Tools Required
For additional assembly support, refer to www.openplan.com
or contact 844.OPS.OPS1
Cordless Drill
Philips bit with extension
for Work Surface screws
(XP-Screw-WS)
XPAND REACH
Single Station: Spine Fabric Screen– Assembly
Instructions
www.openplan.com | 844.OPS.OPS1 | [e-mail]

XPand Parts Used for Assembly
2
XPand Reach – Double Stations-Spine Fabric Screen
Item Part name Part Description Image
1 XP-SB-SRM Screen Bracket, Single Rear
Mount
2 XP-SB-S Screen Bracket For Single
Desk
3 XP-STBP Screen T-Bracket Sleeve,
1.5” h
4 XP-SCREWS-WS 10-9X1 PH Pan Head, ST
P’bd Screw, ZP
5 XP-14XX-TX-A 15”XXX” Fabric Screen
Assembly
6 XP-TXXXX Work Surface XXXX”

To Assemble a Spine Screen on a Single Bench, XP-SB-S (Screen Bracket for Single Station) are used. When a Return Screen or a Return Glass is
assembled to the Single Bench, XP-SB-SRM (Single Rear Mount Bracket) should be used instead of XP-SB-S. The Instructions to assemble XP-SB-S and
XP-SB-SRM are the same.
3
Step 1: Align the Spine screen with the
Work Surface. Locate the Screen holes
and mark the hole locations on the Work
Surface. Secure the screen brackets (XP-
SB-SRM/ XP-SB-S) on the marked locations
using (4) XP-Screw-WS per Bracket.
Step 2: Slide in XP-STBP onto the Screen
Brackets (XP-SB-S/XP-SB-SRM) and place
the Screen guiding the posts into the
Screen holes.
Note: For Thin Screens (XP-14XX-TR/TS-A-T), XP-SB-
SRM-T is used instead of XP-SB-SRM and XP-SB-S-T
is used instead of XP-SB-S as Screen Brackets.
XP-SB-SRM-T
(XP-SB-S-T)
Figure A Figure B
