ONV IPS31064P User manual

USER GUIDE
PoE & Optical Transmission
ONV-IPS31064P
Statement
Copyright @ 2002-2016 Optical Network Video Technologies (Shenzhen) Co., Ltd
All Rights Reserved
®
!
Packing List
Please kindly check the following items:
1 xPoE switch
1 xPower Kits
1x Mounting Kits
1x User Guide/ Certificates/Warranty Card
Note
If any shortage or damage found, please contact us in time.
This document contains proprietary information that is protected by copyright. No part of this document may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language, in any form
or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise without the prior
written permission of Optical Network Video Technologies (Shenzhen) Co., Ltd.
is the registered trademark of Optical Network Video Technologies (Shenzhen) Co., Ltd. The information
and product specifications within this document are subject to change at any time, without notice and without obli-
gation to notify any person of such change.
Product overview
Product Introduction
Note
Feature
!
ONV-IPS31064P series PoE switch features with 4x PoE Ethernet ports that compatible with 10/100BaseT(X),802.3af（PoE）
and 802.3at(PoE+) + 2 Ethernet ports and . The power supply of single PoE port can be up to 30W. The terminal equipment
such as weather-proof IP camera, high performance wireless AP and industrial IP telephony. Highly flexible. Capable of high
anti-electromagnetic interference.
The product ‘Switch’ mentioned in the manual, if without a special request, it is referring to industrial ONV-IPS31064P PoE
switch, PoE switch in short in below.
Comply to IEEE 802.3,IEEE 802.3u,IEEE 802.3z,IEEE 802.3ab,IEEE 802.3x,IEEE 802.1D,IEEE 802.3at,IEEE 802.3af,IEEE 802.1Q
IEEE 802.1p,IEEE 802.1x,IEEE 802.1W,SNMP、IGMP standards;
10/ 100M, 10/ 100/ 1000M self-sensing RJ45 port, support power supply function;
All ports support auto-flip (Auto MDI/MDIX);
Each PoE port can provide power up to 15.4W (af) or 30W (at);
Supply power for powered devices compatible with IEEE802.3af/at;
Support IEEE802.3x full duplex flow control and duplex backpressure flow control;
1.6G backplane bandwidth, 448kpbs forwarding memory;
1K MAC address table;
Its 3KV network port surge protection can adapt to harsh outdoor environment;
Technical Structure and Port Description
A. Power Led Indicator
B. 4x 10/100M POE Ports
C. 2x Uplink 10/100M Ports
119mm
100mm
30mm
SPD SPD
1 2 3 4 5 6
P P
SPD SPD
1 2 3 4 5 6
P P
A B C

：Note Please confirm that the all the PD devices are complying with IEEE802.3af/at standard.
!
output), please use AC100~240V, 50/60Hz power supply;
Power Industrial Terminals: 48 (46 ~57V)VDC, dual redundancy ( More than 50VDC recommended when used PoE+
Indicator description:
Indicator Status Description
Power Indicator: P
Green LED ON
Normal
PoE Indicator: PoE
100M Indicator: Link
OFF Power OFF
Green LED ON Connected PD Device, working properly
Green LED Blink Short circuit or current overload
OFF No Connected PD or Power OFF
Yellow LED Blink Data transmission properly
Yellow LED ON Connected with 10Mbps or 100Mbps network device
OFF No connected PD
Green LED Blink
Green LED ON
OFF
Data transmission properly
Connected with 100Mbps network device
No connected PD
100M Indicator: SPD
PoE Port: The PoE ports support PoE function, which can transmit data and power simultaneously if connected matching
device. The LED lights on the front panel can show working status of each port.
Ethernet Port: beside PoE port, other ports are Ethernet RJ45 port, and all RJ45 port support Auto MDIMDIX, plug and
play.The LED lights on the front panel can show working status of each port.
!
Installation guide
Please install with the supporting devices.
Installation
Please confirm the following things before installation:
1. If the POE port meets the power requirement of the connecting devices.
2. If the POE standard requirement and power supply matches with the power receiving device
(1/2+、3/6-( End -span)/ 4/5+、7/8-(Mid-span))
3 .If the output power of the matched power adapter is compatible with the specification in the label of the POE switch
Please install the POE switch according to the following steps:
1. Put the PoE switch on the surface of a large and stable table.
2. Plug the power adapter into the power connector, and then connect the power outlet through the power cord.
3. Connect the network devices to the POE switch port though network cable.
1.Please do not put heavy products on the POE switch, and please ensure good ventilation environment for the POE switch.
2.Please cut off the power first before plugging the power adapter.
Power
Connect the power cable, plug it into power socket, turn on the power, then the switch will automatically initialize,
and LED lights status will display as following:
1 Except the POE port lights, all the other lights will go through the process of “on-off-on-off”, which means the
estoration is successful.
2 Power LED remains lit.
If initialization is inconsistent with the above, please check the power.
Note
!Note
Connection Diagram
www.onvcom.com
Tel:[phone] Fax:[phone] Email:[e-mail]
Address: Room 1003, Block D , Terra building , Chegongmiao, Futian district ,Shenzhen ,China
Factory address:No 5, A building, SenYuTai S&T park, Longhua road, BaoAn district,Shenzhen, China
Model Descriptions and Installation
ONV-IPS31064P: 6-Port 10/100M Industrial POE Switch, 4x 10/100M POE Ports, 2x 10/100M adaptive Ports.Support
POE power supply. Support Standard IEEE802.3at/af,Support Provides rail-type installation method.
SPD
SPD
123456
P
P
Industrial
PoE Switch
IPS31064P
Wide Are a
Net wor k
