Omation Model 306 Setup Manual Inital Machine Setup
03/09/2018 Condential OPEX Setup Manual - Corp. Use Only - Not for Distribution
Omation Model 306
Inital Setup Manual

Omation Model 306 Setup Manual Inital Machine Setup
03/09/2018 Condential OPEX Setup Manual - Corp. Use Only - Not for Distribution
12
34
Unpack Tilt 35° Place on topLift from bottom
& back
bottom
back
Once the boxes are unpacked. Make sure that the top
and base of the Omation Model 306 are beside one
another on the ground. Engage the wheel brakes on
the base.
Then, with 2 people, tilt the top piece until the back
and the bottom of the top piece are at a 35° angle
from the oor. Place your hands underneath the back
and the bottom while squatting and then lift togeth-
er with your legs.
Carefully walk the top piece over and hold it over the
base.
*Tools and items required: Phillips screw driver and some type of padded material to lay on.

Omation Model 306 Setup Manual Inital Machine Setup
03/09/2018 Condential OPEX Setup Manual - Corp. Use Only - Not for Distribution
Carefully place the back edge of the top piece on the
base.
Then slowly lower until the bottom of the top piece is
at against the top of the base assembly.
Be sure to line up the sides and the rear of the machine
as ush as possible to align at least 4 screws with their
pre-threaded holes.

Omation Model 306 Setup Manual Inital Machine Setup
03/09/2018 Condential OPEX Setup Manual - Corp. Use Only - Not for Distribution
Lay some type pad* across the hard edge of the rear of
the base. This will protect your body from the edge as
you align the holes for the screws and drive them in.
Screw at least 4 Phillips* screws into the top piece from
below. Be sure to screw them in until they are snug.
Plug in the main power cord into the rear of the
machine and power on to congure.
