Omron CPM1A User manual

Programmable Controllers
Smallest PLC in the SYSMAC C Series
SYSMAC CPM1A
SYSMAC C20P/C28P/C40P
SYSMAC C1000H/C2000H
SYSMAC C60H
SYSMAC C20H
/C28H
/C40H
SYSMAC C200H
/C200HS
PWR ERR ALM
RUN
10CH 00 01 02 03
COMM
SYSMAC CPM1A
+
03
00NC
NC COM COM COM
01 02
00 02 04
01
COM
NC
03 05
--
-
-
0CH 00 01 02 03 04 05
V1-type CPU Units
Now Available
V1-type CPU Units
Now Available
OMRON Corporation
FA Systems Division H.Q.
66 Matsumoto
Mishima-city, Shizuoka 411-8511
Japan
Tel:[phone]
Fax:[phone]
Authorized Distributor:
Note: Specifications subject to change without notice. Cat. No. P039-E1-11
Printed in Japan
0404-1M
Regional Headquarters
OMRON EUROPE B.V.
Wegalaan 67-69, NL-2132 JD Hoofddorp
The Netherlands
Tel: [phone]/Fax: [phone]
OMRON ELECTRONICS LLC
1 East Commerce Drive, Schaumburg, IL 60173
U.S.A.
Tel:[phone] /Fax: [phone]
OMRON ASIA PACIFIC PTE. LTD.
83 Clemenceau Avenue,
#11-01, UE Square,
Singapore 239920
Tel: [phone]/Fax : [phone]

23
Programmable Controllers
This catalog contains information necessary
to select models.
It does not include precautionary information.
Please refer to the CPM1A manuals for
the required information.
The Smallest PLC in the SYSMAC Fam ily Shows
Just How Far Downsizing Can Go
The 10-point CPU is
approximately the size of a PC Card.
The SYSMAC C Series began developing a
wide range of Programmable Controllers to
meet factory automation needs in 1973.
And now the CPM1A joins the C Series
history as a small PLC that has all the
power of previous small PLCs but requires
far less mounting space. The CPM1A also
provides flexibility in I/O capacity ranging
from 10 to 100 I/O points. The CPM1A can
replace relay control, help distribute I/O,
work as a miniature machine controller or
sensor controller, or fill many other vital
roles in factory automation.
90mm 85.6mm
Contents
System Configuration
CPM1A Line-up
CPM1A System Configuration
External Dimensions
Specifications
General Specifications
Power Consumption for DC Models
Performance Specifications
I/O Specifications
CPM1A-DRT21 DeviceNet I/O Link Unit
Temperature Sensor Units
Communications Adapter
Specifications CPM1-CIF01/CIF11
CPM2C-PA201 AC Power Supply Unit
Functions
Input Interrupts
Quick-response Inputs
High-speed Counter
Interval Timer Interrupts
Analog Setting
Pulse Output Function
Communications
Programming Instructions
Peripheral Devices
Standard Models
Expansion Memory Unit
6-7
6
7
7
8-15
8
8
9
10
13
13
14
15
16-21
16
17
17
18
18
19
20
22-25
26
27-29
30

45
The CPM1A can be easily built into a wide
array of machines or control panels. For
example, you can use the CPM1A to
control a few more I/O points on existing
lines without having to install a new
control panel. Just install the CPM1A in
available space to control only the required
number of I/O. The CPM1A was born to
reduce waste in the factories by effectively
using valuable space.
Flexible Control and Plenty of Power
in the Minimum Body Size
Select Units to Control from 10 to
100 I/O Points
CPUs are available with from 10 to 40 I/O points and, in
combination with Expansion I/O Units, can be used to
control a total of from 10 to 100 points.
Only 30- and 40-point
CPUs support
Expansion
I/O Units. Up to three
Expansion I/O Units
can be connected.
CPM1A-20EDR1/-20EDT(1)
CPM1A-8ED/-8ER/8ET(1)
Easy Connection to Programmable
Terminals
An optional Communications Adapter supports Host Link
or NT Link connections for high-speed communications
with OMRON PTs.
CQM1-CIF02
Connecting Cable
Hand-held Programming Consoles are
ideal for onsite startup and adjustments.
Programming Consoles
Full Functionality in
a Compact Body
Plenty of programming capacity and a large instruction
set handle even complex control operations.
User memory: 2,048 words
Data memory: 1,024 words
Timers/Counters: 128
High-speed Execution
LOAD instructions execute at 1.7 µs and MOVE
instructions execute at 16.3 µs for fast program execution.
High-speed scanning is thus possible even with large
programs. Interrupt inputs and quick-response inputs can
be used to handle high-speed pulses that are too fast for
the scan time.
CQM1-PRO01-E
Basic instructions: 14
Special instructions: 79
Analog adjustments: 2
CPUs with AC Power Supplies (Relay Output)
10 pts 20 pts 30 pts 40 pts
10 pts 20 pts 30 pts 40 pts
CPUs with DC Power Supplies (Relay and Transistor Output)
SYSMAC
CPM1A
Windows 95, 98, Me, NT 4.0,
2000, or XP
Windows-based Support Software
The Windows-based CX-Programmer Support Software reduces software
development time and provides powerful monitoring and debugging
functions. Other Windows applications can be used and the programming
enviroment has been greatly improved.
Reduce Software Development Time with
Windows-based CX-Programmer
CX-Programmer's many monitoring
and debugging functions provide
powerful support for multiple program
development.
User-friendly operations
Powerful display/monitoring functions
Powerful debugging functions
Remote programming and monitoring
Maintenance functions
Data compatibility with Windows
applications
Expansion I/O Unit

6
CPM1A Line-up
CPU with AC Power Supply •DC input •RY output / TR output
10 I/O points
(Expansion
not possible)
30 I/O points 40 I/O points
20 I/O points
CPM1-CIF01
RS-232C Adapter
CPM1-CIF11
RS-422 Adapter
20 I/O points
(Expansion
not possible)
CPU with DC Power Supply •DC input •RY output / TR output
Expansion I/O Unit
•DC input
•RY output / TR output
Expansion I/O Unit
•DC input
CompoBus/S
I/O Link Unit
Analog I/O Unit
•RY output / TR output CPM1A-SRT21 CPM1A-MAD01
-MAD11
Temperature
Sensor Units
CPM1A-TS001
TS002
TS101
TS102
DeviceNet I/O
Link Unit
CPM1A-DRT21
System Configuration

System Configuration
7
CPM1A System Configuration
CPM1-CIF01/CIF11 Adapter
Peripheral port Connecting cable
Both AC and DC power supplies.
30-point CPU and 40-point CPU only.
May be expanded up to a maximum
of 3 Units.
Expansion I/O Unit Expansion I/O Unit Expansion I/O Unit
Connection Groups for Expansion Units
Group 1 (G1) Group 2 (G2)
Expansion I/O Units,
Analog I/O Unit,
CompoBus/S I/O LInk Unit
DeviceNet I/O Link Unit
CPM1A-TS001/101
CPM1A-TS002/102
In addition to the CPU Unit, Expansion Units from the groups indicated in the above table can be combined as shown below.
Possible Expansion Unit Combinations
Expansion Unit 1 Expansion Unit 2 Expansion Unit 3
G1 G1 G1
G2 G1 ---
Note: 1. Expansion Units 1, 2, and 3 can be mounted in any order.
2. Only one Expansion Unit can be mounted if an NT-AL001 is connected to the RS-232C port.
External Dimensions
DC power supply
AC power supply
Unit: mm
W
90
50
70
Model W (mm)
CPM1A-10CDj-A-V1/D-V1 66
CPM1A-20CDj-A-V1/D-V1 86
CPM1A-30CDj-A-V1/D-V1 130
CPM1A-40CDj-A-V1/D-V1 150
CPM1A-20EDj86 (depth: 50 mm)
CPM1A-8Ej/SRT21 66 (depth: 50 mm)
CPM1A-MAD01 66 (depth: 50 mm)
CPM1A-TSjjj/MAD11 86 (depth: 50 mm)
CPM1A-DRT21 60 (depth: 50 mm)
CPM1-CIF01
CPM1-CIF11
21
90
81
30
50
56
21
90
81
30
50
61

8
General Specifications
Item 10-point I/O 20-point I/O 30-point I/O 40-point I/O
Power supply voltage/
f
AC power supply 100 to 240 VAC, 50/60 Hz
pp y g
frequency DC power supply 24 VDC
Operating voltage AC power supply 85 to 264 VAC
pgg
range DC power supply 20.4 to 26.4 VDC
Power consumption AC power supply 30 VAC max. 60 VAC max.
p
DC power supply (See below.)
Inrush current 30 A max. 60 A max.
External power supply
(AC only)
Power supply
voltage
24 VDC
(Coy)
Power supply
output capacity
200 mA 300 mA
Insulation resistance 20 MΩmin. at 500 VDC between the AC terminals and the protective earth
terminal.
Dielectric strength 2,300 VAC at 50/60 Hz for one minute with a leakage current of 10 mA max.
between all the external AC terminals and the protective earth terminal.
Noise resistance Conforms to IEC61000-4-4, 2 kV (power lines)
Vibration resistance 10 to 57 Hz with an amplitude of 0.075 mm, and 57 to 150 Hz with an accelera-
tion of 9.8 m/s2in the X, Y, and Z directions for 80 minutes each (i.e. swept for
8 minutes, 10 times).
Shock resistance 147 m/s2in the X, Y and Z directions 3 times each.
Ambient temperature (operating) 0°to 55°C
Ambient humidity (operating) 10% to 90% (no condensation)
Ambient environment (operating) With no corrosive gas
Ambient temperature (storage) –20°to 75°C
Terminal screw size M3
Power supply holding time 10 ms min. for AC models, and 2 ms min. for DC models
Weight AC model:
400 g max.
DC model:
300 g max.
AC model:
500 g max.
DC model:
400 g max.
AC model:
600 g max.
DC model:
500 g max.
AC model:
700 g max.
DC model:
600 g max.
Note: The specifications of the Expansion I/O Unit are the same as for the CPU except that the power is supplied from the CPU and
the weight is 300 g.
Power Consumption for DC Models
The power consumptions for CPM1A CPU Units and Expansion I/O Units are given in the tables below. Use them to calculate the
required power supply capacity. The CPM2C-PA201 provides a 15-W power supply. Any surplus power that is beyond that required
for the PLC itself can be used for servicing devices such as sensors.
CPM1A CPU Unit Power
consumption
Expansion
CPM1A-10CDR-D-V1 3.5 W Not supported
CPM1A-20CDR-D-V1 4.5 W Not supported
CPM1A-30CDR-D-V1 5.5 W Supported
CPM1A-40CDR-D-V1 6.5 W Supported
CPM1A-10CDT-V1/T1-D-V1 3 W Not supported
CPM1A-20CDT-V1/T1-D-V1 3.5 W Not supported
CPM1A-30CDT-V1/T1-D-V1 4 W Supported
CPM1A-40CDT-V1/T1-D-V1 4.5 W Supported
CPM1A Expansion I/O Unit Power consumption
CPM1A-20EDR1 2.5 W
CPM1A-20EDT/T1 1.5 W
CPM1A-8ED 1 W
CPM1A-8ER 2 W
CPM1A-8ET/T1 1 W
CPM1A-SRT21/DRT21 1 W
CPM1A-MAD01/MAD11 3.5 W
CPM1A-TS001/TS101 3 W
CPM1A-TS002/TS102 3 W
Note: The power consumption for CPU Units includes the power consumption of Programming Consoles and Units such as
RS-232C Adapters
Specifications

Specifications
9
Performance Specifications
Item 10-point I/O 20-point I/O 30-point I/O 40-point I/O
Control method Stored program method
I/O control method Combination of the cyclic scan and immediate refresh processing methods.
Programming language Ladder diagram
Instruction word 1 step per instruction, 1 to 5 words per instruction
Types of
ii
Basic instructions 14 types
yp
instructions Special
instructions
79 types, 139 instructions
Instruction
ii
Basic instructions 0.72 to 16.2 µs
execution time Special
instructions
MOV instruction = 16.3 µs
Program capacity 2,048 words
Maximum I/O
points
CPU only 10 points (6 input/
4 output points)
20 points (12 input/
8 output points)
30 points (18 input/
12 output points)
40 points (24 input/
16 output points)
po s
With Expansion
I/O Unit
--- --- 90 points (54 input/
36 output points)
100 points (60 input/
40 output points)
Input bits 00000 to 00915 (Words 0 to 9)
Output bits 01000 to 01915 (Words 10 to 19)
Work bits (IR Area) 512: IR 20000 to IR 23115 (IR 200 to IR 231)
Special bits (SR Area) 384: SR 23200 to SR 25515 (SR 232 to SR 255)
Temporary bits (TR Area) 8: TR 0 to TR 7
Holding bits (HR Area) 320: HR 0000 to HR 1915 (HR 00 to HR 19)
Auxiliary bits (AR Area) 256: AR 0000 to AR 1515 (AR 00 to AR 15)
Link bits (LR Area) 256: LR 0000 to LR 1515 (LR 00 to LR 15)
Timers/Counters 128: TIM/CNT 000 to 127
100-ms timer: TIM 000 to TIM 127
10-ms timer: TIM 000 to TIM 127
Decremental counter, reversible counter
Data memory Read/Write 1,024 words (DM 0000 to DM 1023)
y
Read only 512 words (DM 6144 to DM 6655)
Interrupt processing:
External interrupt
2 points (Response
time of 0.3 ms max.)
4 points (Response time of 0.3 ms max.)
Memory protection Maintains the contents of the HR, AR, Counter and Data Memory Areas.
Memory backup Flash memory: User program, data memory (Read only) (Non-battery powered stor-
age)
Super capacitor: Data memory (Read/Write), holding bits, auxiliary memory bits, count-
er (20-day storage at an ambient temperature of 25°C)
Self-diagnostic function CPU error (watchdog timer), memory errors, I/O bus errors
Program check No END instruction programming errors (constantly checked during operation)
Pulse output 1 point: 2 kHz
High-speed counter 1 point: Single phase at 5 kHz or two-phase at 2.5 kHz (linear counting method)
Incremental mode: 0 to 65535 (16-bit)
Decremental mode:–32767 to 32767 (16-bit)
1 point: Single phase at 5 kHz or two-phase at 2.5 kHz (linear counting method)
Incremental mode: 0 to 65535 (16-bit)
Decremental mode:–32767 to 32767 (16-bit)
Quick-response inputs Together with the external interrupt input (minimum pulse width of 0.2 ms)
Input time constant Can be set at 1 ms, 2 ms, 4 ms, 8 ms, 16 ms, 32 ms, 64 ms, or 128 ms.
Analog settings 2 points: (0 to 200)
Note: Bits that are not used for the I/O bits can be used as work bits.

Specifications
10
I/O Specifications
Input Circuit
CPU
Item Specifications Circuit
Input voltage 24 VDC +10%/–15%
Input
IN
Input impedance IN00000 to IN00002: 2 kΩ
Others: 4.7 kΩ4.7 kΩ
(
2 kΩ
)
Input
LED
IN
Input current (typical) IN00000 to IN00002: 12 mA
Others: 5 mA
4
.
7
kΩ
(2
kΩ)
Internal
Circuits
IN 820 kΩ
(510 kΩ)
ON voltage 14.4 VDC min. COM
Ci
rcu
it
s
(510 kΩ)
OFF voltage 5.0 VDC max.
ON delay (see note 1) 1 to 128 ms max.
(default: 8 ms) (see note 1) Note The polarity of the input power supply can be either
positive or negative
OFF delay (see note 1) 1 to 128 ms max.
(default: 8 ms) (see note 1)
pos
iti
ve or nega
ti
ve.
Resistance values in parentheses are for inputs
IN00000 to IN00002.
Note: 1. The actual ON/OFF delay includes an input constant of 1, 2, 4, 8, 16, 32, 64, or 128 ms (default: 8 ms).
2. The delays for IN00000 to IN00002 are as follows when used for the high-speed counter.
Input Increment mode Differential phase mode
IN00000 (A-phase) 5 kHz 2.5 kHz
IN00001 (B-phase) Normal input
IN00002 (Z-phase) ON: 100 µs max. OFF: 500 µs max.
3. The delays for IN00003 to IN00006 are as follows when used for the high-speed counter.
Delay 0.3 ms max. (From the time of input ON until the interrupt subroutine is executed.)
Expansion I/O Unit
Item Specifications Circuit
Input voltage 24 VDC, +10%/–15% In
p
ut
IN
Input impedance 4.7 kΩ
Input
LED
IN
Input current (typical) 5 mA 4.7 kΩ
ON voltage 14.4 VDC min. Internal
Ci it
IN
820 Ω
OFF voltage 5.0 VDC max. COM
Internal
Circuits
820
Ω
ON delay 1 to 128 ms max.
(default: 8 ms) (see note)
OFF delay 1 to 128 ms max.
(default: 8 ms) (see note)
Note The polarity of the input power supply can be either
positive or negative.
Note: The actual ON/OFF delay includes an input constant of 1, 2, 4, 8, 16, 32, 64, or 128 ms (default: 8 ms).

Specifications
11
Output Circuit
CPU and Expansion I/O Unit
Relay Output
Item Specifications Circuit
Maximum switching capacity 250 VAC/2 A (cos φ =1)
24 VDC/2 A
(4 A/common)
OUT
Output
LED
Minimum switching capacity 5 VDC, 10 mA
Relay
service
life
Electrical Resis-
tance
load
150,000 times (at 24 VDC) OUT
COM
Internal
Circuits
Inductive
load
100,000 times (at 220 VAC,
cosφ=0.4) Maximum
250 VAC: 2 A
COM
Mechanical 20 million times
250
VAC:
2
A
24 VDC: 2 A
ON delay 15 ms max.
OFF delay 15 ms max.
Transistor Output (Sink Type/Source Type) (CPU/Expansion I/O Unit)
Item Specifications Circuit
Maximum switching capacity 24 VDC +10%/–15%, 300 mA
(see note 1) OUT
Output LED
Sink Type
Leakage current 0.1 mA max. OUT
COM (–)
Internal
Circuits 24 VDC
Residual voltage 1.5 V max.
()
Source Type
Output LED
ON delay 0.1 ms max.
OUT
COM (+)
Output
LED
Internal
Circuits 24 VDC
OFF delay 1 ms max. (see note 2)
OUT
Note: 1. The maximum switching capacity of the CPM1A with transistor outputs (sink type and source type) are limited to the cur-
rents shown in the following table for the common and for the Unit.
Item 10CDT-V1/
10CDT1-A-V1/D-V1
20CDT-D-V1/
20CDT1-A-V1/D-V1
30CDT-D-V1/
30CDT1-A-V1/D-V1
40CDT-D-V1/
40CDT1-A-V1/D-V1
20EDT/
20EDT1
CPM1A-8ET/
8ET1
Max. switching
capacity
0.9 A/Unit 0.9 A/common
1.8 A/Unit
0.9 A/common
2.7 A/Unit
0.9 A/common
3.6 A/Unit
0.9 A/common
1.8 A/Unit
2. When using the pulse output function of the CPM1A with transistor outputs (sink type and source type):
The output current must be within a range from 100 to 200 mA when using the output 01000 or 01001 as a pulse output with
the maximum frequency of 2 kHz. The outputs 01000 and 01001 will vary depending on the output current.
Load current OFF delay
100 to 200 mA 0.2 ms max.
0 to 300 mA except for the above range 0.5 ms max.

Specifications
12
Analog I/O Unit
CPM1A-MAD01 CPM1A-MAD11
Voltage I/O Current I/O Voltage I/O Current I/O
Analog
it
Number of inputs 22 (2 words allocated)
g
inputs Input signal range 0 to 10 V/1 to 5 V 4 to 20 mA 0 to 5 V/1 to 5 V/0 to 10
V/–10 to 10 V
0 to 20 mA/
4 to 20 mA
Maximum rated input ±15 V ±30 mA ±15 V ±30 mA
External input
impedance
1 MΩmin. 250 Ωrated 1 MΩmin. 250 Ω
Resolution 1/256 1/6,000 (full scale)
Overall precision 1.0% of full scale 25°C: ±0.3% of full scale 25°C: ±0.4% of full scale
p
0 to 55°C: ±0.6% of full scale 0 to 55°C: ±0.8% of full scale
Converted A/D data 8-bit binary Binary data (hexadecimal, 4 digits)
–10 to 10 V input range: Full scale = F448 to 0BB8 Hex
Other input ranges: Full scale = 0000 to 1770 Hex
Analog
tt
Averaging --- Supported (Set for each input using a DIP switch.)
g
outputs
(See
note 2 )
Disconnection
detection
--- Supported
no
t
e
2
.
)
Number of outputs 11 (1 word allocated)
Output signal range 0 to 10 V/
–10 to 10 V
4 to 20 mA 1 to 5 V/0 to 10 V/
–10 to 10 V
0 to 20 mA/
4 to 20 mA
External output max.
current
5 mA --- --- ---
External output allowed
load resistance
--- 350 Ω1 kΩmin. 600 Ωmax.
External output
impedance
--- 0.5 Ωmax. ---
Resolution 1/256 (1/512 for output signal range –10
to 10 V)
1/6,000 (full scale)
Overall precision 1.0% of full scale 25°C: ±0.4% of full scale
p
0 to 55°C: ±0.8% of full scale
Data setting 8-bit binary with sign bit ---
Set D/A data --- Binary data (hexadecimal, 4 digits)
–10 to 10 V input range: Full scale = F448 to 0BB8 Hex
Other input ranges: Full scale = 0000 to 1770 Hex
Conversion time 10 ms/Unit max. (See note 1.) 2 ms/point (6 ms for all points)
Isolation method Photocoupler isolation between I/O
terminals and PLC (There is no isolation
between the analog I/O signals.)
Photocoupler isolation between analog I/O and internal
circuits (There is no isolation between the analog I/O signals.)
Note 1. The conversion time is the total time for 2 analog inputs and 1 analog output.
2. The voltage output and current output can be used at the same time, but the total output current cannot exceed 21 mA.
CompoBus/S I/O Link Unit
Specifications
Item Specification
Model number CPM1A-SRT21
Master/Slave CompoBus/S Slave
Number of I/O bits 8 input bits, 8 output bits
Number of words occupied in
CPM1A I/O memory
1 input word, 1 output word
(Allocated in the same way as other Expansion Units)
Node number setting Set using the DIP switch.
Note: See the CompoBus/S Catalog (Q103) for more details on CompoBus/S communications.

Specifications
13
CPM1A-DRT21 DeviceNet I/O Link Unit
By connecting the DeviceNet I/O Link Unit (CPM1A-DRT21), the CPM2A can function as the slave of a DeviceNet D Master Unit. In
this configuration, I/O links for up to 32 inputs and 32 outputs can be created.
Specifications
Item Specification
Master/slave DeviceNet slave
Model number CPM1A-DRT21
Number of I/O points between
Unit and Master
Input: 32 points
Output: 32 points
Number of words allocated
from CPM2A’s I/O memory
Input: 2 words
Output: 2 words
(Allocated in the same way as other Expansion Units.)
Node address setting method Set using DIP switch.
Maximum number of
connectable nodes
63 (CS1)
32 (CVM1/CV)
25 (C200HX/HG/HE)
16 (C200HS)
(The series names in parentheses are for the CPU Unit to which the Master Unit is mounted.)
Temperature Sensor Units
By mounting a Temperature Sensor Unit (CPM1A-TS001/TS002/TS101/TS102) to the PC, input can be obtained from a thermocou-
ple or platinum resistance thermometer,and temperature measurements can be converted to binary data (4-digit hexadecimal) and
stored in the input area of the CPU Unit. For details on the maximum number of connectable Units, refer to 7.
Specifications
Item Specification
Model number CPM1A-TS001/002 CPM1A-TS101/102
Number of inputs 2 (TS001), 4 (TS002) 2 (TS101), 4 (TS102)
Input types K, J switchable
(Note: Same input for all input points.)
Pt100, JPt100 switchable
(Note: Same input for all input points.)
Indication accuracy [The larger of the indicated value ±0.5% and
±2°C] ±1 digit max.
[The larger of the indicated value ±0.5% and
±1°C] ±1 digit max.
Conversion time 250 ms/2 points (TS001, TS101); 250 ms/4 points (TS002, TS102)
Converted temperature data Binary (4-digit hexadecimal)
Isolation method Photocoupler isolation between the temperature input signals.
Note: The indication accuracy when using a K-type thermocouple for temperatures less than –100°C is ±4°C ±1 digit max.
Input Temperature Ranges for CPM1A-TS001/002
The rotary switch can be used to make of the following range and input type settings for CPM1A-TS001/002 models.
Input type Range (°C) Range (°F)
K–200 to 1300 –300 to 2300
0.0 to 500.0 0.0 to 900.0
J–100 to 850 –100 to 1500
0.0 to 400.0 0.0 to 750.0
Input Temperature Ranges for CPM1A-TS101/102
The rotary switch can be used to make of the following range and input type settings for CPM1A-TS101/102 models.
Input type Range (°C) Range (°F)
Pt100 –200.0 to 650.0 –300 to 1200.0
JPt100 –200.0 to 650.0 –300 to 1200.0

Specifications
14
Communications Adapter Specifications CPM1-CIF01/CIF11
RS-232C Adapter and RS-422 Adapter
Item Specifications
CPM1-CIF01 CPM1-CIF11
Functions Level conversion between the CMOS level (CPU side)
and the RS-232C (peripheral device side)
Level conversion between the CMOS level (CPU side)
and the RS-422 (peripheral device side)
Insulation The RS-232C (peripheral device side) is insulated by a
DC/DC converter and photocoupler.
The RS-422 (peripheral device side) is insulated by a
DC/DC converter and photocoupler.
Power supply Power is supplied by the CPU.
Power consumption 0.3 A max.
Transmission speed 38.4 Kbits/s max.
Vibration resistance 10 to 57 Hz with an amplitude of 0.075 mm, and 57 to 150 Hz with an acceleration of 9.8 m/s2in the X, Y and Z
directions for 80 minutes each in accordance (i.e. swept for 8 minutes, 10 times).
Shock resistance 147 m/s2in the X, Y and Z directions 3 times each.
Ambient temperature
(operating)
0°to 55°C
Ambient humidity
(operating)
10% to 90% (with no condensation)
Ambient environment
(operating)
With no corrosive gas
Ambient temperature
(storage)
–20°to 75°C
Weight 200 g max.
Memory Backup
The user program and memory area data in the CPU Unit are backed up by either one of the following methods.
•Flash Memory:
User program, read-only DM area (DM 6144 to DM 6599), and PC Setup area (DM 6600 to DM 6655).
•Internal Capacitor:
DM areas other than the above, HR area, AR area, and
Counter area.
The capacitor provides backup for a power interruption lasting
20 days at room temperature. If the power is expected to remain
OFF for a period exceeding this data backup period, consider-
ation must be given to the design of the system so that no prob-
lems will occur when the set values become undefined ones. For
further details, refer to CPM1A Operation Manual (W317).
Capacitor backup time (days)
Ambient temperature (_C)
20
10
7
1
25 40 80

Specifications
15
CPM2C-PA201 AC Power Supply Unit
The CPM2C-PA201 is a compact, streamlined Unit that can be used as the power supply for PCs, such as the CPM1A and CPM2A,
and indicators. (When using the CPM2C-PA201, connection must be performed by the user.)
AC Power
Supply Unit
Specifications
Item Specification
Rated output 15 W
Output voltage 24 VDC
Output current 600 mA
Efficiency 75% min. (at rated output)
Input conditions Rated voltage 100 to 240 VAC
p
Allowable voltage range 85 to 264 VAC
Frequency 47 to 63 Hz
Current 100 V 0.4 A
C
200 V 0.2 A
Leakage
t
100 V 0.5 mA max. (at rated output)
g
current 200 V 1 mA max. (at rated output)
Inrush current 100 V 15 A (at 25°C cold start)
200 V 30 A (at 25°C cold start)
Output
htiti
Output voltage accuracy 5%/–10% max.;10%/–15% max. (including input, load, and temperature fluctuations)
Op
characteristics Minimum output current 30 mA
Ripple noise voltage 2% (p-p) max.
Input fluctuation 0.75% max.
Load fluctuation 4% max.
Temperature fluctuation 0.05%/°C max.
Startup time 300 ms max. (at input voltage of 100 VAC or 200 VAC and the rated output)
Output hold time 10 ms (at input voltage of 100 VAC or 200 VAC and the rated output)
Overcurrent protection Self-resetting, operates at 105% to 335% of the rated current, suspended and intermittent operation
Overvoltage protection None
Ambient operating temperature 0 to 55°C
Ambient storage temperature –20 to 70°C (no condensation or icing)
Ambient operating humidity 10% to 90%
Dielectric strength 2,000 V for 1 min between all inputs and GR
Detection current: 10 mA
3,000 V for 1 min between all inputs and all outputs
Detection current: 10 mA
1,000 V for 1 min between all outputs and GR
Detection current: 10 mA
Insulation resistance 100 MΩmin. at 500 VDC between all outputs and any input, and between all outputs and GR
Vibration resistance 10 to 57 Hz, double amplitude of 0.075 mm, 57 to 150 Hz, acceleration: 9.8 m/s2in X, Y, and Z directions for
80 minutes according
(Time coefficient: 8 minutes ×coefficient factor 10 = total time 80 min.)
Shock resistance 147 m/s23 times each in X, Y, and Z directions
Noise terminal voltage FCC class A
Weight 250 g max.
External dimensions 40 ×65 ×90 mm (W ×H ×D)

16
Input Interrupts
There are two input interrupts in the CPM1A 10-point I/O CPU and four in the 20-, 30-, and 40-point I/O CPUs. Input interrupts are
available in two modes.
10-point I/O CPU 20-, 30-, and 40-point I/O CPU
Application Example:
Cutting Metal Sheets to Specified Lengths
The proximity sensor detects the edge of a
metal plate to operate the cutter. Metal sheets
can be cut continuously to the specified
lengths at a high speed.
Cutter
Conveyor
Proximity
sensor
Input
interrupt CPM1A
Cutter
operation
signal
Metal sheets
Input Interrupt Mode
If an input interrupt occurs, the regular program shuts down irrelevant of the cycle time, and the interrupt processing program is
executed immediately.
Regular program
Interrupt program
Input interrupt
Regular program
Counter Mode
When the number of external signals counted at high speed reaches a specified number of counts, the regular program shuts down,
and the interrupt processing program is executed at fixed counts. The count can be set between 0 and 65535.
Counter setting
Regular program
Interrupt program
Regular program
Input interrupt
Functions

Functions
17
Quick-response Inputs
There are two quick-response inputs for the CPM1A 10-point I/O CPU and four for the 20-, 30-, and 40-point I/O CPU (shared with the
interrupt inputs). Since an internal buffer is provided, the quick-response input function can even detect signals modified within one
cycle.
CPU Input no. Minimum input pulse width
10-point I/O CPU 00003 to 00004 0.2 ms
20-point, 30-point, 40-point I/O CPU 00003 to 00006
Overseeing
processes
Program
execution
I/O
refreshing
Overseeing
processes
Program
execution
I/O
refreshing
Input signal
(00003)
IR 00003
One cycle
Application Example:
Calculating the Number of Chips
The metal sensor counts the number of parts
that have passed. Steady counting can be
achieved even when the input-ON time is short.
CPM1A-V1
F2LP-WK4
F2LP-W
0.2 ms min
High-speed Counter
The CPM1A has a high-speed counter function that can be used in the incrementing and up/down mode. Using this function together
with the input interrupts enables zone comparison control or target value control irrelevant of the cycle time.
Item Incrementing mode Up/Down mode
Input no. 00000 Count input A-phase input
p
00001 --- B-phase input
00002 Reset input Z-phase input
Input method Single-phase input Phase-difference, 4×inputs
Count frequency 5.0 kHz 2.5 kHz
Count range 0 to 65535 –32767 to 32767
Note: When using in the incrementing mode, the input 00001 can be used as an input contact.
Count input
Reset input
Solenoid
Inverter, etc.
Sensor Rotary encoder
00000 or 00001 00002

Functions
18
Interval Timer Interrupts
The CPM1A has one interval timer. The interval timer shuts down the regular program irrelevant of the point in the cycle once the time
is up, and immediately executes an interrupt processing program. Interval timers are used in the following two modes.
Item One-shot mode Scheduled interrupt mode
Operation An interrupt is executed only once when the time is up. Interrupts are executed repeatedly at fixed periods.
Setting time 0.5 ms to 319,968 ms (0.1-ms units)
Normal program
Interval timer
Interrupt processing program
Application Example:
Computing the Sheet Speed
The number of pulse inputs is computed in the in-
terrupt mode at a fixed time to calculate the speed.
Encoder
CPM1A-V1
SBN(92) 00
RET(93)
MOV(21)
END(01)
ADD(30)
MOV(21)
Analog Setting
The CPM1A contains two analog setting controls that can be used for a broad range of analog timer and counter settings. Turning the
setting control stores values of 0 to 200 (BCD data) in the SR area.
Analog setting Storage area Setting value (BCD)
Analog setting 0 SR 250 0000 to 0200
Analog setting 1 SR 251
Application Example:
Tact Operation Control of Conveyor Lines
A conveyor can be stopped temporarily as required for assembly
processes. When the timer function and limit switches are used in a
combination, conveyors can be stopped for a fixed time or can be run
at a constant speed for a fixed distance. Fine adjustment of the stop-
ping time can be easily done by using the analog setting controls.
CPM1A
Analog setting 0
Analog setting 1
*Phillips screwdriver is required.
Motor
LS

Functions
19
Program Example
TIM
000
A
250
Value of the analog
setting 0 (0 to 200)
1. Analog timer for 0.0 to 20.0 seconds 2. Analog timer for 0.0 to 60.0 seconds
MUL(32)
250
#0003
DM0500
TIM
001 DM 0500
B
25313(ON)
BCD multiplication
Value of the analog setting 0
(0 to 200)
Triples the above value
Multiplication result (0 to 600)
Pulse Output Function
The CPM1A with transistor output has a function that is capable
of outputting a pulse of up to 2 kHz.
When used in combination with a Stepping Driver or Servodriv-
er, positioning can be easily performed.
Application Example
Changing the speed of the Stepping Motor.
Stepping Motor Driver Stepping Motor
Output point
01000 or 01001
ÉÉÉÉÉ
ÉÉÉÉÉ
ÉÉÉÉÉ
ÉÉÉÉÉ
ÉÉÉÉÉ
25,000 pulses
200 Hz
1 kHZ
00000 turns ON 0001 turns ON (limit switch)
Pulse rate
Output
frequency
Program Example
PULS(65)
000
000
DM 0000
15000
MOV(21)
#5000
DM 0000
25315
MOV(21)
#0002
DM 0001
MOV(21)
#0200
DM 0100
@SPED(64)
000
000
DM 0100
MOV(21)
#0020
DM 0100
25315
00200
15000
00001
00025000
DM 0001 DM 0000
1 scan turns ON.
1 scan turns ON.
Speed change limit switch
Changes to 200 Hz when the
limit switch is turned ON.
Frequency data (x 10 Hz)
Output mode (single)
Frequency conversion:
Pulse rate (BCD 8 digits)
Pulse rate setting
Sets the initial frequency to
2,000 pulses/second.
Sets the number of output pulses as
25,000 (times) in the data memory area.
Output port (output point 01000)

Functions
20
Communications
Host Link Communications
CPM1A host link communications consist of interactive procedures whereby the CPM1A returns a response to a command sent from
the IBM PC/AT or compatible computer. These communications allow the IBM PC/AT or compatible computer to read and write in the
CPM1A’s I/O Areas and Data Memory Areas as well as in areas containing the status of various settings.
1:1 Host Link Communications
CPM1A
CPU
RS-232C
Adapter
Response
Command
1:n Host Link Communications
CPM1A
CPU
RS-422
Adapter CPM1A
CPU
RS-422
Adapter CPM1A
CPU
RS-422
Adapter
Response
Command
Link Adapter
3G2A9-AL004-E

Functions
21
1:1 Links
With a 1:1 link, two CPM1As or a CPM1A and CQM1 or C200Hjare connected 1:1 with one side as the Master and the other as the
Slave to provide an I/O link of a maximum of 256 points (LR 0000 to LR 1515).
Example of a 1:1 Link between CPM1As
Link bits
WRITE area
READ area
LR 00
LR 07
LR 08
LR 15
WRITE
READ
READ area
WRITE area
LR 00
LR 07
LR 08
LR 15
READ
WRITE
Link bits
CPM1A CPU RS-232C Adapter CPM1A CPU
RS-232C Cable
RS-232C Adapter
Master Slave
Limitations of the CPM1A 1:1 Link
CPM1A I/O links are limited to 16 words (LR 00 to LR 15). Therefore, use these 16 words (LR 00 to LR 15) on the CQM1 or C200Hj
side when forming 1:1 links with a CQM1 or C200Hj.
NT Links
High-speed communications can be achieved by providing a direct access through the use of the NT Link between the CPM1A and
Programmable Terminal.
Programmable Terminal
RS-232C Cable
CPM1A CPU
RS-232C
Adapter

22
Summary of Programming Instructions
Function Code Chart
Table
sym-
bols
Details Key operations for
specifying program-
ming instructions
fAllocated to instruction
keys on the Program-
ming Console. These
need not be specified
with function codes.
---
Code Special instructions
specified with function
codes.
FUN WRITE
Code
Differentiated Instructions
Differentiated instructions can sometimes be used for CPM1A
special instructions. Instructions marked with (@) in the mne-
monics can also be used as differentiated instructions. Here the
input rise time (shift from OFF to ON) is used to execute the
instruction in just one cycle.
To specify an instruction, press the NOT Key after the function
code.
Example: Specifying the @MOV (21) instruction
FUN 12 NOT WRITE
Sequence Instructions
Sequence Input Instructions
Instruction Mnemonic Code Function
LOAD LD fConnects an NO condition to
the left bus bar.
LOAD NOT LD NOT fConnects an NC condition to
the left bus bar.
AND AND fConnects an NO condition in
series with the previous condi-
tion.
AND NOT AND NOT fConnects an NC condition in
series with the previous condi-
tion.
OR OR fConnects an NO condition in
parallel with the previous
condition.
OR NOT OR NOT fConnects an NC condition in
parallel with the previous
condition.
AND LOAD AND LD fConnects two instruction
blocks in series.
OR LOAD OR LD fConnects two instruction
blocks in parallel.
Note: f: Instruction keys allocated to the Programming Con-
sole.
Sequence Output Instructions
Instruction Mnemonic Code Function
OUTPUT OUT fOutputs the result of logic to a
bit.
OUT NOT OUT NOT fReverses and outputs the re-
sult of logic to a bit.
SET SET fForce sets (ON) a bit.
RESET RSET fForce resets (OFF) a bit.
KEEP KEEP 11 Maintains the status of the
designated bit.
DIFFER-
ENTIATE
UP
DIFU 13 Turns ON a bit for one cycle
when the execution condition
goes from OFF to ON.
DIFFER-
ENTIATE
DOWN
DIFD 14 Turns ON a bit for one cycle
when the execution condition
goes from ON to OFF.
Note: f: Instruction keys allocated to the Programming Con-
sole.
Sequence Control Instructions
Instruction Mnemonic Code Function
NO
OPERA-
TION
NOP 00 ---
END END 01 Required at the end of the pro-
gram.
INTER-
LOCK
IL 02 If the execution condition for
IL(02) is OFF, all outputs are
turned OFF and all timer PVs
reset between IL(02) and the
next ILC(03).
INTER-
LOCK
CLEAR
ILC 03 ILC(03) indicates the end of an
interlock (beginning at IL(02)).
JUMP JMP 04 If the execution condition for
JMP(04) is ON, all instructions
between JMP(04) and
JME(05) are treated as
NOP(00).
JUMP END JME 05 JME(05) indicates the end of a
jump (beginning at JMP(04)).
Timer/Counter Instructions
Instruction Mnemonic Code Function
TIMER TIM fAn ON-delay (decrementing)
timer.
COUNTER CNT fA decrementing counter.
RE-
VERSIBLE
COUNTER
CNTR 12 Increases or decreases PV by
one.
HIGH-
SPEED
TIMER
TIMH 15 A high-speed, ON-delay
(decrementing) timer.
Note: f: Instruction keys allocated to the Programming Con-
sole.
Programming Instructions
