Otto Bock Juvo User manual

Juvo
Instructions for use (user) ...................................................................................... 3

2 Juvo

Foreword1 7..............................................................................................................................................................
Product description2 8............................................................................................................................................
Function2.1 8..............................................................................................................................................
Product overview2.2 9..................................................................................................................................
Safety3 11..................................................................................................................................................................
Explanation of warning symbols3.1 11............................................................................................................
General safety instructions3.2 12...................................................................................................................
Effects of electromagnetic interference on the product and on the user3.3 13......................................................
Nameplate and warning labels3.4 14..............................................................................................................
Signage on the product3.4.1 14.......................................................................................................................
Nameplate3.4.2 15..........................................................................................................................................
Warning labels3.4.3 16...................................................................................................................................
Delivery4 16...............................................................................................................................................................
Scope of delivery4.1 16................................................................................................................................
Accessories4.2 16.......................................................................................................................................
Accessories from other manufacturers4.2.1 17...................................................................................................
Storage4.3 17..............................................................................................................................................
Storage during daily use4.3.1 17......................................................................................................................
Storage during extended disuse4.3.2 17............................................................................................................
Preparation for use5 18...........................................................................................................................................
Safety instructions5.1 18...............................................................................................................................
Initial operation5.2 18...................................................................................................................................
Settings5.3 18.............................................................................................................................................
Changing control unit parameters5.3.1 18.........................................................................................................
Use6 19......................................................................................................................................................................
Circuit breaker6.1 19...................................................................................................................................
Side panels6.2 19........................................................................................................................................
Removing/installing the side panels6.2.1 19.......................................................................................................
Adjusting the side panels6.2.2 20.....................................................................................................................
Adjusting the control panel position6.2.3 21.......................................................................................................
Legrests6.3 22............................................................................................................................................
Removing/installing the legrests6.3.1 22............................................................................................................
Adjusting the legrests6.3.2 22..........................................................................................................................
Backrest6.4 23............................................................................................................................................
Folding the backrest up/down6.4.1 23..............................................................................................................
Adjusting the Back Angle6.4.2 24.....................................................................................................................
Getting in and transferring6.5 24...................................................................................................................
Control unit6.6 25........................................................................................................................................
VR2 control unit6.6.1 25..................................................................................................................................
Control panel6.6.1.1 25.....................................................................................................................................
Buttons and display functions6.6.1.1.1 26...............................................................................................................
Control panel6.6.1.2 27.....................................................................................................................................
Buttons and display functions6.6.1.2.1 27...............................................................................................................
R-Net control unit6.6.2 29................................................................................................................................
TEN° control panel6.6.2.1 29..............................................................................................................................
Buttons and display functions6.6.2.2 30...............................................................................................................
Adjustment possibilities6.6.2.3 34.......................................................................................................................
Environmental control via Bluetooth6.6.2.4 36.......................................................................................................
Activating devices6.6.2.4.1 36...............................................................................................................................
Pairing6.6.2.4.2 36...............................................................................................................................................
Selecting the connected devices6.6.2.4.3 39...........................................................................................................
Deactivating devices6.6.2.4.4 39............................................................................................................................
Operating mouse functions on a PC6.6.2.4.5 40......................................................................................................
Table of contents
3Juvo
Table of contents

Operating iOS device functions6.6.2.4.6 40............................................................................................................
Operating Android device functions6.6.2.4.7 40......................................................................................................
Environmental control via infrared (IR)6.6.2.5 40...................................................................................................
Operating IR devices6.6.2.5.1 40...........................................................................................................................
Learning and assigning IR codes6.6.2.5.2 41..........................................................................................................
Activating and deactivating IR codes6.6.2.5.3 42.....................................................................................................
Driving functions6.7 43.................................................................................................................................
Safety instructions6.7.1 43...............................................................................................................................
Driving notes6.7.2 44......................................................................................................................................
Switching on and off6.7.3 45............................................................................................................................
Selecting the speed levels6.7.4 46....................................................................................................................
Driving6.7.5 46...............................................................................................................................................
Range6.7.6 47................................................................................................................................................
Anti-tipper6.7.7 48..........................................................................................................................................
Drive-away lock6.7.8 48...................................................................................................................................
VR2 control unit6.7.8.1 48..................................................................................................................................
R-Net control unit6.7.8.2 49................................................................................................................................
Adjusting the driving characteristics6.7.9 50......................................................................................................
Enabling/disabling the brakes6.8 50...............................................................................................................
Batteries/charging process6.9 52..................................................................................................................
Safety instructions6.9.1 52...............................................................................................................................
General6.9.2 52.............................................................................................................................................
Battery charging information6.9.3 52.................................................................................................................
Battery charger6.9.4 53...................................................................................................................................
Charging the battery6.9.5 53............................................................................................................................
Seat6.10 55..................................................................................................................................................
Safety instructions6.10.1 55...............................................................................................................................
Seat type6.10.2 56...........................................................................................................................................
Contoured pads6.10.3 56..................................................................................................................................
Taking off and putting on the covers6.10.3.1 57......................................................................................................
Cleaning the covers6.10.3.2 58............................................................................................................................
Back upholstery6.10.4 58..................................................................................................................................
ADI back support (Baxx line)6.10.5 58................................................................................................................
Seat cushion6.10.6 59......................................................................................................................................
Recaro® seat6.10.7 59......................................................................................................................................
Settings6.10.7.1 59.............................................................................................................................................
Use6.10.7.2 60...................................................................................................................................................
Mounting kit for head/neckrests6.10.8 60............................................................................................................
Headrest6.10.9 60............................................................................................................................................
Power seat functions6.11 61...........................................................................................................................
Safety instructions6.11.1 61...............................................................................................................................
Power seat height adjustment6.11.2 62...............................................................................................................
Power seat tilt6.11.3 63.....................................................................................................................................
Power back angle adjustment6.11.4 64...............................................................................................................
Power legrests6.11.5 65....................................................................................................................................
Controlling power seat functions6.11.6 66...........................................................................................................
VR2 control unit6.11.6.1 66..................................................................................................................................
R-Net control unit6.11.6.2 66................................................................................................................................
Joystick functions6.11.7 67................................................................................................................................
Manual seat functions6.12 68..........................................................................................................................
Safety instructions6.12.1 68...............................................................................................................................
Manually elevating legrests6.12.2 68...................................................................................................................
Lap belt6.13 68.............................................................................................................................................
Adaptation6.13.1 69.........................................................................................................................................
Use6.13.2 70...................................................................................................................................................
Control unit accessories6.14 71......................................................................................................................
Separate LCD monitor6.14.1 71.........................................................................................................................
4 Juvo
Table of contents

Control panel for attendant6.14.2 72...................................................................................................................
Attendant control6.14.3 72.................................................................................................................................
VR2 attendant control6.14.3.1 72..........................................................................................................................
R-Net attendant control6.14.3.2 73........................................................................................................................
Adapter cable for Piko button6.14.4 75...............................................................................................................
Joystick top6.14.5 75........................................................................................................................................
Special controls6.15 75..................................................................................................................................
Safety6.15.1 75................................................................................................................................................
General safety instructions6.15.1.1 75...................................................................................................................
Safety requirements for operation6.15.1.2 76..........................................................................................................
Safety requirements for care, maintenance and disposal6.15.1.3 76..........................................................................
Effects of electromagnetic interference on the product and on the user6.15.1.4 76......................................................
Requirements for the user6.15.1.5 77....................................................................................................................
Safety functions6.15.1.6 77..................................................................................................................................
General6.15.2 78.............................................................................................................................................
Switching on6.15.2.1 78......................................................................................................................................
LCD monitor (Omni module)6.15.2.2 78................................................................................................................
Joystick controls6.15.3 78.................................................................................................................................
Product description6.15.3.1 78.............................................................................................................................
Joystick commands6.15.3.2 79.............................................................................................................................
Drive mode6.15.3.3 79.........................................................................................................................................
Latched drive mode6.15.3.4 79.............................................................................................................................
User switch6.15.3.5 80........................................................................................................................................
Push-button controls6.15.4 80...........................................................................................................................
Product description6.15.4.1 80.............................................................................................................................
1-button control (scan function)6.15.4.2 80............................................................................................................
3-button control6.15.4.3 81..................................................................................................................................
4-button control6.15.4.4 82..................................................................................................................................
Sip and puff control6.15.5 83.............................................................................................................................
Product description6.15.5.1 83.............................................................................................................................
Sip and puff commands6.15.5.2 83.......................................................................................................................
Drive mode6.15.5.3 84.........................................................................................................................................
Cleaning and care6.15.5.4 84...............................................................................................................................
Swivel arm6.15.6 84.........................................................................................................................................
Functions of the satellite switch6.15.6.1 84............................................................................................................
Operating the swivel unit6.15.6.2 85......................................................................................................................
Wireless environmental control6.15.7 85.............................................................................................................
Additional options6.16 86...............................................................................................................................
Control panel holder6.16.1 86............................................................................................................................
Lighting6.16.2 87.............................................................................................................................................
Lighting for road traffic6.16.2.1 87........................................................................................................................
Lighting (not intended for road traffic)6.16.2.2 88....................................................................................................
Belts/belt systems6.16.3 88...............................................................................................................................
Adaptation6.16.3.1 88.........................................................................................................................................
Use6.16.3.2 89...................................................................................................................................................
Caster wheel swivel lock6.16.4 90......................................................................................................................
Spring-mounted caster wheel swing arm6.16.5 91................................................................................................
Mechanical track stabiliser6.16.6 92...................................................................................................................
Electronic track stabiliser6.16.7 92.....................................................................................................................
Tray6.16.8 92...................................................................................................................................................
Safety instructions6.16.8.1 92...............................................................................................................................
Using the product6.16.8.2 93...............................................................................................................................
Cleaning6.16.8.3 94............................................................................................................................................
Maintenance6.16.8.4 94.......................................................................................................................................
Luggage carrier6.16.9 94..................................................................................................................................
Curb climbing assist6.16.10 95............................................................................................................................
External power supply6.16.11 95..........................................................................................................................
5Juvo
Table of contents

Hand heater6.16.12 96.......................................................................................................................................
Overview of other options6.16.13 96.....................................................................................................................
Disassembly and transport6.17 96...................................................................................................................
Safety instructions6.17.1 96...............................................................................................................................
Reducing the transportation size6.17.2 97...........................................................................................................
Preparing for transport6.17.3 98.........................................................................................................................
Use in vehicles for transporting persons with reduced mobility6.18 99..................................................................
Prohibited use6.18.4 101..................................................................................................................................
Care6.19 101................................................................................................................................................
Safety instructions6.19.1 101.............................................................................................................................
Cleaning6.19.2 102..........................................................................................................................................
Disinfection6.19.3 102......................................................................................................................................
Maintenance and repair7 102.................................................................................................................................
Safety instructions7.1 102.............................................................................................................................
Maintenance7.2 102.....................................................................................................................................
Maintenance intervals7.2.1 103........................................................................................................................
Repair7.3 104..............................................................................................................................................
Replacing a defective bulb7.3.1 104.................................................................................................................
Replacing a battery7.3.2 104............................................................................................................................
Troubleshooting7.4 104................................................................................................................................
Types of notifications7.4.1 104.........................................................................................................................
Procedure for warnings and error messages7.4.2 105.........................................................................................
Wheelchair control unit error overview7.4.3 105.................................................................................................
Attendant control error overview7.4.4 109..........................................................................................................
Behaviour in case of breakdowns7.5 110........................................................................................................
Disposal8 110...........................................................................................................................................................
Safety instructions8.1 110.............................................................................................................................
Disposal information8.2 110..........................................................................................................................
Legal information9 110............................................................................................................................................
Liability9.1 110............................................................................................................................................
CE conformity9.2 110...................................................................................................................................
Warranty9.3 111..........................................................................................................................................
Service life9.4 111.......................................................................................................................................
Technical data10 111.................................................................................................................................................
Appendices11 119......................................................................................................................................................
Threshold values for wheelchairs transportable by train11.1 119..........................................................................
6 Juvo
Table of contents

1 Foreword
INFORMATION
Last update: 2018-01-30
►Please read this document carefully before using the product.
►Follow the safety instructions to avoid injuries and damage to the product.
►Have yourself instructed by qualified personnel in the proper and safe use of the product.
►Please keep this document in a safe place.
INFORMATION
►New information regarding product safety and product recalls can be obtained from the Customer Care Cen
ter (CCC) at [email protected] or from the manufacturer's service department (see inside back cover or back
page for addresses).
►You can request this document as a PDF file from the Customer Care Center (CCC) at [email protected] or
from the manufacturer's service department (see inside back cover or back page for addresses). It is possible
to increase the display size of the PDF document.
►For further questions about the instructions for use, please contact the qualified personnel who issued the
product to you.
You have purchased a high-quality product which can be put to versatile, daily use at home and outdoors.
In order to exclude injuries of any type, familiarise yourself with the handling, functions and use of the product
before using it. These instructions for use provide the necessary information.
Please note the following in particular:
• All users and/or their attendants must be trained by qualified personnel in the use of the product with the aid of
the instructions for use (user). In particular, the user(s) and/or attendant(s) must be informed of the residual
risk using the safety instructions in the instructions for use (user).
• The product has been adapted to the needs of the user. Further changes may be made only by qualified per
sonnel. We recommend checking the product settings regularly in order to assure an optimum fit over the long
term. For growing children and youths in particular, fitting should be performed every six months.
• In case of questions or problems, please consult the qualified personnel that adapted the product or the manu
facturer's service (see inside back cover or back page for addresses).
• Note the address and telephone number of the responsible qualified personnel/specialist dealer and keep this
information with you, especially when using your wheelchair outdoors. Inform the qualified personnel immedi
ately in case of a malfunction. Provide all relevant details to make quick assistance possible.
• The operational safety of the product can only be ensured if it is used properly in accordance with the informa
tion contained in these instructions for use. The user is ultimately responsible for accident-free operation.
• Service and repairs to the product may only be carried out by qualified personnel. If you have any problems,
please contact your specialist dealer. This ensures that any necessary repairs will be made exclusively with
Ottobock spare parts.
• Your product may differ from the models shown.
• The manufacturer reserves the right to make technical changes to the model described in these instructions for
use.
7Juvo
Foreword

2 Product description
2.1 Function
The wheelchair is designed solely for individual use by persons who are unable to walk or who have a walking
impediment, and can be operated either by the patient or by an attendant.
The wheelchair can be used on solid ground both indoors and outdoors.
The power wheelchair is equipped with rear-wheel drive for good directional stability and to enable a small turning
radius.
The drive system with two 12 V batteries combined with spring-mounted drive wheels allows obstacles to be
crossed easily (Category B according to EN 12184) and offers safe operating performance.
The power wheelchair is equipped with front-wheel drive for excellent directional stability.
The drive system with two 12 V batteries combined with spring-mounted drive wheels allows obstacles to be
crossed easily (Category B according to EN 12184) and offers safe operating performance.
The power wheelchair is equipped with mid-wheel drive for good directional stability and to enable a very small
turning radius.
The drive system with two 12 V batteries combined with spring-mounted drive wheels allows obstacles to be
crossed easily (Category B according to EN 12184) and offers safe operating performance.
The power wheelchair is controlled by the VR2 wheelchair control device (see Page25). The latter includes a con
trol panel to enter driving commands and display the current status as well as a controller that operates the drive
motors and other electrical functions based on the inputs.
The power wheelchair is controlled by the R-Net wheelchair control device (see Page25). The corresponding
TEN° control panel serves to enter driving commands and display the current status. The control electronics in the
controller make it possible to control the drive motors and other power functions based on the input data.
The special features of the power wheelchair include:
• Individual adaptation possibilities for control device using programming and options.
• Individual adaptation possibilities with options and custom fabrication using modular components (chassis,
seating system, control device, accessories).
• Modular design that allows the power wheelchair to be equipped with additional modules and installed equip
ment in addition to the main components, suchas power seat adjustments, special controls, tray.
• Serviceability due to easy, straightforward access to all components.
8
Product description
Juvo

2.2 Product overview
1
1 Back support 9 Caster wheel
2 Module carrier for control electronics 10 Caster wheel splash guard
3 Side panel with arm support 11 Motor with brake release
4 Back support angle adjustment (power adjust
ment)
12 Suspension
5 Rear lights 13 Front light
6 Drive wheel splash guard 14 Leg support
7 Drive wheel 15 Seat cushion
8 Anti-tipper 16 Control panel
9Juvo
Product description

2
1 Back support 9 Drive wheel
2 Module carrier for control electronics 10 Anti-tipper
3 Side panel with arm support 11 Motor with brake release
4 Back support angle adjustment (power adjust
ment)
12 Drive wheel splash guard
5 Rear lights 13 Front light
6 Suspension 14 Leg support
7 Caster wheel splash guard 15 Seat cushion
8 Caster wheel 16 Control panel
10
Product description
Juvo

3
1 Back support 8 Caster wheels
2 Module carrier for control electronics 9 Drive wheel
3 Side panel with arm support 10 Motor with brake release
4 Back support angle adjustment (power adjust
ment)
11 Front light
5 Rear lights 12 Leg support
6 Suspension 13 Seat cushion
7 Drive wheel splash guard 14 Control panel
3 Safety
3.1 Explanation of warning symbols
WARNING Warning regarding possible serious risks of accident or injury.
CAUTION Warning regarding possible risks of accident or injury.
NOTICE Warning regarding possible technical damage.
11Juvo
Safety

3.2 General safety instructions
Hazards due to improper use of the product
WARNING
Improper product operation
Falling, tipping over, collision due to user error
►The product may only be used by a qualified user.
►As a user or attendant, you must be trained in the use of the product by qualified personnel instructed by the
manufacturer.
►Read the entire instructions for use.
►The product may not be used in case of exhaustion or under the influence of alcohol, medications or drugs.
►The product may not be used by users who have any mental limitations which can temporarily or permanently
limit attentiveness and judgement.
►You must observe road traffic regulations when driving in road traffic.
WARNING
Impermissible use
Risk of pinching, crushing, being pulled in, tipping, falling due to improper handling
►Only use this product for its original intended purpose.
►Only one person may be transported with the product at any one time.
WARNING
Overloading
Severe injuries if the product tips over due to overloading, damage to the product
►Do not exceed the maximum load capacity (see the nameplate and section "Technical data").
►Please note that certain options and add-on components will reduce the remaining load capacity.
WARNING
Exceeding the service life
Serious injuries due to failure to observe the manufacturer's requirements
►Using the product beyond the specified expected service life (see Page111) leads to increased residual risk
and should only take place subject to the due diligence and deliberations of qualified personnel.
►If the service life is reached, the user or a responsible attendant should contact the qualified personnel who
fitted the product or the manufacturer's servicing department (see inside rear cover or back page for
address). Here the user can obtain information about known risks and the current options for refurbishing the
product.
CAUTION
Extreme temperatures
Hypothermia or burns through contact with components, failure of components
►Do not expose the product to any extreme temperatures (e.g. direct sunlight, sauna, extreme cold).
NOTICE
Use under incorrect environmental conditions
Damage to the product due to excessively high or low temperatures
►Only use the product within a temperature range of -15°C to +40°C (5°F to +104°F).
12
Safety
Juvo

3.3 Effects of electromagnetic interference on the product and on the user
CAUTION
Use of mobile devices with electromagnetic emissions (e.g., mobile phones)
Falling, collision with persons or objects due to interference with the control signals
►Turn all mobile devices off while driving, since the driving characteristics of the product are affected by elec
tromagnetic fields.
►Turn the control unit off when it is not required, since the product may generate electromagnetic fields that
can cause interference with other devices. The product has been tested according to EMC regulations.
►Notwithstanding compliance with all applicable EMC directives and standards, the product can be affected by
interference from other electric devices (e.g., department store EAS systems) or cause interference with such
devices. If this occurs, move your product outside the interference range.
• Powered wheelchairs may be susceptible to electromagnetic interference (EMI), which is interfering electro
magnetic energy (EM) emitted from sources such as radio stations, TV stations, amateur radio (HAM) transmit
ters, two-way radios, and cellular phones.
• The interference (from radio wave sources) can cause the powered wheelchair to release its brakes, move by
itself, or move in unintended directions.
• It can also permanently damage the powered wheelchairs control system.
• Because EM energy rapidly becomes more intense as one move closer to the transmitting antenna (source),
the EM fields from hand-held radio wave sources (transceivers) are of special concern. It is possible to uninten
tionally bring high levels of EM energy very close to the powered wheelchair's control system while using these
devices. This can affect powered wheelchair movement and braking.
• Other types of hand-held devices, such as cordless phones, laptop computers, AM/FM radios, TV sets, CD
players, and cassette players, and small appliances, such as electric shavers and hair dryers, so far as we
know, are not likely to cause EMI problems to your powered wheelchair.
13Juvo
Safety

3.4 Nameplate and warning labels
3.4.1 Signage on the product
The warning signs and nameplates are attached at the following mounting points to the power wheelchair:
4
5
14
Safety
Juvo

3.4.2 Nameplate
Label Meaning
AProduct; product reference number
BRead the instructions for use before using the product.
Observe safety information in the instructions for use.
CSymbol for separate collection of electrical and electronic
devices. Components of the power wheelchair and batteries
may not be disposed of in household waste.
DEuropean article number (EAN)
EProduct version*
FSerial number**
GMaximum load capacity (see section "Technical data")
HMaximum climbing ability (see section "Technical data")
IMaximum speed (see section "Technical data")
JAllowable axle load, front
KAllowable axle load, rear
LMaximum gross weight
MManufacturer information/address
NCE marking – product safety in accordance with EU directives
The nameplates are found on the mobility
base.
OManufacturing date***
* NN = country code; VV = country-specific version; C = configuration
** S = speed code; YY = year of manufacture; WW = week of manufacture; PP = production site; XXX = sequential
production number
*** YYYY = year of manufacture; MM = month of manufacture; DD = day of manufacture
Label Meaning
AProduct; product reference number
BRead the instructions for use before using the product.
Observe safety information in the instructions for use
CSymbol for separate collection of electric and electronic
devices. Components of the power wheelchair and batteries
may not be disposed of in household waste.
DEuropean article number (EAN)
EProduct version*
FSerial number**
GMaximum load (see section "Technical data")
HMaximum climbing ability (see section "Technical data")
IMaximum speed (see section "Technical data")
JAllowable axle load, front
KAllowable axle load, middle
LAllowable axle load, rear
MMaximum gross weight
NManufacturer information/address
OCE marking – product safety in accordance with EU directives
The nameplates are found on the mobility
base.
PManufacturing date***
* NN = country code; VV = country-specific version; C = configuration
** S = speed code; YY = year of manufacture; WW = week of manufacture; PP = production site; XXX = sequential
production number
*** YYYY = year of manufacture; MM = month of manufacture; DD = day of manufacture
If the adjacent symbol appears on the nameplate, this indicates the following:
The product may not be used as a seat in vehicles for transporting persons with reduced mobility.
15Juvo
Safety

3.4.3 Warning labels
Label Meaning
APower driving mode: motor brake locked (see Page50)
BManual driving mode: motor brake released (see Page50)
ACaster wheel swivel lock: the caster wheels are unlocked and
can swivel freely (when ordered)
BCaster wheel swivel lock: the caster wheels are locked for driv
ing straight ahead (when ordered)
Risk of pinching. Do not reach into the danger area.
Label Meaning
APower driving mode: motor brake locked (see Page50)
BManual driving mode: motor brake released (see Page50)
Risk of pinching. Do not reach into the danger area.
Label Meaning
(Only in case of installation of ISO sets according to ISO
7176-19)
Fixation point/eyebolt to attach the product in vehicles for trans
porting persons with reduced mobility
4 Delivery
4.1 Scope of delivery
The power wheelchair is normally shipped fully assembled and fitted to the personal requirements of the respective
user.
The scope of delivery includes:
• Fitted power wheelchair with main components
• Options depending on equipment
• Battery charger
• Instructions for use (user)
4.2 Accessories
The standard model can be fitted to the user's personal requirements thanks to a large range of options.
A full list of the available modules and accessories is shown on the order form and in the accessories catalogue.
For use of the options, see the section "Use".
Please note that retrofitting options further reduces the maximum load capacity (user weight + luggage).
16
Delivery
Juvo

The maximum load capacity (see print on the nameplate; see Page15) is thereby respectively reduced by the
weight of the retrofitted options.
4.2.1 Accessories from other manufacturers
As per the order for the power wheelchair, some components from third-party manufacturers have been installed
prior to delivery. Please observe the following instructions in this regard:
• Accessories from other manufacturers must be intended for use on wheelchairs and must fulfil all currently
applicable legal requirements under the Medical Devices Act as well as further applicable standards.
• When using the accessories from other manufacturers, the instructions for use / manufacturer's instructions for
the relevant accessories must be strictly observed. These are included with the instructions for use.
• Ottobock assumes no liability for combinations with medical devices and/or accessories from other manufac
turers not included in Ottobock's modular system.
• In case of questions or problems with accessories from other manufacturers, please contact the qualified per
sonnel who adjusted this product.
4.3 Storage
4.3.1 Storage during daily use
The power wheelchair should always be protected against external influences.
The control unit must be turned off.
4.3.2 Storage during extended disuse
NOTICE
Deep discharge
Battery damage due to standby current
►Deactivate the circuit breaker if the wheelchair is not used for more than 3 days.
►To deactivate the circuit breaker: see Page19
Please observe the following if the power wheelchair is not used for more than 3days:
Storage conditions
• Maintain an ambient temperature between -15°C and +40°C (5°F and +104°F) and relative humidity
between 45% and 85%.
• Store the power wheelchair in a dry, enclosed room with sufficient air circulation and protection from external
influences.
• Protect the wheels against ground frost, e.g.by relieving them completely through assembly blocks or wooden
boards.
• Maintain sufficient clearance from sources of heat. If the product is parked for an extended period of time or
the tyres overheat (e.g.in the vicinity of radiators or in case of exposure to strong sunlight behind glass), the
tyres may become permanently deformed.
• Fill pneumatic tyres with slight overpressure.
• Rotate the wheels weekly to prevent flat tyres from extended standing.
• For extended storage, store the power wheelchair so the wheels are not in contact with the ground.
Note regarding the tyres
• If the power wheelchair is not moved for several days, permanent colour changes may occur where the wheel
chair comes into contact with the surface it is standing on. Therefore a suitable mat should be used when park
ing it for extended periods of time.
• Tyres contain chemical substances that can react with other chemical substances (such as cleaning agents,
acids, etc.).
• Black tyres contain soot particles. They may leave black marks where they come into contact with the ground.
Therefore the manufacturer recommends grey tyres if the wheelchair is primarily used indoors.
• Avoid unnecessary parking outdoors. Direct exposure to sunlight/UV radiation causes the tyres to age more
quickly. As a result, the tread surface hardens and corner pieces break out of the tread.
• The tyres must be changed when the tread is less than 1mm (0.04") to ensure safe driving behaviour.
• The tyres should be replaced every 2years regardless of wear and tear.
• When power wheelchairs with PU tyres are parked for long periods, the tyres may become deformed (flat
spots). This deformation will go away on its own over time while driving.
17Juvo
Delivery

5 Preparation for use
5.1 Safety instructions
WARNING
Improper handling of packaging materials
Risk of suffocation due to neglect of the duty to supervise
►Packaging materials must be kept out of the reach of children.
WARNING
Uncontrolled movement of components when making adjustments
Crushing, pinching, blows due to non-observance of the maintenance and repair instructions
►Ensure that body parts, such as hands or head, are never in the danger zone.
►Perform the work with the aid of a helper for support.
WARNING
Independent modification of settings
Serious injuries to the user due to unallowable changes to the product
►Do not modify the settings established by the qualified personnel.
►In case of problems with the settings (unsatisfactory seating position, caster wheel wobble, etc.) please con
tact the qualified personnel who adjusted your product.
CAUTION
Screw connections not tightened
Pinching, crushing, tipping over, falling of user due to assembly errors
►After all adjusting/readjusting work authorised by the manufacturer, retighten the mounting screws/nuts firmly.
Observe any torque settings which may be specified.
5.2 Initial operation
The specialist dealer ships the power wheelchair fully assembled and ready to use.
The following additional tasks may be required:
• Activating the circuit breaker (see Page19)
• Folding up the backrest (see Page23)
• Charging the battery (see Page53)
5.3 Settings
The user may only perform the fine-tuning adjustments described in the following.
This fine-tuning should be carried out by attendants and only in the presence of the user. The user should sit
upright in the power wheelchair while adjustments are made.
• Adjusting the back angle (see Page24)
• Adjusting the armrests (see Page20)
• Adjusting the position of the control panel (see Page21)
• Adjusting the lower leg length (see Page22)
• Adjusting the lap belt (see Page68)
• Adjusting the belt lengths (see Page88)
Further adjustments may be made only by qualified personnel
All parts of the product should be cleaned thoroughly before adjustments are made.
5.3.1 Changing control unit parameters
WARNING
Incorrect configuration settings
Falling, tipping over, collision due to programming errors
►Programming may only be performed by qualified personnel trained by the manufacturer. The manufacturer of
the product and the control unit manufacturer are not liable in case of damage caused by programming which
was not performed properly and/or which was not adjusted properly according to the user's abilities.
18
Preparation for use
Juvo

If necessary, the qualified personnel can adapt the preprogrammed wheelchair control unit and options to the con
crete requirements of the user.
6 Use
6.1 Circuit breaker
INFORMATION
►Should the automatic circuit breaker deactivate repeatedly after activation for no discernible reason, contact
the qualified personnel.
►For shipping or when the power wheelchair is not being used for an extended period of time, the automatic
circuit breaker should be deactivated.
The automatic circuit breaker has to be activated before the power wheelchair can be switched on.
It is located under the seat between the drive wheels.
6Activating the circuit breaker
►Close the reset lever, which is at an angle (see
fig.6, item1).
→The reset lever engages and the circuit breaker is
activated.
Deactivating the circuit breaker
►Press the pushbutton until the reset lever flips up at
an angle (see fig.6, item2).
→The circuit breaker is deactivated.
6.2 Side panels
The side panels protect the user and his/her clothing from getting dirty.
The installed armrests offer the user additional support for the forearms.
6.2.1 Removing/installing the side panels
To make getting in from the side easier or for transportation, the side panels can be removed if needed.
7Removing the side panel
1) Loosen the thumb screw on the side panel holder
(see fig.7, item1).
2) Pull the side panel out from the side panel holder
and set it aside (see fig.7, item2).
3) Only for side panel with control panel:
→Turn the control device off (see Page25).
→Carefully let the side panel with the control pan
el hang down while getting in.
→For transporting the power wheelchair, place
the side panel on the seat.
Installing the side panel
1) Insert the side panel into the side panel holder.
2) Re-tighten the thumb screw on the side panel hold
er (see fig.7, item1).
To make getting in from the side easier or for transportation, the side panels can be removed if needed.
19Juvo
Use

8Removing the side panel
1) Loosen the thumb screw on the side panel holder
(see fig.8, item1).
2) Pull the side panel out from the side panel holder
and set it aside (see fig.8, item2).
3) Only for side panel with control panel:
→Turn the control unit off (see Page25).
→Carefully let the side panel with the control pan
el hang down while getting in.
→For transporting the power wheelchair, place
the side panel on the seat.
Installing the side panel
1) Insert the side panel into the side panel holder.
2) Re-tighten the thumb screw on the side panel hold
er (see fig.8, item1).
To make getting in from the side easier or for transportation, the side panels can be removed if needed.
9Removing the side panel
1) Loosen the thumb screw on the side panel holder
(see fig.9, item1).
2) Pull the side panel out from the side panel holder
and set it aside.
3) Only for side panel with control panel:
→Turn the control unit off (see Page25).
→Carefully let the side panel with the control pan
el hang down while getting in.
→For transporting the power wheelchair, place
the side panel on the seat.
Installing the side panel
1) Insert the side panel into the side panel holder.
2) Re-tighten the thumb screw on the side panel hold
er (see fig.9, item1).
6.2.2 Adjusting the side panels
The height of the armrests, the forearm length and the clothing protector can be subsequently adapted.
The height of the armrests, the forearm length and the depth position of the side panel can be subsequently adap
ted.
10 Adjusting the armrest height
1) Loosen the Allen head screw on the side panel
mounting (see fig.10, item1).
2) Slide the armrests up or down to the desired posi
tion.
3) Re-tighten the Allen head screw.
Adjusting the armrest to the forearm length
1) Loosen the 2 Allen head screws on the underside of
the armrest (see fig.10, item2).
2) Push the armrest to the front or back into the
desired position.
3) Tighten the 2 Allen head screws.
20
Use
Juvo
