Ammortizzatore Bumper
44.82 Distanziale Spacer
50.83 Pulsante completo Trigger valve ass’y
50.83.3 Comando a distanza Remote fire valve
51.83 Boccola pulsante Trigger valve housing
53.83 Pistone servovalvola Valve piston
54.83 Pulsante Trigger valve
55.83 Raccordo pulsante Bush
60.83 Guida sx Left guide
61.83 Guida dx Right guide
64.83 Carter Carter
67.80.1 Distanziale Spacer
68.80 Fondello Backplate
71.87 Reggicaricatore Support
73.71.2 Perno Pin
86.17.3 Carrucola Pulley
86.80 Boccola Bush
91.00 Molla Spring
91.73 Molla Spring
92.73 Molla Spring
93.47.2 Molla Spring
21.80.29 Battente Driver
70.80.29 Spingipunto Pusher
80.80.00 Flangia Flange
80.80.29 Controtestina Nose
90.80.29 Testina Nose plate
D01 Boccetta olio Oiler
D02 Occhiali protettivi Protective goggles
00.78.4
02.48
01.75
02.42.2
Guarnizioni - O-Rings - Dichtungen - Joints - Kit O-Rings - Lasticakia - Kit O-Rings - O-ringen - Pakninger
00.54
01.51
00.48
01.37
28.81 10.55
00.09
00.21
00.14
01.56.2
01.49
1841750-3_B1770CL4-3_4 201217 IV
1- Arretrare lo spingipunto fino al finecorsa
Pull the pusher backwards
2
Non azionare MAI la valvola comando
durante il caricamento.
NEVER actuate thecommand valve while
loading magazine.
Caricamento - Loading
1
2- Inserire i punti
Load fasterners
3- Rilasciare lo spingipunto premendo il
pulsante di sgancio
Press the releasing button to release the
pusher
Disinceppamento - Jam clearing
1- Arretrare lo spingipunto fino al finecorsa e
rimuovere i punti
Pull the pusher backwards and remove fastener
2- Allentare le viti e rimuovere la testina
Loosen the screw and remove nose plate
3- Rimuovere il punto inceppato
Remove the jammed nail
4- Riassemblare in ordine inverso ed eseguire il caricamento
Reassemble in reverse order and load with fasteners
Scollegare l’aria prima di procedere
Disconnect air supply before proceeding
3
1
2
