INSTRUCTION MANUAL
Evolv
®
Upper Arm Blood Pressure Monitor
Model BP7000
®
ENGLISH

2
INTRODUCTION
Thank you for purchasing the OMRON BP7000 Blood Pressure Monitor.
Your new blood pressure monitor uses the oscillometric method of blood pressure
measurement. This means the monitor detects your blood movement through your
brachial artery and converts the movements into a digital reading. An oscillometric
monitor does not need a stethoscope so the monitor is simple to use.
Symbols Glossary
For symbol information, visit:
OmronHealthcare.com/symbols-glossary

3
TABLE OF CONTENTS
INTENDED USE...........................................................................................4
IMPORTANT SAFETY INFORMATION .......................................................5
1. KNOW YOUR MONITOR ......................................................................8
2. PREPARATION ...................................................................................12
3. USING THE MONITOR WITHOUT A SMART DEVICE ......................16
4. USING THE MONITOR WITH A SMART DEVICE..............................18
5. ERROR MESSAGES AND TROUBLESHOOTING .............................25
6. MAINTENANCE, STORAGE AND CLEANING ...................................29
7. DISPOSAL ...........................................................................................30
8. SPECIFICATIONS ...............................................................................31
9. FCC STATEMENT...............................................................................33
10. LIMITED WARRANTY .........................................................................34
11. GUIDANCE AND MANUFACTURER’S DECLARATION ....................35

4
INTENDED USE
This device is a digital monitor intended for use in measuring blood pressure and
pulse rate in adult patient population with arm circumference ranging from 9 inches
to 17 inches (22 cm to 42 cm). The device detects the appearance of irregular
heartbeats during measurement and gives a warning signal with readings.

5
IMPORTANT SAFETY INFORMATION
Please read the Important Safety Information in this instruction manual before
using the unit.
Please follow this instruction manual thoroughly for your safety.
Please keep for future reference. For specific information about your own blood
pressure, CONSULT YOUR PHYSICIAN.
Contraindications
• The device is contraindicated for use in ambulatory environments.
• The device is contraindicated for use on aircraft.
Warning
Indicates a potentially hazardous situation
which, if not avoided, could result in death or
serious injury.
• DO NOT adjust medication based on measurement results from this blood
pressure monitor. Take medication as prescribed by your physician. Only a
physician is qualified to diagnose and treat high blood pressure.
• DO NOT use this monitor on an injured arm or an arm under medical treatment.
• DO NOT wear the arm cuff on your arm while on an intravenous drip or blood
transfusion.
• DO NOT apply or inflate the arm cuff around any body parts other than your upper
arm.
• DO NOT use this monitor in areas containing high frequency (HF) surgical
equipment, magnetic resonance imaging (MRI) equipment, computerized
tomography (CT) scanners or in oxygen rich environments.
• DO NOT use this monitor on infants, toddlers, children or persons who cannot
express themselves.
• Consult your physician before using this monitor if you have common arrhythmias
such as atrial or ventricular premature beats or atrial fibrillation; arterial sclerosis;
poor perfusion; diabetes; pregnancy; pre-eclampsia; or renal disease. Note that
any of these conditions in addition to patient motion, trembling, or shivering may
affect the measurement reading.
• Always consult your physician. Self-diagnosis of measurement results and self-
treatment are dangerous.
• Contains small parts that may cause a choking hazard if swallowed by children,
toddlers or infants.
• Keep the BATTERY out of the reach of children, toddlers and infants.

6
IMPORTANT SAFETY INFORMATION
• This product emits radio frequencies (RF) in the 2.4 GHz band. DO NOT use this
product in locations where RF is restricted, such as on an aircraft or in hospitals.
For further information on any potential restrictions refer to documentation on
Bluetooth®usage by the FCC.
Caution
Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderate injury to the user or patient or damage
to the equipment or other property.
• Stop using this monitor and consult your physician if you experience skin irritation
or discomfort.
• Consult your physician before using this monitor on an arm with an arterio-venous
(A-V) shunt.
• Consult your physician before using this monitor if you have had a mastectomy.
• Consult your physician before using the monitor if you have severe blood flow
problems or blood disorders as cuff inflation can cause bruising.
• Do not take measurements more often than necessary because bruising, due to
blood flow interference, may occur.
• Remove the arm cuff if it does not start deflating during the measurement.
• Do not use this monitor for any purpose other than measuring blood pressure.
• Do not use a mobile phone or other electrical devices that emit electromagnetic
fields near this monitor except when transferring your readings to your smart
device. This may result in incorrect operation of this monitor.
• Do not disassemble or attempt to repair the monitor or components. This may
cause an inaccurate reading.
• Do not use in a location where there is moisture or a risk of water splashing the
monitor. This may damage the monitor.
• Do not use this monitor in a moving vehicle such as in a car.
• Do not drop, or subject this monitor to strong shocks or vibrations.
• Do not use this monitor in places with high or low humidity or high or low
temperatures. See the “8. SPECIFICATIONS” section of the manual.
• Please check, by observation of the arm being used, that the monitor is not
causing any impairment of patient blood circulation.
• Do not use this monitor in high-use environments such as medical clinics or
physician offices.

7
IMPORTANT SAFETY INFORMATION
• Avoid bathing, drinking alcohol or caffeine, smoking, exercising and eating for 30
minutes before taking a measurement.
• Rest for at least 5 minutes before taking the measurement.
• Remove t
ight-fitting or thick clothing from your arm while taking a measure ment.
• Remain still and do not talk while taking a measurement.
Data Transmission
• Do not replace the battery while your reading is being transferred to your smart
device. This may result in the incorrect operation of your monitor and failure to
transfer your blood pressure data.
• Do not place integrated circuit cards, magnets, metal objects, or other devices that
emit electromagnetic fields near this monitor while your reading is being
transferred to your smart device. This may result in the incorrect operation of your
monitor and failure to transfer your blood pressure data.
Battery Handling and Usage
• Do not insert the batteries with their polarities incorrectly aligned.
• Use only 4 “AAA” alkaline batteries with this monitor. Do not use other types of
batteries. Do not use new and used batteries together.
• Remove the batteries if the monitor will not be used for a long period of time.
• If battery fluid should get in your eyes, immediately rinse with plenty of clean
water. Consult a physician immediately.
• If battery fluid should get on your skin, wash your skin immediately with plenty of
clean, lukewarm water. If irritation, injury or pain persists, consult a physician.
• Do not use batteries after their expiration date.
• Periodically check your batteries to ensure they are in good working condition.
• Only use batteries specified for this monitor. Use of unsupported batteries may
damage and/or may be hazardous to the monitor.

8
1. KNOW YOUR MONITOR
Contents:
Monitor, 4 “AAA” batteries, instruction manual, quick start guide
Monitor:
A
BC
D
E
A. START/STOP button
B. Connection button
C. Display
D. Arm cuff
E. Battery compartment
F. Systolic blood pressure
G. Diastolic blood pressure
H. Pulse display
G
H
F
Display:

9
1. KNOW YOUR MONITOR
1.1 Display symbols
Connection symbol ( )
Appears when transferring the data or pairing with your smart device.
Connection OFF symbol ( )
Appears when Bluetooth is off.
Connection ON symbol ( )
Appears when Bluetooth is on.
Movement error symbol ( )
The movement error symbol will display when your body is moving during
measurement. If the movement symbol displays, remove the monitor and wait
for 2 to 3 minutes. After 2 to 3 minutes, remain still and take another
measurement.
SYNC symbol ( )
• When the SYNC symbol appears on the display, make sure that your
monitor has been pairing with the smart device or transfer the data.
• When the SYNC symbol appears on the display, transfer the data before the
measurements are deleted. Maximum internal memory is for 100
measurements. The oldest value will be deleted when this is reached before
transferring.
Connection symbol Irregular heartbeat symbol
Connection OFF symbol Battery symbol (low)
Connection ON symbol Battery symbol (depleted)
Movement error symbol Deflation symbol
SYNC symbol Heartbeat symbol
(Flashes during measurement.)

10
1. KNOW YOUR MONITOR
Irregular heartbeat symbol ( )
When the monitor detects an irregular rhythm two
or more times during the measurement, the
irregular heartbeat symbol will appear on the
display along with the measurement values.
An irregular heartbeat rhythm is defined as a
rhythm that is 25% less or 25% more than the
average rhythm detected while the monitor is
measuring the systolic and diastolic blood
pressure.
If the irregular heartbeat symbol displays with your measurement results, we
recommend you consult your physician. Follow the directions of your
physician.
Battery symbol (low) ( )
Appears when the batteries are low.
Battery symbol (depleted) ( )
Appears when the batteries are depleted.
Deflation symbol ( )
Flashes while arm cuff is deflating.
Heartbeat symbol ( )
Flashes while taking a measurement.
Irregular Heartbeat
Normal Heartbeat
Pulse
Blood pressure
Blood pressure
Short Long
Pulse

11
1. KNOW YOUR MONITOR
1.2 Classification of BP (Blood Pressure)
ACC/AHA 2017 Hypertension guidelines defines categories of BP in adults as
below.
Categories of BP in Adults*
* Individuals with Systolic BP and Diastolic BP in 2 categories should be designated
to the higher BP category.
BP indicates blood pressure (based on an average of ≥2 careful readings obtained
on ≥2 occasions).
Source: ACC/AHA 2017 High Blood Pressure Clinical Practice Guideline
1.3 Before Taking a Measurement
To help ensure an accurate reading, follow these directions:
• Stress raises blood pressure. Avoid taking measurements during stressful
times.
• Measurements should be taken in a quiet place.
• Keep a record of your blood pressure and pulse readings for your physician.
A single measurement does not provide an accurate indication of your true
blood pressure. You need to take and record several readings over a period
of time. Try to measure your blood pressure at the same time each day for
consistency.
BP Category Systolic BP Diastolic BP
Normal <120 mmHg and <80 mmHg
Elevated 120 - 129 mmHg and <80 mmHg
Hypertension
Stage 1
Stage 2
130 - 139 mmHg or 80 - 89 mmHg
≥140 mmHg or ≥90 mmHg
Avoid bathing, drinking alcohol or caffeine, smoking, exercising and eating for
30 minutes before taking a measurement.
Rest for at least 5 minutes before taking the measurement.

12
2. PREPARATION
2.1 Battery Installation
1. Remove the battery cover.
Insert your fingernail into the slot of
the battery cover, and push
downwards to remove the cover.
2. Insert battery, slide over so it is
secured inside the circular
battery positioner. Then insert
the second battery.

13
2. PREPARATION
3. Replace the battery cover.
When the batteries have been securely placed in this monitor, the message
below will appear on the screen:
Notes:
• When the depleted battery symbol “ ” appears on the display, turn the
monitor off and remove all the batteries. Replace with 4 new batteries at the
same time. Long life alkaline batteries are recommended.
• The measurement values continue to be stored in the memory even after the
batteries are replaced.
• The supplied batteries may have a shorter life than new batteries.
• Disposal of used batteries should be carried out in accordance with the
national/local regulations for the disposal of batteries.
• When the batteries are replaced, the words “Please pair this device.” or
“Pairing not completed. No data transfer.” will appear on the display. Press
the [ ] button to pair with the smart device or transfer the data before taking
a measurement.

14
2. PREPARATION
2.2 Applying the Arm Cuff
1. Apply the arm cuff to your left upper
arm.
The bottom edge of the arm cuff should be 1/2
inch (1 to 2 cm) above the elbow. The display
should be in clear view and easy to read,
positioned slightly on the inside of your arm.
2. Securely close with the fabric
fastener.
Notes:
• The blood pressure can differ between the
right arm and the left arm, and the measured
blood pressure values can be different.
Omron recommends to always use the same arm for measurement. If the
values between both arms differ substantially, please check with your
physician as to which arm to use for your measurements.
• Positioning the monitor with the [START/STOP] button toward the body
makes it easier to use the monitor.
Remove tight-fitting or thick clothing from your arm while taking a
measurement.
1/2 inch
(1 - 2 cm)

15
2. PREPARATION
2.3 How to Sit Correctly
To take a measurement, you need to be relaxed and
comfortably seated, at a comfortable room temperature.
• Sit in a chair with your legs uncrossed and your feet flat on
the floor.
• Sit upright with your back straight.
• Sit with your back and arm being supported.
• The arm cuff should be placed on your arm at the same level
as your heart.

16
3. USING THE MONITOR WITHOUT A SMART DEVICE
You can use this blood pressure monitor without pairing to a smart device.
3.1 Taking a Measurement
Notes:
• To stop the measurement, press the [START/STOP] button once to deflate
the arm cuff.
• Remain still and do not talk while taking a measurement.
• When using this blood pressure monitor without a smart device, you will not
be able to view your prior readings stored in the memory.
• Do not use the monitor with any other electrical device simultaneously. This
may result in incorrect operation of the monitor.
1. Press the [START/STOP] button.
The arm cuff will start to inflate.
The following symbols indicate incorrect measurement
• If “Please remeasure” and any of these symbols below are displayed, please
take another measurement and try again.
2. Remove the arm cuff.
START INFLATING DEFLATING
COMPLETED
Example:

17
3. USING THE MONITOR WITHOUT A SMART DEVICE
3. Write down your SYS/DIA and Pulse readings, along with the
date and time of your measurement on a piece of paper to
keep a record of your history.
DO NOT adjust medication based on measurement results from this blood
pressure monitor. Take medication as prescribed by your physician. Only a
physician is qualified to diagnose and treat high blood pressure.
Always consult your physician. Self-diagnosis of measurement results and
self-treatment are dangerous.

18
4. USING THE MONITOR WITH A SMART DEVICE
4.1 Pairing Your Monitor with a Smart Device
The date and time on your monitor will automatically be set when you pair it
with your smart device.
1. Make sure the Bluetooth
®
in your smart device is turned on.
2. Download and install the free “OMRON connect US/CAN” app
on your smart device.
* If you already have the “OMRON connect US/CAN” app, and have created
your account, open the app and add your new monitor.
3. Open the app on your smart device and follow the set-up and
pairing instructions.
4. Confirm the monitor is connected successfully.
If the monitor is connected successfully to the smart device, “OK” will appear
on the display.
If “Error” appears, refer to section 5.1 for more detail.
For more information, visit OmronHealthcare.com
Review the list of compatible smart devices at: OmronHealthcare.com

19
4. USING THE MONITOR WITH A SMART DEVICE
Notes:
• If you use any other app instead of “OMRON connect US/CAN”, the date
and time may not be automatically set.
If you need to set the date and time, pair your monitor or transfer the data by
using “OMRON connect US/CAN” app.
• The date/time will only be set for future measurements taken after the
measurement that was transferred. It will not be saved to the measurement
that was just transferred.
• Please be aware that OMRON will not be responsible for the loss of data
and/or information.

20
4. USING THE MONITOR WITH A SMART DEVICE
4.2 Taking a Measurement
Notes:
• To stop the measurement, press the [START/STOP] button once to deflate
the arm cuff.
• Remain still and do not talk while taking a measurement.
• This monitor will store 100 measurements. Stored measurements cannot be viewed
on the monitor's display. You will need to use the “OMRON connect US/CAN” app to
view all measurements prior to the most recent reading taken.
• Do not use a mobile phone or other electrical devices that emit electromagnetic fields
near this monitor except when transferring your readings to your smart device. This
may result in incorrect operation of this monitor.
1. Press the [START/STOP] button.
The arm cuff will start to inflate.
The following symbols indicate incorrect measurement
• If “Please remeasure” and any of these symbols below are displayed, please
take another measurement and try again.
START INFLATING DEFLATING
COMPLETED
Example:
