Onan Protec Series User manual

Installation Manual
YD PTO
PROTEC Series
Printed inU.SA
929-0600
10-94

TableofContents
SECTIONTITLEPAGE
SAFETYPRECAUTIONSii,iii
1INTRODUCTION1-1
General1-1
Generator1-1
VoltageRegulator1-1
Meter/BreakerBox1-1
Operation1-1
2 SPECIFICATIONS 2-1
3PRE-INSTALLATION3-1
General3-1
GeneratorMounting3-1
Meter/BreakerBoxMounting3-1
PTOSystemConfiguration3-2
4GENERATORMOUNTING4-1
GeneratorSupportFramework4-1
ConnectingthePTO4-2
5METER/BREAKERBOX,VOLTAGEREGULATORMOUNTING5-1
General5-1
6SYSTEMWIRING6-1
SystemConnections6-1
7INSTALLATIONAND WIRING DIAGRAMS7-1

SafetyPrecautions
Beforeoperatingthegenerator,readtheOperator's Manual andbecomefamiliar with it and theequipment.
Safe anaefficientoperationcanbeachievedonlyiftheunitisproperlyoperatedandmantained.
Manyaccidentsarecausedbyfailuretofollowfundamentalrulesandprecautions.
Thefollowingsymbols,foundthroughoutthismanual,alertyoutopotentiallydangerousconditionstotheop-
erator,servicepersonnel,ortheequipment.
EliTiVMihl This symbol warns of Immediate hazards which will result in severe personal injury or
death.
IAWARNINGI This symbol refers to a hazard or unsafe practice which can result in severe personal in-
jury or death.
This symbol refers to a hazard or unsafe practice which can result in personal Injury or
product or property damage.
GASOLINE AND LPG FUEL MAY BE ACCIDENTALLY IGNITEDBY ELECTRICAL SPARKS, presenting
thehazardof fire or explosion, whichcanresultin severe personal Injuryordeath.WhenInstallingthe
generatorset:
•Donottieelectricalwiringtofuellines.
•Donotrunelectricallinesandfuellinesthroughthesamecompartmentopenings.
•Keepelectricalandfuellinesasfarapartaspossible.
•Placea physicalbarrierbetweenfuellinesandelectricallineswhereverpossible.
•Ifelectricalandfuellinesmustpassthroughthesamecompartmentopening,makecertainthattheyare
physicallyseparatedbyrunningthemthroughindividualchannels,orbypassingeachlinethrougha sepa-
ratepieceoftubing.
•DONOTSMOKEwhileservicingbatteries.Leadacidbatteriesemita highlyexplosivehydrogengasthat
canbeignitedbyelectricalarcingorbysmoking.

SafetyPrecautions
MOVING PARTS CAN CAUSE SEVERE PERSONAL INJURY OR DEATH
•Beforestartingworkonthegenerator,disconnectbatteries,negative(-)cablelast.Thiswillprevent acci-
dentalarcing.
•Keepyourhandsawayfrommovingparts.
•Makesurethatfastenersonthegeneratoraresecure.Tightensupports and clamps,keepguards in position
overfans,drivebelts,etc.
•Donotwearlooseclothingorjewelrywhileworkingongenerators.Looseclothingandjewelrycanbecome
caughtinmovingparts.Jewelrycanshortoutelectricalcontactsandcauseshockorbuming.
•Ifadjustmentmustbemadewhiletheunitisrunning,useextremecautionaroundhotmanifolds,moving
parts, etc.
ELECTRICAL SHOCK CAN CAUSE SEVERE PERSONAL INJURY OR DEATH
•Disconnectstartingbatterybeforeremovingprotectiveshieldsortouchingelectricalequipment.Userubber
insulativematsplacedondrywoodplatformsoverfloorsthataremetalorconcretewhenaroundelectrical
equipment.Donotweardampclothing(particularlywetshoes)orallowskinsurfacestobedampwhen han-
dlingelectricalequipment.
•Useextremecautionwhenworkingonelectricalcomponents.Highvoltagescancauseinjuryordeath.
•Followallstateandlocalelectricalcodes.Haveallelectricalinstallationsperformedbya qualifiedlicensed
electrician.Tagopenswitchestoavoidaccidentalclosure.
•DONOTCONNECTGENERATORDIRECTLYTOANYBUILDINGELECTRICALSYSTEM.Hazardous
voltagescanflowfromthegeneratorsetintotheutilityline.Thiscreatesa potentialforelectrocutionorprop-
ertydamage.Connectonlythroughanapproveddeviceandafterbuildingmainswitchisopen.Consultan
electricianinregardtoemergencypoweruse.
GENERAL SAFETY PRECAUTIONS
•Haveafireextinguisher nearby. Maintainextinguisherproperlyandbecomefamiliarwithits use. Extinguish-
ersratedABCbytheNFPAareappropriateforallapplications.Consultthelocalfiredepartmentforthe
correcttypeofextinguisherforvariousapplications.
•Removeallunnecessarygreaseandoilfrom theunit.Accumulatedgreaseandoilcancauseoverheating
andgeneratordamage,whichpresentsa potentialfirehazard.
•DONOTstoreanythinginthegeneratorcompartmentsuchasoilorgascans,oilyrags,chains,wooden
blocks,portablepropanecylinders,etc.A firecouldresultorthegeneratorsetoperation(cooling,noiseand
vibration)maybeadverselyaffected.Keepthecompartmentfloorcleananddry.
•Donotworkonthisequipmentwhenmentallyorphysically fatigued, orafterconsuminganyalcoholordrug
thatmakestheoperationofequipmentunsafe.
GEN-1
iii

Sectioni. Introduction
GENERAL
Thismanualprovidesinstructionsformounting:
•OnanACPTOgenerator
•Voltageregulatorbox
•Meter/breakerpanel
Onandoesnotprovidetheassociatedcomponents
thatcomprisea completePTOsystem(power take-
offs, in-cabcontroldevices,interlock switches, PTO
transmissions, etc.). Consultthemanufacturer's
instructionsfordetailsonnon-Onanequipment.
TheOperator'sManual(929-0100)thataccompa-
nieseachACPTOgeneratordescribesoperation
andmaintenance.
IAWARNINGI Incorrect Installation, service, or re-
placement ofparts can result In severe personal
injury, death and/or equipment damage. Ser-
vice personnel must be qualified to perform
electrical and mechanical component installa-
tion.
GENERATOR
TheOnanYDseriesACgeneratorsaretwo-bear-
ing, 1800rpm,60hertzunitsdesignedfordirect
drivefroma powertakeoffunitconnectedtoa ve-
hicleengine.
Acentrifugalbloweronthefrontendoftherotor
shaftdrawscoolingairthroughtheendbellcover,
overthegeneratorrotor,anddischargesitthrough
anoutletattheblowerend.
Aballbearingateachendofthegeneratorsupports
therotor shaft. Theendbellandstatorhousingare
attachedbyfourthrough-studswhichpassthrough
thestatorassembly.Thebrushlessexciterstator
mountsintheend bell. Theexciterrotoranditsro-
tatingrectifierassembliesmountontherotorshaft.
VOLTAGE REGULATOR
Thevoltageregulatorassemblyincludesthefollow-
ingcomponents:
•Printedcircuitboard
•Voltagereferencetransformer
•Commutatingreactorassembly
•Fieldcircuitbreaker
Thevoltageregulatorboxismountednearthe gen-
erator.
METER/BREAKER BOX
Themeter/breakerboxcontainsthefollowingcom-
ponents:
•Voltmeter
•Ammeters
•Hourmeter
•Frequencymeter
•Linecircuitbreakers
•Markedoutputterminals
ThegeneratorACoutputisroutedtotheOnanme-
ter/switchboxwhereamperage,voltageandfre-
quencyaredisplayedona meterpanel.Circuit
breakersprotectthegeneratorfromovercurrent
conditions.Themeter/breakerboxismounted
withina 15footradiusofthegenerator:theACload
isattachedhere.
OPERATION
Thegeneratorandvoltageregulatoroperateas fol-
lows:
•Residualmagnetismintherotoranda perma-
nentmagnetembeddedinoneexciterfield
polebeginthevoltagebuildupprocessasthe
generatorstartsrunning.
•Single-phaseAC voltage, takenfromoneofthe
statorwindings,isfedtothevoltageregulator
asa referencevoltageformaintainingthe gen-
eratoroutputvoltage.
•TheACreferencevoltageisconvertedtoDC
bya siliconcontrolledrectifierbridgeonthe
voltageregulatorprintedcircuitboardandfed
intotheexciterfieldwindings.
•Theexciterarmatureproducesthree-phase
ACvoltagethatisconvertedtoDCbytherotat-
ingrectifierassembly.
•TheresultingDCvoltageexcitesthegenerator
rotorwindingtoproducethestatoroutputvolt-
agefortheAC load.
1-1

GENERATOR
DRIVESHAFT
WITHKEY
JUNCTIONBOX
VOLTAGEOUTPUTLEADS
EXTENDOUTOFJUNCTIONBOX
TOVOLTAGEREGULATORBOX,
METER/BREAKERBOX
COOUNGAIRINUET
(ENDOFGENERATOR)
MOUNTINGFOOT
FIGURE 1-1.YDPTO GENERATOR
1-2

NOTE: AMMETERRATINGS
VARYDEPENDINGONMODEL
FREQUENCY
METER-
(45-65HZ)
TWO-POLE
CIRCUIT-
BREAKER
AMMETER AMMETER
so 100 ISO
200
VOLTMETER HOURMETER
so 100150H
/« AMPERES
® 100 150200
250
A* VOLTS 300
J0=
HOURS
loWolololol
e
o
FIGURE 1-2.YDPTO GENERATOR METER/BREAKER BOX(20kW UNIT SHOWN)
1-3

CONDUITCONNECTOR
INCH)
FIELDCIRCUIT
BREAKERCB21
TERMINAL
STRIPTB"
VOLTAGE.
ADJUST
O o
VOLTAGE
REGULATOR
ASSEMBLY
CONDUITCONNECTOR
(1/2INCH)
VIEWWITH
COVERREMOVED
TERMINALSTRIPTB21
(CONNECTIONTO
GENERATOR)
.FIELDCIRCUIT
BREAKERCB21
FIE
FIGURE 1-3.YDPTO GENERATORVOLTAGEREGULATOR BOX
1-4

Section 2. Specifications
Design: Revolving field: 4 pole.Drip-proof
construction.Skewedstatorminimizesfieldheat-
ingandvoltageharmonics.Statorlaminations
weldedinheavysteel frame. Dynamicallybalanced
rotor.Windingsepoxyimpregnatedandover-
coatedforenvironmentalprotectionandimproved
cooling.
Bearings:2,doublesealed,prelubricatedball
Cooling: Direct-drivecentrifugalblower.Single-
openingairoutlet,250f^/m(7.08m3/min),easily
ducted
OutputBox:Topmounted.Housesoutputtermi-
nalsandconduitconnectors.
ExciterSystem:Brushless,with 8-pole stator
mountedinend bell. Rectifierassembliesencapsu-
latedforenvironmentalprotection.Permanent
magnetinstatorfieldprovidesreliablevoltage
buildup.
VoltageRegulator:Componentsincludeprinted
circuitboard,voltagereferencetransformer,com-
mutatingreactor,fieldcircuitbreaker,voltageadjust
rheostat.
InsulationSystem:ClassF,perNEMA MG1 -1.65
definition. Insulatingvarnishconformswith
MIL-l-24092,GradeCB,Class155°C.
Electromagnetic InterferenceAttenuation:
Meetsrequirementsofmostindustrialandcommer-
cialapplications.
Configuration:Platform-mountedorside-
mounted.
2-1

15KW GENERATOR
Voltage/Frequency:120/240VAC <S> 60Hz
Phase:One
Wires: Four
Watts: 15Kw
kVAatPF:15.0@ 1.0powerfactor
Circuitbreakerrating:70amps
Amperemeterrating:0-100amperes
Height:19.55inches
Width: 15.0inches
Length: 21.9inches
Weight:306pounds
Meter/breakerboxdimensions:
10-15/16"x 16-7/16"x 4-1 /2"
20KW GENERATOR
Voltage/Frequency:120/240VAC@ 60Hz
Phase:One
Wires: Four
Watts: 20Kw
kVAatPF:20.0@ 1.0powerfactor
Circuitbreakerrating(amps):85
Amperemeterrating:0-100amperes
Height:19.55inches
Width: 15.0inches
Length: 23.34inches
Weight:356pounds
Meter/breakerboxdimensions:
15" x 16-1/2"x 10"
24KW GENERATOR
Voltage/Frequency:120/240VAC@ 60Hz
Phase:One
Wires: Four
Watts: 24Kw
kVAatPF:24.0 <3> 1.0powerfactor
Circuitbreakerrating(amps):100
Amperemeterrating:0 -150amperes
Height:19.55inches
Width: 15.0inches
Length: 24.59inches
Weight:398pounds
Meter/breakerboxdimensions:
15" x 16-1/2"x 10"
30KW GENERATOR
Voltage/Frequency:120/240VAC@ 60Hz
Phase:One
Wires: Four
Watts: 30Kw
kVAatPF:30.0@ 1.0powerfactor
Circuitbreakerrating:150amps
Amperemeterrating:0 - 200amperes
Height:19.55inches
Width: 15.0inches
Length: 26.21inches
Weight:453pounds
Meter/breakerboxdimensions:
15" x 16-1/2"x 10"
35KW GENERATOR
Voltage/Frequency:120/240VAC@ 60Hz
Phase:One
Wires: Four
Watts: 35Kw
kVAatPF:35.0@ 1.0powerfactor
Circuitbreakerrating:175amps
Amperemeterrating:0 - 200amperes
Height:19.55inches
Width: 15.0inches
Length: 27.97inches
Weight:512pounds
Meter/breakerboxdimensions:
15" x 16-1/2"x 10"
Voltage RegulatorBoxDimensions(allgenerators)
8"x 7.75"x 2.75"
2-2

Section 3.Pre-lnstallation
GENERAL
Thefollowingfactorsshouldbeconsideredbefore
installingthegenerator,voltageregulatorboxand
meter/breakerbox:
•Location
•Adequatecoolingair
•Electricalconnections
•Accessibilityforoperationandservice
•Vibrationisolation
ThePTOsystemmustbe designed, configuredand
installedproperlyfortheOnanYDPTOACgenera-
tortooperatecorrectly.EachPTOinstallationis dif-
ferent,dependingonthemanufacturer'srequire-
ments.PTOoperatingconsiderationsastheyaffect
theOnangeneratoraredescribedlaterinthissec-
tion.
IAWARNINGI Incorrect Installation, service, or
parts replacement can result In severe personal
Injury, death, and/or equipment damage. Ser-
vice personnel must be qualified to Install elec-
trical and mechanical components.
GENERATOR MOUNTING
Generatormountingconsiderationsinclude:
•Generatorsupportarea:Themounting
frameworkmustbeabletosupporttheweight
ofthegenerator.Generatorweightisfoundin
Section2ofthis manual. Thevehiclemanufac-
turerandtheinstallermustprovideastructural-
lysoundsupportarea.
•Generatormountingholeconfiguration:
Themountingareamustbeabletoacceptthe
mountingholearrangementfoundonthe gen-
erator.Generatormountingholesareillus-
tratedinSection7 ofthismanual.
•Generatorventilation:Themountingarea
musthavesufficientventilationforthegenera-
tor'scoolingrequirements.Anareawith mini-
maldustanddirtispreferable.Generatorair
requirementsarelistedinSection2 ofthis
manual.
NOTE: Avoidrecirculationofventilationair.
Configurethegeneratorventilationsothatonly
freshairiscirculatedthroughthegenerator.
•Protectionfromexhaustheat:Thegenerator
mustbeprotectedfromexcessheat:forthis
reason, itshouldnotbemountedclosetothe
vehiclemufflerorexhaustareaunlessitisab-
solutelynecessary.Usea heatshieldifthe
mufflerandgeneratoraretobemountedclose
together.
•Generatormountinghardware:Alongwitha
mountingframeworkforthegenerator,hard-
wareforconnectingthegeneratortothePTO
outputshouldbeconsidered.Components
thatmustbeselectedtypicallyinclude:
•A keyedcouplertoconnectthegenerator
shafttothePTOoutput
• U-joints forthePTO-generatorcoupling
•A slidingcouplerelementtopreventthrust
loadonthefrontbearingofthegenerator
•A shear-limitingcouplertopreventdam-
agetothetransmissionorgeneratordue
toa seizedbearingorhighstartingtorque
METER/BREAKER BOX MOUNTING
Meter/breakerenclosuremountingconsiderations
include:
•Meter/breakerboxmountingholeconfigu-
ration: Themountingareamustbeabletoac-
ceptthemountingholearrangementfoundon
thecontrolbox.Section5 ofthismanualde-
scribesmeter/breakerboxmounting.
•Meter/breakerboxvibrationmounting:
Rubber/plasticvibrationmountsshouldbe
usedbetweentheboxandthemountingframe-
work.Theboxmustbeprotectedfrompoten-
tiallyharmfulvibration.
•Meter/breakerboxprotection:Thebox
shouldbemountedinanareathatisprotected
fromtheelements: rain, dust,etc.canharm
electricalcomponents.
Figure 3-1 showsatypicalmeter/breakerboxinstal-
lation.
3-1

BOXMOUNTEDIN
COMPARTMENT
BELOWCABOF
TRUCK
PTOSYSTEM CONFIGURATION
Theinstallationandoperationofa vehicle-mounted
PTOsystemareoutsidethescopeofthismanual.
However,anyPTOsystemmustbeconfigured
bearingtheseconsiderationsinmind:
Control System
Thecontrolsystemcanhaveasmanyorasfewau-
tomatedelementsasisnecessary.Controlsmay
bemountedinsideoroutsidethevehiclecab,inany
location. Figure3-2illustratessometypicalcontrol
mountinglocations.
FIGURE 3-1. METER/BREAKER BOX MOUNTING
3-2

TYPICAL IN-CAB PTO CONTROL
PTO ON-OFF SWITCH
FIGURE 3-2. EXAMPLES OFPTO CONTROL PANELS
Interlocks
ThePTOcontrolsystemshouldhaveinterlocksto
keepthePTOfrombeingengagedunderthefollow-
ingcircumstances:
•Whenthevehicleismoving(emergencybrake
interlock)
•Whenthevehicleisingear(transmission neu-
tralinterlock)
•Iftheenginespeedishigher than thespeedre-
quiredtorunthegenerator(enginegovernor
interlock)
Otherinteriocksmaybenecessarydependingon
theapplicationandthecontrolsystemselected.
ConsultthePTOandcontrolsystems'manualsfor
guidelines.Figure3-3isa blockdiagramofa typical
PTO/generatorsystem,showinghowtheOnan
componentsfitintoa standardconfiguration.
3-3

CO
I
n
Q
c
30
m
w
m
I
3D
9
OD
r
§
§
>
Vehicle
Propulsion
Engine
PTO Shift
Solenoid
Vehicle
Transmission
PTO
Onan YD PTO
AC Generator
Fuel Injection
Pump
Onan Control/
Breaker Panel
VehiclePropulsion
EngineGovernor
1
I
AC Power
Distribution Panel
PTOController Transmission
Control
VehicleTransmission
NeutralInterlock
AC Load
PTOOn/OffSwitch
VehicleParking
BrakeInterlock

Section 4.Generator Mounting
GENERATOR SUPPORT FRAMEWORK
Thegeneratormustbemountedona framework
thatiscapableofsupportingitsweight.Generator
weightsarelistedinSection2 ofthismanual.
Normallya frameworkisconstructedunderneath
thevehiclechassis,locatedinlinewiththePTO
transmission..SeeFigure4-1.A tubularsteel
frameworkcradlesthePTOgeneratorfromthe
mainframerailattherighthandsideofthevehicle.
Thegeneratorcoolingairoutletpointsdownwardin
thisexample:however,ona differentinstallation,
theoutletmightpointtowardtheside.
Point§toconsiderwhenconstructingsucha frame-
workinclude:
•Clearance:Allowasmuchclearanceaspos-
siblebetweenthegeneratorframeworkand
theroad,especiallyiftraveloverroughsur-
facesorgrassandbrushislikely.
•Framesupport:Theframesupportmustbe
reinforcedtoavoidsystemresonancesat gen-
eratormnningspeed(andmultiplesofrunning
speed).
•Framealignment:Alignmentiscriticalto gen-
eratoroperation.Sideloadsduetomisalign-
mentcouldprovidea sourceforsystemreso-
nanceatmultiplesofrunningspeed.
SeeSection7 ofthismanualforanoutlinedrawing
ofthegeneratorshowingitsmounting holes, dimen-
sions, andairinletandoutletlocations.
GENERATORVENTILATION
OUTLETPOINTSDOWNWARD
GENERATORMOUNTINGBOLTS
PASSTHROUGHUNDERSIDEOF
FRAMEWORKSUSPENDEDFROM
VEHICLECHASSIS
FIGURE 4-1. YDGENERATORONMOUNTINGFRAMEWORKUNDERNEATHVEHICLECHASSIS
4-1

CONNECTING THEPTO
Astandardkeyedcouplingshouldbeusedto con-
nectthegeneratordriveshaftwiththePTOoutput
shaft.InFigure 4-1, thedriveshaftyokeiscoupled
tothegenerator'sstraightshaftwithafour-boltsteel
flangecouplingkeyedtotheshaft.Figure4-2
showsthegeneratorshaftandkey.A fulloutline
drawingofthegeneratorisfoundinSection7 ofthis
manual.
PointstoconsiderwhenconnectingthePTOAC
generatortothedrivingsource:
•Generatorinertia load: Notethattheentire
drivetrainincludingthegeneratorshaftmust
bedesignedtoabsorbthestartingtorquedue
totheinertiaofthegeneratorrotor.A torsional
drawingshowingtheinertia,weight,stiffness
andlengthofeachpartofthegeneratorrotoris
includedinSection7 ofthismanual.
Generatordriveshafttakeupsection:Note
thatthedriveshaftshouldhavea sliderbar,
splinedtake-upsectionorothervariable-
lengthcoupling,totakeupslightdriveshaft
lengthvariances,andtopreventthrustloadon
thefrontbearing.
Generatordriveshaftshearlimiter:A shear
limitingdevicemaybeneededinthecoupling
topreventdamagetothetransmissionor gen-
eratorduetoa seizedbearingorhighstarting
torque.
Driveshaftalignment:Sideloadsduetomis-
alignmentcouldprovidea sourceforrunning
speed vibration. AlignmentiscriticalontheYD
PTOgenerator.
KEY
DIMENSIONS:
50x .50x 2.00
INCHES
DIAMETER:
1.875^
INCHES
_ aift. rin J
ri
I1
T
nT
i
i
i
i
i
i
i
i
i
i
i
i
i
i
i
i
i
l_L|-___
1
-(+:
—X
FIGURE 4-2. DETAIL OF GENERATOR SHAFT AND MOUNTING KEY
4-2

Section 5.Meter/BreakerBox,
VoltageRegulatorBox Mounting
GENERAL
Mountingthevoltageregulatorboxandtheoptional
meter/breakerboxsuppliedwiththeOnanYDPTO
ACgenerator is a relativelyuncomplicatedprocess.
Theboxesareboltedtoaconvenientsurfacewhich
is:
•Protectedfromtheelements
•Convenienttotheelectricalloadorloadpanel
•Within15feetofthegenerator(thelengthofthe
generatorleads)
SeeSection3 ofthismanual(Pre-lnstallation)for
factorsregardingtheselectionofthelocationforthe
meter/breakerbox.
Mountingthetwoboxessimplyinvolves:
•Selectingthemountingarea
•Measuringthemountingarea
•Drillingthemountingholes
•Installingboltsandnutstoholdtheboxinplace
SeeSection7 ofthismanualfordrawingsofthe
voltageregulatorboxandofthetwosizesofmeter/
breakerbox,withdimensionsandthelocationsof
theirmountingholes.
PTOCONTROLCIRCUITSMOUNTED
NEXTTOMETER/BREAKERBOX ONANMETER/BREAKERBOXMOUNTEDINSIDE
LARGERENCLOSUREFABRICATEDBYINSTALLER
illlllllll
•:5:5^
iliiiiP
•ss^jWffi'iTW:1:^ VOLTAGEREGULATORBOXMOUNTEDATBOTTOM
OFENCLOSUREFABRICATEDBYINSTALLER
FIGURE 5-1. ONANMETER/BREAKERPANELMOUNTING
5-1

Section 6. System Wiring
SYSTEMCONNECTIONS
TheYDPTOACgenerator,voltageregulatorbox
andmeter/breakerboxaresimplyinterconnected:
fourwiresextendfromthesmallconduitboxontop
ofthegeneratortothemeter/breakerbox,andfour
wiresextendfromthegeneratortothevoltageregu-
latorbox.
IAWARNINGI Incorrect Installation, service or re-
placement ofparts can result In severe personal
Injury, death and/or equipment damage. Ser-
vice personnel must be qualified to perform
electrical and/or mechanical component instal-
lation.
Oncethegenerator,voltageregulatorboxand con-
trol/meterboxaremounted,performthefollowing
steps:
1. Cutandfit watertightconduitbetweenthe gen-
eratorandthevoltageregulator,andbetween
thegeneratorandthemeter/breaker box. Con-
duitconnectorsizes:
Generator T1, T2,T3,T4:1-1/4"
Generatorvoltagereg.leads:1/2"
Voltageregulatorbox:1/2"
15KWmeter/breakerbox:1/2",3/4", 1-1/2" (2
each)
20, 24,30,35KWmeter/breakerbox:1/2",1",
1-1/4" (2each)
2. Passtheleadsfromthesmallconduitopening
onthegeneratorthroughtheconduittothevolt-
ageregulatorbox.
3.Passtheleadsfromthelargeconduitopening
onthegeneratorthroughtheconduitleadingto
themeter/breakerpanel.
4. (20,24,30,35KWmeterbreaker boxes): Pass
the T1, T2,T3,T4leadsthroughcurrenttrans-
formers CT1 andCT2asshowninFigure6-2or
Figure6-3.
5.Connecttheleadsinsidethevoltageregulator
boxandthemeter/breakerboxaccordingtothe
appropriatediagramfoundinthismanualsec-
tion:
•15KWgeneratorwiring:Figure6-1
•20,24KWgeneratorwiring:Figure6-2
•30,35KWgeneratorwiring:Figure6-3
Wiringdiagramsforthemeter/breaker panels, gen-
erator,andvoltageregulatorarefoundinSection7
ofthismanual.
6-1

ro
3
O
c
m
cn
i
m
I
30
3D
Z
O
GENERATOR
ro—
lloo
TB21-1 LEAD, TB21-2LEAD,—
FlLEAD,F2LEAD:CONNECT
TOMARKEDTERMINALS ON TB21
VOLTAGE
fia^ REGULATOR
o
on
T2, T3LEADS:CONNECT
TO TERMINAL AT BOTTOMOFBOX
@
O
CONNECTLOADAT
081BREAKERCB1
T1LEAD:CONNECTT4LEAD:CONNECT
TO M1 TERMINALTO M2 TERMINAL
METER/BREAKER
BOX

cn
63
n
O
c
3]
m
<?>
ro
ro
p
O
m
z
m
1
JO
3
z
o
GENERATOR
IF PI
fl
TB21-1 LEAD, TB21-2LEAD,-
FlLEAD,F2LEAD:CONNECT
TOMARKEDTERMINALS ON TB21
T2 LEAD, T3LEAD:
CONNECT TO LO TERMINAL
CONNECTLOADAT
L1,L2TERMINALS
ONLOADBLOCK
METER/BREAKER
BOX
T1LEAD: PASS THROUGH CT1, T4LEAD:PASSTHROUGHCT2,
CONNECT TO BREAKER CB1 CONNECT TO BREAKERCB1
