Omron 3G3RX-V1 Series Instruction Manual

Machine Automation Controller NJ-series
DeviceNetTM Connection Guide
OMRON Corporation
3G3RX-V1 Series Inverter
P546-E1-01

About Intellectual Property Rights and Trademarks
Microsoft product screen shots reprinted with permission from Microsoft Corporation.
Windows is registered trademark of Microsoft Corporation in the USA and other countries.
ODVA and DeviceNetTM are trademarks of ODVA.
EtherCAT®is registered trademark and patented technology, licensed by Beckhoff Automation
GmbH, Germany.
Sysmac is a trademark or registered trademark of OMRON Corporation in Japan and other
countries for OMRON factory automation products.
Company names and product names in this document are the trademarks or registered
trademarks of their respective companies.

Table Of Contents
1. Related Manuals........................................................................................ 1
2. Terms and Definitions............................................................................... 1
3. Remarks..................................................................................................... 2
4. Overview .................................................................................................... 4
5. Applicable Products and Support Software............................................ 5
5.1. Applicable Products ........................................................................... 5
5.2. Device Configuration.......................................................................... 6
6. DeviceNet Settings.................................................................................... 8
6.1. DeviceNet Communications Settings................................................. 8
6.2. Allocation for Remote I/O Communications ....................................... 9
7. Connection Procedure.............................................................................11
7.1. Overview of Setting up Remote I/O Communications.......................11
7.2. Work Flow........................................................................................ 12
7.3. Setting Up the Inverter..................................................................... 13
7.4. Setting Up the Controller.................................................................. 20
7.5. Setting Up the Network.................................................................... 29
7.6. Connection Status Check................................................................. 35
8. Initialization Method................................................................................ 40
8.1. Controller ......................................................................................... 40
8.2. Inverter............................................................................................. 41
9. Appendix 1 Details on Remote I/O Communication Settings................................ 42
9.1. Global Variable Table....................................................................... 42
10. Appendix 2 Setting Procedure without the Configuration Files......................... 44
10.1. Overview of Setting Procedure without the Configuration Files ....... 44
10.2. Work Flow of the "Procedure for Setting Parameters from the Beginning"........... 45
10.3. Setting Up the Controller without the Configuration Files................. 47
10.4. Setting Up the Network by CX-Integrator......................................... 56
11. Revision History .................................................................................. 64

1．Related Manuals
1
1. Related Manuals
The table below lists the manuals that relate to this document.
To ensure system safety, make sure to always read and heed the information provided in all
Safety Precautions, Precautions for Safe Use, and Precaution for Correct Use of manuals for
each device which is used in the system.
Cat.No. Model Manual Name
W500 NJ501-[][][][]
NJ301-[][][][] NJ-series CPU Unit Hardware User's Manual
W501 NJ501-[][][][]
NJ301-[][][][] NJ-series CPU Unit Software User's Manual
W497 CJ1W-DRM21 CJ-series DeviceNet™ Units Operation Manual for
NJ-series CPU Unit
W267 - DeviceNet™ Operation Manual
W504 SYSMAC-SE2[][][] Sysmac Studio Version 1 Operation Manual
W464 - CX-Integrator Ver.2 Network Configuration Tool
Operation Manual
I578 3G3RX-V1-[][][][][]-V1 RX Series Type V1 High-function General-purpose
Inverter User's Manual
I581 3G3AX-RX-DRT-E MX2/RX Series DeviceNet Communications Unit User's
Manual
2. Terms and Definitions
Term Explanation and Definition
Master/Slave A master is a unit that controls the DeviceNet communications.
Amaster sends output data to multiple slaves and receives input data from
the slaves.
Slaves receive output data that are sent from the master, and send input
data to the master.
At least one master is required for DeviceNet communications.
EDS file An EDS file is a file that contains the I/O points of DeviceNet slave units
and the parameters that can be set via DeviceNet.
Node address
(MAC ID) A node address is an address to identify a unit connected to a DeviceNet network. With DeviceNet, a MAC (Media Access Control) ID is used as a
node address. Thus, a node address is a MAC ID.
Scan list A scan list is used to register slaves with which a master communicates in
DeviceNet remote I/O communications. A master communicates with the
slaves based on the scan list settings.

3．Remarks
2
3. Remarks
(1) Understand the specifications of devices which are used in the system. Allow some
margin for ratings and performance. Provide safety measures, such as installing safety
circuit in order to ensure safety and minimize risks of abnormal occurrence.
(2) To ensure system safety, always read and heed the information provided in all Safety
Precautions, Precautions for Safe Use, and Precaution for Correct Use of manuals for
each device used in the system.
(3) The user is encouraged to confirm the standards and regulations that the system must
conform to.
(4) It is prohibited to copy, to reproduce, and to distribute a part of or whole part of this
document without the permission of OMRON Corporation.
(5) The information contained in this document is current as of January 2013. It is subject to
change without notice for improvement.

3．Remarks
The following notation is used in this document.
Indicates a potentially hazardous situation which, if not avoided,
will result in minor or moderate injury, or may result in serious
injury or death. Additionally there may be significant property
damage.
Indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury or in property damage.
Precautions for Safe Use
Precautions on what to do and what not to do to ensure safe usage of the product.
Application precautions
Precautions on what to do and what not to do to ensure proper operation and performance.
Additional Information
Additional information to read as required.
This information is provided to increase understanding or make operation easier.
3

4．Overview
4
4. Overview
This document describes the procedure for connecting the Inverter (3G3RX-V1 series) of
OMRON Corporation (hereinafter referred to as OMRON) to the NJ-series Machine
Automation Controller (hereinafter referred to as the Controller) via DeviceNet and provides
the procedure for checking their connection.
Specifically, it describes the procedure for connecting DeviceNet using DeviceNet settings of
the project files prepared beforehand (hereinafter referred to as the "procedure for using the
configuration files").
Section 9 A-1 and Section 10 A-2 describe the procedures for setting parameters without the
prepared configuration files (hereinafter referred to as the "procedure for setting parameters
from the beginning").
To follow the "procedure for using the configuration files", prepare the latest "Sysmac Studio
project file" and "CX-Integrator project file" (they are referred to as "configuration files") from
OMRON in advance.
Name File name Version
Sysmac Studio project file
(extension: SMC) OMRON_3G3RX-V1_DN_EV100.SMC Ver.1.00
CX-Integrator project file
(extension: cin) OMRON_3G3RX-V1_DN_EV100.cin Ver.1.00

5．Applicable Products and Support Software
5. Applicable Products and Support Software
5.1. Applicable Products
The applicable devices are as follows:
Manufacturer Name Model Version
OMRON NJ-series CPU Units NJ501-[][][][]
NJ301-[][][][]
OMRON DeviceNet Unit (Master) CJ1W-DRM21
OMRON Inverter 3G3RX -[][][][][]-V1
OMRON DeviceNet Communications
Unit 3G3AX-RX-DRT-E
Versions listed in
Section 5.2 or higher
versions
Precautions for Correct Use
As applicable devices above, the devices with the models and versions listed in Section 5.2.
are actually used in this document to describe the procedure for connecting devices and
checking the connection.
You cannot use devices with versions lower than the versions listed in Section 5.2.
To use the above devices with versions not listed in Section 5.2 or versions higher than those
listed in Section 5.2, check the differences in the specifications by referring to the manuals
before operating the devices.
Additional Information
This document describes the procedure to establish the network connection. Except for the
connection procedure, it does not provide information on operation, installation or wiring
method. It also does not describe the functionality or operation of the devices. Refer to the
manuals or contact your OMRON representative.
5

5．Applicable Products and Support Software
5.2. Device Configuration
The hardware components to reproduce the connection procedure of this document are as
follows:
DeviceNet cable
3G3RX-A2055-V1 +
3G3AX-RX-DRT-E
NJ501-1500+
CJ1W-DRM21
Personal computer
(Sysmac Studio
installed,
OS: Windows7)
USB cable
T-branch Tap (DCN1-1C)
Manufact
urer Name Model Version
OMRON DeviceNet Unit (Master) CJ1W-DRM21 Ver.1.1
OMRON CPU Unit NJ501-1500 Ver.1.03
OMRON Power Supply Unit NJ-PA3001
OMRON DeviceNet cable DCA1-5C10
OMRON T-branch Tap DCN1-1C
OMRON Sysmac Studio SYSMAC-SE2[][][] Ver.1.04
OMRON CX-Integrator (Included with Sysmac Studio) Ver.2.55
OMRON Sysmac Studio project file OMRON_3G3RX-V1_DN_EV1
00.SMC Ver.1.00
OMRON CX-Integrator project file OMRON_3G3RX-V1_DN_EV1
00.cin Ver.1.00
- Personal computer
(OS: Windows 7) -
- USB cable
(USB 2.0 type B connector) -
OMRON Inverter 3G3RX -A2055-V1
OMRON DeviceNet Communications
Unit 3G3AX-RX-DRT-E
6

5．Applicable Products and Support Software
Precautions for Correct Use
To use the configuration files, prepare the latest "Sysmac Studio project file" and
"CX-Integrator project file" in advance.
(To obtain the files, contact your OMRON representative.)
Precautions for Correct Use
Update the Sysmac Studio to the version specified in this section or higher version using the
auto update function.
If a version not specified in this section is used, the procedures described in Section 7 and
subsequent sections may not be applicable. In that case, use the equivalent procedures
described in the Sysmac Studio Version 1 Operation Manual (Cat.No. W504).
Additional Information
For information on the DeviceNet cable and network wiring, refer to Chapter 2 Network
Configuration and Wiring of the DeviceNet Operation Manual (Cat. No. W267).
Connect a terminating resistance to each end of the trunk line of the DeviceNet.
Additional Information
In this document, a USB is used to connect with the Controller. For information on how to
install a USB driver, refer to A-1 Driver Installation for Direct USB Cable Connection of the
Sysmac Studio Version 1 Operation Manual (Cat.No. W504).
7

6．DeviceNet Settings
8
6. DeviceNet Settings
This section provides the specifications such as communications parameters and variables
that are defined in this document.
Hereinafter, the Inverter is referred to as the "destination device" in some descriptions.
6.1. DeviceNet Communications Settings
The DeviceNet settings are shown below.
DeviceNet Unit Inverter
Unit number 0 -
Node address (MAC ID) 63 0
Baud rate (bps) 500 kbps (Automatically follows the Master Unit)
Remote I/O - 1 (Extended Speed I/O)

6．DeviceNet Settings
6.2. Allocation for Remote I/O Communications
The remote I/O communications data of the destination device are allocated to the Controller's
global variables. An allocation for the remote I/O communications data is called a scan list.
The relationship between the device data and the global variables is shown below.
The following global variables are defined in the "configuration file".
■Output area (Controller →Inverter)
Offset Destination device
data Memory used for CJ-series Unit Global variable name Data type
+0 Command %3200 DN00_CMD_OUT BOOL[16]
+1 Rotation Speed
Reference %3201 DN00_DATA_OUT
WORD
■Input area (Controller ←Inverter)
Offset Destination device
data Memory used for CJ-series Unit Global variable name Data type
+0 Status information %3300 DN00_STA_IN BOOL[16]
+1 Rotation Speed
Monitor %3301 DN00_DATA_IN WORD
Additional Information
For details on I/O format, refer to Section 4 Remote I/O in the MX2/RX Series DeviceNet
Communication Unit User's Manual (Cat. No. I581).
Additional Information
When a DeviceNet Unit is used with a Controller, slave data are allocated to the memory
used for CJ-series Units. With programs, specify variable names for the memory used for
CJ-series Units.
With Sysmac Studio, add the prefix "%" to each address to indicate the memory used for
CJ-series Units.
9

6．DeviceNet Settings
10
■Details on output area
Global variable Name Meaning
DN00_CMD_OUT[0] FW Forward/stop 0: Stop, 1: Forward
DN00_CMD_OUT[1] RV Reverse/Stop 0: Stop, 1: Reverse
DN00_CMD_OUT[2] RS Fault reset 0:-, 1: Fault reset
DN00_CMD_OUT[5] CTR Net Ctrl. 0: Follow the setting of parameter A002.
1: Follow the reference from network control.
DN00_CMD_OUT[6] REF Net Ref. 0: Follow the setting of parameterA001.
1: Follow the reference from network control.
DN00_DATA_OUT Rotation Speed
Reference
If parameter P049 (Number of Poles for Rotation
Speed Setting) is set appropriately, the rotational
speed unit is [min -1].
If parameter P049 (Number of Poles for Rotation
Speed Setting) is set to 0, the frequency unit is [0.01
Hz].
■Details on input area
Global variable Name Meaning
DN00_STA_IN[0] AL Alarm
output 0:Normal, 1: Fault/Trip
DN00_STA_IN[1] WR Warning 0: Normal, 1: Warning
DN00_STA_IN[2] FWR
During
forward
operation
0: During reverse run/Stopping, 1: During forward run
DN00_STA_IN[3] RVR
During
reverse
operation
0: During forward run/Stopping, 1: During reverse run
DN00_STA_IN[4] IRDY
Operation
ready 0: Not ready, 1: Ready
DN00_STA_IN[5] CFN
Ctrl.From
Net 0: Follow the setting of parameterA002. 1: DeviceNet reference
DN00_STA_IN[6] RFN
Ref.From
Net 0: Follow the setting of parameterA001. 1: DeviceNet reference
DN00_STA_IN[7] FA1 Constant speed
reached
0: Accelerating or decelerating/Stopping, 1: Frequency
agree
DN00_STA_IN [15] to [11] [10] [9] [8]
1: Startup 0 0 0 1
2: Not ready 0 0 1 0
3: Ready 0 0 1 1
4: Operation in
progress 0 1 0 0
5: Stopping 0 1 0 1
6: Fault/Trip stop 0 1 1 0
DN00_STA_IN[8]
to
DN00_STA_IN[15]
Drive Status
7: Fault/Trip 0 1 1 1
DN00_DATA_IN Rotation Speed
Reference
If parameter P049 (Number of Poles for Rotation Speed
Setting) is set appropriately, the rotational speed unit is
[min -1].
If parameter P049 (Number of Poles for Rotation Speed
Setting) is set to 0, the frequency is monitored in units of
[0.01 Hz].

7．Connection Procedure
7. Connection Procedure
This section describes the procedure for connecting the Controller to Inverter via DeviceNet
using the "procedure for using the configuration files".
This document explains the procedures for setting up the Controller and Inverter from the
factory default setting. For the initialization, refer to Section 8 Initialization Method.
Personal computer
11
Destination
device
Controller
7.1. Overview of Setting up Remote I/O Communications
The following figure shows the relationship of processes to perform DeviceNet remote I/O
communications using the "procedure for using the configuration files".
Opening
project file
Sysmac Studio project file CX-Integrator project file
Importing
project file
Toolbox
Transferring
scan list
CX-Integrator
Sysmac Studio
Transferring
project data
Precautions for Correct Use
Prepare the latest "Sysmac Studio project file" and "CX-Integrator project file" from OMRON
in advance.
(To obtain the file, contact your OMRON representative.)

7．Connection Procedure
12
7.2. Work Flow
Take the following steps to make connection settings for remote I/O communications of
DeviceNet.
7.3. Setting Up the Inverter Set up the Inverter.
↓
7.3.1 Hardware Setting Mount the DeviceNet Communications Unit on the
Inverter.
↓
7.3.2 Parameter Setting Set the parameters for the Inverter.
↓
7.4. Setting up the Controller Set up the Controller.
↓
7.4.1 Hardware Setting for DeviceNet
Unit Set the hardware switches on the DeviceNet Unit and connect to the Controller.
↓
7.4.2. Starting the Sysmac Studio and
Importing the Project File Start the Sysmac Studio and import the Sysmac Studio project file.
↓
7.4.3 Connecting Online and
Transferring the Project Data Connect online with the Sysmac Studio and transfer the project data to the Controller.
↓
7.5 Setting Up the Network Set up remote I/O communications of DeviceNet.
↓
7.5.1. Starting the CX-Integrator and
Opening the Project File Start the CX-Integrator and open the CX-Integrator project file.
↓
7.5.2. Connecting Online and
Transferring a Scan List Connect online with the Controller, and transfer the setting (scan list) of the set device to the DeviceNet
Unit via the Controller.
↓
7.6. Connection Status Check Check the connection status of the DeviceNet
network.
↓
7.6.1. Checking the Connection Status Confirm that the DeviceNet communications is
normally performed.
↓
7.6.2. Checking Data that are Sent
and Received Confirm that the correct data are sent and received.

7．Connection Procedure
7.3. Setting Up the Inverter
Set up the Inverter.
7.3.1. Hardware Setting
Mount the DeviceNet Communications Unit on the Inverter.
Precautions for Correct Use
Make sure that the power supply is OFF when you perform the settings.
1 Check the name of each part on
the Inverter and the DeviceNet
Communications Unit by
referring to the right figure.
●Inverter
●DeviceNet Communications Unit
A. Inverter connection PCB
B. LED indicators (MS and NS)
C. Flat cable
D. DeviceNet connector
E. Grounding cable
F. Housing
A. Digital Operator
B. Spacer cover
C. Terminal cover
D. Front cover
E. Operator connecto
r
13

7．Connection Procedure
2 Mount the DeviceNet
Communications Unit on the
Inverter.
*For the mounting procedure of
the DeviceNet Communications
Unit, refer to 2-2-2 Mounting
Procedure of DeviceNet
Communications Unit on
RX-series Inverter in the
MX2/RX Series DeviceNet
Communication Unit User's
Manual (Cat. No. I581).
3 Connect the power supply to the
main power supply input
terminal.
*The location of the power
supply input terminal differs
depending on the model.
Refer to 2-3-4 Wiring for Main
Circuit Terminals in the RX
Series Type V1 High-function
General-purpose Inverter
User's Manual (Cat. No. I578).
14

7．Connection Procedure
7.3.2. Parameter Setting
Set the parameter (node address) for the Inverter.
Additional Information
Make sure that DeviceNet is not connected when you perform the setting up.
1 Turn ON the power supply to the
Inverter.
*Set the parameter by using the
Digital Operator on the front of
the Inverter.
Data display Displays the frequency reference value, output current value or set value, or other
relevant data.
RUN key
Runs the Inverter. This key is enabled
when RUN Command Selection is set to
Digital Operator.
(Check that the RUN command LED
indicator is lit.)
STOP/RESET
key
Decelerates to stop the inverter. This key is
used to reset an error when an error is
occurring in the Inverter.
Mode key Switches between Monitor Mode (d [][][]),
Basic Function Mode (F000) and Extended
Function Mode (A [][][], b[][][], C[][][], H[][][]).
Enter key Enters the set value.
(Make sure to press this key when you
change the set value.)
Increment Key Switches each mode.
This Key is also used to increment the set
value of each function.
Decrement
Key
Switches each mode.
This Key is also used to decrement the set
value of each function.
Operation keys
RUN command LED indicator
Data display
15

7．Connection Procedure
2
When you turn ON the power
supply, the display shows data
as shown on the right.
Set the parameters by using the
procedure on the right.
[A001] Frequency Reference
Selection 1: 05
[A002] RUN Command
Selection 1: 05
*Set 05 (Option 2).
00.00
a001
a002
05
a001
a002
02
a005
a002
Press the Increment Key three times.
Press the Enter Key.
Press the Increment Key once.
Parameter A002 is displayed.
The parameter is displayed again.
Press the Enter Key.
The data is changed to 05.
The default data is displayed.
The parameter is displayed again.
Press the Enter Key.
The data is changed to 05.
Press the Increment Key three times.
The default data is displayed.
Press the Enter Key.
Press the Mode Key three times.
Parameter A001 is displayed.
(By default, the display shows the data of
d001 (Output Frequency Monitor).)
A
fter turning ON the power
supply, the display shows data.
16

7．Connection Procedure
3 Set the parameter by using the
procedure on the right.
[C102] Reset selection: 03
*Set 03 (Trip reset only). By
setting this value, the
communications connection is
not reset even if the Inverter is
reset.
a002
c001
c102
02
03
c102 The parameter is displayed again.
Press the Enter Key.
The data is changed to 03.
Press the Increment Key once.
Press the Enter Key.
The default data is displayed.
Parameter C102 is displayed.
Press the Increment Key and display
C102.
Parameter C001 is displayed.
Press the Mode Key twice.
The parameter is displayed.
17
