ORiNG IMC-V111ET-TB User manual

Quick Installation Guide
Version 1.0
Quick Installation Guide
Introduction
PRINTED ON RECYCLED PAPER
QIG IMC-V111ET-TB 1907-2-29-IMCV111ETTB-1.0
The is a cost-effective solution for extending an Ethernet
connection beyond its inherent distance limitation. can
extend the distance to 2,400 meters using 26AWG cable. It has a switching
architecture with 1 RJ-45 100Mbps Ethernet port and one asymmetric or
symmetric Ethernet over VDSL2 port which is a terminal block connector
supports 2-wired transmission. provides a wide operating
temperature range from -40~75 C, making it suitable for harsh operating
environments.
IMC-V111ET-TB
IMC-V111ET-TB
IMC-V111ET-TB
o
Package Contents
Installation
The series is shipped with the following items. If any of these items is missing
or damaged, please contact your customer service representative for
assistance.
Preparation
Before installation, make sure you have all of the package contents
available.
Elevated Operating Ambient:
Reduced Air Flow:
Mechanical Loading:
Circuit Overloading:
If installed in a closed cabinet, the operating
ambient temperature of the rack environment may be greater than room ambient.
Therefore, consideration should be given to installing the equipment in an
environment compatible with the maximum ambient temperature (Tma) specified
by the manufacturer.
Installation of the equipment should be such that the
amount of air flow required for safe operation of the equipment is not
compromised.
Mounting of the equipment in the d should be
such that a hazardous condition is not achieved due to uneven mechanical
loading.
Consideration should be given to the connection of the
equipment to the supply circuit and the effect that overloading of the circuits
might have on overcurrent protection and supply wiring. Appropriate
consideration of equipment nameplate ratings should be used when addressing
this concern.
in-rail
Safety & Warnings
Contents
Wall-mount Kit
DIN-rail Kit
IMC-V111ET-TB
Pictures Number
X2
X1
QIG X1
Dimension (Unit: mm)
Panel Layouts
Front Panel
1. PWR1 LED
2. PWR2 LED
3.CEPmodeLED
4. LNK/ACT LED for extension port
5. Extension port
6. DIP switch for mode selection
7. LNK/ACT LED for LAN port
8. LAN Port
IMC-V111ET-TB
X1
Top Panel
12
1. Wall-mount screw
holes
2. Terminal block
Real Panel
1
1. Din-rail screw holes
Step 1:
Step 2:
Slant the switch and screw the Din-rail kit onto the back of the switch, right in the
middle of the back panel.
Slide the switch onto a DIN-rail from the Din-rail kit and make sure the switch clicks into
the rail firmly.
DIN-rail Installation
Step 1:
Step 2:
Step 3:
Screw the two pieces of wall-mount kits onto both sides of the switch. A
total of eight screws are required, as shown below.
Use the switch, with wall mount plates attached, as a guide to mark the correct
locations of the four screws.
Insert four screw heads through the large parts of the keyhole-shaped apertures, and
then slide the switch downwards. Tighten the four screws for added stability.
Wall-mounting
Industrial Extended Media Converter
Media
Converter
Media
Converter
INDUSTRIAL
4-pin terminal block X1
2
70.0
20.0
43.5
33.6
12.5
41.0
95.0
28.0
20.0
22.0
29.0
13.1
22.6
8.0
14.0 13.5
40.0
50.0
25.3
41
19.0
IMC-V111ET-TB
P1 P2
LNK/ACT
2
Line
1
ETH 100M
CPE
CO
Mode
CO
Inter.
Sym.
9db
CPE
Fast
Asym.
6db
LNK/ACT
IMC-V111ET-TB
P1 P2
LNK/ACT
2
Line
1
ETH 100M
CPE
CO
Mode
CO
Inter.
Sym.
9db
CPE
Fast
Asym.
6db
LNK/ACT
1
4
3
5
6
7
8
IMC-V111ET-TB
P1 P2
LNK/ACT
2
Line
1
ETH 100M
CPE
CO
Mode
CO
Inter.
Sym.
9db
CPE
Fast
Asym.
6db
LNK/ACT

QIG Quick Installation Guide
PRINTED ON RECYCLED PAPER
Quick Installation Guide
ORing Industrial Networking Corp.
Copyright© 2016 ORing
All rights reserved.
TEL: [phone]
FAX: [phone]
Website: www.oring-networking.com
E-mail: [email protected]
The switch supports dual redundant power supplies which are
located on the 4-pin terminal block.
Insert the negative/positive wires into the V-/V+
terminals, respectively.
To keep the DC wires from pulling loose, use a small
flat-blade screwdriver to tighten the wire-clamp screws on the
front of the terminal block connector.
STEP 1:
STEP 2:
Version 1.0
QIG
Configurations
After installing the device and connecting cables, the green power LED should turn on.
Please refer to the following tablet for LED indication.
LED indication table
Specifications
Wiring
PWR2
V2+ V2-
PWR1
V1+ V1-
ORing Extended Converter
Model IMC-V111ET-TB
100Base-TX Ports in RJ45 Auto
MDI/MDIX 1
Physical Ports
Technology
Ethernet Standards IEEE 802.3u for 100Base-TX, VDSL ITU T G. 993.1, VDSL2 ITU T G. 993.2
Power
Input power
Power consumption(Typ.)
Dual 12~48 VDC power inputs at 4-pin terminal block
4.75Watts
Overload current protection Present
Physical Characteristic
Enclosure IP-30
Dimension(WxDxH) 41(W) x 70(D) x 95.5(H)mm (1.61x 2.76 x 3.76inch.)
Weight ( g)
Environmental
-40to85C(-40to185F)
oo
Storage Temperature
Operating Temperature
5% to 95% Non-condensingOperating Humidity
Regulatory Approvals
FCC Part 15, CISPR (EN55022) class AEMI
EN61000-4-2 (ESD), EN61000-4-3 (RS), EN61000-4-4 (EFT),
EN61000-4-5 (Surge),EN61000-4-6 (CS), EN61000-4-8, EN61000-4-11
EMS
IEC60068-2-27Shock
IEC60068-2-32
IEC60068-2-6Vibration
Free Fall
Warranty
5 years
Processing Store-and-Forward
272 g
-40to75C(-40to167F)
oo
Network Connection
The has a standard Ethernet port. According to the link type, the device
uses CAT 3,4, 5,5e UTP cables to connect to any other network devices (PCs,
servers, switches, routers, or hubs). Please refer to the following table for cable
specifications.
IMC-V111ET-TB
Cable Types and Specifications:
Cable Type Max. Length Connector
100BASE-TX Cat. 5 100-ohm UTP UTP 100 m (328 ft) RJ-45
For pin assignments for different types of cables, please refer to the following tables.
100Base-TX RJ-45
Pin Number Assignment
1TD+
2TD-
3RD+
4Notused
5Notused
6RD-
7Notused
8Notused
100Base-TX MDI/MDI-X
Pin Number MDI port MDI-X port
1 TD+(transmit) RD+( recei ve)
2 TD-(transmit) RD-(receive)
3 RD+(receive) TD+(transmit)
4NotusedNotused
5NotusedNotused
6 RD-(receive) TD-(transmit)
7NotusedNotused
8NotusedNotused
DIP Switch Setting
LED Col or Status Description
PW1 Green On DC power module 1 activated
PW2 Green On DC power module 1 activated
10/100Base-TX RJ45 Port
LNK/ACT Green O n Port is l inked/ Transmitting data
Ethernet Extender Port
LNK/ACT Green O n Port is l inked/ Transmitting data
On CEP mode
CO/CEP mode Green
Off CO mode
100Mbps Ethernet Extender Ports 1 (support 2-wired)
Industrial Extended Media Converter
Media
Converter
Media
Converter
INDUSTRIAL
100Mbps Extension port Terminal Block
Pin Number Assign ment*
1D1+
2D1-
100Mbps Extension port Terminal Block
Pin Number Assignment*
1D1+
2D1-
3D2+
4D3+
5D3-
6D2-
7D4+
8D4-
Note: “+” and “-” signs represent the polarity of the wires that
make up each wire pair.
DI P- s w it c h 1 f o r C P E / CO ( S la v e/ M a s t er ) m od e s e le c t : (O N ) C P E mo d e (O f f ) C O m od e
DIP-switch 2 for fast/interleaved mode select : (ON) Fast mode (Off) Inter. mode
DIP-switch 3 for Asymmetric/Symmetric mode select : (ON) Asym. mode (Off) Sym. mode
DIP-switch 4 for SNR mode select : (ON) 6db mode (Off) 9 db mode
Performance
VDSL speed
IMC-V111ET-TB
IMC-V111ET-TB
Appendix A
Annex-17a- A-17a-eu32_I-8/2
Downstrea m Upstream
Loop Length
(m , PE 0.4mm loop) Act DataRate
(Mbps)
Noise M argin
Reported (dB)
Act DataRate
(Mbps)
Noise Margin
Reported (dB)
0101.0 14. 8 52.5 7.2
200 101.0 12.4 52.5 7
400 88.2 6.6 45. 8 6.8
600 60.5 5.9 30. 4 6.3
800 44.6 6.1 12. 7 6.5
1000 33.5 6.3 5.6 6.1
1200 28.4 7.4 2.1 6
1400 21.5 7.5 0.7 6
1600 16.8 7.1 0.7 6.3
1800 12.9 7.4 0.7 6.2
2000 9.8 7.6 0.8 6.1
2200 7.7 7.4 0.8 6.1
2400 5.9 7.4 0.7 6.2
Annex- B-B7-9_I- 8/2
Downstrea m Upstream
Loop Length
(m , PE 0.4mm loop) ActD ataRate
(Mbps)
Noise M argin
Reported (dB)
Act DataRate
(Mbps)
Noise Margin
Reported (dB)
071.7 7.1 76.4 7.1
200 69.6 7.7 74. 7 7.1
400 60.0 7.1 65. 3 6.9
600 46.8 6.4 44. 6 6.5
800 37.8 6.8 19. 6 6.1
1000 29.5 6.3 9.1 5.7
1200 26.1 6.8 4.2 5.7
1400 22.2 7.8 1.2 5.6
1600 18.0 7.4 0.7 6.2
1800 14.5 7.2 0.7 6.2
2000 11.5 7.2 0.8 5.9
2200 9.3 7.3 0.7 6
2400 7.4 7.3 0.6 6.1
Annex-30a- A-30a-eu32_I-8/2
Downstrea m Upstream
Loop Length
(m , PE 0.4mm l oop) A ctDataRate
(Mbps)
Noise M argin
Reported (dB)
ActDataRate
(Mbps)
Noise Margin
Reported (dB)
0101.0 25 10 1.0 8.2
200 101.0 19. 4 97.1 6.3
400 100.9 653. 3 5.7
600 60.8 5.8 32. 8 7
800 39.3 5.6 15. 4 8.9
1000 31.9 6.3 5.5 7
1200 29.2 7.2 2.1 6.1
Annex-B-B7-10_I-8/2
Downstream Upstrea m
Loop Len gth
(m , PE 0.4mm lo o p) Ac tDataRate
(Mb ps )
Noise Margin
Repor ted (dB)
ActDataRate
(Mb ps )
Nois e Margin
Reporte d (d B)
0101.0 17.6 101.0 17.4
200 101.0 10.2 101.0 17.8
400 64.8 6.3 96.2 6.8
600 46.9 5.9 51.5 6.6
800 32.6 8.1 21.0 7.7
1000 29.2 6.3 9.1 6
1200 25.7 7.5 4.9 5.6
RefertoAppendixA.
