Optoma TW6000 Installation instructions

English
74
RS232 Commands
RS232 Connector
9 8 7 6
54321
Pin No Specification
1 N/A
2 RXD
3 TXD
4 DTR
5 GND
6 DSR
7 RTS
8 CTS
9 N/A
Appendices

English
75
RS232 Protocol Function List
RS232 Commands
Due to the
difference
application
for each
model.
Function is
dependent
on the model
purchased.
v
Baud Rate 9600
Data Bits 8
Parity Check None
Stop Bits 1
Flow Control None
UART16550 FIFO Disable
Lead Code Projector ID Command ID space variable carriage return
~ X X X X X n CR
Fix code
One Digit
Set in OSD
00~99
Two Digit
00 is for universal use
Defined by Optoma
2 or 3 Digit
See the Follow content
One Digit Per item
Definition
Fix code
One Digit
Keypad Command
Function ASCII Pass Fail
Power On/Off n=1/n=2 & 0 ~XX00 n P F
Power On with Password ~XX00 1nnnn P F
Resync n=1 ~XX01 n P F
AV Mute On/Off n=1/n=2 & 0 ~XX02 n P F
Mute On/Off n=1/n=2 & 0 ~XX03 n P F
Freeze n=1 ~XX04 n P F
Unfreeze n=2
IR Function On/Off n=1/n=2 & 0 ~XX11 n P F
Direct Source Selection ~XX12 n P F
HDMI n=1
DVI-D n=2
BNC n=4
VGA 1 n=5
VGA 2 n=6
VGA 1 SCART n=7
VGA 1 Component n=8
S-Video n=9
Video n=10
VGA 2 SCART n=12
VGA 2 Component n=13
Component RCA n=14
OSD/Image
Function ASCII Pass Fail
Presentation ʳn=1 ~XX20 n P F
Bright ʳn=2 ʳ
Movie ʳn=3 ʳ
sRGB ʳn=4 ʳ
Classroom n=7
Blackboard n=8
User 1 ʳn=5 ʳ
Display Mode
3D ʳn=11 ʳ
Brightness ʳ ʳ n= -50 - +50 ~XX21 n P F
Contrast ʳ ʳ n= -50 - +50 ~XX22 n P F
Sharpness ʳ ʳ n= -15 - +15 ~XX23 n P F
Appendices

English
76
Function ASCII Pass Fail
Saturation n= -50 - +50 ~XX45 n P F
Tint n= -50 - +50 ~XX44 n P F
BrilliantColor
TM 1
ʳn= 0 - 10 ~XX34 n P F
Film n=1 ~XX35 n P F
Video n=2
Graphics n=3 ʳ
Degamma
PC n=4 ʳ
Warm n=1 ~XX36 n P F
Medium n=2 ʳ
Color Temp.
Cold n=3 ʳ
Hue n=-50 ~ 50 ~XX170 n P F
Saturation n=-50 ~ 50 ~XX171 n P F
Red
Gain n=-50 ~ 50 ~XX27 n P F
Hue n=-50 ~ 50 ~XX172 n P F
Saturation n=-50 ~ 50 ~XX173 n P F
Green
Gain n=-50 ~ 50 ~XX28 n P F
Hue n=-50 ~ 50 ~XX174 n P F
Saturation n=-50 ~ 50 ~XX175 n P F
Blue
Gain n=-50 ~ 50 ~XX29 n P F
Hue n=-50 ~ 50 ~XX176 n P F
Saturation n=-50 ~ 50 ~XX177 n P F
Cyan
Gain n=-50 ~ 50 ~XX30 n P F
Hue n=-50 ~ 50 ~XX178 n P F
Saturation n=-50 ~ 50 ~XX179 n P F
Yellow
Gain n=-50 ~ 50 ~XX31 n P F
Hue n=-50 ~ 50 ~XX180 n P F
Saturation n=-50 ~ 50 ~XX181 n P F
Magenta
Gain n=-50 ~ 50 ~XX32 n P F
Color Settings
ʳReset n=1 ~XX33 n P F
Auto n=1 ~XX37 n P F
RGB n=2 ʳ
/Advanced
Color Space
YUV n=3 ʳ
HDMI n=1 ~XX39 n P F
DVI-D n=2 ʳ
BNC n=4
VGA 1 n=5
VGA 2 n=6
RCA Component n=8
S-Video n=9 ʳ
/Advanced Input Source Filters
Video n=10 ʳ
On n=1 ~XX40 n P F
/Advanced De-Interlace
Off n=2 & 0 ʳ
1If no patent issue, the term will be modified to BrilliantColorTM.
Appendices

English
77
ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
OSD/Display
Function
ASCII Pass Fail
4:3 n=1 ~XX60 n P F
16:9 I/16:9 n=2 ʳ
16:9 II / 16:10 n=3
Native n=6 ʳ
Format
Auto n=7 ʳ
Overscan ʳn=0-10 ~XX61 n P F
Zoom ʳn= -30 - +100 ~XX62 n P F
H Image Shift ʳn= -50 - +50 ~XX63 n P F
V Image Shift (16:9) ʳn= -24 - +24 ~XX64 n P F
V Keystone ʳn= -30 - +30 ~XX66 n P F
3D Off/DLP-Link n=2&0, n=1 ~XX230 n P F
3D Sync Invert On/Off n=1/n=2 &0 ~XX231 n P F
OSD/Setup
Function ASCII Pass Fail
English ʳn=1 ~XX70 n P F
German ʳn=2 ʳ
French ʳn=3 ʳ
Italian ʳn=4 ʳ
Spanish ʳn=5 ʳ
Portuguese ʳn=6 ʳ
Polish ʳn=7 ʳ
Dutch ʳn=8 ʳ
Swedish ʳn=9 ʳ
Norwegian/Danish ʳn=10 ʳ
Finnish ʳn=11 ʳ
Greek ʳn=12 ʳ
Traditional Chinese ʳn=13 ʳ
Simplified Chinese ʳn=14 ʳ
Japanese ʳn=15 ʳ
Korean ʳn=16 ʳ
Russian ʳn=17 ʳ
Hungarian ʳn=18 ʳ
Czechoslovak ʳn=19 ʳ
Arabic ʳn=20 ʳ
Thai ʳn=21
Language
Turkish ʳn=22 ʳ
Front-Desktop ʳn=1 ~XX71 n P F
Rear-Desktop ʳn=2 ʳ
Front-Ceiling ʳn=3 ʳ
Projection
Rear-Ceiling ʳn=4 ʳ
Top Left ʳn=1 ~XX72 n P F
Top Right ʳn=2 ʳ
Centre ʳn=3 ʳ
Bottom Left ʳn=4 ʳ
Menu Location
Bottom Right ʳn=5 ʳ
Signal Frequency ʳn= 0~31 ~XX73 n P F
Appendices

English
78
Appendices
Function ASCII Pass Fail
Phase ʳn= -5 - +5 ~XX74 n P F
H. Position ʳn= -5 - +5 ~XX75 n P F
V. Position ʳn= -5 - +5 ~XX76 n P F
Security Timer Hour/Day/Month nnnnnn ~XX77 n P F
Change
Password ʳ ʳ
send back the
password to
confirm
Security
Security Settings Enable/Disable n=1/n=2 &0 ~XX78 n P F
Projector ID ʳ ʳ n=00-99 ~XX79 n P F
Mute On/Off n=1/n=2 &0 ~XX80 n P F
Audio
Volume ʳn=0-10 ~XX81 n P F
Logo Optoma/User n=1/n=2 ~XX82 n P F
Logo Capture ʳn=1 ~XX83 n P F
Advanced
Closed Captioning On/Off n=1/n=2 &0 ~XX88 n P F
RS232 n=1 ~XX86 n P F
RS232 ʳ
Network n=2 ʳP F
OSD/Option
Function ASCII Pass Fail
Source Lock ʳOn/Off n=1/n=2 &0 ~XX100 n P F
High Altitude ʳOn/Off n=1/n=2 &0 ~XX101 n P F
Information Hide ʳOn/Off n=1/n=2 &0 ~XX102 n P F
Keypad Lock ʳOn/Off n=1/n=2 &0 ~XX103 n P F
Blue ʳn=1 ~XX104 n P F
Black ʳn=2 ʳ
Red ʳn=3 ʳ
Green ʳn=4 ʳ
Background Color
White ʳn=5 ʳ
Direct Power On On/Off n=1/n=2 &0 ~XX105 n P F
Signal Power On On/Off n=1/n=2 &0 ~XX113 n P F
Auto Power Off (min) ʳn=0-180 ~XX106 n P F
Sleep Timer (min) ʳn=000-995 ~XX107 n P F
Advanced
Power Mode(Standby) ECO mode/Active
Mode n=1/n=2 &0 ~XX114 n P F
Lamp Hour ʳn=1 ~XX108 n nnnn F
Lamp Reminder On/Off n=1/n=2 &0 ~XX109 n P F
Brightness Mode Bright/STD n=1/n=2 ~XX110 n P F
Yes n=1 ~XX111 n P F
Lamp Setting
Lamp Reset
No n=2 ʳ
Yes n=1 ~XX112 n P F
Reset ʳ
No n=2 ʳ
Note: To also include AMX beacon signal in RS232 protocol
In basic terms, AMX controllers will issue a poll periodically to detect 3rd party devices connected to the RS232 port (in this case
Optoma). The poll is "AMX" in ASCII followed by a carriage return '\r'.
On recognition of the poll, the Optoma projector will respond with a beacon string (in ASCII) identifying your device. The AMX controller
(Branded NetLinx) can then download the interface from the amx website to control your device. An example beacon string for Optoma
could be:
AMXB<-SDKClass=VideoProjector><-Make=Optoma><-Model=EX???><-Revision=1.0.0>
The beacon needs to be terminated by a carriage return (‘\r’, 0x0D)
Revision will indicate the firmware version that is running on the Optoma projector.
Device discovery is also supported over IP if control protocol works across it (most manufacturers take their RS232 command set and
also use it for IP on a dedicated application port)

English
79
Appendices
ʳ
ʳ
ʳ
ʳ ʳ
ʳ ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
ʳ ʳ
ʳ ʳ
ʳ ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
Information Format: INFOa
Status
Code Definition
Standby Mode a=0
Warming up a=1
Cooling Down a=2
Out of Range a=3
Lamp Fail a=4
Thermal Switch Error a=5
Fan Lock a=6
Over Temperature a=7
Lamp Hour Running Out a=8
Information display:
Function ASCII Display Format Fail
Information n=1 ~XX150 n Okabbbbccdddde F
Format Definition Code Definition
a = Power State On a=1
Off a=0
b = Lamp Hour ʳbbbb
c = Input Source None c=0
HDMI c=1
DVI-D c=2
BNC c=3
VGA 1 c=4
VGA 2 c=5
Component RCA c=6
S-Video c=7
Video c=8
d = Firmware Version ʳdddd
e = Display mode None e=0
ʳPresentation e=1
ʳBright e=2
ʳMovie e=3
ʳsRGB e=4
User1 e=5
User2 e=6
ʳClassroom e=7
Blackboard e=8
Note: The command ~XX150 n MUST work when projector is in standby mode
Model Name
Function ASCII Display Depends Fail
Model Name n=1 ~XX151 n Okaa=1/2/
1=EX785, 2=EW775 F
RS232 Version No
Function ASCII Display Depends Fail
RS232 Version No n=1 ~XX152 n Okaa=?? F
Input Source Display
Function ACCII Display Fail
Input Source n=1 ~XX121 n OkaF
Note: The command ~XX121 n MUST work when projector is in standby mode

English
80
Appendices
Status Code Definition
None c=0
HDMI c=1
DVI-D c=2
BNC c=3
VGA 1 c=4
VGA 2 c=5
Component RCA c=6
S-Video c=7
Video c=8
Software Version
Function ACCII Display Fail
Software Version n=1 ~XX122 n Okdddd F
Display Mode
Function ACCII Display Fail
Display Mode n=1 ~XX123 n OkaF
Status Code Definition
Presentation a=0
Bright a=1
Movie a=2
sRGB a=3
User 1 a=4
User 2 a=5
Classroom a=6
Blackboard a=7
Power State
Function ACCII Display Fail
Power State n=1 ~XX124 n OkaF
Note: The command ~XX124 n MUST work when projector is in standby mode
Status Code Definition
On a=1
Off a=0
Brightness
Function ACCII Display Fail
Brightness n=1 ~XX125 n OkaF
Contrast
Function ACCII Display Fail
Contrast n=1 ~XX126 n OkaF
Aspect Ratio
Function ACCII Display Fail
Aspect Ratio n=1 ~XX127 n OkaF
Status Code Definition
4:3 a=0
16:9 I a=1
16:9 II / 16:10 a=2
Native a=3
Auto a=4

English
81
Appendices
Color Temperature
Function
ASCII Display Fail
Color Temperature n=1 ~XX128 n OkaF
Status Code Definition
Warm a=0
Medium a=1
Cold a=2
Projection Mode
Function ASCII Display Fail
Projection Mode n=1 ~XX129 n OkaF
Status Code Definition
Front-Desktop a=0
Rear-Desktop a=1
Front-Ceiling a=2
Rear-Ceiling a=3
Remote control
Customer code : 0x32CD
Item Key Definition ASCII Pass Fail
1 Power n=1 ~XX140 n P F
2 Resync n=2 P F
3 Keystone n=3 ʳP F
4 AV Mute n=4 ʳP F
5 Freeze n=5 ʳP F
6 Display n=6 ʳP F
7 Zoom in n=7 ʳP F
8 Zoom out n=8 ʳP F
9 Volume + n=9 ʳP F
10 Volume - n=10 ʳP F
11 Enter (for projection MENU) n=11 ʳP F
12 Menu n=12 ʳP F
13 Left n=13 ʳP F
14 Up n=14 ʳP F
15 Right n=15 ʳP F
16 Down n=16 ʳP F
17 Brightness n=17 ʳP F
18 Format/1 n=18 ʳP F
19 HDMI/2 n=19 ʳP F
20 YPbPr/3 n=20 ʳP F
21 Source/4 n=21 ʳP F
22 DVI/5 n=22 P F
23 BNC/6 n=23 ʳP F
24 VGA-1/7 n=24 ʳP F
25 Video/8 n=25 ʳP F
26 Video/9 n=26 ʳP F
27 VGA-2/0 n=27 ʳP F
