CompactRIO PROFIBUSDP
-
Installation Instruction
-
V1.
6
/
0
3
.03
.2010

COMSOFT
CompactRIOPROFIBUSDP
Installation Instruction
V1.6/03.03.2010

d:\windoc\icp\project\5362_crio-dp_master\anwenderdoku\installation\version_1.6\crio_pb_e.doc
RevisionHistory
Version
DateDescriptionResp.
V1.603.03.2010 MinorFixesSF
V1.516.02.2010 NationalInstrumentsspecificchangesSF, JK
V1.423.09.2009 Technicaldatatableupdated SF
V1.307.05.2009 Technicaldatatableupdated BS
V1.228.04.2009 Technicaldatatableupdated SF
V1.120.08.2008 Technicaldatatableupdated JK
V1.021.02.2008 InitialVersion
COMSOFT
GmbH
Wachhausstrasse5a
76227Karlsruhe
Phone[phone]
Fax[phone]
Copyright 2010by COMSOFT GmbH
BusinessConfidential/COMSOFT Proprietary
Thisdocumentincludesdatathatshallnotbeduplicated,used,ordisclosed -in wholeorinpart-foranypurposeotherthan
toevaluatethisdocument. If,however,acontractwithacustomerisin force,thecustomershallhavetherighttoduplicate,
use,ordisclosethedatatotheextentprovided inthiscontract. Thisrestriction doesnotlimitthecustomer’srighttousethe
datainthisdocumentifit can alsobeobtainedfromanothersourcewithout restriction. Thedatasubjecttothisrestrictionare
confidential inallpagesofthisdocument.

Installation InstructionContents
COMSOFTCompactRIO PROFIBUSDP-Installation Instruction-V1.6/03.03.2010 i
Business Confidential/COMSOFT Proprietary
Contents
1InstallationoftheModule...............................................................................................1
2LEDsandConnectors...................................................................................................2
2.1 PositionofLEDsand Connectors.........................................................................2
2.2 LED's...................................................................................................................3
2.3 Powerconnector..................................................................................................4
2.4 9pinSUBDconnector.........................................................................................4
3TechnicalData..............................................................................................................5
3.1 Useinhazardouslocations..................................................................................5
4CE-ConformityDeclaration...........................................................................................6

ContentsInstallation Instruction
iiCompactRIO PROFIBUSDP-Installation Instruction-V1.6/03.03.2010COMSOFT
Business Confidential/COMSOFT Proprietary
ListofFigures
Figure1:cRIO PB module......................................................................................................1
Figure2:LEDsand connectors..............................................................................................2
Figure3:Profibus-Terminator(cabletypeBisnolongerused)..............................................4
ListofTables
Table1:MeaningoftheLEDs................................................................................................3
Table2:Powerrequirements..................................................................................................4
Table3:PinAssignment9pinSUBDconnector....................................................................4
Table4:TechnicalData..........................................................................................................5

Installation InstructionInstallation oftheModule
COMSOFTCompactRIO PROFIBUSDP-Installation Instruction-V1.6/03.03.2010 1
Business Confidential/COMSOFT Proprietary
1Installation oftheModule
The cRIOPBmoduleisaPROFIBUSDPMaster/SlavemoduleforNationalInstruments
CompactRIO, Single-BoardRIOsystems.Theconfigurationentirelytakesplacebymeansof
thedeliveredsoftware. Thus, nojumpersorDIP-switchadjustmentsarenecessary.
Tomountthemoduleinthe CompactRIO orSingle-BoardRIOproceedasfollows:
•Switchoff theCompactRIO orSingle-BoardRIO
•PlugthecRIO PBmoduleintoslot1until it snapsin.
Payattentiontoaproperadjustmentof theboardinthe guidance(avoidcanting!).
Importantnote: TheCompactRIO PROFIBUSDPmodulesrequire2.5Wofpower,soyou
must useitinSlot1whileleavingSlot2empty.
Importantnote: TheCompactRIO PROFIBUSDPmodulesissupported onlyin
CompactRIO reconfigurablechassis, suchasanNI cRIO-911x, andNISingle-BoardRIO
devices.
Figure1:cRIO PB module

LEDsand ConnectorsInstallation Instruction
2CompactRIO PROFIBUSDP-Installation Instruction-V1.6/03.03.2010COMSOFT
Business Confidential/COMSOFT Proprietary
2LEDsand Connectors
2.1Position ofLEDsand Connectors
Figure2:LEDsand connectors
SPI -ActivityLED
PWR -PowerindicationLED RUN -PROFIBUSActivityLED
BF -PROFIBUSBusFailLED
DP
–
PROFIBUS9pinSUB
-
Dconnector
Power
–
Powersupplyconnector(plug
withinscope of delivery)

Installation InstructionLEDsand Connectors
COMSOFTCompactRIO PROFIBUSDP-Installation Instruction-V1.6/03.03.2010 3
Business Confidential/COMSOFT Proprietary
2.2LED's
LED Colour State Function
OFF NopowersupplyconnectedPWRGreen ONPowersupplyconnected
OFF SPIbusnotactiveSPIGreen ONSPIbusactive
RUN Green
OperationasDP-Master
OFF ScanningnotactivatedONScanningactivated
OperationasDP-Slave
OFF DPSlavenot active
ONDPSlaveinitialized
Flash
fast DPSlave(AutoSlaveMode) waitsforaDPMasterto
communicate
Flash
slow DPSlave(AutoSlaveMode) baud ratedetectionactive
BFRed
OperationasDP-Master
OFF PROFIBUSOK
PROFIBUSBusFail
Possiblereasons:
Configurationerror
ON
Non respondingDP-Slave
OperationasDP-Slave
OFF DataexchangeO.K
Nodataexchange withDP
Master
Possiblereasons:
Configurationerror
DPMasternotactive
DPMastergone
ON
Watchdogexpired
Flash
fast DPSlave(AutoSlaveMode) waitsforaDPMasterto
communicate
Flash
slow DPSlave(AutoSlaveMode) baud ratedetectionactive
Table1:MeaningoftheLEDs

LEDsand ConnectorsInstallation Instruction
4CompactRIO PROFIBUSDP-Installation Instruction-V1.6/03.03.2010COMSOFT
Business Confidential/COMSOFT Proprietary
2.3Powerconnector
Parameter Value
Nominalvalue24 VoltsDC
Input range 11 –30 VoltsDC
Powerconsumption2.5WinActivemode
(Receivingand
Transmitting)
Table2:Powerrequirements
2.49pin SUB Dconnector
PinNumber Signal Function Direction
1-shielding
3RxD/TxD-PData+Input/Output
50V(potentialfree80mA)Feedingof busterminatorInput
65V(potentialfree80mA)Feedingof busterminatorOutput
8RxD/TxD-NData-Input/Output
Table3:PinAssignment9pinSUBDconnector
Remark: Toassurecorrectoperationof thePROFIBUS, aterminating resistormustbe
mountedat eachbusend.
Figure3:Profibus-Terminator(cabletypeBisnolongerused)
220 Ω390 Ω390 Ω
0VData-
Data
+
+5V 150 Ω390 Ω390 Ω
Cabletype A
Cabletype B

Installation InstructionTechnicalData
COMSOFTCompactRIO PROFIBUSDP-Installation Instruction-V1.6/03.03.2010 5
Business Confidential/COMSOFT Proprietary
3Technical Data
ProcessorARM9at150MHz
ProfibusControllerASPC2at48 MHz
Memory32 MbyteSRAM
4MbyteFlashTypeMemory
SPIInterfaceSPISlaveup to4Mbit/s
ProfibusInterface1Port (Sub-D9pins)
InterfacePhysics RS485(isolated)
ProfibusDataRates9600 Bit/s–12000Kbit/s
DataSizeof Process Imagemax. 8KByte
PROFIBUSIsolationVoltage 500VDC
PowerRequirements2.5WActiveMode (Transmitting
andReceiving)
StorageTemperatureRange-25 °C–+70 °C
Ambient TemperatureRange 0°C–+50°C
Weight0,16KG
RoHSCompliant 2002/95/EC
Certification DINEN55024, issue 2003-10
DINEN55022, issue 2007-04
Table4:TechnicalData
3.1Use in hazardouslocations
The moduleisonlysuitableforusein nonhazardous locations.

CE-ConformityDeclaration Installation Instruction
6CompactRIO PROFIBUSDP-Installation Instruction-V1.6/03.03.2010COMSOFT
Business Confidential/COMSOFT Proprietary
4CE- ConformityDeclaration
WeherewithdeclarethattheCompactRIO Module
cRIO PB
correspondstotherequirementsstatedinthe
EUstandards2004/108/EG.
The devicecorrespondstothefollowingstandards:
DINEN55024, issue 2003-10
DINEN55022, issue 2007-04
Manufacturer:
COMSOFT GmbH
Wachhausstr.5a
D-76227 Karlsruhe
