Ultra-slim Signal Converter K3FP Series 1
Ultra-slim Signal Converter
K3FP Series
Complete Lineup of Ultra-slim, High-
performance Converters for Every
Application
• Ultra-slim 6.2-mm size.
Close mounting makes devices more compact.
• Easily wired and flexible with 8 terminal blocks.
• Multi-range I/O provides flexibility for the desired signal format.
• High-precision analog conversion with minimum current
consumption.
• Reduced wiring through power supply connection with DIN rail
bus connector (optional).
Product Selection
Product Model Input signal Output signal Power supply
voltage
Reference
page
3-Way Signal Isolator K3FP-YV-I-I 0 (4) to 20 mA DC 0 (4) to 20 mA DC 24 V DC 3
3-Way Signal Isolator K3FP-YV-U-U −10 (0) to 10 V DC −10 (0) to 10 V DC 24 V DC
3-Way Signal Isolator K3FP-VS-UI-UI 0 to 20 mA DC, 4 to 20 mA DC,
0 to 10 V DC, 2 to 10 V DC,
0 to 5 V DC, 1 to 5 V DC
(selected by DIP switch setting)
0 to 20 mA DC, 4 to 20 mA DC,
0 to 10 V DC, 2 to 10 V DC,
0 to 5 V DC, 1 to 5 V DC
(selected by DIP switch setting)
24 V DC 6
Dual Output 3-Way Signal
Isolator
K3FP-VS-UI-2I 0 to 20 mA DC, 4 to 20 mA DC,
0 to 10 V DC, 1 to 5 V DC
(selected by DIP switch setting)
0 to 20 mA DC, 4 to 20 mA DC
(selected by DIP switch setting)
24 V DC 10
Loop-powered Isolator
(1-channel)
K3FP-SN1-I-I 0 (4) to 20 mA DC 0 (4) to 20 mA DC --- 14
Loop-powered Isolator
(2-channel)
K3FP-SN2-I-I 0 (4) to 20 mA DC 0 (4) to 20 mA DC ---
Thermocouple Transducer K3FP-TS-UI Type J and K Thermocouples
(Conforms to IEC 60584-1)
(Input temperature range is
selected by DIP switch setting.)
0 to 20 mA DC, 4 to 20 mA DC,
20 to 0 mA DC, 20 to 4 mA DC,
0 to 5 V DC, 1 to 5 V DC,
0 to 10 V DC, 10 to 0 V DC
(selected by DIP switch setting)
24 V DC 17
RTD Transducer K3FP-RS-UI PT100 Platinum Resistance
Thermometer
(Conforms to IEC 60751)
(Input temperature range is
selected by DIP switch setting.)
0 to 20 mA DC, 4 to 20 mA DC,
20 to 0 mA DC, 20 to 4 mA DC,
0 to 5 V DC, 1 to 5 V DC,
0 to 10 V DC, 10 to 0 V DC
(selected by DIP switch setting)
24 V DC 23
Repeater Power Supply K3FP-DY-I-I 0 (4) to 20 mA DC 0 (4) to 20 mA DC 24 V DC 30
Limit Value Switch K3FP-SL-UI 0 to 20 mA DC, 0 to 10 V DC
(selected by DIP switch setting)
SPDT output 24 V DC 33

2Ultra-slim Signal Converter K3FP Series
Applications
External device
2-conductor
PT100
3-conductor
PT100
4-conductor
PT100
Width: Just 6.2 mm.
Data Logger
Alarm
indicator
Digital Panel Meter
Consider the following products for judging non-DC
signal inputs.
For AC current single-phase signal inputs: K8AB-AS
For AC voltage single-phase signal inputs:
K8AB-VS/K8AB-VW
For AC voltage three-phase signal inputs: K8AB-PW
For thermocouple and platinum resistance
thermometer sensor inputs: K8AB-TH
Select the number of conductors for the input platinum resistance
thermometer using the DIP switch on the side of the Unit.
Set any input range from −150°C to 850°C.
The input signal provides power for the Isolator, so power supply
capacity does not need to be considered when expanding Units:
No power line wiring is required.
This ultra-slim 6.2-mm Signal Converter can be installed in limited
space, such as where expansion is required, and help to reduce the
overall size of devices.
K3FP-RS-UI RTD Transducer
K3FP-VS-UI-UI
Dual Output 3-Way Signal Isolator
K3FP-VS-UI-2I K3FP-SL-UI Limit Value Switch
Install in Limited Space Isolators That Do Not Require Power Supply
K3FP Series
One-channel Passive Loop-powered Isolator
K3FP-SN1-I-I
Two-channel Passive Loop-powered Isolator
K3FP-SN2-I-I
Reduces Spare Parts Three- and four-conductor RTD Transducers
Isolated Duplicate Signal Output Limit Value Switches
Input and output ranges are
set using a DIP switch on
the side of the Unit.
Output signal
0 to 10 V DC
2 to 10 V DC
0 to 5 V DC
1 to 5 V DC
0 to 20 mA DC
4 to 20 mA DC
Input signal
0 to 10 V DC
2 to 10 V DC
0 to 5 V DC
1 to 5 V DC
0 to 20 mA DC
4 to 20 mA DC
4 to 20 mA DC
4 to 20 mA DC
Input signal
0 to 20 mA DC,
4 to 20 mA DC,
0 to 10 V DC,
1 to 5 V DC
(switch using
DIP switch)
Field device
For details, refer to Measuring and Monitoring Relays K8AB Series/
61F-D21T (Cat. No.: N141).
Page 33Page 10
Page 23Page 6
Page 14
Page 14
Note:
3-Way Signal Isolator

3-Way Signal Isolator K3FP-YV-I-I/K3FP-YV-U-U 3
3-Way Signal Isolator
K3FP-YV-I-I/K3FP-YV-U-U
6.2-mm Ultra-slim Isolator
• Isolates between input, output, and power supply. 1,500 V AC
dielectric strength.
• Close mounting.
• CE Marking compliant.
• UL certified.
Refer to Common Precautions on page 38.
Ordering Information
■Isolator
■Optional Products
Model Number Structure
DC Current Isolator
1. Model
2. Input or output signal
Current input
I: 0 (4) to 20 mA DC
Current output
I: 0 (4) to 20 mA DC
DC Voltage Isolator
1. Model
2. Input or output signal
Voltage input
U: −10 (0) to 10 V DC
Voltage output
U: −10 (0) to 10 V DC
Ratings and Specifications
■Ratings and Specifications
Name Model
DC Current Isolator K3FP-YV-I-I
DC Voltage Isolator K3FP-YV-U-U
Name Model
DIN rail bus connector K3FP-1
12
K3FP-YV-I-I
12
K3FP-YV-U-U
Item Model K3FP-YV-I-I K3FP-YV-U-U
Supply voltage 24 V DC
Allowable supply
voltage range
80% to 125% of rated supply voltage
Current consumption 20 mA DC max. 10 mA DC max.
Power consumption 450 mW max. 200 mW max.
Error ±0.1% FS max.
Temperature
coefficient
Maximum: 0.01%/°C max.,
Typical: 0.002%/°C max. (at 23°C)
Cut-off frequency 100 Hz
Response time
(10% to 90%)
3.5 ms max.
Insulation resistance 10 MΩmin. between inputs, outputs, and
power supply (at 500 V DC)
Dielectric strength 1,500 V AC, 50 Hz, 1 min (between inputs,
outputs, and power supply)
Noise resistance Conforms to IEC 61000
Ambient operating
temperature
−20 to 65°C
Ambient storage
temperature
−40 to 85°C
Ambient operating
humidity
95% max. (with no condensation)
0
4
8
12
16
20
4 8 12 16 20
Input current (mA) Input voltage (V)
−10
10
0
−10
100
K3FP-YV-I-I K3FP-YV-U-U
Output current (mA)
Output voltage (V)

43-Way Signal Isolator K3FP-YV-I-I/K3FP-YV-U-U
■Input Specifications
■Output Specifications
Nomenclature
Ambient storage
humidity
95% max. (with no condensation)
Connection method Screw connections (M3)
Tightening torque 0.5 N·m
Connecting
cable
Solid
wire
0.14 to 2.5 mm2
Stranded
wire
0.2 to 2.5 mm2
AWG 24 to 12
Wire
stripping
length
12 mm
Degree of protection IP20
Housing material PBT
Weight 55 g
Safety standards UL 508
EMC EMI:
Radiated EMI: EN 55011
EMS:
ESD immunity: EN 61000-4-2
Rated electromagnetic field immunity:
EN 61000-4-3
Burst immunity: EN 61000-4-4
Surge immunity: EN 61000-4-5
Conducted disturbance immunity:
EN 61000-4-6
Item Model K3FP-YV-I-I K3FP-YV-U-U
Input signal
Item
0 (4) to 20 mA DC −10 (0) to 10 V DC
Input impedance Approx. 50 ΩApprox. 100 kΩ
Max. input signal 50 mA 30 V
Output signal
Item
0 (4) to 20 mA DC −10 (0) to 10 V DC
Allowable load
impedance
500 Ωmax. 10 kΩmin.
Max. output signal 28 mA 12.5 V
Non-load voltage 12.5 V max. ---
Short-circuit
current
--- 22 mA max.
Ripple 20 mV pp max. (500 Ω) 20 mV pp max.
Span adjustment
range
±0.5%
1
2 Input signals
3
4 Supply voltage
7
8 Supply voltage
5
6 Output signals
Translucent cover
Snap for mounting DIN rail
DIN rail bus connection
Potentiometer for adjustment
Note: The potentiometer is for adjustment at the factory. Do not adjust the potentiometer.

3-Way Signal Isolator K3FP-YV-I-I/K3FP-YV-U-U 5
Connections
■Internal Block Diagram
Dimensions
Note: All units are in millimeters unless otherwise indicated.
Precautions
Refer to pages 38 and 39 for common precautions.
1
2
3
4
5
6
7
K3FP-1
8
Input signal
Supply voltage
−
+
−
+
−
+
−
+
Output signal
Supply voltage
93.1 6.2
102.5
K3FP-YV-I-I
K3FP-YV-U-U
Note: 1. Use solid wire with a diameter
of 2.5 mm2max. or bar
terminals with insulation
sleeves for terminal
connections.
To preserve dielectric strength
after connection, the length of
the exposed conductive part
inserted into the terminal must
be 12 mm max.
2. Screw Tightening Torque
Recommended torque:
0.5 N·m
12 mm max. 12 mm max.
For 2.5-mm2(max.)
solid wire:
For bar terminals with
insulation sleeves:

63-Way Signal Isolator K3FP-VS-UI-UI
