Oriental motor ASTEP AZ Series User manual

Thank you for purchasing an Oriental Motor product.
This Manual describes product handling procedures and safety precautions.
•Please read it thoroughly to ensure safe operation.
•Always keep the manual where it is readily available.
HM-60440
AZ Series/
Motorized Actuator equipped with AZ Series
mini Driver RS-485 Communication Type
USER MANUAL

2
1 Introduction ............................................. 3
1-1 Before using the product................................3
1-2 Operating manuals ...........................................3
1-3 Overview of the product.................................5
1-4 System conguration.......................................5
2 Safety precautions .................................. 6
3 Precautions for use.................................. 8
4 Preparation............................................. 10
4-1 Checking the product ................................... 10
4-2 How to identify the product model ......... 10
4-3 Products possible to combine ................... 10
4-4 Information about nameplate ................... 10
4-5 Names and functions of parts.................... 11
4-6 Indication of LEDs........................................... 12
5 Installation.............................................. 13
5-1 Location for installation................................ 13
5-2 Installation method ....................................... 13
6 Connection ............................................. 15
6-1 Connection example..................................... 15
6-2 Connecting the main power supply
and the control power supply (CN1) ....... 16
6-3 Connecting the RS-485 communication
cable (CN3)........................................................ 18
6-4 Connecting the USB cable........................... 20
6-5 Noise measures ............................................... 20
6-6 Conformity to EMC......................................... 21
7 Setting of switches................................ 23
7-1 Protocol.............................................................. 23
7-2 Transmission rate............................................ 23
7-3 Address number (slave address) ............... 24
7-4 Termination resistor....................................... 25
8 ID share mode ........................................ 26
8-1 Overview of ID share mode ........................ 26
8-2 Flow of setting of ID share mode.............. 28
8-3 Setting of share group.................................. 29
8-4 Setting of data to be read or written....... 31
8-5 Executing read/write..................................... 37
9 Addresses and codes lists .................... 46
9-1 Addresses and codes specic to the
mini Driver......................................................... 46
9-2 Addresses and codes not compatible
with the mini Driver....................................... 52
9-3 I/O signals assignment list........................... 53
10 Inspection and maintenance .............. 56
10-1 Inspection.......................................................... 56
10-2 Warranty............................................................. 56
10-3 Disposal.............................................................. 56
11 Troubleshooting .................................... 57
11-1 Detection of communication errors ........ 57
11-2 Alarm................................................................... 59
11-3 Information....................................................... 60
11-4 Troubleshooting and remedial actions .. 61
12 Cables ...................................................... 63
12-1 Connection cables.......................................... 63
12-2 RS-485 communication cables .................. 65
13 Reference materials .............................. 66
13-1 Timing chart ..................................................... 66
13-2 Specications................................................... 68
13-3 Regulations and standards.......................... 68

Introduction
3
1 Introduction
1-1 Before using the product
Only qualied personnel of electrical and mechanical engineering should work with the product.
Use the product correctly after thoroughly reading the section “2 Safety precautions”on p.6. In addition, be sure to
observe the contents described in warning, caution, and note in this manual.
The product described in this manual is designed and manufactured to be incorporated in general industrial
equipment. Do not use for any other purpose. Oriental Motor Co., Ltd. is not responsible for any compensation for
damage caused through failure to observe this warning.
1-2 Operating manuals
Related operating manuals
For operating manuals, download from Oriental Motor Website Download Page or contact your nearest Oriental
Motor sales oce.
•AZ Series/ /Motorized Actuator equipped with AZ Series mini Driver
RS-485 Communication Type USER MANUAL (this document)
•AZ Series/Motorized Actuator equipped with AZ Series
OPERATING MANUAL Function Edition
Read the following operating manuals for motors and motorized actuators.
•OPERATING MANUAL Motor Edition
•OPERATING MANUAL Actuator Edition
•Motorized Actuator OPERATING MANUAL Function Setting Edition
How to use operating manuals
To use the product, read this manual together with the AZ Series OPERATING MANUAL Function Edition.
This manual describes contents specic to the mini Driver RS-485 communication type, and the AZ Series OPERATING
MANUAL Function Edition describes contents common to the AZ Series products. Refer to the AZ Series OPERATING
MANUAL Function Edition for the contents not included in this manual.
For each control method, reference destinations are indicated according to the ow of use.
zHow to read reference destinations
The title name of the operating manual is described in the reference destination.
The title number described in the reference destination may be changed. Use the title name when
checking the reference destination.
Reference destination in this manual
Reference destination in
AZ Series OPERATING MANUAL Function Editio
n
Procedure
8 ID share mode
Setting of parameters
4 Parameters
5 Method of control via Modbus RTU
(RS-485 communication)
7 Address/code lists

Introduction
4
zWhen controlling with Modbus RTU (RS-485 communication)
5 Installation
6 Connection
Installation and connection
7 Setting of switches
Setting of switches
8 ID share mode
9 Address and code lists
Setting of parameters Operation
1 Before starting operation *1
4 Parameters
5 Method of control via Modbus RTU
(RS-485 communication)
7 Address/code lists
2 Operation
3 I/O signals
5 Method of control via Modbus RTU
(RS-485 communication)
8 Measures for various cases
11 Appendix *2
Before starting operation
*1 When a motorized actuator is used, the following contents cannot be operated via RS-485 communication. Use the
support software MEXE02.
· Copying the xed value (parameter) of the ABZO sensor to driver
· Creation of recovery data le and method of recovery
*2 Refer to this manual for“LEDs of the driver.”(_p.12)
zWhen controlling via industrial network
Before starting operation
5 Installation
6 Connection
Installation and connection
7 Setting of switches
Setting of switches
9 Address and code lists
Setting of parameters
4 Parameters
6 Method of control via
industrial network
7 Address/code lists
Operation
2 Operation
3 I/O signals
6 Method of control via
industrial network
8 Measures for various cases
11 Appendix *2
1 Before starting operation *1
*1 When a motorized actuator is used, the following contents cannot be operated via industrial network. Use the
support software MEXE02.
· Copying the xed value (parameter) of the ABZO sensor to driver
· Creation of recovery data le and method of recovery
*2 Refer to this manual for“LEDs of the driver.”(_p.12)
Description of power supplies
This manual describes contents when a main power supply and a control power supply are used.
The mini Driver can also be used with a main power supply only.
When using it with only the main power supply, replace“main power supply and control power supply” or“control
power supply” with “main power supply” to read this manual.

Introduction
5
1-3 Overview of the product
The AZ Series mini Driver RS-485 communication type is the dedicated driver for the AZ Series products.
zCompact and light weight
Compact and lightweight are achieved, oering the dimensions of 47×53×24 mm (1.85×2.09×0.94 in.) and the mass
of 56 g (1.98 oz.).
zCompatible with network communications
With Modbus RTU (RS-485 communication) or via industrial networks using an Oriental Motor’s network converter,
operation data and parameters can be set, and also executing and stopping operation can be controlled.
Operation data and parameters can also be set using the support software MEXE02.
1-4 System conguration
Control power supply *1 Circuit breaker *2
Circuit breaker *2
Noise lter
A
C power supply
Host controller
RS-485
communication
RS-485 communication
compatible product
PC in which the MEXE02
has been installed Driver
Motor
Main power supply
*1 Connecting the control power supply allows you to continue monitoring even if the main power supply is shut o.
Connect it as necessary.
*2 It is recommended that a circuit breaker or a circuit protector is connected because incorrect wiring may cause the
internal input circuit to short-circuit.

Safety precautions
6
2 Safety precautions
The precautions described below are intended to ensure the safe and correct use of the product, and to prevent the
user and other personnel from exposure to the risk of injury. Use the product only after carefully reading and fully
understanding these instructions.
Handling the product without observing the instructions that accompany a“WARNING”
symbol may result in serious injury or death.
Handling the product without observing the instructions that accompany a“CAUTION”
symbol may result in injury or property damage.
The items under this heading contain important handling instructions that the user
should observe to ensure safe use of the product.
The items under this heading contain related information and contents to gain a further
understanding of the text in this manual.
General
•Do not use the product in explosive or corrosive environments, in the presence of ammable gases, locations
subjected to splashing water, or near combustibles. Doing so may result in re, electric shock, or injury.
•Assign qualied personnel to the task of installing, wiring, operating/controlling, inspecting and troubleshooting
the product. Handling by unqualied personnel may result in re, electric shock, injury or damage to equipment.
•Do not transport, install, connect or inspect the product while the power is supplied. Doing so may result in electric
shock.
•Do not touch the driver while the power is on. Doing so may result in re or electric shock.
•When the driver generates an alarm (any of the driver's protective functions is triggered), rst remove the cause
and then clear the protective function. Continuing the operation without removing the cause of the problem may
cause malfunction of the motor and driver, leading to injury or damage to equipment.
Installation
•Install the driver in an enclosure. Failure to do so may result in electric shock or injury.
Connection
•Keep the input power voltage of the driver within the specied range. Failure to do so may result in re or electric
shock.
•Connect the product securely according to the wiring diagram. Failure to do so may result in re or electric shock.
•Do not forcibly bend, pull, or pinch the connection cable. Doing so may result in re or electric shock.
Operation
•Turn o the main power supply and control power supply in the event of a power failure. Failure to do so may
result in injury or damage to equipment.
•Do not remove the motor excitation during operation. Doing so may cause the motor to stop and lose the holding
force, resulting in injury or damage to equipment.
Repair, disassembly and modication
•Do not disassemble or modify the driver. Doing so may result in injury or damage to equipment.

Safety precautions
7
General
•Do not use the driver beyond the specications. Doing so may result in electric shock, injury, or damage to
equipment.
•Keep your ngers and objects out of the openings in the driver. Failure to do so may result in re, electrical shock,
or injury.
•Do not touch the driver while operating or immediately after stopping. Doing so may result in a skin burn(s).
•Do not forcibly bend or pull the cable that is connected to the driver. Doing so may cause damage to the product.
Installation
•Keep the area around the driver free of combustible materials. Failure to do so may result in re or a skin burn(s).
•Do not leave anything around the driver that would obstruct ventilation. Doing so may result in damage to
equipment.
Operation
•Use a motor and a driver only in the specied combination. An incorrect combination may cause a re.
•Take measures against static electricity when operating the switches of the driver. Failure to do so may result in the
driver malfunction or damage to equipment.
•Provide an emergency-stop device or emergency-stop circuit external to the equipment so that the entire
equipment will operate safely in the event of a system failure or malfunction. Failure to do so may result in injury.
•When moving the moving part by hands, put the motor into a non-excitation state. Operating in a state where the
motor is excited may cause injury.
•For the main power supply and control power supply, use a DC power supply with reinforced insulation on its
primary and secondary sides. Failure to do so may result in electric shock.
•When an abnormal condition has occurred, immediately stop operation to turn o the main power supply and
control power supply. Failure to do so may result in re, electrical shock, or injury.

Precautions for use
8
3 Precautions for use
This chapter explains restrictions and requirements the user should consider when using the product.
zAlways use Oriental Motor cables to connect a motor and a driver.
Refer to the cable models on p.63.
zWhen conducting the insulation resistance measurement or the dielectric strength test, be sure to
separate the connection between the motor and the driver.
Conducting the insulation resistance measurement or dielectric strength test with the motor and driver connected
may result in damage to the product.
zNote when connecting a main power supply and a control power supply in a state of grounding the
positive side
The USB communication connector, CN1, CN2, and CN3 connectors on the driver are not electrically insulated. When
grounding the positive terminals of a main power supply and a control power supply, do not connect any equipment
(PC, etc.) whose negative terminal is grounded. Doing so may cause the driver and this equipment to short, damaging
both. When connecting, do not ground equipment.
zSaving data to the non-volatile memory
Do not turn o the control power supply while writing the data to the non-volatile memory, and also do not turn o
for ve seconds after the completion of writing the data. Doing so may abort writing the data and cause an alarm of
EEPROM error to generate. The non-volatile memory can be rewritten approximately 100,000 times.
zNoise elimination measures
Refer to p.20 for the noise elimination measures.
zRegeneration
When operating a large load inertia at a high speed, the regenerative energy generated may increase the voltage of
the main power supply, causing an alarm of the overvoltage to generate. To prevent damage to the driver, reconsider
the operating conditions so that regenerative voltage does not generate.
Notes when the connection cable is used
Note the following points when an Oriental Motor cable is used.
zWhen inserting the connector
Hold the connector main body, and insert it in straight securely. Inserting the connector in an inclined state may result
in damage to terminals or a connection failure.
zWhen pulling out the connector
Pull out the connector in straight while releasing the lock part of the connector. Pulling out the connector with
holding the cable may result in damage to the connector.
zBending radius of cable
Use the cable in a state where the bending radius of the cable is more than
6 times of the cable diameter.
Do not bend the lead wires part or secure with a clamp, etc. Doing so may
result in damage to the connector.
More than 6 times
of cable diameter.
Do not bend the
lead wires part.

Precautions for use
9
zHow to x the cable
Fix the cable near the connectors at two places as shown in the gure or x it with a wide clamp to take measures to
prevent stress from being applied to the connectors.
Motor
Driver
In the case of a exible cable,
this area is a movable range.
Fixing at two places.
Fixing at two places.
Do not bend the lead wires
part or secure with a clamp.

Preparation
10
4 Preparation
4-1 Checking the product
Verify that the items listed below are included. Report any missing or damaged items to the Oriental Motor sales
oce from which you purchased the product.
•Driver ............................................................................... 1 unit
•Instructions and Precautions for Safe Use.......... 1 copy
4-2 How to identify the product model
Check the driver model against the model shown
on the nameplate. Refer to “4-4 Information about
nameplate” for how to identify the nameplate.
AZD - K R 2 D
1 2 3 4 5
1 Series AZD: AZ Series driver
2 Power supply input K: DC power input
3 Driver gure R: Compact
4 Reference number
5 Type D: RS-485 communication type
4-3 Products possible to combine
Products with which the driver can be combined are listed below. Check the model name of the product with the
nameplate.
Power supply
type Product type Applicable Series Model name representing Series name *1 Example of model name
DC power
input
Stepping motor AZ Series AZM AZM46AK
Motorized
actuator
EAC Series *2 EACM EACM2E05AZAK
EAS Series *2 EASM EASM4NXD005AZAK
EZS Series *2 EZSM EZSM6D005AZAK
DR Series DR DR28G2.5B03-AZAKU
DRS2 Series DRSM DRSM60-05A4AZAK
DGII Series *2 DGM
DGB
DGM85R-AZAK
DGB85R12-AZAKR
EH Series *2 EH EH4-AZAKH
LSeries *2 LM LM4F150AZAK-1
*1 The driver described in this manual can be combined with products that begin with these model names.
*2 For these motorized actuators, the equipped motors have been evaluated to ax the CE Marking. The model name
of the equipped motor can be checked as follows.
EAC Series, EAS Series, EZS Series: Check with the motor nameplate.
DGII Series, EH Series, LSeries: Check with “P/N (Motor P/N)” described on the actuator nameplate.
4-4 Information about nameplate
The gure shows an example.
Driver model
Serial number
Manufac
turing date

Preparation
11
4-5 Names and functions of parts
Function setting
switches (SW1)
POWER/ALARM LED
(Green/Red/Blue)
C-DAT/C-ERR LED
(Green/Red)
Cutouts (2 places)
USB communication
connec
tor
Power supply
connector (CN1) Motor/encoder/
electromagnetic brake
connector (CN2)
RS-485 communication
connector (CN3)
Heat sink
Address number
setting switch (SW2)
Termination
resistor
setting switch (SW3)
Type Name Description
LED
C-DAT/C-ERR LED (Green/Red) This LED indicates the status of RS-485 communication.
POWER/ALARM LED
(Green/Red/Blue) This LED indicates the status of the driver.
Switch
Function setting switch (SW1)
•No.1: Sets the address number (slave address) of RS-485
communication using together with the address
number setting switch (SW2).
Factory setting: OFF
•No.2: Sets the RS-485 communication protocol.
Factory setting: ON
•No.3: Sets the transmission rate of RS-485 communication.
Factory setting: ON
•No.4: Not used.
Address number setting switch
(SW2)
Sets the address number (slave address) of RS-485
communication using together with the function setting
switch SW1-No.1.
Factory setting: 1
Termination resistor setting switch
(SW3)
Sets the termination resistor (120 Ω) of RS-485
communication.
Factory setting: OFF
Connector
Power supply connector (CN1) Connects a main power supply and a control power supply.
Motor/encoder/electromagnetic
brake connector (CN2) Connects the motor, encoder, and electromagnetic brake.
RS-485 communication connector
(CN3) Connects the RS-485 communication cable.
USB communication connector Connects a PC in which the MEXE02 has been installed.
(USB2.0 mini-B port)

Preparation
12
4-6 Indication of LEDs
The status of the driver and RS-485 communication can be checked using the indication of LEDs.
The lighting colors of the POWER/ALARM LED and the C-DAT/C-ERR LED can be changed from green
to white using the“LED (PWR/C-DAT) color changing” parameter.
POWER/ALARM LED
This LED indicates the status of the driver.
LED status Description
No light The main power supply and the control power supply are not turned on.
Green light The main power supply and/or the control power supply are turned on.
Blinking red
An alarm is being generated. The alarm message generated can be checked by
counting the number of times the LED blinks.
The LED is lit in green when the alarm is reset.
Blinking blue Information is being generated. The LED is lit in green when the information is
cleared.
Repeating “Green →Red →
Simultaneously lit * →No light” This is the driver simulation mode.
* Green and red colors may overlap and it may be visible to yellow.
C-DAT/C-ERR LED
This LED indicates the status of RS-485 communication.
LED status Description
Green light or
blinking green The driver communicates with the host controller properly via RS-485 communication.
Red light
An error occurs in communication with the host controller via RS-485 communication.
The LED will be lit or blink in green when the communication status returns to the
normal state.

Installation
13
5 Installation
5-1 Location for installation
The driver is designed and manufactured to be incorporated in equipment. Install it in a well-ventilated location that
provides easy access for inspection. The location must also satisfy the following conditions:
•Inside an enclosure that is installed indoors (provide vent holes)
•Operating ambient temperature: 0 to +50 °C [+32 to +122 °F] (non-freezing)
•Operating ambient humidity: 85 % or less (non-condensing)
•Area free of explosive atmosphere, toxic gas (such as sulfuric gas), or liquid
•Area not exposed to direct sun
•Area free of excessive amount of dust, iron particles or the like
•Area not subject to splashing water (rain, water droplets), oil (oil droplets) or other liquids
•Area free of excessive salt
•Area not subject to continuous vibration or excessive shocks
•Area free of excessive electromagnetic noise (from welders, power machinery, etc.)
•Area free of radioactive materials, magnetic elds or vacuum
•Up to 1,000 m (3,300 ft.) above sea level
5-2 Installation method
The driver can be installed in any direction.
Install the driver onto a at metal plate oering high heat conductivity [material: aluminum, 150×150×2 mm
(5.91×5.91×0.08 in.) or equivalent].
When installing the driver, use the cutouts for mounting and secure to the metal plate with two screws (M3: not
included).
Metal plate
Screws (M3)
Ti
ghtening torque: 0.5 N·m (71 oz-in)
•Install the driver in an enclosure.
•Do not install any equipment that generates a large amount of heat or noise near the driver.
•Do not install the driver underneath a host controller or other equipment sensitive to heat.
•If the ambient temperature of the driver exceeds 50 °C (122 °F), reconsider the ventilation
conditions such as providing forced cooling by using fans.

Installation
14
Dimensions [Unit: mm (in.)]
Mass: 56 g (1.98 oz.)
41 (1.61)
47 (1.85) 53 (2.09)
R1.75
(0.069)
R1.75 (0.069)
[40 (1.57)]
47 (1.85)
3 (0.12)
3 (0.12)
2 (0.08)
24 (0.94)0.25 (0.01)

Connection
15
6 Connection
This chapter explains a connection example of a driver and a motor, connection methods of a main power supply and
a control power supply, and others.
It also explains installation and wiring methods to conform to the EMC as well as measures against electrical noise.
For protection against electric shock, do not turn on the main power supply and the
control power supply until the wiring is completed.
6-1 Connection example
The gure shows an example when the AZM14 motor is connected.
Control
power supply *2
Main
power supply
Connect to CN3
Circuit
breaker *3
Circuit
breaker *3
Motor
Host controller
Driver
Connect to CN2
Connection cable *1
Required
Connect to CN1
Connect to CN1
RS-485 communication cable
*1 It is an Oriental motor cable. Purchase is required separately.
*2 Connecting the control power supply allows you to continue monitoring even if the main power supply is shut o.
Connect it as necessary.
*3 It is recommended that a circuit breaker or a circuit protector is connected because incorrect wiring may cause the
internal input circuit to short-circuit.
•Connect the connectors securely. Insecure connections may cause malfunction or damage to the
motor or driver.
•When connecting the cables, secure them so that no load is applied to the CN1 to CN3 connectors.
Applying a load to the connector may result in a connection failure, causing the driver to
malfunction.
•Keep 10 m (32.8 ft.) or less for the wiring distance between a motor and a driver. Exceeding 10 m
(32.8 ft.) in the wiring distance may result in increase of the electrical noise emitted from the driver.
•Keep 2 m (6.6 ft.) or less for the cable length of the main power supply and control power supply.
•Before connecting or disconnecting a connector, turn o the main power supply and the control
power supply, and check the POWER/ALARM LED has been turned o.
•When disconnecting the connector, pull out while pressing the latches on the connector with
ngers.
•GND of the power supply connector and SG of the RS-485 communication connector are
electrically insulated.

Connection
16
6-2 Connecting the main power supply and the control power supply
(CN1)
Connect a main power supply to the CN1 connector.
Connecting the control power supply allows you to continue monitoring even if the main power supply is shut o.
Connect it as necessary.
Make sure the polarity of the power supply before connecting. Reverse-polarity connection may
cause damage to the driver.
Applicable connector
Type Part number Applicable lead wire
Connector housing 1-1827864-2 (TE Connectivity) AWG22 (0.34 to 0.37 mm2)
AWG20 (0.51 to 0.53 mm2)
AWG18 (0.85 to 0.87 mm2)
Lead wire insulation outer diameter:
ø1.4 to 2.2 mm (ø0.055 to 0.087 in.)
Lead wire insulation strip length:
1.7 to 2.3 mm (0.067 to 0.091 in.)
Contact 1827589-2 (TE Connectivity)
Designated crimp tool 2119142-1 (TE Connectivity)
Pin assignment
The gure shows the view from the insertion side of contacts.
Pin No. Name Description
A1 GND Ground
A2 GND Ground
B1 Control power supply +24 VDC/+48 VDC
B2 Main power supply +24 VDC/+48 VDC
B1
A1
B2
A2
A1 and A2 are not electrically insulated.
Voltage specications
The voltage specications of power supply input include the rated voltage and the allowable operating voltage.
The voltage specications are common for the main power supply and the control power supply.
Rated voltage 24 VDC±5 %
48 VDC±5 %
Allowable operating voltage 24 VDC input: 20 to 32 VDC (22.8 to 32 VDC) *
48 VDC input: 40 to 55 VDC
* The value in parentheses ( ) is the one when the electromagnetic brake motor is connected.
Set the “main power mode”parameter to “0: 24 VDC” or “1: 48 VDC” when the main power supply
starts up slowly or the voltage of the main power supply is unstable. (_p.50)

Connection
17
Internal input circuit
The driver can be used with the main power supply and control power supply, or with the main power supply only.
When using only the main power supply, the power is supplied from the main power supply to the control power
supply circuit inside the driver.
Main power supply input
24/48 VDC
GND
Control power supply input
24/48 VDC
GND
Power supply current capacity
zCurrent capacity for main power supply
The current capacity for the main power supply varies depending on the product combined.
Check the current capacity in reference to the equipped motor model name when using the EAC Series, EAS Series,
or EZS Series.
Series Model Rated voltage Power supply
current capacity
AZ Series
EAC Series
EAS Series
EZS Series
AZM14
24 VDC±5 %
0.4 A or more
AZM15 0.5 A or more
AZM24, AZM26 1.4 A or more
AZM46
24 VDC±5 %
48 VDC±5 %
1.6 A or more
AZM48 2.1 A or more
AZM66 3.7 A or more
AZM69 3.5 A or more
DGII Series
DGM60 24 VDC±5 % 1.4 A or more
DGB85
24 VDC±5 %
48 VDC±5 %
1.6 A or more
DGB130 3.7 A or more
DGM85 1.6 A or more
DGM130 3.7 A or more
DR Series DR20 24 VDC±5 % 0.4 A or more
DR28 1.3 A or more
DRS2 Series DRSM42 24 VDC±5 %
48 VDC±5 %
1.5 A or more
DRSM60 2.6 A or more
EH Series EH3 24 VDC±5 % 0.4 A or more
EH4 1.4 A or more
LSeries LM2, LM4 24 VDC±5 %
48 VDC±5 % 3.7 A or more
zCurrent capacity for control power supply
Rated voltage Power supply current capacity
Without electromagnetic brake With electromagnetic brake
24 VDC±5 %
48 VDC±5 % 0.15 A 0.4 A *
* The AZM46 type is 0.23 A.

Connection
18
6-3 Connecting the RS-485 communication cable (CN3)
Connect the RS-485 communication cable to the CN3 connector.
A cable to connect with the host controller and that to connect between drivers are required to be provided by the
customer. Cables that connect to the network converter or the robot controller MRC01 are provided by Oriental
Motor separately. Refer to p.65 for the model name.
Applicable connector
Type Part number Applicable lead wire
Connector housing 1-1827579-1 (TE Connectivity) AWG28 (0.08 mm2)
AWG26 (0.12 mm2)
AWG24 (0.2 mm2)
AWG22 (0.37 mm2)
Lead wire insulation outer diameter:
ø1.08 to 1.9 mm (ø0.043 to 0.075 in.)
Lead wire insulation strip length:
1.7 to 2.3 mm (0.067 to 0.091 in.)
Contact 1827588-2 (TE Connectivity)
Designated crimp tool 2119143-1 (TE Connectivity)
Pin assignment
The gure shows the view from the insertion side of contacts.
Pin No. Signal name Description
A1 SG1 Ground 1 for RS-485 communication
A2 SG2 Ground 2 for RS-485 communication
B1 TR1− Negative side of signal 1 for RS-485 communication
B2 TR2− Negative side of signal 2 for RS-485 communication
C1 TR1+ Positive side of signal 1 for RS-485 communication
C2 TR2+ Positive side of signal 2 for RS-485 communication
C1
B1
C2
B2
A1 A2
SG1 and SG2, TR1− and TR2−, and TR1+ and TR2+ are internally connected.

Connection
19
Internal input circuit
GND of the power supply connector and SG of the RS-485 communication connector are electrically insulated.
SW3 is a double-pole double-throw switch.
Driver 1st unit
SG
RS-485
*1
SG
TR+
TR−
SG
TR+
TR−
120 Ω
1 kΩ
1 kΩ
5 V
SG
SG
SW3 SW3
Driver 2nd unit
SG
TR+
TR−
SG
TR+
TR−
120 Ω
1 kΩ
1 kΩ
5 V
SG
SG
SW3 SW3
Driver 31st unit
SG
TR+
TR−
120 Ω
1 kΩ
1 kΩ
5 V
SG
SG
SW3 SW3
*2 *2
*1 Termination resistor 120 Ω
*2 Turn the termination resistor ON.

Connection
20
6-4 Connecting the USB cable
Using a USB cable with the following specications, connect a PC in which the MEXE02 has been installed to the USB
communication connector.
Specications USB2.0 (Full speed)
Cable Length: 3 m (9.8 ft.) or less
Shape: A to mini B
•Connect the driver and a PC directly using a USB cable.
•In large electrically noisy environments, use the USB cable with a ferrite core or install a ferrite core
to the USB cable.
6-5 Noise measures
There are two types of electrical noises: One is a noise to invade into the driver from the outside and cause the driver
malfunction, and the other is a noise to emit from the driver and cause peripheral equipment malfunction.
For the noise that is invaded from the outside, take measures to prevent the driver malfunction. It is needed to take
adequate measures because signal lines are very likely to be aected by the noise.
For the noise that is emitted from the driver, take measures to suppress it.
Measures against electrical noise
There are the following three methods mainly to take measures against the electrical noise.
zNoise suppression
•When relays or electromagnetic switches are used, use noise lters or CR circuits to suppress surge generated by
them.
•Use an Oriental Motor connection cable when extending the wiring distance between a motor and a driver. Refer
to p.63 for the model name. This is eective in suppressing the electrical noise emitted from the motor.
•Cover the driver by a metal plate such as aluminum. This is eective in shielding the electrical noise emitted from
the driver.
zPrevention of noise propagation
•Connect a noise lter on the input side of the DC power supply.
•Place the power lines, such as the motor and power supply cables, keeping a distance of 200 mm (7.87 in.) or more
from the signal lines, and also do not bundle them or wire them in parallel. If a power cable and a signal cable have
to cross, cross them at a right angle.
•Use shielded twisted pair cables for power lines and signal lines.
•Keep cables as short as possible without coiling and bundling extra lengths.
•Grounding multiple points will increase eect to block electrical noise because impedance on the grounding
points is decreased. However, ground them so that a potential dierence does not occur among the grounding
points.
•To ground a shielded cable, use a metal cable clamp that can maintain
contact with the entire circumference of the shielded cable, and ground
as near the product as possible.
Cable clamp
Shielded cable
zSuppression of eect by noise propagation
•Loop the noise propagated cable around a ferrite core. Doing so will prevent the propagated noise invades into
the driver or emits from the driver. The frequency band in which an eect by the ferrite core can be seen is
generally 1 MHz or more. Check the frequency characteristics of the ferrite core used. When increasing the eect of
noise attenuation by the ferrite core, loop the cable a lot.
