Ono Sokki HT-5200 User manual

HT-5200
Handheld Tachometer
Instruction Manual
ONOSOKKI
ONO SOKKI CO., LTD.

1. Thisdocumentmaynotbereproduced,inwholeorpart,inanyfromorby
anymeanswithoutthepriorwrittenpermissionofthepublisher.
2. Thecontentsofthisdocumentaresubjecttochangewithoutnotice.
3. Thisdocumenthasbeenproducedbasedonaseriesofstrictverifications
andinspections.Shouldafailureoccurnonetheless,pleaseinformour
salesrepresentativeorsalesoffice.
4. OnoSokkishallhavenoliabilityforanyeffectresultingfromanyopera-
tion,whetherornottheeffectisattributabletoadefectinthedocumenta-
tion.
CopyrightcONOSOKKICO.,Ltd.2004Allrightsreserved.

1
PrecautionstoObserveBeforeUsingtheHT-5200
・ Besuretoreadthisinstructionmanual.
ToensurethatyougetthemostoutoftheHT-5200,andoper-
ateitsafely,besuretoreadthisinstructionmanual.
・ Avoidsuddenchangesintemperature.
AvoidbringingtheHT-5200suddenlyfromahotlocationinto
acoolone,orviceversa,asthiscancauseinternalcondensa-
tionwhichcanleadtofailures.
・ Takecarethatwateranddustarenotallowedtoenter
theinsideoftheHT-5200.
AvoidusingtheHT-5200inlocationsthatwouldsubjectitto
excessivedust,water,andhighhumidity.
・ DonotdroptheHT-5200orotherwisesubjectitto
shock.
TheHT-5200containsprecisionelectronicscomponents.Do
notdropit,andavoidsubjectionittosevereshock.
・ Takecarethatthelensofthelightprojector-receiver
isnotdamaged.
Damagetothislenswillcausealossofperformance.
・ WipedirtfromtheHT-5200usingeitheradryclothor
onemoistenedjustslightly(wetandwrungoutwell)
withaneutraldetergent.
Neverwipedirtoffusingthinners,benzene,orothervolatile
liquidsoralcohol.
・ IftheHT-5200istobeleftunusedforalongtime,re-
moveitsbatteries.
Removebatteriestopreventdamagefromfluidleakingfrom
wornbatteries.
・ Donotapplyanyvoltagestothepluseoutputcon-
nector.
・ NeveruseanyACadaptorotherthanthePB-703(op-
tion).

2
WARNING
SAFETYPRECAUTIONS
・ WhenusinganACadaptorortheAX-1200pulseoutputcable,
takecarethatthecabledoesnotbecometangledaroundthe
rotatingbody,asthiscanbeextremelydangerous.
・ Whenusingacontactadaptortightenthemountingscrewse-
curelybyhandtoholditsecurelytotheHT-5200.
・ Whenusingacontactadaptortomakerpmmeasurements,be
extremelycarefulwithsafetyprecautions.
Particularcareisrequiredinmakingmeasurementsover10,000
r/min.Whenusingthecircumferentialringtomeasuretan-
gentialspeed,takecarewithmeasurementsathighspeed.(For
details,refertopage29.)
・ Thecontacttipandcircumferentialringareexpendableitems
thatwear.Measurementwithacontacttiporcircumferential
ringwhichhasbecomedeformedorhascrackedisextremely
dangerous.Replacesuchitemswithnewones.
・ Itisdangeroustouseacrackedcontactadaptor.Replacesuch
anitemwithanewone.

3
TableofContents
GENERALPRECAUTIONS
1. INTRODUCTION............................................... 5
1.1 Features .................................................................. 5
1.2 Configuration .......................................................... 6
1.3 Options(SeparatelySold)....................................... 6
2. NAMESANDFUNCTIONSOFPARTS ............ 7
3. POWERSUPPLY ........................................... 12
4. RELATIONSHIPOFMEASUREMENTMODES
TOSWITCHSETTINGSANDUNITS ............ 13
5. MEASUREMENTPREPARATION.................. 15
5.1 Non-ContactMeasurements................................ 15
5.2 ContactMeasurements ........................................ 16
6. MEASUREMENTMETHODS ......................... 17
7. OPERATIONGUIDE....................................... 22
8. OTHERFUNCTIONS...................................... 23
8.1 PulseOutput ......................................................... 23
8.2 MemoryRecall ...................................................... 24
8.3 AlarmFunctionSetting ......................................... 24
9. OPERATINGPRECAUTIONS ........................ 26
9.1 Non-ContactMeasurements................................ 26
9.2 MeasurementsUsingaContactAdaptor ............ 29
WARNING.............................................................. 29
10. OVERRANGEDISPLAY ................................. 31

4
11. TROUBLESHOOTING .................................... 32
12. SPECIFICATIONS .......................................... 34
12.1 MeasurementSection........................................... 34
12.2 DetectionSection ................................................. 36
12.3 PulseOutput ......................................................... 37
12.4 StorageTime......................................................... 38
12.5 CalculationMethod .............................................. 38
12.6 GeneralSpecifications ......................................... 38
13. OUTERDIMENSIONS .................................... 39
14. STORAGEMETHOD ...................................... 39
15. WARRANTY ................................................... 40
16. OMISSIONOFTEST
QUALIFICATIONISSUANCE............................. 40

5
1. INTRODUCTION
TheHT-5200isavisible-lighttypenon-contacthand-heldtachom-
eterwhichmeasuresrpmbymeansofareflectivemarkonthe
rotatingbody.
TheadvancedHT-5200featuresafullcomplimentoffunctions
inasinglecompactunit,includinganaccessorycontactadaptor
thatenablescontact-typemeasurementsaswell.
1.1 Features
・ Autorangingmeasurements(non-contactmode)fromaslow
as6r/mintoashighas99999r/min.
・ Selectablemeasurementunits:r/min,r/s,m/min.,count,ms.
・ Direct-readingmeasurementoftangentialspeed.
・ MAXandMINmodesdisplaymaximumandminimumval-
ues(exceptforcountmode).
・ Amemoryrecallfunctionenableseasyverificationofmea-
surementresults.
・ Analarmfunctioncanbeusedtosoundabeeperwhenthe
measuredvalueexceedsasetvalue.
・ Pulseoutputaccordingtotherpmvalue.
・ Anaccessorycontactadaptor(HT-0501)enablesuseasacon-
tact-typetachometer.
・ Tripodmountingispossible(non-contactmeasurementsonly).
・ OperatesontypeAAbatteriesoranACadaptor.
・ Backlitfunctionconvenientforeasyreadingindarklocation.

6
1.2 Configuration
① HT-5200Tachometer ⑥Screwdriver
② HT-0501ContactAdaptor ⑦TypeAAManganese
Batteries(3)
③ KS-300ContactTip ⑧InstructionManual
(thisdocument)
④ KS-200CircumferentialRing⑨CarryingCase
⑤ ReflectiveMarks
1.3 Options(SeparatelySold)
AX-1200 PulseOutputCable
PB-703 ACAdaptor
HT-011 ReflectiveMarks(10sheets,with250marksmea-
suring12mm× 12mm)
KS-100 CircumferentialRing(mm/s)
①HT-5200
Tachometer ②HT-0501 ContactAdaptor ③KS-300 Contact Tip ④KS-200 Circumferential
Ring
⑤Reflective
Marks
⑥Screwdriver ⑦Manganese Batteries
(TypeAA) ⑧Instruction Manual ⑨Carrying Case

7
2. NAMESANDFUNCTIONSOFPARTS
ThenamesandfunctionsofHT-5200partsarekeyedtothecircled
numbersinthefigurebelow.
ON
HOLD
HT-5200
DIGITAL TACHOMETER
IND
UNITMODERECALL
MAX MIN H BATT
OVER
COUNT
PERIOD
m/min r/s
ms
r/min
MAX MIN H
BATT
OVER
COUNT
PERIOD
m/min r/s
ms
r/min
ONOSOKKI
LIGHT
ON OFF
5
4
3
2
1
0
9
8
7
6
5
4
3
2
1
0
9
8
7
6
5
4
3
2
1
0
9
8
7
6
DC INOUT
PULSE OUT PULSE
e
r
w
8
3
2
1
456
q09
u
t
io
s
d
f
pa
h
j
g
7
y
To access t and y, open w.

8
① Powerswitch（refertopage22）
ByslidingthisswitchtotheONposition,powerisappliedtothe
HT-5200.Whenyoureleaseyourfinger,powerisswitchedoff.If
youslidetheswitchtotheHOLDposition,itwilllockintheon
conditionevenwhenyouremoveyourfinger.
② Display
Thisdisplayprovidesadirectreadingofthemeasuredvaluesin
allmodes.
③ Detectionsection
Thislightprojector-receiverisusedindetectedlightreflectedfrom
thereflectedmark（i.e.,therpmsignal.）
④ UNITswitch（refertopage20through22）
Eachtimethisswitchispressed,themeasurementunitchangesin
thesequencer/min→r/s→m/min→count→period(ms).
⑤ MODEswitch（refertopage22）
ThisswitchispressedtoswitchbetweentheMAXandMINmodes
inthesequence（NORMAL）→MAX→MIN（intheNOR-
MALmodethereisnodisplay）.
r/min r/s m/min COUNT
PERIOD ms
MIN
r/min
MAX
r/minr/min

9
⑥ RECALLswitch（refertopage24）
Whenthepowerisoff,thisswitchcanbepressedtorecallamea-
suredvaluestoredinmemorytothedisplay.Whenpowerison,
thisswitchactsasaresetswitchforthemaximumvalue,mini-
mumvalue,andaccumulatedcountvalue.
⑦ Indicator（inputsignalindicatorlamp）
ThisLEDlampflasheswhenthedetectionsectionisdetecting
thereflectedlightfromthereflectivemark.
⑧ Backlightingswitch
WhenthisswitchisslidintotheONposition,thedisplayback-
lightingisturnedon.
⑨ PULSEOUTconnector（refertopage23）
ThisconnectorprovidesapulseoutputsignalfortheCF-1200
Analyzerorotherexternaldevice.UsetheAX-1200cable(op-
tion)tomakeconnectiontothisconnector.
⑩ PULSEOUTswitch（refertopage23）
Thisswitchisusedtoselecteitherpositivelogicornegativelogic
ofthepulseoutputsignal.
⑪ DCINjack
ThisistheDCinputjackforconnectiontoaPB-703ACAdaptor.
⑫ Batterycover
⑬ Threadedtripodmountinghole
ThisthreadedholeisusedtotripodmounttheHT-5200.Itisalso
usedtomountthecontactadaptor,andsobothtripodmounting
andthecontactadaptorcannotbeusedatthesametime.
⑭ Contactadaptorpinguidehole
WhenthecontactadaptorismountedtotheHT-5200,theprotru-
sionofthecontactadaptorentersthishole,theHT-5200sensesit
andswitchestothecontact-typemeasurementmode.

10
⑮ Alarmon/offswitch（refertopage24）
Thisswitchislocatedatthebottomofthebatterycompartment
andisaccessedbyremovingthebatterycover.Ifitisslidtothe
ON(forward)position,the(((・)))markwillappearonthedis-
play,andifthemeasuredvalueexceedsthesetvalueabeeper
willsoundandHwillappearonthedisplay.
⑯ Presetswitches
Theseswitchesarealsolocatedatthebottomofthebatterycom-
partment.
Thesethreeswitcheshavethefollowingtwofunctions.
Alarmfunction(refertopage24)
Tangentialspeeddirectreadingfunction(refertopage17)
(onlyfornon-contactmeasurement)
⑰ OVERindicator
Thisindicatorappearsinthedisplaywhenthemeasuredvalue
exceedsthemeasurementrange.
⑱ Modeindicators（refertopages13and20-21）
MAX ：Maximumvalueisheld.
MIN ：Minimumvalueisheld.
⑲ Alarmsettingindicator
This(((・)))indicatorappearsinthedisplaywhenthealarmset-
tingison.
⑳ Hindicator
Thisindicatorappearsinthedisplaywhenthemeasuredrpmvalue
exceedsthesetalarmlimit.Ifthemeasuredvalueexceedsthe
measurementrange,itwillappeartogetherwiththeOVERindi-
cator.
aBATTindicator
Thismarkwarnsthatitistimetoreplacethebatteries,andap-
pearswhenthebatteryvoltagedropsbelowapproximately3.3V.
Whenthismarkappears,replacethebatteriesassoonaspossible.

11
sMeasurementunitindicators（refertopage13and22）
dCOUNTindicator（refertopages19and22）
ThisindicatorappearswhentheHT-5200isintheaccumulated
countmode.
fPERIODindicator（refertopages19and22）
Thisindicatorappearstogetherwiththemsindicatorwhen
theHT-5200ismeasuringperiod.
gHT-0501ContactAdaptor（refertopages16and22）
ThisadaptorismountedtotheHT-5200andusedtoconvertthe
HT-5200toacontact-typetachometer.
hMountingscrew
UsedtomountthecontactadaptortotheHT-5200.
jProtrusion
ProvidedtoenabletheHT-5200tosensethepresenceofthecon-
tactadaptorandswitchtocontact-typemeasurement.

12
3. POWERSUPPLY
・ TheHT-5200operateson3typeAAbatteriesoraPB-703AC
Adaptor(option).
・ IfthebatteriesweardownandtheBATTwarningindicator
appearsinthedisplay,replacethebatteries.
Whenreplacingbatteries,besuretoalwaysreplaceall3atthe
sametime.
BatteryReplacementMethod
① Liftupthebatterycoverwhilepushingthebuttonofthebat-
terycovertoremovethecover.
② Insertnewbatteries,takingcaretoobserveproper(＋)and(
−)polarities(seefigurebelow).
③ Closethebatterycover.
Battery (+)
and (
- ) marks

13
4. RELATIONSHIPOFMEASUREMENT
MODESTOSWITCHSETTINGSANDUNITS
(Displayunitsandsymbols)
[UNIT Switch]
[MODE
Switch]RPM
r/min
r/s
Tangen.
speed Period Accum. count
m/min Period,
ms Count
r/min
r/s m/min Period,
ms
---
r/min
r/s m/min Period,
ms
---
MAX display
MIN display
NORMAL
MAX
value
MIN
value
Non-Contact
measurement
(HT-5100 only)

14
NOTE: mm/smeasurementisperformedbymountingthe
KS-100CircumferentialRing(separatelysold)anddis-
playingr/minmeasurementunits.Theunitmm/
sdoesnotappearonthedisplay.
[UNIT Switch]
[MODE
Switch]
RPM
r/min
r/s
Tangen.
speed Period Accum. count
m/min
(mm/s)
m/min
(mm/s)
m/min
(mm/s)
Period,
ms Count
r/min
r/s
Period,
ms
---
r/min
r/s
Period,
ms
---
MAX display
MIN display
NORMAL
MAX
value
MIN
value
Contact
measurement
(HT-5100
+ contact
adaptor)
（Displayunitsandsymbols）

15
5. MEASUREMENTPREPARATION
5.1 Non-ContactMeasurements
① WhenusingtheHT-5200forthefirsttime,installbatteries.
(Thisappliestocontacttypemeasurementsaswell.)
② Applyareflectivemarktotherotatingbodytobemeasured.
(RefertoSection9:PrecautionsforNon-ContactMeasure-
mentsfordetailsonapplyingthereflectivemark.)
A) Cleananyoil,water,anddustoffofthesurfacetowhich
thereflectivemarkistobeapplied,andapplythemarkto
aflatpartofthesurface.
B) Ifthesurfacetowhichthemarkisappliedisshiny(e.g.,a
platedsurface),eithermakemeasurementsatananglere-
movedfromtheperpendiculartothissurface,orpaintthe
surfaceblackbeforeapplyingthereflectivemark.
③ Pressthepowerswitchandshinethelightfromthelightpro-
jector-receiver(detectionsection)ontothemark,verifyingthat
theinputsignalindicatorlampflashes.(Athighrpm,thelamp
willappeartobelightedcontinuously.)
A) Toensureproperdata,makeeachmeasurementforatleast
3seconds.
B) Maintainaproperdistancebetweenthereflectivemarkand
thedetectionsectionoftheHT-5200.(RefertoSection9:
PrecautionsforNon-ContactMeasurementsfordetailson
themeasurementdistance.)
Rotating body
Reflective mark

16
5.2 ContactMeasurements
① AlignthecontactadaptorwiththedetectorsectionoftheHT-
5200,sothattheprotrusionontheadaptorfitsintotheguide
holeoftheHT-5200,andtightenthescrewoftheadaptorse-
curelyintothethreadedtripodmountingholeoftheHT-5200.
(Theprotrusionoftheadaptorissensedintheguideholeto
automaticallyswitchtheHT-5200fromnon-contactmeasure-
menttocontactmeasurement.)
② TurnthepoweroftheHT-5200on,androtatethedetection
shafttoverifythatthedisplaycomeson.
③ MounttheKS-300ContactTip,andusetheUNITswitchto
selectthemeasurementunits(r/min,r/s,orms).
④ Pressthecontacttipupagainsttherotatingshafttobemea-
suredsothatthereisnoslippagebetweenitandtheholeinthe
centeroftheshaftend.Whendoingthis,
holdtheHT-5200so
thatitsaxisisparallelwiththatoftheshaftbeingmeasured.
A) DonotattempttousetheHT-5200withshaftsnothaving
acountersunkdepressionattheend.
B) Measurementerrormayoccur,dependinguponthemate-
rialoftherotatingbodyandthemannerinwhichthecon-
tactadaptormakescontactwithit.
90˚
90˚ centercountersunk
Rotating shaft
Shaft center
Minimize up/down
& left/right movement.

17
6. MEASUREMENTMETHODS
Measured
Item
RPM
Tangential
speed
◆Non-contact
method
Switch
Setting
UNIT
UNIT
Display/
Units
r/min
or
r/s
m/min
Description
①Measurestherpmofaro-
tatingbody.
②Therpmdisplayisupdated
every1s.
① Thesettingdescribedbe-
lowenablesdirectreading
oftangentialspeed.
② Settingmethod
A) Setthediameterofthero-
tatingbodyonthepreset
switcheslocatedunderthe
batteries.
B) Thesettingcanbemadein
therange1to999mm,in
1-mmsteps.
C) Theweightsofthepreset
switchesare(fromtheleft)
100,10,and1mm.

18
Measured
Item
Tangential
speed
◆Contact
method
Usingthe
KS-200
Switch
Setting
UNIT
Display/
Units
m/min
Description
①MounttheKS-200Circum-
ferentialRingtothedetec-
tionshaft,beingsurethat
thepinoftheshaftfitsinto
theslotofthering.
② Asshowninthefigure,
pressthecircumferential
ringupagainsttheobject
undermeasurementper-
pendicularlyfromthedis-
playside.
Asasafetymeasure,be
suretoholdtheHT-5200
withbothhands.
Contact tip
end angle
