Open Plan Systems XPAND REACH User manual

For additional assembly support, refer to www.openplan.com
or contact 844.OPS.OPS1
XPAND REACH
Single Station: Spine Glass/Return End Glass
- Assembly Instructions
www.openplan.com | 844.OPS.OPS1 | [e-mail]
Tools Required
Cordless Drill
Level
Rubber Mallet
Philips bit with extension
for Work Surface screws
(XP-Screw-WS)

XPand Parts Used for Assembly
2
XPand Reach Single Station: Spine Glass/Return End Glass
Item Part name Part Description Image
1
XP-G-XXXX/
XP-G-XXXXF Clear/Frosted Glass
2 XP-G-RSB-EC Glass Extrusion End Caps for
Return screens-Pair
3 XP-G-EXX Glass Extrusion XX”
4 Flat Bracket 2" X 3" Flat Bracket
(Modfified)
5 XP-Screw-WS 10-9X1 PH Pan Head, ST
P’bd Screw, ZP
6 Self Tapping screw
14x3/4" Hex Washer head
Zinc finish steel self-drilling
screw
7 Flat washers ¼” Flat Washer

To assemble the Rear/Return Glass Assembly to the Single Bench, Modified Flat brackets and XP-G-RSB-EC (End Caps for Return Screen) are used.
Refer to “Single Station Bench Assembly Instructions” to build the Single Bench.
3
Step 1: Align the Glass Extrusion with the Work Surface and place the Flat Bracket in
flush with the Extrusion (shown in Figure A). Secure the Flat Bracket to the Extrusion
with (2) Self Tapping Screws. Using the center hole of the flat bracket, secure the
Work Surface using (1) XP-Screw-WS, drill the screw half way in. Using (2) ¼” washers
on the other end of the Flat Bracket, secure the Flat bracket's to the Work Surface
using (2) XP-Screw-WS. Now, drill the center screw all the way in.
XPand Reach Single Station: Spine Glass/Return End Glass
Work Surface
XP-Screw-WS
with ¼” washer
XP-Screw-WS
XP-G-EXX
Self-Tapping
Screws
Figure A
Step 4: Assemble the End Caps (XP-G-RSB-EC) to the Extrusion using (1) XP-
Screw per end cap. Secure the End cap to the Work Surface using (1) XP-
Screw-WS per End Cap. Slide in the Glass (XP-G-XXXX/XP-G-XXXXF) into the
extrusion.
