Osaki 3D Avalon User manual

SAVE THESE INSTRUCTIONS
OPERATION INSTRUCTIONS
MASSAGE CHAIR
3D Avalon

01
CONTENTS
Before Use
Important Safety Instruction
Instructions De Securite Importantes
Installation Parts
Place Massage Chair
Before Use
Product Structure
02-03
04-05
06-07
08-09
10-11
12-18
Usage Method
Operation Instructions
Massage close
19-50
50
Maintain
Cleaning and Maintenance 51
Important
Troubleshooting
Product Specifications
52
53
Thank You for purchasing this product. Please read this manual instruction carefully
in order to know how to use this product correctly before operation. Please pay
more attention to the important safety warnings and keep this manual book properly
for future use.
Note: We reserve the right to change the design and manual of the product. Details
are subject to change over time, and will not be informed otherwise. If there are
some differences between the products in the market circulation and the description
in the manual, it is a normal update of the product. Specific product functions and
colors are subject to change at any time.

0302
Important Safety Instruction Important Safety Instruction
When using an electrical appliance, basic precautions should
always be followed, including the following:
Read all instructions before using (this appliance)
DANGER-To reduce the risk of electric shock:
1) Always unplug this appliance from the electrical outlet immediately after
using and before cleaning.
WARNING-To reduce the risk of burns, fire,
electric shock, or injury to Persons:
1) An appliance should never be left unattended when plugged in. Unplug
from outlet when not in use, and before putting on or taking off parts.
2) Do not operate under blanket or pillow. Excessive heating can occur and
Cause fire, electric shock, or injury to persons.
3) Close supervision is necessary when this appliance is used by, on, or near
children, invalids, or disabled persons.
4) Use the appliance only for its intended use as described in this manual.
Do not use attachments not recommended by the manufacturer.
5) Never operate this appliance if it has a damaged cord or plug, if it is not
working properly, if it has been dropped or damaged, or dropped into
water. Return the appliance to a service center for examination and repair.
6) Do not carry this appliance by supply cord or use cord as a handle.
7) Keep the cord away from heated surfaces.
8) Never operate the appliance with the air openings blocked. Keep the air
openings free of lint, hair, and the like.
9) Never drop or insert any object into any opening.
10) Do not use outdoors.
11) Do not operate where aerosol (spray) products are being used or where
oxygen is being administered.
12) To disconnect, turn all controls to the off position, then remove plug from
outlet.
13) The appliance is intended for household and indoor use only.
14) Connect this appliance to a properly grounded outlet only ,see grounding
instructions .
15)Keep children away from extended foot support (or other similar parts
16)Do not use massager in close proximity to loose clothing or jewelry.
17)Keep long hair away from massager while in use.
18)Connect this appliance to properly grounded outlet only. See Grounding Instructions.
GROUNDING INSTRUCTIONS
This product must be grounded, if it should malfunction or breakdown, grounding
provides a path of least resistance for electric current to reduce the risk of electric
shock, this product is equipped with a cord having an equipment grounding
conductor and a grounding plug, the plug must be plugged into an appropriate outlet
that is properly installed and grounded in accordance with all local codes and
ordinances.
DANGER: Improper connection of the equipment grounding
conductor can result in a risk of electric shock, check with a qualified electrician or
serviceman of you are in doubt as to whether the product is properly grounded, do
not modify the plug provided with the product-if it will not fit the outlet, have a proper
outlet installed by a qualified electrician.
1)This product is for use on nominal 120-volt circuit, and has a grounding plug that
looks like the plug illustrated in sketch on the page 50, A temporary adapter that
looks like the adapter illustrated in sketches B and C may be used to connect this
plug to a 2-pole receptacle as shown in sketch B if a properly grounded outlet is not
available the temporary adapter should be used only until a properly grounded
outlet (shetch A )can be installed by a qualified electrician, the green colored rigid
ear, lug, or the like extending from the adapter must be connected to a permanent
ground such as a properly grounded outlet box cover, Whenever the adapter is
used, it must be held in place by a metal screw.
SAVE THESE INSTRUCTIONS

Instructions De Securite Importantes Instructions De Securite Importantes
lors de l'utilisation d'un appareil électrique, des précautions de bases doivent être
respectées, y compris ce qui suit :
Lisez toutes les instructions avant d'utiliser l'appareil.
DANGER- Pour réduire le risque de choc électrique:
1) Toujours débrancher cet appareil de la prise électrique immédiatement après
usage et avant nettoyage
AVERTISSEMENT- Pour réduire le risque de brûlures, d'incendie, de choc
électrique ou de blessures:
1) Cet appareil ne doit jamais quittervotre surveillance lorsqu'il est branché.
Débranchez le de la prise lorsqu'il estinutilisé, et avant de placer ou d'enlever des
pièces.
2) Ne pas utiliser cet appareil sous une couverture ou un oreiller. Une chaleur
excessive peut provoquer un incendie, un choc électrique ou des blessures
corporelles.
3) Soyez prudent et maintenez une surveillance accrue lorsque cet appareil est
utilisé par, sur, ou près des enfants, de personnes invalides ou handicapées.
4) Utilisezl'appareil uniquement pour un usage habituel, comme décrit dans ce
manuel. Ne pas utiliser d'accessoires non recommandés par le fabricant.
5) Ne jamais faire fonctionner cet appareil si le cordon ou la fiche sont
endommagés, s'il ne fonctionne pas correctement, s'il est endommagé ou s'il est
tombé dans l'eau. Retournez l'appareil auservice technique pour examen et
réparation.
6) Ne transportez pas cet appareil par le cordon d'alimentation ou d'utilisation
comme une poignée.
7) Gardez le cordon loin des surfaces chauffées.
8) Ne jamais faire fonctionner l'appareil en obstruant les ouvertures d'air. Gardez les
ouvertures à l'air, libre de peluches, de cheveux, etc.
9) Ne jamais laisser tomber, ou insérer d'objet dans les ouvertures.
10) Ne pas utiliser à l'extérieur.
11) Ne pas utiliser dans les lieux où des aérosols (vaporisateurs) sont utilisés, ni là
où l'oxygène est administré.
12) Pour débrancher, mettre tous les boutons de l'appareil sur la position arrêt, puis
retirer la fiche de la prise.
13) L'appareil est destiné à un usage domestique et à l'intérieur seulement.
14) Connectez cet appareil à une prise correctement reliée à la terre. Voir les
instructions de mise à la terre.
15) Éloignez les enfants du support de pied ouvert (ou des autres pièces
semblables).
16) Ne pas utiliser de massage à proximité des vêtements amples ou des bijoux.
17) Garder les cheveux longs à l'écart de masseur en cours d'utilisation.
18) Raccordez cet appareil à une prise correctement mise à la terre.
Ce produit doit être relié à la terre. Si il dysfonctionne ou tombe en panne, la
terrefournit un chemin de moindre résistance pour le courant électrique afin de
réduire le risque de choc électrique. Cet appareil est équipé d'un cordon avec un
conducteur de mise à la terre des équipements et une prise de terre. La fiche doit
être branchée dans une prise appropriée qui est correctement installée et mise à la
terre conformément à la règlementation locale.
DANGER: un mauvais branchement de l'équipement à la prise de terre, peut
entraîner un risque de choc électrique. Consultez un électricien qualifié si vous avez
des doutes quant à savoir si le produit est correctement mis à la terre. Ne pas
modifier la fiche fournie avec le produit si elle ne rentre pas dans la prise. Adressez
vous à un électricien qualifié le cas échéant.
1)Ce produit est destiné à être utilisé sur un circuit de 120 volts, et possède une
fiche de mise à la terre semblable à la fiche illustrée sur le croquis de la page 50. Un
adaptateur temporaire qui ressemble à l'adaptateur illustré sur le croquis B et C peut
être utilisé pour brancher cette fiche à un réceptacle 2-pole, comme indiqué sur le
croquis B. Si une prise de terre n'est pas disponible, l'adaptateur temporaire ne doit
être utilisé que jusqu'à une prise de terre correcte (croquis A) pour être installé par
un électricien qualifié. L'oreille rigide de couleur verte, qui dépasse de l'adaptateur,
doit être connectée à une terre permanente comme un couvercle de boîte de sortie
mise à la terre. Chaque fois que l'adaptateur est utilisé, il doit être maintenu en
place par une vis en métal.
S'il vous plaît noter que lorsque ne pas coincer votre détection des doigts
Avant le nettoyage ou la réparation doivent couper l'alimentation
CONSERVER CES INSTRUCTIONS
INSTRUCTIONS DE BASES
0504

0607
Installation Parts
Armrest Installation Instructions
1. After power on, use the remote controller to lie down the backrest .
2. Insert the wire harness and air pipes on the side of the steel frame into the
corresponding positions on the armrest (Figure 1).
3. Lift up the armrest with the air pipes and wires inserted, and hang all the hooks
on both sides of the steel frame (Figure 2).
1 2
3 4
4. Press the roller at the rear end of the armrest into the corresponding slot (Figure
3), and lower the armrest downwards.
Then push the armrest backwards, and lock it with 2 M6*16 screws (Figure 4).
Installation Parts
Calf Installation Instructions
1. Insert the wires and air pipes of the footrest into the front sockets of the steel
frame assembly respectively (Figure 1).
2. After the wire connection is completed, open the fixing covers of the footrest on
both sides of the steel frame assembly (Figure 2).
3. Lift the footrest, put them into the slot, then flip the fixing cover down, fixing them
with two M5*12 screws (Picture 3).
1 2
3
Touchscreen Remote Controller Bracket Installation Instructions
1. Align the bracket with the front hole of the armrest (right) and fasten it with M5*16
screws (Figure 1).
2. Align the bracket decoration with the bracket and press down along the bracket
rod to the end. (figure 2).
3. After the entire bracket is installed, shake the bracket lightly to confirm whether it
is firmly installed; the bracket installation is complete (Figure 3).
1 2
3

0809
Make sure there is enough
space for the massage chair to
be tilted at least 4 inches.
Do not expose the massage chair
directly to high temperature
environment due to sunlight(such
as: in front of heating equipment),
and place it to where can avoid
high temperature and direct
sunlight. It is recommended to lay
a soft cushion for long-term use in
a designated location. When laying
the cushion, the size of the
cushion should be enough to cover
Keep the range where the machine
touches the floor and the range
where your feet touch the floor.
Require team work to lift and move
the chair to avoid injury.
1. Please lift the massage chair to
move it on vulnerable ground such as
wooden floor.
2. When moving on a similar wooden
floor, it is recommended to lift it.
Avoid damage to the casters. When
the floor is lifted and moved to the
designated position, be careful to
keep your hands out of the way to
avoid injury, and be careful of your
feet being crushed. Do not let go of
the unit until the unit is completely
flat, the floor may be damaged,
therefore, it is recommended to place
mats, etc. on the floor.
Caution
Product lift instruction
Installation placement
Caution
Place Massage Chair
45°
12
Zipper
How to disassemble and use headrest cushion and backrest cushion
Move method
Caution
Use the rear casters to move the
massage chair.Move the chair by
tilting it down and backward about
45° as shown in the diagram.
NOTE: Excessive force to title will
cause the chair to tip over
completely and product damage.
1.Before moving, please shut down the
machine properly to reset the whole
machine, and then cut off the power.
2.Please keep the chair vacant when
moving. (People, pets or clutter will not
be able to stay on the chair.)
3.When moving, do not cross a drop
barrier higher than 2mm or a gap
greater than 5mm.
4.When using casters to move this
product, single continuous movement
is not supported; if the distance
exceeds 50 meters, please make this
product move slowly and evenly.e the
product slowly and uniformly.
Zipper
Using a headrest cushion can reduce the intensity
of kneading massage on the neck and shoulders,
and you can decide whether to use a headrest
cushion according to your needs (recommended to
use a headrest cushion). The backrest cushion
and the backrest are connected by a zipper (1),
and the headrest cushion and the backrest
cushion are connected by a zipper (2).
Caution
Place Massage Chair
4 inches

10 11
Check around
Make sure there are no foreign objects in the
gaps of the machine
Make sure that there are no people, pets and
other objects around the unit. Caution
Caution
Before massaging, make sure that no
foreign objects are caught in the legs,
feet, etc.
Under no circumstances allow hands,
feet, and head to penetrate into the area
between the lower leg mechanism and
main body, or the area between the
armrest and the capsule.
Under no circumstances should hands,
feet, or head sink under the fabric or
leather covering of the massage area.
Before Use
POWER I NPUT
ON/OFF
FUSE:
T6.3AL 250V
POWER IN PUT
ON/OFF
FUSE:
T6.3AL 250V
Turn on the power
Caution
Plug in power cord Schematic diagram
of power on Turn on the power
switch ("I" position)
Before Use
Warn
■Please check the power cord and plug for damage before use.
■Please supply power to this product in accordance with the working
power requirements of this product's calibration.
■It is strictly forbidden to use a power supply other than the nominal
power supply of this product.
■It is strictly forbidden to connect various power conversion devices
without authorization to supply power to this product.

1213
Description of Components
Product Structure
1
2
3
4
5
6
7
8
9
10
11
12
1.Head cushion
2.Remote controller
3.Arm air pressure
4.Leg massage unit
5.Ambient lighting
6.Space capsule
7.Shoulder air pressure
8.Shawl backrest cushion
9.Armrest Shortcut Keys
10.Health sensor
11.Armrest
12.Side panel
Product Structure
Schematic view of functional distribution
1
2
3
4
5
6
7
8
9
1.Shoulder
Airbag massage·
2.Arm
Remote controller rest·
Mobile phone placement rest·
USB charging socket·
Wireless charger·
Built-in voice control microphone·
3.Hand
Airbag massage·
4.Leg
Airbag massage·
5.Sole
Roller massage·
6.Both sides of the head
Audio music playback·
7.Head & neck to seat part
Manipulator massage·
8.Waist and shoulder
Heating function·
9.Leg
Airbag massage·
Kneading massage·

1415

How to use the shawl
Product Structure
Heating area
Heating area
Schematic diagram
of use on back and waist Schematic diagram of use
on shoulder and abdomen
·It is provided with a unique shawl assembly, with innovative heating functions on
the shoulder, back, waist and abdomen and heating with graphene. Users can
place the shawl at different massage positions according to massage
requirements. When the shawl assembly is placed at the shoulder position, it will
heat the acupoints such as Bingfeng, Tianzong, Yunmen and Qihu around the
shoulder and clavicle by graphene heating, effectively relieving symptoms such
as scapulohumeral periarthritis and cough, and removing cold and moisture from
shoulder joints.
·When the shawl assembly is placed on the abdomen and back (dual-purpose),
through graphene heating, it plays the role of dispelling cold and relieving pain,
warming channels and removing blood stasis in the back and abdomen,
distributing Qi and blood of the back and abdomen meridian, alleviating the
symptoms such as irregular menstruation and dysmenorrhea for women, relieving
low back pain and kidney discomfort, warming intestines and stomach and
clearing intestinal cold, with a good effect on some people with deficiency of qi and
deficiency of spleen and stomach.
Product Structure

Power Pause
Angle
Auto
Manual
Home
Settings
4D +
4D -
Speed -
Speed +
Air intensity +
00:30
Full
4D I
Back heat Roll Calf Voice
Manual
Area
Shoulder
Strong
Gentle
Soothing
12
11 10
09
08
07
060504030201
13
14
15
16
1920
18
212223
17
24
25
26
Main information interface
1617
I.Remote controller keys instruction
01.On/off touch key: Enable or disable the massage chair function.
02.Pause key: Pause the massage or exit from pause massage.
03.Back heating key: Enable or disable the back heating function.
04.Sole roller key: Enable or disable the sole roller function.
05.Calf kneading key: Enable or disable the calf kneading function.
06.Voice control key: Enable or disable the voice control function.
07.Intensity selection key: Select one from different automatic massage intensities.
08.Button on/ff key: Turn on or off the massage chair.
09.Air intensity key: The function of regulating air intensity massage.
10.Massage area key: The function of selecting massage position.
11.Shoulder position adjustment key: Regulate shoulder position and confirm massage
criterion.
12.Current status key: Enter to view current massage chair status.
13.Automatic function menu key: Enter to select automatic massage program.
14.Remote function menu key: Enter to remotely set the massage function.
15.Seat adjustment menu key: Enter the sitting posture adjustment interface to select
sitting posture angle.
16.Setting menu key: Enter the setting menu interface.
Width +
Air intensity -
Width -
Power Pause
Customise
Memory
Health
00:30
Full
4D I
Back heat Roll Calf Voice
Manual
Area
Shoulder
Strong
Gentle
Soothing
4D +
Speed +
Speed -
4D -
Width +
Air intensity +
Air intensity -
Width -
Product StructureProduct Structure
17.Massage technique selection key: Select the massage technique.
18.Massage width key: Adjust the massage width.
19.Status display bar key: Display the massage program status information.
20.Air massage selection key: Select air position.
21.Time adjustment menu key: Adjust the massage time.
22.Massage speed key: Adjust the massage speed.
23.4D intensity key: Adjust 4D intensity.
24.Health detection menu key: Enter the health detection interface.
25.Custom menu key: Enter the custom interface.
26.Storage menu key: Enter the storage interface.


1. Press the remote controller side button on/off key or long press the armrest
on/off key
1819
III. Start massage
Angle adjustment
Area
Power
II. Description of armrest shortcut keys
Select level
Gentle Soothing Strong
Power
Product Structure Operation Instructions
2. After the system is started, select the massage intensity by clicking on any one of
the Gentle , Comfort or Strong keys on the remote controller to turn
on the massage chair and enter the lying state. If it is not selected within 5 minutes,
the massage chair will turn off automatically.
3.For automatic angular adjustment, select the automatic program, then the massage
chair will be automatically adjusted to zero-gravity angle, and wait until its adjustment
is completed. To skip a step, press the skip key
Skip to go directly to the next step.
Button On/Off key
Press this key to turn
the equipment on
1
2
3
4
5
6
7
8910
1.On/off key: Turn on or off the massage chair.
2.Voice key: Long press to turn on or off the voice assistant function. Short press to
wake up the voice assistant function.
3.Zero-gravity key I: For zero-gravity angle setting, press this key to adjust the
massage chair seat-down angle to zero-gravity key I position.
4.Linkage rising key: Adjust the massage chair angleupward.
5.Leg unit extension key: Leg unit stretching.
6.4D intensity knob key: Turn the knob clockwise to enhance the 4D intensity Turn
the knob counterclockwise to weaken the 4D intensity.
7.Automatic mode key: Automatic massage program switching.
8.Zero-gravity key II: For zero-gravity angle setting, press this key to adjust the
massage chair seat-down angle to zero-gravity key II position.
9.Linkage lowering key: Adjust the massage chair angle downward.
10.Leg unit shrinkage key: Leg unit shortening. 

20 21
Checking,
Please wait
Body sensing
Skip
Power Pause
Position too high
Proper position
Position too low
0
OK
Shoulder position adjustment
Power Pause
Operation InstructionsOperation Instructions
Skip
4. Wait until body shape detection is completed, or you can press the skip key
to skip detection and start massage directly.
IV. Pause function (please use this function after the equipment is turned on)
V. Automatic program (please use this function after the equipment is turned on)
Automatic program selection
(1) Select the Automatic key in the left menu bar to enter the automatic selection
interface.
After the massage chair is turned on, press the pause key to enter the pause
state, then all massage functions will be suspended, and press the pause key
again to resume the previous massage state.
Note: In the pause state, all functions do not work except shutdown.
For fine adjustment of shoulder position, after body shape detection, the remote
controller or a voice prompt will remind the user of fine adjustment of shoulder
position. If the massage roller stops at the shoulder position, directly press the OK
OK
key to start massage. If not, use the Up key and Down key to
adjust the massage roller to the shoulder position, and then press the OK key
to start the massage. If no operation is made within 20s, directly default the current
massage roller position for the shoulder position and start massage.
OK
(2) In the automatic program selection interface, there are 20 automatic program
options available: Total Relax, Chinese Massage, Relieve Muscle, Body Balance,
Thai Massage, Full-body Stretch, Neck & Shoulder Care, Hips&legs Fit,
Spine Traction, Leg&foot Relieve, Superior Enjoyable, President Cosy, Keep Fit,
Office Regimen, Health Recharge, Energy Boost, Lunch Break, Back Spa,
Sport Recovery, Sweet Dream.
Schematic diagram of automatic massage program selection
(3) Select the desired automatic massage program and click to start massage.
Gentle waves rub
Fatigue Recovery
Chinese Massage
Total Relax Thai Massage
AI
Intelligent
Auto Program
Power Pause
Angle
Auto
Manual
Home
Settings
Manual
Relaxing and
Activating Exclusive for Family Overall
Relaxation

2223
Operation InstructionsOperation Instructions
Thai
Massage
Full-body
Stretch
By means of kneading, patting, finger pressing and medical
massage techniques mainly, clamp the legs, hands and shoulders
with the aid of air massage, and then apply stretching massage to
soothe the meridians, promote blood circulation, relieve blockages
in the body.
Neck &
Shoulder
Care
Massage the neck and shoulders by means of kneading and
stretching techniques mainly, and also the upper back by medical
massage, and then press the Jianjing acupoint to relieve cervical
spondylosis and achieve the effect of relaxing the muscles of the
neck and shoulders. Massage intensity is gentle, suitable for people
working in office and suffering from cervical fatigue.
Hips&legs
Fit
Massage buttocks by kneading and medical massage mainly, and
then through patting and kneading, deeply massage buttocks and
perineum, to relax the hip muscles and lift the hip, which is suitable
for women massage, and also for men for maintenance of prostate.
Spine
Traction
Massage the waist by means of kneading, patting and medical
massage mainly, while the movement holds against the back and
waist for 3D medical massage, so as to relieve lumbar spine pain;
combined with the thermostatic heat configuration around the waist,
maintain a comfortable temperature to bring warm massage
experience; with gentle and moderate massage intensity and
comfortable temperature, bring warm massage experience.
Leg&foot
Relieve
Massage the shoulders and waist by means of kneading, patting,
kneading and patting mainly, apply air massage on the legs and
feet for squeezing massage, allowing more soothing leg and foot
massage, suitable for sedentary people with low stress on the legs
and feet, not only relieving the cervical spine, lumbar spine pain of
sedentary people, but also soothing the legs and feet. Massage
intensity is gentle.
Massage scenes(AI Intelligent)
Function Description
Total Relax
Chinese
Massage
Relieve
Muscle
Body
Balance
With the aid of flexible guide rails, let the body posture angle closer
to lying flat; with the effective anti-arch stretching of 3D movement
to the back, achieve zero pressure stretching, effectively relieve
lumbar muscle pain, and eliminate fatigue, thus to get a better
massage experience, relieve the stress on the body and mind.
By means of Traditional Chinese medicine massage technique
mainly, apply 3D massage on the back and waist so as to promote
the blood circulation of the back and waist, soothe the meridians
and relieve the blockage of the back and waist through massage. It
is suitable for people with back and waist pain, and lumbar muscle
strain. Massage intensity is gentle.
Apply deep pressure on the neck, back and waist, buttocks, and
legs by means of kneading, patting, finger pressing techniques
mainly to relieve the fatigue on body, allowing the body to better
relax.
Apply full air massage mainly, with the use of airbags for cross
circulation of kneading and pressure, so as to promote blood
circulation, alleviate pain in various body parts, and deeply relieve
muscle fatigue. (Remarks: full air massage mainly, with frequent air
massage action)
Mainly use calf and backrest electric push rod to clamp legs, hands
and shoulders with the aid of air massage, and then apply stretching
massage, while the movement holds against the back and waist for
3D medical massage, so that the body is in the Thai stretching
state. It is suitable for people under high stress to improve their
head-down on chest and humpback. Massage intensity is strong.
Massage scenes(Relaxing and Activating)
Function Description

Energy
Boost
Massage the waist, shoulders and neck by means of kneading,
patting, kneading and patting techniques, to awaken the body's
vital energy, stimulate physical energy through such deep
massage of the whole body with the massage intensity being
heavy, which is suitable for people with strong stress, such as
athletes, for stimulating the potential before a race.
Lunch
Break
Massage the back and waist by means of kneading and patting
techniques, and press the Shenyu acupoint, to improve the quality
of lunch break, so that the user is more energetic in afternoon
work. It is suitable for office workers, and the massage intensity is
gentle.
Back Spa
Deeply massage the whole body by pressing related acupoints by
means of kneading, patting, finger pressing and other massage
techniques, to let the stimulation fully reach the deep layer of
muscle tissue, feel warm locally combined with the function of hot
compress, and regulate the Qi and blood in a bid to achieve the
effect of warmth and damp expelling. (Note: the whole body
massage together with hot compress)
Sweet
Dream
Massage the shoulders, neck, back and waist by means of
kneading and medical massage techniques, and press the
acupoints of Fengchi and Shenyu, to improve the sleep quality
and help sleep. It is suitable for people suffering from poor sleep,
and the massage intensity is gentle.
Operation Instructions Operation Instructions
2425
Massage scenes(Exclusive for Family)
Function Description
Massage scenes(Overall Relaxation)
Function Description
Massage the shoulders, neck, back and waist by means of
kneading, patting, kneading and patting mainly, to relieve fatigue,
promote blood circulation, and release stress by such deep
massage. It is suitable for men, and the massage intensity is
moderate.
Massage the shoulders, neck, waist and hips by means of
kneading and finger pressing techniques, through the massage
on the whole body, to relax the body and mind, and enjoy the
queen-level treatment. It is suitable for women, and the massage
intensity is gentle.
Apply air massage on the whole body, with the foot roller and calf
kneading massage. Calf stretching function is canceled, suitable
for the elderly and people suffering stress on back. The massage
intensity is gentle.
Massage the shoulders, neck and waist by means of kneading,
patting, kneading and patting techniques mainly, to relieve
shoulder and neck pain, improve lumbar muscle soreness and
maintain lumbar spine through such deep massage. It is suitable
for office white-collar and sedentary people, and the massage
intensity is moderate.
Deeply massage the whole body by means of kneading, patting
and finger pressing techniques, to promote blood circulation
throughout the body and prevent blood clots. It is suitable for
people who live at home for a long time and do not like to go out,
and the massage intensity is moderately gentle.
President
Cosy
Keep Fit
Superior
Enjoyable
Office
Regimen
Health
Recharge Sweet
Dream
Massage the shoulders, neck, back and waist by means of
kneading and medical massage techniques, and press the
acupoints of Fengchi and Shenyu, to improve the sleep quality
and help sleep. It is suitable for people suffering from poor sleep,
and the massage intensity is gentle.

Operation Instructions Operation Instructions
Remote program selection
VI. remote program (please use this function after the equipment is turned on)
1. In the massage technique menu, a total of 11 options are available, including
kneading, patting I, patting II, kneading and patting, finger pressing I, finger pressing
II, shoulder grasp, 4DI, 4DII, 4DIII and 4DIV. (Note: Click the "leftward arrow
and rightward arrow " button in the remote adjustment menu to scroll left and right
to display more massage techniques).
Manual Air
Area 4D intensity
Spot Partial Full
Upper Lower
Massage Width
Massage Speed
Position
Up
Stop Knead Flap I Flap II Knead&Tap Shiatsu I Shiatsu II
Angle
Auto
Manual
Home
Settings
Power Pause
Manual
Down
4DⅠ
4DⅡ
4DⅢ
4DⅣ
Function Massage roller adjustment
Speed and strength.
Speed and strength.
Speed, width and strength.
Speed, width and strength.
-Adjustable speed in
five gears
-Adjustable width in
five gears
-Adjustable intensity
in five gears
Remote program - Schematic diagram of technique selection
Select the remote key in the left menu bar and click to enter the remote menu
to select massage technique, massage area, 4D intensity, massage hand
adjustment, massage width, massage speed, air massage, air intensity and other
massage functions.
Power Pause
00:30
Full
4D I
Back heat Roll Calf Voice
Manual
Area
Shoulder
Strong
Gentle
Soothing
4D +
Speed +
Speed -
4D -
Width +
Air intensity +
Air intensity -
Width -
Angle
Auto
Manual
Home
Settings
Knead
Stop
Grasp
Shiatsu Ⅱ
Shiatsu Ⅰ
Knead&Tap
FlapⅡ
FlapⅠ
4D I
4D II
4D III
4D IV
Function Massage roller adjustment
Press this key to massage without
any technique.
The speed and strength can be adjusted.
The speed, width and strength can be
adjusted.
The speed, width and strength can be
adjusted.
The speed and strength can be adjusted.
The speed, width and strength can be
adjusted.
The speed, width and strength can be
adjusted.
The speed and strength can be adjusted.
-Adjustable speed in
five gears
-Adjustable width in
five gears
-Adjustable intensity
in five gears
Note: You can also click the massage technique key in the "Current Status
No technique
Current Status - Schematic diagram of technique selection
” interface to select the corresponding massage technique in the pop-up menu
for massage (this function is a shortcut for switching massage techniques in the
current status page of the remote program - technique adjustment).
2627
Stop
Knead
Flap I
Flap II
Knead&Tap
Shiatsu I
Shiatsu II
Grasp

Operation Instructions
Manual Air
Area 4D intensity
Spot Partial Full
Upper Lower
Massage Width
Massage Speed
Position
Up
Stop Knead Flap I Flap II Knead&Tap Shiatsu I Shiatsu II
Angle
Auto
Manual
Home
Settings
Power Pause
Manual
Down
2.The massage area menu has five options: Spot, Partial, Full, Upper and Lower.
Select the corresponding massage area for massage.
Remote program - Schematic diagram of massage area selection
Key Description
Fixed-point massage at fixed-point position.
Small-scope local massage back and forth.
Full back massage back and forth.
Upper back massage back and forth.
Lower back massage back and forth.
Note: You can also click the massage area key in the "Current Status "
interface to select the corresponding massage area in the pop-up menu for massage
(this function is a shortcut for switching massage areas in the current status page of
the remote program - massage area).
Area
Operation Instructions
2829
Current Status - Schematic diagram of massage area selection
Power Pause
00:30
Full
4D I
Back heat Roll Calf Voice
Manual
Area
Shoulder
Strong
Gentle
Soothing
4D +
Speed +
Speed -
4D -
Width +
Air intensity +
Air intensity -
Width -
Angle
Auto
Manual
Home
Settings
4DⅠ
4D强度
4D强度
按摩速度
按摩速度
Spot
Partial
Full
Upper
Lower
Manual Air
Area 4D intensity
Spot Partial Full
Upper Lower
Massage Width
Massage Speed
Position
Up
Stop Knead Flap I Flap II Knead&Tap Shiatsu I Shiatsu II
Angle
Auto
Manual
Home
Settings
Power Pause
Manual
Down
3.You can adjust 4D intensity in the 4D intensity menu. There are 1~5 gears
available for adjustment with 1 being the weakest and 5 being the strongest. The
stronger the 4D intensity, the higher the massage roller ejection and the greater the
massage strength. Select plus key or minus key to reduce
the 4D intensity.
Remote program - Schematic diagram of 4D intensity

Operation Instructions Operation Instructions
Press this key to increase 4D intensity which is adjustable from 1 to 5.
Level 0
4D 4D
Power Pause
00:30
Full
4D I
Back heat Roll Calf Voice
Manual
Area
Shoulder
Strong
Gentle
Soothing
4D +
Speed +
Speed -
4D -
Width +
Air intensity +
Air intensity -
Width -
Angle
Auto
Manual
Home
Settings
Press this key to decrease 4D intensity which is adjustable from 1 to 5.
Key Description
Note: You can also select the 4D intensity + key or 4D intensity - key
in the "Current Status " interface to adjust the 4D intensity. (This function is a
shortcut to the 4D intensity in the current status page of the remote program-4D
intensity).
Level 1 Level 2 Level 3 Level 4
4D
4D
Level 0 Level 1 Level 2 Level 3 Level 4 Level 5
Key Description
Current Status - remote program-4D intensity
Press this key to increase 4D intensity which is adjustable from 1 to 5.
Press this key to decrease 4D intensity which is adjustable from 1 to 5.
Level 5
30 31
Manual Air
Area 4D intensity
Spot Partial Full
Upper Lower
Massage Width
Massage Speed
Position
Up
Stop Knead Flap I Flap II Knead&Tap Shiatsu I Shiatsu II
Angle
Auto
Manual
Home
Settings
Power Pause
Manual
Down
Manual Air
Area 4D intensity
Spot Partial Full
Upper Lower
Massage Width
Massage Speed
Position
Up
Stop Knead Flap I Flap II Knead&Tap Shiatsu I Shiatsu II
Angle
Auto
Manual
Home
Settings
Power Pause
Manual
Down
4. For massage hand adjustment, select the Up arrow or the Down arrow
down to upwards or downwards fine-adjust the massage hand position.
Remote program - Schematic diagram of massage hand adjustment
5. For massage width, as shown in the figure below, select the massage width to
adjust.
Remote program - Schematic diagram of massage width

Operation Instructions Operation Instructions
Power Pause
00:30
Full
4D I
Back heat Roll Calf Voice
Manual
Area
Shoulder
Strong
Gentle
Soothing
4D +
Speed +
Speed -
4D -
Width +
Air intensity +
Air intensity -
Width -
Angle
Auto
Manual
Home
Settings
(1)The width can be adjusted only when the user enters the remote mode in
selecting massage technique or massage area.
(2)The massage width is available from 1 to 5 gears, with 1 being the narrowest and
5 being the widest. Please use the following massage techniques: PattingⅠ, Patting
Ⅱ, Finger PressingⅠ, Finger Pressing Ⅱ, 4D Ⅲ and 4D Ⅳ.
Level 0 Level 1 Level 2 Level 3 Level 4 Level 5
Level 0 Level 1 Level 2 Level 3 Level 4 Level 5
Key Description
Press this key to increase massage width which is adjustable from 1 to 5.
Press this key to decrease massage width which is adjustable from 1 to 5.
Note: You can also select the massage width + key or massage width - key
in the "Current Status " interface to adjust the massage width.
Width +
Width -
Current Status - Schematic diagram of massage width
32 33
Manual Air
Area 4D intensity
Spot Partial Full
Upper Lower
Massage Width
Massage Speed
Position
Up
Stop Knead Flap I Flap II Knead&Tap Shiatsu I Shiatsu II
Angle
Auto
Manual
Home
Settings
Power Pause
Manual
Down
Width +
Width -
Key Description
Press this key to increase massage width which is adjustable from 1 to 5.
Press this key to decrease massage width which is adjustable from 1 to 5.
6. For massage speed, as shown in the figure below, select the massage speed to
adjust.
Remote program - Schematic diagram of massage speed
(1)The speed can be adjusted only when the user enters the remote mode in
selecting massage technique or massage position.
(2)The massage speed is available from 1 to 5 gears, with 1 being the fastest and 5
being the slowest. The speed cannot be adjusted when the massage technique
stops.
Level 0 Level 1 Level 2 Level 3 Level 4 Level 5
Key Description
Press this key to increase massage speed which is adjustable from 1 to 5.
Press this key to decrease massage speed which is adjustable from 1 to 5.

Power Pause
00:30
Full
4D I
Back heat Roll Calf Voice
Manual
Area
Shoulder
Strong
Gentle
Soothing
4D +
Speed +
Speed -
4D -
Width +
Air intensity +
Air intensity -
Width -
Angle
Auto
Manual
Home
Settings
Operation Instructions Operation Instructions
Note: You can also select the massage speed + key or massage speed -
key in the "Current Status " interface to adjust the massage speed.
Speed +
Speed -
Current Status - Schematic diagram of massage speed
Level 0 Level 1 Level 2 Level 3 Level 4 Level 5
Key Description
Press this key to increase massage speed which is adjustable from 1 to 5.
Press this key to decrease massage speed which is adjustable from 1 to 5.
Speed +
Speed -
3435
Air intensity
Full Upper body Lower body
Remote program-Schematic diagram of air massage
Upper body air pressure Lower body air pressure Whole body air pressure
Angle
Auto
Manual
Home
Settings
Manual Air
Power Pause
Manual
7.For air massage, as shown in the figure below, enter the air massage menu to
select the air mode. The air modes include upper body, lower body, and whole body
air massage. The air function will be disabled when all above modes are off.
Key Description
Press this key to enable or disable the whole body air massage function.
Press this key to enable or disable the upper body air massage function.
Press this key to enable or disable the lower body air massage function.
Air pressure display

Operation Instructions Operation Instructions
Power Pause
00:30
Full
4D I
Back heat Roll Calf Voice
Manual
Area
Shoulder
Strong
Gentle
Soothing
4D +
Speed +
Speed -
4D -
Width +
Air intensity +
Air intensity -
Width -
Angle
Auto
Manual
Home
Settings
Full
Lower body
Full
Upper body
Air intensity
Full Upper body Lower body
Angle
Auto
Manual
Home
Settings
Manual Air
Power Pause
Manual
Note: You press also air massage key in the "Current Status " interface,
and select corresponding air mode in the pop-up menu. (This function is a shortcut
to the air massage in the current status interface of the remote function - air
massage.)
Current status - Schematic diagram of air massage
8.For air intensity adjustment, the air function shall be turned on so as to adjust the
air intensity, with a total of five adjustable levels, with 1 being the weakest and 5
being the strongest.
3637
Current status - Schematic diagram of air intensity
Air intensity +
Power Pause
00:30
Full
4D I
Back heat Roll Calf Voice
Manual
Area
Shoulder
Strong
Gentle
Soothing
4D +
Speed +
Speed -
4D -
Width +
Air intensity +
Air intensity -
Width -
Angle
Auto
Manual
Home
Settings
Level 0 Level 1 Level 2 Level 3 Level 4 Level 5
Key Description
Press this key to increase the air intensity which is adjustable from 1 to 5.
Press this key to decrease the air intensity which is adjustable from 1 to 5.
Air intensity -
Note: You can also adjust the air intensity by selecting the air intensity+ key or
air intensity- key in the "Current Status " interface with the adjustable
intensity in five levels.
Level 0 Level 1 Level 2 Level 3 Level 4 Level 5
Air intensity +
Air intensity -
Key Description
Press this key to increase the air intensity which is adjustable from 1 to 5.
Press this key to decrease the air intensity which is adjustable from 1 to 5.
