Omnik Omniksol-1k-TL User manual

User Manual V4.2
User Manual
-Installation
-Operation
Omniksol-1k-TL
Omniksol-1.5k-TL
Omniksol-2k-TL
Omnik New Energy Co.,ltd

User Manual V4.2
1
Catalog
1. Notes on this manual .......................................................................................................................................3
1.1 Scope of Validation......................................................................................................................................3
1.2 Symbols Used .............................................................................................................................................3
1.3 Target Group ...............................................................................................................................................4
2. Preparation........................................................................................................................................................5
2.1 Safety Instructions.......................................................................................................................................5
2.2 Explanations of Symbols on Inverter...........................................................................................................6
3. Product Information .........................................................................................................................................8
3.1 Overview......................................................................................................................................................8
3.2 Major Characteristics...................................................................................................................................9
3.3 Datasheet ..................................................................................................................................................10
4. Packing checklist............................................................................................................................................13
4.1 Assembly parts..........................................................................................................................................13
4.2 Product Appearance..................................................................................................................................14
4.3 Product Identification.................................................................................................................................15
4.4 Further Information....................................................................................................................................15
5. Installation.......................................................................................................................................................16
5.1 Safety.........................................................................................................................................................16
5.2 Mounting Instructions ................................................................................................................................16
5.3 Safety Clearance.......................................................................................................................................17
5.4 Mounting Procedure..................................................................................................................................18
5.4.1 Mounting with bracket........................................................................................................................18
5.4.2 Mounting without bracket...................................................................................................................20
5.5 Safety lock.................................................................................................................................................22
5.5.1 Safety lock （with the wall mounting bracket）.................................................................................22
5.5.2 Safety lock （without the wall mounting bracket）............................................................................22
6. Electrical Connection.....................................................................................................................................23
6.1 Safety.........................................................................................................................................................23
6.2 Overview of Connection Area....................................................................................................................24
6.3 AC Side Connection..................................................................................................................................25
6.4 DC Side Connection..................................................................................................................................27
6.5 Communication and Monitoring Device.....................................................................................................32
7. Display.............................................................................................................................................................33
7.1 LCD Panel .................................................................................................................................................33
7.2 LCD Display...............................................................................................................................................34
7.3 Set Language............................................................................................................................................36
7.4 Instructions of Safety Standard selection when power-up........................................................................37
7.5 State Information.......................................................................................................................................39

User Manual V4.2
2
8. Recycling and Disposal .................................................................................................................................40
9. Troubleshooting .............................................................................................................................................41
10. Abbreviation....................................................................................................................................................42
11. Contact.............................................................................................................................................................43

User Manual V4.2
3
1.Notes on this manual
1.1 Scope of Validation
The main purpose of this User’s Manual is to provide instructions and detailed procedures for
installing, operating, maintaining, and troubleshooting the following three types of Omnik New
Energy-Solar Inverters:
Omniksol-1k-TL
Omniksol-1.5k-TL
Omniksol-2k-TL
Please keep this user manual all time available in case of emergency.
1.2 Symbols Used
DANGER
DANGER indicates a hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING
WARNING indicates a hazardous situation which, if not
avoided, can result in death or serious injury or moderate
injury.
CAUTION
CAUTION indicates a hazardous condition which, if not
avoided, can result in minor or moderate injury.
or moderate injury.
NOTICE
NOTICE indicates a situation that can result in property
damage, if not avoided.

User Manual V4.2
4
1.3 Target Group
Chapter 1, 2, 3, 4, 7, 8, 9, 10 and Chapter 11 are intended for anyone who is
intended to use Omnik Grid Tie Solar Inverter. Before any further action, the operators
must first read all safety regulations and be aware of the potential danger to operate high-
voltage devices. Operators must also have a complete understanding of this device’s
features and functions.
Chapter 5 and Chapter 6 are only for qualified personnel who are intended to install
or uninstall the Omnik Grid Tie Solar Inverter.
WARNING
Do not use this product unless it has been successfully installed
by qualified personnel in accordance with the instructions in
Chapter 5, “Installation”.
NOTICE
Hereby qualified personnel means he/she has the valid license
from the local authority in:
•Installing electrical equipment and PV power systems
(up to 1000 V).
•Applying all applicable installation codes.
•Analyzing and reducing the hazards involved in
performing electrical work.
•Selecting and using Personal Protective Equipment
(PPE).

User Manual V4.2
5
2.Preparation
2.1 Safety Instructions
DANGER
DANGER due to electrical shock and high voltage
DONOT touch theoperatingcomponentof the inverter, it
mightresultin burningordeath.
TOpreventrisk of electric shockduringinstallation and
maintenance,please makesurethat all AC and DC terminals
are pluggedout.
DONOT stay close to the instrumentswhilethereissevere
weatherconditionsincludingstorm,lightingetc.
WARNING
The installation，service ，recycling and disposal of the
inverters must be performed by qualified personnel only in
compliance with national and local standards and
regulations. Please contact your dealer to get the
information of authorized repair facility for any maintenance
or repairmen.
Any unauthorized actions including modification of product
functionality of any form will affect the validation of warranty
service; Omnik may deny the obligation of warranty service
accordingly.
NOTICE
Public utility only
The PV inverter designed to feed AC power directly into the
public utility power grid，do not connect AC output of the
device to any private AC equipment.

User Manual V4.2
6
2.2 Explanations of Symbols on Inverter
Symbol
Description
Dangerous electrical voltage
This device is directly connected to public grid, thus all
work to the inverter shall only be carried out by
qualified personnel.
DANGER to life due to high electrical voltage!
There might be residual currents in inverter because
of large capacitors. Wait 10 MINUTES before you
remove the front lid.
NOTICE, danger!
This device directly connected with electricity
generators and public grid.
Danger of hot surface
The components inside the inverter will release a log
of heat during operation, DO NOT touch aluminum
housing during operating.
An error has occurred
Please go to Chapter 9 “Trouble Shooting” to remedy
the error.
This device SHALL NOT be disposed of in
residential waste
Please go to Chapter 8 “Recycling and Disposal” for
proper treatments.
CAUTION
The PV inverter will become hot during operation; please
don’t touch the heat sink or peripheral surface during or
shortly after operation。
Risk of damage due to improper modifications.
Never modify or manipulate the inverter or other components
of the system.

User Manual V4.2
7
Without Transformer
This inverter does not use transformer for the isolation
function.
German mark of conformity
The inverter complies with the requirement of the
German Grid Regulations.
Certified Safety
The inverter complies with the requirements of the
Equipment and Product Safety Act in Europe.
Standards Association of Australian
The inverter complies with the requirement of the
AS4777.
CE Mark
Equipment with the CE mark fulfils the basic
requirements of the Guideline Governing Low-Voltage
and Electromagnetic Compatibility.
No unauthorized perforations or modifications
Any unauthorized perforations or modifications are
strictly forbidden, if any defect or damage
(device/person) is occurred, Omnik shall not take any
responsibility for it.

User Manual V4.2
8
3.Product Information
3.1 Overview
Industrial Layout
、
Excellent Heat Elimination

User Manual V4.2
9
Effective Shield For DC/AC/Communication Connections
3.2 Major Characteristics
Omnik inverter has following characteristics which make Omnik inverter “High Efficiency, High
Reliability, High Cost Effective Ratio”
Wide DC input voltage and current ranges, enables more PV panels connected.
Wide MPP voltage range ensure high yield under various weather conditions.
High MPP tracking accuracy, ensure the minimum power loses during converting.
Complete set of protection methods.
Also, following protection methods are integrated in Omnik inverter:
Internal overvoltage
DC insulation monitoring
Ground fault protection
Grid monitoring
Ground fault current monitoring
DC current monitoring
Integrated DC switch (Optional)

User Manual V4.2
10
3.3 Datasheet
Omniksol-1k-TL
Type
Omniksol-1k-TL
Input (DC)
Max. PV-generator power
Ppv [W]
1300
Max DC voltage
Vmax(DC) [V]
500
MPPT DC voltage range
Vmppt [V]
80- 300
Turn off DC Voltage
Vmin(DC) [V]
80
Max. DC current
Imax(DC) [A]
16
Nominal DC current
IN(DC) [A]
8.5
Number of DC connection
1
DC-connection
MC4
Number of MPP trackers
1
Turn on power
Pmin(DC) [W]
10
Output (AC)
Max. AC Power
Pmax(AC) [V]
1100
Nominal AC power
PN(AC) [W]
1000
Max. AC current
Imax(AC) [A]
5.8
Nominal AC current
IN(AC) [A]
4.3
Power connection
Single phase
Grid voltage range
According to VDE 0126-1-1, RD1663, ENEL2010,C10/11,
G83/1 AS4777
Grid frequency range
According to VDE 0126-1-1, RD1663, ENEL2010,C10/11,
G83/1, AS4777
Power factor
0.99 (>30% of Full Load)
Harmonic distortion (THD) at nominal output
<2%
AC Connector
Plug-in connector
Power consumption
Own consumption in operation
Pown(AC) [W]
30
Power consumption at night
Pnig(AC) [W]
0
Power consumption at standby
Pstd(AC) [W]
6
Efficiency
Max. Efficiency (at 360VDC)
97.4%
Euro efficiency (at 360VDC)
96.6%
MPPT efficiency
99.9%
Safety and protection
Internal overvoltage protection
Yes
DC Insulation monitoring
Yes
Earth fault protection
Yes
Grid monitoring
According to VDE 0126-1-1, RD1663, ENEL2010,C10/11
G83/1, AS4777
Earth fault current monitoring
According to VDE 0126-1-1, RD1663, ENEL2010,C10/11
G83/1, AS4777
DC current monitoring
According to VDE 0126-1-1, RD1663, ENEL2010,C10/11
G83/1, AS4777
Islanding protection
According to VDE 0126-1-1, RD1663, G83/1, AS4777
Normative reference
CE- compliant according to
EN 62109, EN 61000-6-1, EN 61000-6-3, EN 61000-6-2, EN
61000-6-4
EN61000-3-2, EN61000-3-3, EN61000-3-12, EN61000-3-11

User Manual V4.2
11
Dimensions and weight
Dimensions (WxHxD)
[mm]
330x425x130
Weight
[kg]
13
Environmental limits
IP protection type
IP 65 according to IEC 60529
Operating temperature range
-20°C to +60°C
Relative humidity
0% to 98%, no condensation
Maximum altitude (above sea level)
[m]
2000
Noise level
[dBA]
< 40
General data
Isolation type
Transformerless
Cooling concept
Convection
Housing
Stainless steel housing for inside and outside installation
Mounting information
Wall bracket
LED display
3
LCD display
Backlight, 16 x 2 Character LCD
Data logger
RS485, Optional (Wi-Fi, GPRS, Ethernet)
Data communication interfaces
Computer Communication
RS232 as Option
Standard warranty
5 years (optional 10 years)
Omniksol-1.5k/2k-TL
Type
Omniksol-1.5k-TL
Omniksol-2k-TL
Input (DC)
Max. PV-generator power
Ppv [W]
1750
2300
Max DC voltage
Vmax(DC) [V]
500
MPPT DC voltage range
Vmppt [V]
120 - 450
Turn off DC Voltage
Vmin(DC) [V]
120
Max. DC current
Imax(DC) [A]
18
Nominal DC current
IN(DC) [A]
14
16.5
Number of DC connection
1
DC-connection
MC4
Number of MPP trackers
1
Turn on power
Pmin(DC) [W]
10
Output (AC)
Max. AC Power
Pmax(AC) [V]
1650
2200
Nominal AC power
PN(AC) [W]
1500
2000
Max. AC current
Imax(AC) [A]
9.0
12.0
Nominal AC current
IN(AC) [A]
6.5
8.5
Power connection
Single phase
Single phase
Grid voltage range
According to VDE 0126-1-1, RD1663, ENEL2010,C10/11,
G83/1 AS4777
Grid frequency range
According to VDE 0126-1-1, RD1663, ENEL2010,C10/11,
G83/1, AS4777
Power factor
0.99 (>30% of Full Load)
Harmonic distortion (THD) at nominal output
<2%
AC Connector
Plug-in connector
Power consumption
Own consumption in operation
Pown(AC) [W]
30

User Manual V4.2
12
Power consumption at night
Pnig(AC) [W]
0
Power consumption at standby
Pstd(AC) [W]
6
Efficiency
Max. Efficiency (at 360VDC)
97.5%
Euro efficiency (at 360VDC)
96.6%
MPPT efficiency
99.9%
Safety and protection
Internal overvoltage protection
Yes
DC Insulation monitoring
Yes
Earth fault protection
Yes
Grid monitoring
According to VDE 0126-1-1, RD1663, ENEL2010,C10/11
G83/1, AS4777
Earth fault current monitoring
According to VDE 0126-1-1, RD1663, ENEL2010,C10/11
G83/1, AS4777
DC current monitoring
According to VDE 0126-1-1, RD1663, ENEL2010,C10/11
G83/1, AS4777
Islanding protection
According to VDE 0126-1-1, RD1663, G83/1, AS4777
Normative reference
CE- compliant according to
EN 62109, EN 61000-6-1, EN 61000-6-3, EN 61000-6-2, EN
61000-6-4
EN61000-3-2, EN61000-3-3, EN61000-3-12, EN61000-3-11
Dimensions and weight
Dimensions (WxHxD)
[mm]
330x425x130
Weight
[kg]
13
Environmental limits
IP protection type
IP 65 according to IEC 60529
Operating temperature range
-20°C to +60°C
Relative humidity
0% to 98%, no condensation
Maximum altitude (above sea level)
[m]
2000
Noise level
[dBA]
< 40
General data
Isolation type
Transformerless
Cooling concept
Convection
Housing
Metal housing for inside and outside installation
Mounting information
Wall bracket
LED display
3
LCD display
Backlight, 16 x 2 Character LCD
Data logger
RS485, Optional (Wi-Fi, GPRS, Ethernet)
Data communication interfaces
Computer Communication
RS232 as Option
Standard warranty
5 years (optional 10 years)

User Manual V4.2
13
4.Packing checklist
4.1 Assembly parts
After you receive the Omnik inverter, please check if there is any damage on the carton, and
then check the inside completeness for any visible external damage on the inverter or any
accessories. Contact your dealer if anything is damaged or missing.
A
B
C
D
E
F
G
H
Object
Quantity
Description
A
1
Omnik inverter
B
1 pair
DC connector
C
1
AC connector
D
1
Mounting bracket
E
4
Screw (ST6×50)
F
4
Expansion tube
G
1
Installation and operating instructions
H
1
DC Switch (Optional)

User Manual V4.2
14
4.2 Product Appearance
Front
Bottom
Object
Description
A
Removable front shield
B
LED light(Green) –RUN
C
LED light(Red) –FAULT
D
LED light(Yellow) –COM
E
Function key for displays and choice of language
F
Monitoring LCD with backlighting
A
A
F
F
E
E
D
D
C
C
B
B
A
B
C

User Manual V4.2
15
Object
Description
A
Plug connectors for DC input.
B
RS232/RS485 interface
C
Terminal for grid connection (AC output)
4.3 Product Identification
You can identify the inverter by the side nameplate. Information such as serial number (SN.),
type of the inverter, as well as inverter specifications are specified on the side name plate. The
name plate is on the middle part of the right side of the inverter housing. And the following
figure is the side name plate example as on Omniksol-1.5k-TL.
4.4 Further Information
If you have any further questions concerning the type of accessories or installation, please
check our website www.omnik-solar.com or contact our service hotline.

User Manual V4.2
16
5.Installation
5.1 Safety
5.2 Mounting Instructions
DANGER
DANGER to life due to potential fire or electricity shock.
DO NOT install the inverter near any inflammable or
explosive items.
This inverter will be directly connected with HIGH
VOLTAGE power generation device, the installation must
be performed by qualified personnel only in compliance with
national and local standards and regulations.
NOTICE
NOTICE due to the inappropriate or the harmonized
installation environment may jeopardize the life span
of the inverter.
Installation directly expose under intensive sunshine is not
recommended.
The installation site MUST have good ventilation condition.
M
Ma ax x 1 15 5° °

User Manual V4.2
17
Omnik inverter is designed for indoors and outdoors installation
Please mount the inverter in the direction as illustrated above
Install the inverter in the vertical direction is recommended, with a max.15 degrees
backwards.
For the convenience of checking the LCD display and possible maintenance
activities, please install the inverter at eye level.
Make sure the wall you selected is strong enough to handle the screws and bear the
weight of the inverter
Ensure the device is properly fixed to the wall
It is not recommended that the inverter is exposed to the strong sunshine, because
the excess heating might lead to power reduction
The ambient temperature of installation site should be between -20 °C and +60 °C
( between -4 °F and 140 °F )
Make sure the ventilation of the installation spot, not sufficient ventilation may reduce
the performance of the electronic components inside the inverter and shorten the life
of the inverter
5.3 Safety Clearance
Observe the following minimum clearances to walls, other devices or objects to guarantee
sufficient heat dissipation and enough space for pulling the electronic solar switch handle.
10 CM
10 CM
30 CM
30 CM

User Manual V4.2
18
Direction
Minimum clearance
Above
30 cm
Below
30 cm
Sides
10 cm
5.4 Mounting Procedure
5.4.1 Mounting with bracket
1) Mark 4 positions of the drill holes on the wall according to the wall mounting bracket in
the carton box.
（Depth 50mm）
250
213
First, according to the marks, drill 4 holes in the wall. Then, place four expansion tubes
in the holes using a rubber hammer. Next, make 4 screws through the mounting holes in
the bracket, then tighten the screws into the expansion tubes. So far, the wall mounting
bracket is fixed already.
