Oriental motor CVD Series User manual

1
Introduction
Before use
Only qualied personnel of electrical and mechanical engineering should work with the
product.
Use the product correctly after thoroughly reading the section “Safety precautions.” In
addition, be sure to observe the contents described in warning, caution, and note in this
manual.
The product described in this manual is designed and manufactured to be incorporated
in general industrial equipment. Do not use for any other purpose. Oriental Motor Co.,
Ltd. is not responsible for any compensation for damage caused through failure to
observe this warning.
Related operating manuals
For operating manuals not included with the product, contact your nearest Oriental
Motor sales oce or download from Oriental Motor Website Download Page.
Operating manual name Included or not included
with product
CVD Series RS-485 communication type
OPERATING MANUAL Driver Edition (this document) Included
CVD Series RS-485 communication type
USER MANUAL Not included
CVD Series RS-485 communication type
OPERATING MANUAL Function Edition Not included
Safety precautions
The precautions described below are intended to ensure the safe and correct use of the
product, and to prevent the customer and others from exposure to the risk of injury. Use
the product only after carefully reading and fully understanding these instructions.
Handling the product without observing the instructions that
accompany a“WARNING”symbol may result in serious injury
or death.
Handling the product without observing the instructions
that accompany a“CAUTION”symbol may result in injury or
property damage.
The items under this heading contain important handling
instructions that the user should observe to ensure the safe
use of the product.
The items under this heading contain related information and
contents to gain a further understanding of the text in this
manual.
HM-60393
OPERATING MANUAL
Thank you for purchasing an Oriental Motor product.
This Operating Manual describes product handling procedures and safety precautions.
yPlease read it thoroughly to ensure safe operation.
yAlways keep the manual where it is readily available.
Drivers for 2-Phase, 5-Phase Stepping Motors
CVD Series RS-485 communication type
Driver Edition
General
yDo not use the driver in explosive or corrosive environments, in the presence of
ammable gases, locations subjected to splashing water, or near combustibles. Doing
so may result in re, electric shock or injury.
yAssign qualied personnel to the task of installing, wiring, operating/controlling,
inspecting, and troubleshooting the driver. Failure to do so may result in re, electric
shock, injury or damage to equipment.
yWhen an alarm is generated in the driver (any of the driver’s protective functions
is triggered), remove the cause before clearing the alarm (protective function).
Continuing the operation without removing the cause of the problem may cause
malfunction of the motor and driver, leading to injury or damage to equipment.
Installation
yInstall the driver inside an enclosure. Failure to do so may result in electric shock or
injury.
Connection
yAlways keep the power supply voltage of the driver within the specied range. Failure
to do so may result in re or electric shock.
yConnect the cables securely according to the wiring diagram. Failure to do so may
result in re or electric shock.
yDo not forcibly bend, pull, or pinch the cable. Doing so may result in re or electric
shock.
Operation
yTurn o the main power supply in the event of a power failure. Failure to do so may
result in injury or damage to equipment.
yDo not remove the motor excitation during operation. Doing so may cause the motor
to stop and lose the holding force, resulting in injury or damage to equipment.
yFor a main power supply, use a DC power supply with reinforced insulation on its
primary and secondary sides. Failure to do so may result in electric shock.
Repair, disassembly and modication
yDo not disassemble or modify the driver. Doing so may result in injury or damage to
equipment.
General
yDo not use the driver beyond its specications. Doing so may result in electric shock,
injury, or damage to equipment.
yDo not insert a nger or an object between the board and the heat sink. Doing so may
result in re, electric shock, or injury.
yDo not touch the driver during operation or immediately after stopping. Doing so may
result in a skin burn(s).
yDo not forcibly bend or pull the cable that is connected to the driver. Doing so may
result in damage to the product.
Installation
yDo not place combustibles around the driver. Doing so may result in re or a skin
burn(s).
yDo not leave anything around the driver that would obstruct ventilation. Doing so
may result in damage to equipment.
Operation
yUse a motor and driver only in the specied combination. An incorrect combination
may cause a re.
yProvide an emergency stop device or emergency stop circuit external to the
equipment so that the entire equipment will operate safely in the event of a system
failure or malfunction. Failure to do so may result in injury.
yBefore supplying main power to the driver, turn all input signals to the driver to OFF.
Failure to do so may result in injury or damage to equipment.
Introduction .............................................. 1
Safety precautions .................................. 1
Precautions for use ................................. 2
Preparation................................................ 2
Installation ................................................. 3
Connection................................................ 4
Setting......................................................... 7
Alarms.......................................................... 7
Inspection and maintenance .............. 7
Specications............................................ 8
Regulations and standards .................. 8

2
yWhen moving the moving part manually, put the motor into a non-excitation state.
Continuing the work while the motor is in an excitation state may result in injury.
yImmediately when a problem occurred, stop operation and turn o the main power
supply. Failure to do so may result in re, electric shock, or injury.
Precautions for use
This section covers restrictions and requirements the user should consider when using
the product.
•When conducting the insulation resistance measurement or the
dielectric strength test, be sure to separate the connection between the
motor and the driver.
Conducting the insulation resistance measurement or dielectric strength test with the
motor and driver connected may result in damage to the product.
•Note on connecting a power supply whose positive terminal is grounded
The USB communication connector (CN3) of the driver is not electrically insulated. When
grounding the positive terminal of the power supply, do not connect any equipment
(PC, etc.) whose negative terminal is grounded. Doing so may cause the driver and these
equipment to short, damaging both. When connecting, do not ground equipment.
•Storing data in non-volatile memory
Do not turn o the main power supply while writing the data to the non-volatile
memory, and also do not turn o for 5 seconds after the completion of writing the
data. Doing so may abort writing the data and cause an alarm of the EEPROM error to
generate. The non-volatile memory can be rewritten approximately 100,000 times.
•Noise elimination measures
Refer to the USER MANUAL for the noise elimination measures.
•Regeneration
When a large load inertia is operated at a high speed, the power supply voltage may
increase by the regenerative energy generated, causing an alarm of overvoltage to
generate. This may result in damage to the driver, so reconsider the operating condition
so as not to generate the regenerative voltage.
Preparation
Package contents
Verify that the items listed below are included. Report any missing or damaged items to
the Oriental Motor sales oce from which you purchased the product.
yDriver............................................................................ 1 unit
yOPERATING MANUAL Driver Edition................. 1 copy (this document)
When taking out the driver from the electrostatic discharge (ESD) protection
bag, make sure your hands are not charged with static electricity. Static
electricity may cause damage to the driver.
How to identify the product model
Check the model name of the driver against the number shown on the nameplate. Refer
to “Information about nameplate” for how to identify the nameplate.
CVD 2 B R - K R
1 2 3 4 5 6
1 Series CVD: CVD Series
2Number of phases of motor 2: 2-phase
5: 5-phase
3 Driver shape B: Driver with mounting plate
4 Connector shape R: Right angle
Blank: Vertical
5 Power supply input K: DC power supply
6 Type R: RS-485 communication type
Information about nameplate
The gure shows an example.
Driver model
Serial number
Manufac
turing date
The position describing the information may vary depending on the product.
Products possible to combine
Products with which the driver can be combined are listed below. Check the model name
of the product with the nameplate.
Driver model Product type Applicable
Series Motor model *1
CVD2B-KR
CVD2BR-KR
2-phase stepping motor
bipolar PKP Series
PKP213D05
PKP214D06
PKP22D15
PKP22D152
PKP23D15
PKP23D23
PKP24D082
PKP24D152
PKP24D232
PKP24MD152
PKP25D28A2
PKP262FD15A
PKP26D142
PKP26D282
PKP26MD282
CVD5B-KR
CVD5BR-KR 5-phase stepping motor
PKP Series
PKP52
PKP54MN
PKP54N182
PKP56FMN
PKP56FN242
PK Series
PK513
PK52H
PK52P
PK54
PK56*2
*1 The motor model column in the table describes part of the entire name of models.
Drivers can be combined with motors that include the model names listed here.
The box () in the motor model indicates a number representing the motor length.
The box () in the motor model indicates A(single shaft) or B(double shaft)
representing the shape.
*2 Only motors with rated current of 1.4 A/phase. Motors other than 1.4 A/phase cannot
be combined.
Names and functions of parts
The gure shows the driver which connector shape is of right angle.
Power supply
connector (CN1)
Motor connector (CN2
)
USB communication
connector (CN3)
RS-485 communication
connectors (CN4, CN5)
C-DAT/C-ERR LED (Green/Red)
Cutouts for mounting A
(4 places)
PWR/ALM LED (Green/Red)
Termination resistor
setting switch (SW2)
I/O signal connec
tor
(
CN6)
Motor setting
switch (SW1)
Cutouts for mounting B (2 places)
Name Description
PWR/ALM LED
(Green/Red)
yThis LED is lit in green while the main power supply is
turned on.
yIf an alarm (protective function) is generated, the LED
will blink in red.
yIf information is generated, the LED will simultaneously
blink in red and green twice. (Green and red colors may
overlap and it may be visible to orange.)
C-DAT/C-ERR LED
(Green/Red)
yThis LED will blink or illuminate in green when the
driver is communicating with the host controller
properly via RS-485 communication.
yThis LED will be lit in red if a RS-485 communication
error occurs with the host controller.
Motor setting switch (SW1) Sets an applicable motor.
Factory setting: 0
Termination resistor setting
switch (SW2)
Sets the termination resistor (120 Ω) of RS-485
communication.
Factory setting: OFF for both No.1 and No.2
(termination resistor disabled)

3
Name Description
Power supply connector
(CN1) Connects the main power supply.
Motor connector (CN2) Connects the motor.
USB communication
connector (CN3)
Connects a PC in which the support software MEXE02
has been installed. (USB2.0 mini-B port)
RS-485 communication
connectors (CN4, CN5)
Connects the RS-485 communication compatible
product.
I/O signal connector (CN6) Connects when using direct I/O or sensors.
Installation
Installation location
The driver is designed and manufactured to be incorporated in equipment.
Install it in a well-ventilated location that provides easy access for inspection. The
location must also satisfy the following conditions:
yInside an enclosure that is installed indoors (provide vent holes)
yOperating ambient temperature 0 to +50 °C (+32 to +122 °F) (non-freezing)
yOperating ambient humidity 85 % or less (non-condensing)
yArea free of explosive atmosphere or toxic gas (such as sulfuric gas) or liquid
yArea not exposed to direct sun
yArea free of excessive amount of dust, iron particles or the like
yArea not subject to splashing water (rain, water droplets), oil (oil droplets), or other
liquids
yArea free of excessive salt
yArea not subject to continuous vibrations or excessive shocks
yArea free of excessive electromagnetic noise (from welders, power machinery, etc.)
yArea free of radioactive materials, magnetic elds or vacuum
yUp to 1,000 m (3,300 ft.) above sea level
Installation direction
Install the driver in vertical or horizontal position on a at metal plate having excellent
vibration resistance. If the driver is installed in a state other than vertical or horizontal
position, its heat radiation eect will deteriorate.
The items shown below are necessary in order to install the driver. They must be
provided by the customer.
Items to be prepared Cutouts for mounting A Cutouts for mounting B
M3 screw 4 pcs. 2 pcs.
M3 spring washer 4 pcs. 2 pcs.
M3 nut * 4 pcs. 2 pcs.
* Not necessary if screw holes are provided in the enclosure.
There must be clearances of at least 25 mm (0.98 in.) and 50 mm (1.97 in.) in the
horizontal and vertical directions respectively, between the driver and enclosure or other
equipment within the enclosure. When two or more drivers are to be installed side by
side, provide clearances in the horizontal and vertical directions as shown in the gure.
The gure shows the driver which connector shape is of right angle.
yInstall the driver inside an enclosure
yDo not install any equipment that generates a large amount of heat or
noise near the driver.
yIf the ambient temperature of the driver exceeds 50 °C (122 °F), reconsider
the ventilation condition.
•Horizontal installation [Unit: mm (in.)]
20 (0.79) or more
40 (1.57) or mor
e
•Vertical installation [Unit: mm (in.)]
50 (1.97) or more
40 (1.57) or more
Installation method
Install the driver using either the “cutouts for mounting A” or “cutouts for mounting B.”
Torque the mounting screw to 0.5 N·m (71 oz-in).
The gure shows the driver which connector shape is of right angle.
If both cutouts A and B are used for installation, the heat sink is distorted,
causing the board to apply stress.
When tightening the screws, make sure that the screw tightening tool does
not touch the I/O signal connector (CN6).
•Horizontal installation
Install the driver in a direction shown in the gure. Installing the driver upside down
causes the heat radiation eect to deteriorate.
yWhen using the cutouts for mounting A
M3 screws
Spring washers
Metal plate

4
yWhen using the cutouts for mounting B
Spring washers
Metal plate
M3 screws
•Vertical installation
The driver can be installed in any direction.
yWhen using the cutouts for mounting A yWhen using the cutouts for mounting B
Spring washers
M3 screws
Metal plate
Metal plat
e
Spring washers
M3 screws
zDimension [Unit: mm (in.)]
The gure shows the driver which connector shape is of right angle.
Mass: 0.065 kg (2.3 oz.)
78 (3.07)
78 (3.07)
85 (3.35)
24.5 max
(0.96 max.)
20
(0.79)
2 (0.08)
52.5 (2.07)
30 (1.18) 3.5
(0.14)
2.5 (0.10)
3.5 (0.14)
3.5 (0.14)
3.5 (0.14)
5.5 max (0.22 max.)
8 (0.31)
[16.5 (0.65)]
5 (0.20)
3.5 (0.14)
Connection
Connection example
Host controller
Main power supply
Connect to CN6
Connect to CN2
I/O signal cable *1 *2
Connect to CN4 or CN5
Connection cable *1
RS-485 communication cable
(For connecting host controller) *1
GND
+24 V
Power supply cable *1
Connect to CN1
*1 This cable is provided as our product.
*2 Connect when using direct I/O or sensors.
yWhen connecting, pay attention to the polarity of the power supply.
Reverse-polarity connection may cause damage to the driver.
yConnect the connectors securely. Insecure connections may cause
malfunction or damage to the driver.
yWhen disconnecting the connector, pull out while pressing the latches on
the connector.
yWhen turning on the main power supply again or connecting/
disconnecting the connector, turn o the main power supply and wait for
the PWR/ALM LED to turn o.
ySeparate an I/O signal cable at least 100 mm (3.94 in.) from inductance
loads such as electromagnetic relays, and wire so that it is not in parallel
with power supply cables and connection cables.
yDo not wire the power supply cable of the driver in the same cable duct
with other power lines or connection cables.
yIf the connection cable or power supply cable generates an undesirable
amount of noise depending on the installation and wiring, shield the cable
or install a ferrite core.
yUp to three pieces of cables can be used to connect between the motor
and the driver. Keep 10 m (32.8 ft.) or less for the wiring distance between
the motor and the driver.
yKeep 10 m (32.8 ft.) or less for the total wiring distance of the RS-485
communication cable. To extend more than 10 m (32.8 ft.) causes the driver
to be aected easily by electrical noise.
Connecting the motor (CN2): 2-phase stepping motor
Connector pin assignments vary depending on the motor. Refer to the table when
connecting. “Color” in the table shows the colors of lead wires of our connection cable.
The pin number is shown in the gure.
The motors of the model A and model B are dierent in pin assignments. The
motor does not rotate properly if the connection is wrong.
Model A Model B Model C
51 1 6
Pin No.Pin No.

5
zPin assignment
15
Driver
CN2 pin No.
Model A Model B Model C
Pin No. Color Pin No. Color Color
1 4 Blue 1 Blue Blue
2 5 Red 3 Red Red
3 − − −
4 2 Green 6 Green Green
5 1 Black 4 Black Black
zApplicable connector
Manufacturer Molex Incorporated
Connector housing 51103-0500
Contact 50351-8100
Designated crimping tool 63811-8100
Applicable lead wire
yAWG24 to AWG22 (0.2 to 0.3 mm2) *
yOuter sheath diameter:
ø1.15 to 1.8 mm (ø0.045 to 0.071 in.)
yStripping length of wire insulation:
2.3 to 2.8 mm (0.091 to 0.11 in.)
* If a motor whose motor setting switch (SW1) is set to“A” is used, use the lead wires of
AWG22 (0.3 mm2). Refer to p.7 for the motor setting switch.
•Motors of frame size 20 mm (0.79 in.)
When motors of the frame size 20 mm (0.79 in.) (PKP213, PKP214) are used, connect
by relaying lead wires of AWG24 to AWG22 (0.2 to 0.3 mm2) since the wire diameter
of the motor lead wires is as small as AWG26 (0.14 mm2). Connection cables (without
termination processing) provided by us can also be used. Refer to the USER MANUAL for
the model name.
Lead wires of AWG24 to AWG22
Lead wires of AWG26
PKP213
PKP214
Connecting the motor (CN2): 5-phase stepping motor
Connector pin assignments vary depending on the motor. Refer to the table when
connecting. “Color” in the table shows the colors of lead wires of our connection cable.
The pin number is shown in the gure.
The motors of the model A and model B are dierent in pin assignments. The
motor does not rotate properly if the connection is wrong.
Model A Model B Model C
51 1 5
Pin No.Pin No.
zPin assignment
15
Driver
CN2 pin No.
Model A Model B Model C
Pin No. Color Pin No. Color Color
1 5 Blue 1 Blue Blue
2 4 Red 2 Red Red
3 3 Orange 3 Orange Orange
4 2 Green 4 Green Green
5 1 Black 5 Black Black
zApplicable connector
Manufacturer Molex Incorporated
Connector housing 51103-0500
Contact 50351-8100
Designated crimping tool 63811-8100
Applicable lead wire
yAWG24 to AWG22 (0.2 to 0.3 mm2) *
yOuter sheath diameter:
ø1.15 to 1.8 mm (ø0.045 to 0.071 in.)
yStripping length of wire insulation:
2.3 to 2.8 mm (0.091 to 0.11 in.)
* If a motor whose motor setting switch (SW1) is set to“7”is used, use the lead wires of
AWG22 (0.3 mm2). Refer to p.7 for the motor setting switch.
Connecting the main power supply (CN1)
zPower supply current capacity
The current capacity of the main power supply varies depending on the product to be
combined.
•2-phase stepping motor
Motor model * Input power supply
voltage
Power supply current
capacity
PKP213D05
24 VDC±10 %
0.5 A or more
PKP214D060.5 A or more
PKP22D15
PKP22D152
PKP23D15
1.9 A or more
PKP23D232.0 A or more
PKP24D0820.8 A or more
PKP24D1521.4 A or more
PKP24D2322.0 A or more
PKP24MD1521.4 A or more
PKP25D28A2 3.0 A or more
PKP262FD15A 1.9 A or more
PKP26D1421.3 A or more
PKP26D282
PKP26MD2823.0 A or more
* The motor model column in the table describes part of the entire name of models.
The box () in the motor model indicates a number representing the motor length.
The box () in the motor model indicates A(single shaft) or B(double shaft)
representing the shape.
•5-phase stepping motor
Motor model * Input power supply
voltage
Power supply current
capacity
PK513
24 VDC±10 %
0.6 A or more
PK52H1.4 A or more
PK52P0.6 A or more
PK541.4 A or more
PK561.8 A or more
PKP521.7 A or more
PKP54MN
PKP54N1822.8 A or more
PKP56FMN
PKP56FN2423.0 A or more
* The motor model column in the table describes part of the entire name of models.
The box () in the motor model indicates a number representing the motor length.
The box () in the motor model indicates A(single shaft) or B(double shaft)
representing the shape.
zPin assignment
12
Pin No. Description
1 +24 VDC Power supply input
2 Power supply GND

6
zApplicable connector
Manufacturer Molex Incorporated
Connector housing 43645-0200
Contact 43030-0001
Designated crimping tool 638190000
Applicable lead wire
yAWG22 (0.3 mm2)
yOuter sheath diameter:
ø1.85mm (ø0.073 in.)
yStripping length of wire insulation:
2.54 to 2.92 mm (0.1 to 0.115 in.)
Keep the wiring distance as short as possible [less than 2 m (6.6 ft.)] to
suppress the eect of noise.
Connecting the RS-485 communication compatible
product (CN4, CN5)
Connect the RS-485 communication cable to CN4 or CN5 connector. A vacant connector
can be used to connect a dierent driver.
zPin assignment
123
Pin No. Signal name Description
1 TR+ RS-485 communication signal (+)
2 TR− RS-485 communication signal (−)
3 SG Signal ground
zApplicable connector
Manufacturer J.S.T. Mfg. Co., Ltd.
Connector housing PAP-03V-S
Contact SPHD-001T-P0.5 or SPHD-002T-P0.5
Designated
crimping tool
yWhen the contact model is SPHD-001T-P0.5
AWG24 to AWG22: YC-611R
AWG26 to AWG24: YC-610R
yWhen the contact model is SPHD-002T-P0.5
YRS-620
Applicable lead wire
yWhen the contact model is SPHD-001T-P0.5
AWG26 to AWG22 (0.13 to 0.33 mm2)
Outer sheath diameter: ø1 to 1.5 mm (ø0.039 to 0.059 in.)
yWhen the contact model is SPHD-002T-P0.5
AWG28 to AWG24 (0.08 to 0.21 mm2)
Outer sheath diameter: ø0.76 to 1.5 mm (ø0.03 to 0.059 in.)
Twisted-pair wires or shielded wires are recommended for RS-485
communication cable.
Connecting the USB cable (CN3)
Using a USB cable of the following specication, connect a PC in which the MEXE02 has
been installed to the USB communication connector (CN3).
Specication USB2.0 (full speed)
Cable Length: 3 m (9.8 ft.) or less
Shape: A to mini B
yConnect the driver and PC directly using the USB cable.
yIn large electrically noisy environments, use the USB cable with a ferrite
core or install a ferrite core to the USB cable.
Connecting the I/O signals (CN6)
zPin assignment
1
24681012
357911
Pin No. Signal name Description *
1 IN-COM Input common
2 IN0 Control input 0 [FW-POS]
3 IN1 Control input 1 [RV-POS]
4 IN2 Control input 2 [STOP]
5 IN3 Control input 3 [ALM-RST]
6 IN4 Control input 4 [HOMES]
7 IN5 Control input 5 [FW-LS]
8 IN6 Control input 6 [RV-LS]
9 OUT0 Control output 0 [ALM-B]
10 OUT1 Control output 1 [TIM]
11 OUT-COM Output common
12 N.C. N.C.
* Values in brackets [ ] are initial values.
zApplicable connector
Manufacturer J.S.T. Mfg. Co., Ltd.
Connector housing PHDR-12VS
Contact SPHD-001T-P0.5
Designated crimping tool YC-610R
Applicable lead wire
yAWG26 (0.14 mm2)
yOuter sheath diameter:
ø1 to 1.5 mm (ø0.039 to 0.059 in.)
yKeep the wiring distance as short as possible [less than 2 m (6.6 ft.)] to
suppress the eect of noise.
yTwisted-pair wires or shielded wires are recommended for I/O signal cable.

7
Setting
Setting the applicable motor
Set the motor setting switch (SW1) according to the motor used.
If the switch is set, the output current of the driver is automatically set.
yBe sure to set the switch according to the motor. If the
output current of the driver is set to a value higher than the
rated current of the motor by mistake, re or a skin burn(s)
may result.
yTurn o the main power supply of the driver before setting
the switch. Failure to do so may result in electric shock.
yThe set switch is enabled after the main power supply is turned on again.
ySetting the switch to a value not shown in the table causes the motor to
remain in a non-excitation state, and the information of motor setting error
is generated.
z2-phase stepping motor
Factory setting 0 (No setting)
Setting of switch Motor model *
Output current of
driver to be set
(A/phase)
2PKP213D050.5
3PKP214D060.6
4PKP24D0820.85
5PKP26D1421.4
6
PKP22D15
PKP22D152
PKP23D15
PKP262FD15A
1.5
7PKP24D152
PKP24MD1521.5
8PKP23D232.3
9PKP24D2322.3
A
PKP25D28A2
PKP26D282
PKP26MD282
2.8
* The motor model column in the table describes part of the entire name of models.
The box () in the motor model indicates a number representing the motor length.
The box () in the motor model indicates A(single shaft) or B(double shaft)
representing the shape.
z5-phase stepping motor
Factory setting 0 (No setting)
Setting of switch Motor model *
Output current of
driver to be set
(A/phase)
2PK513
PK52P0.35
3PK52H
PK540.75
4PKP521.2
5PK561.4
6PKP54MN
PKP54N1821.8
7PKP56FMN
PKP56FN2422.4
* The motor model column in the table describes part of the entire name of models.
The box () in the motor model indicates a number representing the motor length.
The box () in the motor model indicates A(single shaft) or B(double shaft)
representing the shape.
Setting of termination resistor
Set the termination resistor (120 Ω) of RS-485 communication to the driver located the
farthest away (positioned at the end) from the host controller.
Set both No.1 and No.2 of the termination resistor setting switch (SW2) to ON.
Factory setting OFF for both No.1 and No.2 (termination resistor disabled)
SW2 switch-No.1, No.2 Termination resistor (120 Ω)
Both are OFF Disabled
Both are ON Enabled
Turn o the main power supply of the driver before setting the
switch. Failure to do so may result in electric shock.
If only one of the two is set to ON, a communication error may occur.
Setting of communication parameters
Refer to the USER MANUAL for setting of communication parameters.
Alarms
If an alarm is generated, the ALM-A output is turned ON and the ALM-B output is turned
OFF to stop the motor. At the same time, the PWR/ALM LED blinks in red.
Before resetting an alarm, always remove the cause of the alarm and ensure safety.
Refer to the USER MANUAL for details about alarm.
Inspection and maintenance
Inspection
It is recommended that periodic inspections are conducted for the items listed below
after each operation of the motor. If an abnormal condition is noted, discontinue any use
and contact your nearest Oriental Motor sales oce.
zInspection item
yCheck if the mounting place of the driver is loose.
yCheck if any of the connection parts of the connector is loose.
yCheck if dust and others attach on the driver.
yCheck if the driver has unusual smells or appearance defects.
The driver uses semiconductor components. Static electricity may damage
the semiconductor components of the driver, so be extremely careful when
handling the driver.
Warranty
Check on the Oriental Motor Website or General Catalog for the product warranty.
Disposal
Dispose the product correctly in accordance with laws and regulations, or instructions of
local governments.

8
yUnauthorized reproduction or copying of all or part of this manual is prohibited.
yOriental Motor shall not be liable whatsoever for any problems relating to industrial
property rights arising from use of any information, circuit, equipment or device
provided or referenced in this manual.
yCharacteristics, specications and dimensions are subject to change without notice.
yWhile we make every eort to oer accurate information in the manual, we welcome
your input. Should you nd unclear descriptions, errors or omissions, please contact
your nearest Oriental Motor sales oce.
yis a registered trademark or trademark of Oriental Motor Co., Ltd., in
Japan and other countries.
Modbus is a registered trademark of the Schneider Automation Inc.
© Copyright ORIENTAL MOTOR CO., LTD. 2020
Published in October 2020
T
echnical Support Tel:[phone]
8:30
A.M. to 5:00 P.M., P.S.T. (M-F)
7:30
A.M. to 5:00 P.M., C.S.T. (M-F)
www
.orientalmotor.com
Schiessstraße 44, 40549 Düsseldor
f, Germany
T
echnical Support Tel:[phone]
www
.orientalmotor.de
T
el:01256-347090
www
.oriental-motor.co.uk
T
el:01 47 86 97 50
www
.orientalmotor.fr
T
el:02-93906346
www
.orientalmotor.it
T
el:[phone]
www
.orientalmotor.com.br
• Please contact your nearest Oriental Motor oce for further information.
4-8-1Higashiueno
,Taito-ku,Tokyo 110-8536
Japan
T
el:03-6744-0361
www
.orientalmotor.co.jp
Tel:[phone]
www.orientalmotor.com.tw
Singapore
Tel:[phone]
www.orientalmotor.com.sg
Tel:[phone]
www.orientalmotor.com.my
Korea
Tel:[phone]
www.inaom.co.kr
Tel:[phone]
www.orientalmotor.co.th
Tel:[phone]
www.orientalmotor.com.cn
Tel:[phone]
www.orientalmotor.co.in
Hong Kong Branch
Tel:[phone]
Specications
Product specications
Input voltage 24 VDC±10 %
Input current 2-phase: 0.5 to 3.0 A *
5-phase: 0.6 to 3.0 A *
Interface
Control input Number of input points: 7, photocoupler
Control output Number of output points: 2,
photocoupler/open collector
Field network Modbus RTU (RS-485 communication)
* A current value varies depending on a motor combined. Refer to p.5.
General specications
Operating
environment
Ambient
temperature 0 to +50 °C (+32 to +122 °F) (non-freezing)
Humidity 85 % or less (non-condensing)
Altitude Up to 1,000 m (3,300 ft.) above sea level
Surrounding
atmosphere No corrosive gas, dust, water, or oil.
Storage
environment
Shipping
environment
Ambient
temperature −25 to +70 °C (−13 to +158 °F) (non-freezing)
Humidity 85 % or less (non-condensing)
Altitude Up to 3,000 m (10,000 ft.) above sea level
Surrounding
atmosphere No corrosive gas, dust, water, or oil.
Regulations and standards
CE Marking
This product is axed the CE Marking under the EMC Directive.
•Low Voltage Directive
The input power supply voltage of this product is 24 VDC. Therefore this product is not
subject to the Low Voltage Directive, but install and connect it as follows.
yThis product is designed and manufactured to be incorporated in equipment. Be sure
to install the product inside an enclosure.
yFor the driver power supply, use a DC power supply with reinforced insulation on its
primary and secondary sides.
•EMC Directive
This product is conducted EMC testing under the conditions specied in "Example of
installation and wiring" on the USER MANUAL. The conformance of your mechanical
equipment with the EMC Directive will vary depending on such factors as the
conguration, wiring, and layout for other control system devices and electrical parts
used with this product. It therefore must be veried through conducting EMC measures
in a state where all parts including this product have been installed in the equipment.
Applicable Standards
EMI EN 55011 Group1 Class A
EN 61000-6-4
EMS EN 61000-6-2
This equipment is not intended for use in residential
environments nor for use on a low-voltage public network
supplied in residential premises, and it may not provide
adequate protection to radio reception interference in such
environments.
RoHS Directive
The products do not contain the substances exceeding the restriction values of RoHS
Directive (2011/65/EU).
