Ono Sokki SE-2400 User manual

DIGITALENGINETACHOMETER
SE-2400
INSTRUCTIONMANUAL
ThankyouforyourselectionoftheSE-2400DigitalEn-
gineTachometer.Toensurethatyougetmostoutofthe
instrument,westronglyrecommendyoureadfollowthe
instructioninthismanualcarefully.
① Detectionhead
Thispartdetectstherotationalsignal（leakageofmag-
neticflux）whenplacedclosetotheignitioncoilofan
engine.
② Powerswitch
ByslidingthisswitchtotheONposition,powerisap-
pliedtotheSE-2400.Whenyoureleaseyourfinger,power
isswitchedoff.IfyouslidetheswitchtotheHOLDposi-
tion,itwilllockintheonconditionevenwhenyoure-
moveyourfinger.
③ Indicator
Thisblinkswhenthesensorcircuitdetectstherotation
signal（leakageofmagneticflux）.
④ Sensitivityadjustmentvolume
Volumeforadjustingthesignallevel.
⑤ UNITswitch
Eachtimethisswitchispressed,themeasurementunit
changesfromr/stor/minorviceversa.
⑥ CYLINDERselectionswitch
Thenumberofcylindercanbeselectedwhenthefunc-
tionselectionswitch⑨isontheSETposition.
⑦ RECALLswitch
Whenthepowerisoff,thisswitchcanbepressedtore-
callthelatestmeasuredvaluestoredinmemorytothe
display.Whenpowerison,thisswitchclearshestored
value.
⑧ Externalpowerinputterminal
ThisterminalisfortheoptionalACadaptorinput.
⑨ Functionselectionswitch
WhenthefunctionselectionswitchisontheSETposi-
tion,thenumberofcylindercanbeselectedbyusingthe
CYLINDERselectionswitch,whilewhenthefunction
selectionswitchisontheMEASposition,therpm/rpsof
anenginecanbemeasured.
⑩ Externalsensorinputterminal
ThisistheinputterminalfortheIP-2800（accessory）
ortheVP-201（option）externalsensor.
⑪ Backlightingswitch
WhenthisswitchisslidintotheONposition,thedisplay
backlightingisturnedon.
⑫ Batterycover
⑬ Lowbatteryindicator
Whenthebatterieshavebeendischargedandbecomeless
than3.3V, markwillbeindicated.
⑭ Measurementunitdisplay
Themeasurementunitwillbedisplayedasr/minorr/s.
TheunitwillbechangedwiththeUNITswitch.
⑮OVERindicator
OVERindicatorappearsonthedisplaywhentherota-
tionalspeedexceeds20000r/minor333.33r/s.
⑯ Thenumberofcylindersdisplay
Thenumberofcylindersfor2-cycleengineswillbedis-
playedontheleftsideofthedisplay,andthatfor4-cycle
engineswillbedisplayedontherightside.
1.OUTLINE
TheSE-2400hand-heldenginetachometerhasitsoneunit
constructioncontainingthedetector,thecounterandthedis-
playsrotationalspeedofagasolineenginein1r/minor0.01
r/sunitssimplybymakingitclosetotheignitioncoilofa
gasolineengine.
2.FEATURES
・Non-contactingdetectionenablesaneasyandsafe
measurement.
・Accuraterotationalspeedcanbeobtainedin1r/minor
0.01r/sunit.
・Theaccessoryexternalsensor(IP-2800)makesit
possibletomeasurefromadistance.
・Withthebacklightingfunction,adisplaycanbeassured
eveninadarkplace.
・Witharecallfunction,thelatestmeasurementresultcan
bedisplayedwhenthepowerisswitchedoff.
・Byusingtheoptionalexternalsensor(VP-201),the
numberofrotationsofdiesel-enginescanbemeasured.
・2-waypoweredoperation-typeAAbatteriesorthe
optionalACadaptor(PB-703).
3.STANDARDACCESSARIES
Yourpackageshouldcontainthefollowingmaterials.Please
makesurethatyouhavereceivedalltheseitemsuponun-
packing.
① DigitalEngineTachometerSE-2400....................... 1
② ExternalSensorIP-2800..........................................1
③ SizeAABatteries ....................................................3
④ CarringCase ............................................................1
⑤ InstructionManual................................................... 1
GENERALDESCRIPTION
 CAUTION
● Careshouldbetakennottotouchtherotating
partsoftheenginewhenmakingmeasurements.
Whenusingtheoptionalexternalsensorandtheoptional
ACadaptor,specialcareisrequiredforthecordnottobe
caughtintherotatingpartsoftheengine.
● Careshouldbetakennottotouchtheheatedparts
oftheenginewhenmakingmeasurements.
 CAUTION
● DonotbringtheSE-2400incontactwithheated
parts(suchasexhaustpipes)oftheengine,as
thismaycausedamagesbecauseitisnot
heatproof.
● DonotbringtheSE-2400incontactwithan
ignitioncoil,asthismaycausemalfunctionsor
damages.
● Measurementisnotpossibleonengineswithmore
thanoneignitioncoil.
● Theenginewithafaultinignitionsystems(such
asadistributor,ahigh-tensioncodeandignition
plug)cannotbecorrectlymeasured.
● Donotapplyvoltagetotheexternalsensorinput
terminaloftheSE-2400.
● DonotuseanyotherACadaptorsbuttheoptinal
PB-703.
Otheradaptorsmaycausemalfunctionsordamages.
● DonotusetheSE-2400atalocationsubjected
tosuddentemperaturechanges.
DonothastilymovetheSE-2400fromhightemperature
tolowtemperatureenvironmentsorviceversatopre-
ventinternalcondensationwhichmaycauseanequip-
mentfailure.
● Becarefulnottoallowwaterordusttointrude
insidethecabinet.
DonotusetheSE-2400atalocationwhereitmaybe
exposedtosplashingwater,excesivemoistureordust.
CAUTION
● DonotdroporgivestrongshockstotheSE-2400.
Itcontainsprecisionelectroniccomponentswhichcan
bedamagedbydroppingorstrongshocks.
● Iftheoutercasebecomessoiled,wipeitoffwith
adrysoftclothorwithaclothslightlydampened
withaneutraldetergent.
Avoidvolatileorganicsolventssuchasthiners,
benzineandalchol.
GENERALOPERATINGPRECAUTIONS
CopyrightcONOSOKKICO.,LTD.
2002Allrightsreserved.
ONOSOKKI
WORLDWIDE
Ono Sokki Co., Ltd.
1-16-1 Hakusan, Midori-ku,Yokohama 226-8507,Japan
Phone : [phone]
Fax : [phone]
E-mail : [email protected]
■OmissionofTestQualificationIssuance
Sincethisproducthasbeentestedthroughaseriesofstrictinspections
andacompleteprogramofqualitycontrol,issuanceofthetestqualifi-
cationhasbeenomitted.
■Warranty
1. Thisproductiscoveredbyawarrantyforaperiodofoneyear
fromthedateofpurchase.
2. Thiswarrantycoversfree-of-chargerepairfordefectsjudgedtobe
theresponsibilityofthemanufacturer,i.e.,defectsoccurredwhile
theproductisusedundernormaloperatingconditionsaccordingto
descriptionsinthismanualandnoticesontheunitlabel.
3. Forfree-of-chargerepair,contacteitheryoursalesrepresenta-
tiveoroursalesofficenearby.
4. Thefollowingfailureswillbehandledonafeebasisevenduring
thewarrantyperiod.
(a)Failuresoccurringthroughmisuse,mis-operation,or
modification
(b) Failuresoccurringthroughmishandling(dropping)ortrans-
portation
(c)Failuresoccurringthroughnaturalcalamities(fires,
earthquakes,flooding,andlightening),environmentaldis-
ruption,orabnormalvoltage.
*Forrepairsafterthewarrantyperiodexpired,contactyoursales
representativeoroursalesofficenearby.
B00001755/IM01052502(2)023(MS)030
NAMEANDFUNCTIONOFEACHPART
*Outerappearanceandspecificationsaresubjecttochangewithoutpriornotice.
HOMEPAGE:http://www.onosokki.co.jp/English/english.htm
BATT
RECALL
ONOFF
LIGHT
IND
SE-2400
DIGITAL
ENGINE TACHOMETER
ONOSOKKI
CYL SEL UNIT
ON
HOLD
EXT
PICKUP
FUNCT
SET/ MEAS
DCIN
ONOSOKKI
SE-2400
DIGITALENNGINE TACHOMETER
ONO SOKKI CO., LTD.
MADE IN JAPAN
DIGITALENGINETACHOMETER
SE-2400
INSTRUCTIONMANUAL
ThankyouforyourselectionoftheSE-2400DigitalEngine
Tachometer.Toensurethatyougetmostoutoftheinstru-
ment,westronglyrecommendyoureadfollowtheinstruc-
tioninthismanualcarefully.
CopyrightcONOSOKKICO.,LTD.
2001Allrightsreserved.
1 DigitalEngine
TachometerSE-2400
4 CarringCase
3 ExternalSensor
IP-2800
4 SizeAABatterie
s
5 InstructionManu
al
ON
HOLD
SE-2400
ENGINE TACHOMETER
DIGITAL
IND
UNITCYL SELRECALL
LIGHT
ON OFF
SET/MEAS
FUNCT
DC IN
PICKUP
EXT
BATTOVER
r/ s r/min
BATTOVER
r/min
ONOSOKKI
w
q
3
765
09 8
2
te
r
y
4
1TheDisplay

Whenthefunction
selectionswitchison
theMEASposition.
Whenthefunction
selectionswitchison
theSETposition.

1.Applyingpower
①ByslidingthepowerswitchtotheONposition,poweris
appliedtotheSE-2400.Whenyoureleaseyourfinger,
theswitchreturnstothecenterpositionandpoweris
switchedoff.
②IfyouslidethepowerswitchtotheHOLDposition,it
willlockintheonconditionevenwhenyouremoveyour
finger.Forswitchingoffthepower,theswitchistobe
movedtothecenterposition.
ItisconvenienttokeeptheswitchtotheHOLDposition
whencontinuouslymeasuringtherotationalspeed.
2.Settingthenumberofcylinder
Setthenumberofcylinderaccordingtotheenginetobe
measured.Intheinitialcondition,4-cycle1-cylinderis
selected.Whenthebatteriesarereplacedwithnewonesor
whentheoptionalPB-703ACadaptorisdisconnected（no
batteryisinstalled）,theinitialsettingof4-cycle1-cylinder
willbeselected.
①ByslidingthefunctionselectionswitchtoSETposition,
theFig.1asshownbelowwillbedisplayed.The−
intheleftsidedisplaystandsforthenumberofcylinders
for2-cycleenginesandthe1inrightsidedisplay
standsfornumbersforcylinderof4-cycleengines.
②Eachtimethecylinderselectionswitchispressed,the
displaywillbechangedintheorderoftheChart1below.
③Whenadesirednumberofcylinderisdisplayed,slide
thefunctionselectionswitchtoMEASposition.
3.Settingthemeasurementunit
EachtimetheUNITswitchispressed,themeasurementunit
willbechangedfromr/mintor/sorviceversa.Intheinitial
condition,ther/minunitisselected.
4.Startingmeasurement
①SlidethepowerswitchtotheONorHOLDpositionto
supplypowertotheunit.
②Aftersettingthenumberofcylinder,slidethefunction
selectionswitchtoMEASposition.
③Setameasurementunit.
④Whenthedetectionheadisplacedclosetoanignition
coiloftheengine,theindicatorstartsblinking.
⑤Whenyoubringthedetectionheadmuchclosertothe
ignitioncoil,theindicatorlampblinksataconstant
frequency.Athighrotationalspeedthelamplooksasif
growingwithoutblinking.Thisdistanceisthemeasuring
position.Thedistancebetweentheignitioncoilandthe
detectorheadisnormally10to200mm.
⑥Adjustthesensitivityadjustmentvolumeinordertomake
thesignalsensitivitystablewhenthemeasurementismade
unstable.
5.Measurementwiththe
IP-2800externalsensor
WhenyoufurtherextendthecableoftheIP-2800,usethe
optionalIP-001extensioncable（3m）.
①InsertthejackoftheIP-2800totheexternalsensorinput
terminaloftheSE-2400.
②MountthesensorpartoftheIP-2800totheignitioncoil.
③SlidethepowerswitchtotheONorHOLDpositionto
supplypowertotheunit.
④Aftersettingthenumberofcylinder,slidethefunction
selectionswitchtotheMEASposition.
⑤Setthemeasurementunit.
⑥Nowyouarereadytotakeameasurement.
6.Measurementprecaution
● DonotputanyobstaclebetweentheSE-2400and
ignitioncoil.
Theaccuratemeasurementisimpossibleifthereisany
obstaclebetweenthemsincetherotationsignaliscutoff.
● Careshouldbetakennottobringthemainbodyor
thedetectionheadincontactwithanignitioncoil.
Ifanirregulardisplayoccursduetoanaccidentalcontact
withtheignitioncoil,slidethepowerswitchtooffand
thenturnitonagain.
● DonotplaceamagneticobjectneartheSE-2400
undermeasurement.
SincetheSE-2400detectsleakageofmagneticfluxgen-
eratedfromtheignitioncoil,ifthereisanymagneticob-
jectnearby,anirregulardisplaywilloccur.
● MeasurementrangeoftheSE-2400is20000r/min
（max.）.Useitwithinthisrange.
● Pleasekeepthecorrectdirectionoftheunitat
thethemeasurementsothattheINDlampblinks
atafixedinterval.
TheApartofopenmag-
neticcircuittypeignition
coil（especialycylin-
dricalshape）structually
generateshigherdensity
magneticflux,andBpartofitgeneratessmallerdensity
magneticflux.
SincetheSE-2400detectsleakageofmagneticflux,de-
tectingfromtheAdirectionissuitableformeasurement.
Closedmagneticcircuittypeignitioncoilhasa
complecatedleakageflowofmagneticflux,sotheremay
beacasewhenadisplayfluctuatesdependingonmea-
suringdirectionsormethods.Inthiscase,placetheSE-
2400alittlebitapartfromtheignitioncoilandmake
measurementwherethedisplaybecomesstable.
7.Aboutthebatteries
ThisinstrumentoperatesonthreeSizeAAdrycellbatteries
ortheoptionalPB-703ACadaptor.
Whenthebatterieshavebeendischargedandthedisplay
showsa mark,besuretoreplaceallthreebatteries
withnewbatteries.
Howtoreplacethebatteries
①Removethebatterycoverbyslidingoutitwhilepressing
theknob.
②Afterremovingtheexistingbatteries,insertnewbatteries
withcareoftheirpolarity.
③Closethebatterycover.
1.Detectorsection
Detectionmethod ：Electromagneticinductionmethod
Detectingobject ：Ignitioncoil
Detectiondistance ：10to200mm.
2.Measurementsection
Measurementunit ：r/min、r/s
Measurementrange：
Numberofdisplaydigits：5
Displaytype ：7-segmentLCDdisplaywithbacklight-
ing
Timebase ：Quartscrystaloscillator（32.768kHz）
Measurementdisplaytime：1s,automaticallyrepeating
Accuracy ：±1r/min（±2r/minfor10000r/min
ormore）
OVER ：indicator:OVERindicatorappearson
thedisplaywhentherotationalspeedex-
ceeds20000r/minor333.33r/s.
3.Generalspecifications
Storagetime ：Thelastmeasuredvalueisstoredinmemory
untilbatteriesweardownoruntilpowersup-
plyfromanACadaptorisinterrupted.
Powersource：AAbatteries×3
Batterieslife ：Approx.150hours
Approx.20hours（Whenbacklightisused）
Lowbatteryindication ：About3.3V
Operatingtemperature ：0℃to＋40℃
Storagetemperature ：−10℃to＋55℃
Weight ：Approx.130g（withoutincl.Batteries）
Outerdimensions ：（unit:mm）
2-cycle
1cylinder
2cylinder
3cylinder
4cylinder
4-cycle
1cylinder
2cylinder
3cylinder
4cylinder
5cylinder
6cylinder
8cylinder
Measuringrange
120to20000r/min
120to20000r/min
120to20000r/min
120to20000r/min
120to20000r/min
120to15000r/min
120to12000r/min
TROUBLESHOOTING
IfamalfunctionoftheSE-2400issuspected,anditemsinthefollowingtablearecheckedbuttheunitstillseemstobe
malfunctioning,contactyoursalesrepresentativeoroursalesoffice.
MEASURINGMETHOD Specifications
ON
HOLD
SE-2400
ENGINE TACHOMETER
DIGITAL
IND
Thepowerswitchisnotlocke
d.
Thepowerswitchislocked.
RECALL
ONOFF
LIGHT
IND
SE-2400
DIGIT
AL
ENGINET
ACHOMETER
ONOSOKKI
CYL SEL UNIT
ON
HOLD
EXT
PICKUP
FUNCT
SET / MEAS
DCIN
ignitioncoil
external
sensorinp
ut
terminal
RECALL
ON OFF
LIGHT
IND
SE-2400
DIGIT
AL
ENGINETACHOMETER
ONOSOKKI
CYL SELUNIT
ON
HOLD
EXT
PICKUP
FUNCT
SET / MEAS
DCIN
ignitioncoil
●Conductmeasurement
 whilealigningtheaxis
directionsthedevice
andignitioncoil.
A
B
ON
HOLD
SE-2400
ENGINE TACHOMETER
DIGITAL
IND
UNITCYL SELRECALL
LIGHT
ON OFF
BATTOVER
r/ s r/min
ONOSOKKI
60
179.5
130
31.5
36
Cameratripodthread
1/4,6mmdeep
BATT
Numberofthe
cylindersat
2-cycleengine.
Numberofthe
cylindersat
4-cycleengine.
ｰ∗1
1
ｰ
2
ｰ
3
4
1
2
3
4
5
6
8
Fig.1
Chart1
Itreturnsthesetting
conditiontomeasure

4-cyle/onecylinder
enginebypressing
thechange-over
switchtothenumbe
r
ofthecylinderwhen

itis4cyle/eight
cylinders.

*1
"-"indicatesnosubject
.
Storage
Thestoragetemperaturerangeis−10℃〜＋55℃.
Avoidstoringtheunitinadampplaceandunderdirect
sunlight,andprovideagoodventilation.Whennotinuse
forlongperiod,removebatteriestopreventpossibledam-
agefrombatteryleakage.
Option
①ACadaptor（PB-703）
InsertthejackofthePB-703totheexternalpowerinput
terminaloftheSE-2400.ConnecttheplugofthePB-703
totheAC100Vreceptacle.ByconnectingthePB-703in
thismanner,theSE-2400operatesfromAClinepower.
②ExternalSensor（VP-201）
TheVP-201canbeusedtomeasuretherotationalspeed
（rpm）of4-cyclegasoline-enginesand4-cyclediesel-
engines.
Symptom
Noindication
Unstable
indication
Therotationspeeds
isextremely
high/low
Checkitem
●Batteriesareinserted？
●Batterypolarityiscorrect？
●Batteriesarecharged？
●ACadaptorispluged？
●Isthemeasuringdistancecorrect？
●Isn′ttheignitioncoilcontactingtotheSE-2400？
●IsthereanyobstaclebetweentheSE-2400and
ignitioncoil？
●Isanignitioncoilclosedmagneticcircuittype？
●Isthesettingofthenumberofcylinderiscorrect？
●Isanignitioncoilclosedmagneticcircuittype？
●Therotationspeedisdisplayedtwice.
Countermeasure
●Insertbatteries.
●Insertbatteriesincorrectpolarity.
●Replacebatterieswithnewones.
●PlugACadaptor.
●Thedistanceatwhichmeasurementcanbeexecuted
is10to200mmfromanignitioncoil.
●DonotlettheignitioncoilcontacttotheSE-2400.
●DonotputanobstaclebetweentheSE-2400andig-
nitioncoil.
●Changethemeasuringdirection.
●Setthecorrectvaluereferringto2.Settingthenum-
berofcylinder.
●Changethemeasuringdirection.
●Itmayhappenwiththespecificationofanignition
coil.Pleasechangeasetupofthenumberofcylin-
ders.
