Otto Bock Motus CV User manual

Motus CV, Motus CS
Instructions for use ............................................................................................... 3

2 Motus CV, Motus CS

Foreword1 6..............................................................................................................................................................
Product description2 7............................................................................................................................................
Function2.1 7..............................................................................................................................................
Product overview2.2 7..................................................................................................................................
Intended use3 9........................................................................................................................................................
Indications for use3.1 9................................................................................................................................
Special features of the CLT version3.1.1 9.........................................................................................................
Indications3.2 9...........................................................................................................................................
Contraindications3.3 9.................................................................................................................................
Absolute Contraindications3.3.1 9....................................................................................................................
Relative Contraindications3.3.2 9.....................................................................................................................
Qualification3.4 9.........................................................................................................................................
Safety4 9....................................................................................................................................................................
Explanation of warning symbols4.1 9..............................................................................................................
Safety instructions for assembly and adjustments4.2 9......................................................................................
Safety instructions for use4.3 10....................................................................................................................
Side effects4.4 13........................................................................................................................................
Further information4.5 13..............................................................................................................................
Nameplate and warning labels4.6 13..............................................................................................................
Delivery5 14...............................................................................................................................................................
Scope of delivery5.1 14................................................................................................................................
Options5.2 14.............................................................................................................................................
Storage5.3 14..............................................................................................................................................
Storage during daily use5.3.1 14......................................................................................................................
Storage during extended disuse5.3.2 14............................................................................................................
Preparing the product for use6 14.........................................................................................................................
Assembly6.1 14...........................................................................................................................................
Settings and assembly instructions7 15................................................................................................................
Prerequisites7.1 15......................................................................................................................................
Safety Instructions for Assembly7.2 16...........................................................................................................
Adjusting the drive wheels7.3 16....................................................................................................................
Setting the drive wheels horizontally7.3.1 17......................................................................................................
Adjusting the drive wheels vertically7.3.2 17.......................................................................................................
Adjusting the drive wheel camber7.3.3 18..........................................................................................................
Adjusting the track7.3.4 20..............................................................................................................................
Adjusting the quick-release axle7.3.5 20............................................................................................................
Adjusting the handrims7.3.6 20........................................................................................................................
Adjusting the caster wheels7.4 21..................................................................................................................
Adjusting the caster journal angle7.4.1 21..........................................................................................................
Changing the installation position of the caster wheels7.4.2 22............................................................................
Adjusting the wheel locks7.5 23.....................................................................................................................
Adjusting the knee lever wheel locks7.5.1 23.....................................................................................................
Adjusting the scissor wheel locks7.5.2 23..........................................................................................................
Adjusting the braking force of the drum brake7.5.3 24.........................................................................................
Adjusting the back support7.6 24...................................................................................................................
Adjusting the back support height7.6.1 24.........................................................................................................
Adjusting the back support angle7.6.2 25..........................................................................................................
Adjusting the back support upholstery / seat upholstery7.7 25...........................................................................
Adjusting the back support upholstery7.7.1 25...................................................................................................
Adjusting the seat upholstery7.7.2 26................................................................................................................
Adjusting the leg supports7.8 27....................................................................................................................
Adjusting the lower leg length7.8.1 27...............................................................................................................
Adjusting the support angle7.8.2 27..................................................................................................................
Adjusting the posterior lower leg pad on the elevating leg support7.8.3 28............................................................
Table of contents
3Motus CV, Motus CS
Table of contents

Adjusting the side panels7.9 28.....................................................................................................................
Adjusting the anti-tipper7.10 29.......................................................................................................................
Adjusting the lap belt7.11 30...........................................................................................................................
Delivery8 30...............................................................................................................................................................
Final inspection8.1 30..................................................................................................................................
Transport to the customer8.2 31....................................................................................................................
Handing over the product8.3 31.....................................................................................................................
Use9 31......................................................................................................................................................................
Instructions for use9.1 31..............................................................................................................................
Getting in and transferring9.2 31...................................................................................................................
Legrests9.3 32............................................................................................................................................
Removing and attaching the leg supports9.3.1 33...............................................................................................
Folding the foot plate up and down9.3.2 34.......................................................................................................
Removing and fastening the calf strap9.3.3 34...................................................................................................
Adjusting the angle of the elevating leg support9.3.4 35......................................................................................
Adjusting the leg supports9.3.5 35....................................................................................................................
Seat and back upholstery9.4 35.....................................................................................................................
Removing and fastening the seat cushion9.4.1 35...............................................................................................
Removing and fastening the back support pad9.4.2 36........................................................................................
Backrest9.5 37............................................................................................................................................
Side panels9.6 37........................................................................................................................................
Adjusting the height of the forearm support9.6.1 39............................................................................................
Removing the side panels9.6.2 39....................................................................................................................
Removing the padded arm support9.6.3 40........................................................................................................
Push handles9.7 40......................................................................................................................................
Adjusting the height of the push handles9.7.1 40................................................................................................
Removing the push handles9.7.2 41..................................................................................................................
Stabiliser bar9.8 41......................................................................................................................................
Drive wheels9.9 42.......................................................................................................................................
Removing and mounting the drive wheels9.9.1 42...............................................................................................
Spoke protector9.9.2 43..................................................................................................................................
Caster wheels and caster forks9.10 43.............................................................................................................
Approach in case of stiffness9.10.1 43................................................................................................................
Wheel locks9.11 44.......................................................................................................................................
Using the wheel locks9.11.1 44..........................................................................................................................
Drum brake9.11.2 45........................................................................................................................................
Anti-tipper/tip-assist9.12 46............................................................................................................................
Activating and deactivating the anti-tipper9.12.1 46..............................................................................................
Using the tip-assist9.12.2 47..............................................................................................................................
Crutch holder with hook-and-loop fastening strap9.13 47...................................................................................
Wheelbase extension9.14 47...........................................................................................................................
Transport wheels9.15 48................................................................................................................................
Using the transport wheels9.15.1 48...................................................................................................................
Lap belt (seat belt)9.16 49..............................................................................................................................
Tray9.17 49...................................................................................................................................................
Additional options9.18 50...............................................................................................................................
Disassembly and transport9.19 50...................................................................................................................
Use in vehicles for transporting persons with reduced mobility9.20 52..................................................................
Required accessories9.20.1 52..........................................................................................................................
Using the product in a vehicle9.20.2 53...............................................................................................................
Restrictions for use9.20.3 56.............................................................................................................................
Care9.21 58..................................................................................................................................................
Cleaning9.21.1 58............................................................................................................................................
Cleaning by hand9.21.1.1 58................................................................................................................................
Cleaning the seat cushion9.21.1.2 58....................................................................................................................
Cleaning belts/straps9.21.1.3 58..........................................................................................................................
Disinfection9.21.2 59........................................................................................................................................
4 Motus CV, Motus CS
Table of contents

Maintenance and repair10 59...................................................................................................................................
Maintenance10.1 59.......................................................................................................................................
Maintenance intervals10.1.1 59..........................................................................................................................
Maintenance tasks10.1.2 60..............................................................................................................................
Repair10.2 60...............................................................................................................................................
Inner tube, rim tape and tyre replacement10.2.1 60..............................................................................................
Disposal11 61.............................................................................................................................................................
Disposal information11.1 61............................................................................................................................
Information on re-use11.2 62...........................................................................................................................
Legal information12 62..............................................................................................................................................
Liability12.1 62..............................................................................................................................................
Warranty12.2 62............................................................................................................................................
Service life12.3 62.........................................................................................................................................
Technical data13 62...................................................................................................................................................
Appendices14 64........................................................................................................................................................
Threshold values for wheelchairs transportable by train14.1 64...........................................................................
Required tools14.2 64....................................................................................................................................
Torque values of the screw connections14.3 65.................................................................................................
5Motus CV, Motus CS
Table of contents

1 Foreword
INFORMATION
Date of last update: 2020-03-19
►Please read this document carefully before using the product and observe the safety notices.
►Obtain instruction from the qualified personnel in the safe use of the product.
►Please contact the qualified personnel if you have questions about the product or in case of problems.
►Report each serious incident in connection with the product, in particular a worsening of the state of health, to
the manufacturer and to the relevant authority in your country.
►Please keep this document for your records.
INFORMATION
►New information regarding product safety and product recalls as well as the declaration of conformity can be
obtained at [email protected] or from the manufacturer’s service department (see inside or outside of back
cover for addresses).
►You can request this document as a PDF file at [email protected] or from the manufacturer’s service depart
ment (see inside or outside of back cover for addresses). The PDF file can also be displayed in a larger size.
You have received a product that is very versatile for everyday use at home and outdoors.
In order to exclude injuries of any type, familiarise yourself with the handling, functions and intended use of the
product before using it. These instructions for use provide you with the related necessary information.
Please note the following in particular:
• All users and/or their attendants must be trained by qualified personnel in the use of the product. In particular,
users and/or attendants must be informed of the residual risks with the aid of the safety notices in the instruc
tions for use (user).
• The product was adapted to the needs of the user. Subsequent changes may be made only by qualified per
sonnel. We recommend checking the product settings onceper year to ensure optimal treatment over the long
term. Especially for users with a changing anatomy (forexample body dimensions, weight), an adjustment at
least onceevery six months is recommended.
• Your product may differ from the models shown. In particular, not all the options described in these instruc
tions for use will be installed on your product.
• The manufacturer reserves the right to make technical changes to the model described in these instructions for
use.
6 Motus CV, Motus CS
Foreword

2 Product description
2.1 Function
The wheelchair is intended exclusively for transporting one person on the seat.
The wheelchair can be used on solid ground both indoors and outdoors.
2.2 Product overview
1
Motus CV
Maximum load: 125 kg (140 kg with double crossbrace)
Thanks to its frame geometry, the wheelchair makes it possible to guide the legs precisely. The leg supports can
be swung away and removed.
1 Side panel 9 Caster wheel
2 Seat/seat pad 10 Drive wheel with handrim
3 Leg support (removable) 11 Release button for quick-release axle
4 Knee lever wheel lock 12 Rear frame
5 Front frame 13 Back tube
6 Crossbrace 14 Back support, back support upholstery
7 Foot plate (segmented) 15 Push handle
8 Caster fork
7Motus CV, Motus CS
Product description

2
Motus CS
Maximum load:125 kg (140 kg with double crossbrace)
Thanks to its closed, rigid frame geometry, the wheelchair enables particularly active driving. The leg support
remains on the wheelchair.
1 Side panel 8 Caster wheel
2 Seat/seat pad 9 Drive wheel with handrim
3 Knee lever wheel lock 10 Release button for quick-release axle
4 Front frame 11 Rear frame
5 Crossbrace 12 Back tube
6 Foot plate (single-panel) 13 Back support, back support upholstery
7 Caster fork 14 Push handle
8
Product description
Motus CV, Motus CS

3 Intended use
The safe use of the product can only be ensured in case of intended use in accordance with the information con
tained in these instructions for use. The user is ultimately responsible for accident-free operation.
3.1 Indications for use
The wheelchair is intended for everyday indoor and outdoor use, by the user or an attendant, of people with tem
porary or permanent limitations of the ability to walk, inability to walk or difficulty standing up.
The product is suitable for users with intact skin whose anatomy (suchas body dimensions and weight) permits the
intended use of the product.
The wheelchair may only be used with the options listed on the product order form.
Ottobock assumes no liability for combinations with medical devices and/or accessories from other manufacturers
outside the modular system.
Combinations based on a combination agreement that have been evaluated for effectiveness and safety are an
exception to this.
3.1.1 Special features of the CLT version
In the CLT version, the wheelchair features permanently welded side supports for mounting the drive wheel attach
ment devices, a permanently welded back support and permanently welded caster attachment devices. In this
weight-saving version, the back support height and back support angle, for example, cannot be subsequently
adjusted. Furthermore, installation of certain options is not possible with this version.
For these reasons, this wheelchair version is intended only for experienced users with sporting ambitions who,
thanks to their physiological capabilities, are able to handle the wheelchair proficiently. Before fitting with this ver
sion, the user should be examined intensively for suitability (adequate physiological capabilities).
3.2 Indications
• Minor to pronounced or complete restrictions of mobility
3.3 Contraindications
3.3.1 Absolute Contraindications
• None known
3.3.2 Relative Contraindications
• Failure to meet physical or mental requirements
3.4 Qualification
Installation and adjustment tasks may only be carried out by qualified personnel. Compliance with all manufacturer
specifications and all applicable legal provisions is required. Please contact the manufacturer’s service department
for further information (see inside or outside of rear cover for addresses).
4 Safety
4.1 Explanation of warning symbols
WARNING Warning regarding possible serious risks of accident or injury.
CAUTION Warning regarding possible risks of accident or injury.
NOTICE Warning regarding possible technical damage.
4.2 Safety instructions for assembly and adjustments
WARNING
Making incorrect adjustments
Risk of falling, tipping over or malposition of the user due to incorrect settings
►Settings may only be changed by qualified personnel unless otherwise prescribed.
►Before testing setting changes with the user seated, all screw connections must be firmly tightened.
►Check the product for safety and functionality after changing the settings.
9Motus CV, Motus CS
Intended use

4.3 Safety instructions for use
Hazards during preparation for use
WARNING
Independent modification of settings
Serious injuries to the user due to improper changes to the product
►Do not modify the settings established by the qualified personnel. Only the settings described in the section
“Use” in these instructions for use may be adjusted independently.
►In case of problems with the settings, please contact the qualified personnel who adjusted your product.
WARNING
Improper handling of packaging materials
Risk of suffocation due to neglect of the duty to supervise
►Packaging materials must be kept out of the reach of children.
Risk of hand injuries
CAUTION
Pinching on components
Pinching, crushing due to lack of caution in danger areas
►Do not reach between the drive wheel and wheel lock or drive wheel and side panel when driving the wheel
chair.
►Do not reach into the spokes of the rotating drive wheel.
►Pay attention not to pinch parts of your body at the wheel lock lever or between the side or frame parts.
CAUTION
Heat development when braking with handrims
Burns due to insufficient hand protection
►Wear wheelchair gloves when travelling at high speeds.
Hazards while driving
WARNING
Improper use of the wheel lock
Falling due to abrupt braking, rolling away of the wheelchair, damage to the wheel lock
►Do not use the wheel lock as a driving brake.
►Apply the wheel lock to prevent the wheelchair from moving on uneven ground or during transfers (e.g.into a
car).
CAUTION
Lack of driving experience
Tipping over, falling due to errors in handling the product
►Practise on level, open ground first.
►Learn with the support of an assistant how the product reacts to changes in centre of gravity, e.g.downward
or upward slopes, inclines or when overcoming obstacles.
CAUTION
Leaning forward in the wheelchair
Tipping over, overturning due to incorrect centre of gravity
►Do not lean too far out of the wheelchair when trying to pick up objects.
►Lean well forward with your upper body when climbing gradients, overcoming obstacles on gradients or on
ramps. If users cannot lean their upper body forward, accompanying persons must support the wheelchair
from behind.
10
Safety
Motus CV, Motus CS

CAUTION
Risky operation
Falling, tipping over backwards due to approaching obstacles incorrectly
►Push slowly when crossing obstacles (e.g. steps, curbs) and negotiating uphill or downhill slopes and
inclines.
►Never cross obstacles at an angle. Always approach obstacles head on (at an angle of 90°).
►Raise the front wheels before crossing obstacles.
►Avoid collisions with obstacles and dropping off curbs/ledges.
►Avoid riding cross-country.
CAUTION
Lack of tipping resistance on public transport
Tipping over, user falls, damage to the product due to incorrect positioning
►When using public transit, always observe the currently applicable legal requirements and the safety notices
of the public transit operator.
►Use the permanently installed seats in the vehicle. If you depend on using your wheelchair as a seat, please
use the designated wheelchair spaces and safety securing equipment provided. Always ensure that you are
held in place securely.
CAUTION
Incorrect handling at level crossings
User may fall or tip over due to driving error
►Only cross railway systems and railway tracks in the designated areas.
►Negotiate level crossings so the caster wheels of the product cannot get caught in the gap between the rail
and the road surface.
CAUTION
Driving in the dark
Risk of collisions with other traffic participants due to lack of lighting
►Wear bright clothing or clothing with reflectors.
►Install active lighting on your product.
►Ensure that the reflectors on the product are clearly visible.
Hazards when overcoming obstacles
WARNING
Overcoming steps and obstacles without assistance
Tipping over, falling of the user due to failure to observe transportation instructions
►Always have accompanying persons help you negotiate steps and other obstacles.
►Use available facilities (e.g. access ramps or lifts).
►If such facilities are not available, have 2 assistants carry you over the obstacle.
WARNING
Improper lifting by attendants
Tipping over, falling of the user due to lifting on components that come loose or are not intended for lifting
►Only lift the product on permanently welded components (e.g. main frame).
►Do not lift the product on components installed with screw connections or add-on components.
11Motus CV, Motus CS
Safety

WARNING
Reduced ground clearance with the "foot-propelled chair" option
Tipping over, falling due to getting caught on obstacles
►Please note that wheelchairs with the "foot-propelled wheelchair" option might fall below the minimum ground
clearance of 40mm depending on the selected settings for the lower leg length and the front seat height.
►Adjust your driving to the reduced ground clearance and exercise particular caution with obstacles on the
ground e.g.steps, curbs and thresholds.
Hazard in case of broken skin
CAUTION
Skin damage
Skin damage or pressure points due to overloading
►Check your skin for intactness before and during use of the product.
►Pay attention to diligent skin care and pressure redistribution during interruptions in using the product.
►If skin damage or other problems occur during use, stop using the product. Consult the qualified personnel.
Hazards due to fire, heat and cold
CAUTION
Extreme temperatures
Hypothermia or burns due to contact with components, failure of components
►Do not expose the product to any extreme temperatures (e.g.direct sunlight, sauna, extreme cold).
►Do not leave the product in the immediate vicinity of heaters.
Hazards due to improper use of the product
WARNING
Overloading
Severe injuries if the product tips over due to overloading, damage to the product
►Do not exceed the maximum load capacity (see the nameplate and section "Technical data").
►Please note that certain accessories and add-on components will reduce the remaining load capacity.
WARNING
Exceeding the service life
Serious injuries due to failure to observe the manufacturer’s requirements
►Using the product beyond the specified expected service life leads to increased residual risk.
►Observe the specified service life.
WARNING
Incorrect pushing or pulling of the wheelchair
Risk of falling, tipping over due to user error
►Only the push handles may be used for pushing or overcoming obstacles. The tip-assist should be used in
addition.
►If a stabiliser bar is installed, it must not be used for pulling or pushing.
►The attendant should make sure that he/she has a secure stance and firm grip (on both sides).
►In case of damage, have the push handles repaired promptly.
CAUTION
Use of the product during diagnostic examinations and therapeutic treatment
Impairment of the examination results or the effectiveness of treatment due to interactions of the product with
devices that are used
►Make sure that examinations and treatments are carried out exclusively under the prescribed conditions.
12
Safety
Motus CV, Motus CS

CAUTION
Uncontrolled driving behaviour, unexpected sounds or odours
Falling, tipping, collision with persons or nearby objects due to defects
►If any faults, defects or other hazards that can lead to personal injury are detected, the product must be taken
out of service immediately. This includes uncontrolled movements as well as sounds that are unexpected or
previously not noted or odours that deviate significantly from the state of the product at the time of delivery.
►Contact the qualified personnel.
NOTICE
Use under incorrect environmental conditions
Damage to product due to corrosion or abrasion
►Do not use the product in salt water.
►Make sure that the wheel bearings are not damaged by sand or other particles.
4.4 Side effects
The following side effects may occur during use of the product:
• Neck, muscle and joint pain
• Circulatory disorders, risk of pressure sores
Contact a doctor or therapist in case of problems.
4.5 Further information
INFORMATION
Even in the event of compliance with all applicable guidelines and standards, alarm systems (e.g. in department
stores) may respond to your product. Should this happen, remove your product from the area where the alarm
was triggered.
INFORMATION
The serial number required for enquiries and orders can be found on the nameplate. For explanations of the
nameplate, see the section "Nameplate" (Nameplate).
4.6 Nameplate and warning labels
The nameplates are found on the crossbrace.
Label Meaning
AManufacturer’s product name
BCE marking
CMaximum load (see section “Technical data”)
DManufacturer information/address
ESerial number1)
FManufacturing date2)
GSymbol for medical device
HWARNING! Read the instructions for use before using the
product. Observe important safety-related information
(e.g.warnings, precautions).
IManufacturer’s reference number for the product variant
JSerial number (PI)3),1)
KGlobal Trade Item Number (DI)4)
1)YYYY = year of manufacture; WW = week of manufacture; PP = production site; XXXX = sequential production
number
2)YYYY = year of manufacture; MM = month of manufacture; DD = day of manufacture
3)UDI-PI to GS1 standard; UDI = Unique Device Identifier, PI = Product Identifier
4)UDI-DI to GS1 standard; UDI = Unique Device Identifier, DI = Device Identifier
13Motus CV, Motus CS
Safety

Label Meaning
Fixation point to attach the product in vehicles for transporting
persons with reduced mobility
5 Delivery
5.1 Scope of delivery
• Wheelchair ready for use
• Instructions for use
• Instructions for use for accessories (depending on equipment)
5.2 Options
The standard model can be fitted to the user's personal requirements thanks to a large range of options. For use of
these options: see Page31 ff.
5.3 Storage
5.3.1 Storage during daily use
The product should always be stored so it is protected against external influences.
5.3.2 Storage during extended disuse
The product must be stored in a dry place. Specific information for extended storage: see Page62.
It is not necessary to disassemble the product.
Maintain sufficient clearance from sources of heat. If the product is parked for an extended period of time or the
tyres overheat (e.g.in the vicinity of radiators or in case of exposure to strong sunlight behind glass), the tyres may
become permanently deformed.
During extended storage, the knee lever wheel lock on wheelchairs with PU tyres (=tubeless tyres) must be
released since tyre deformation may otherwise result.
6 Preparing the product for use
6.1 Assembly
CAUTION
Exposed pinch points
Crushing, pinching due to incorrect handling
►When folding the wheelchair out or together, only grip by the specified components.
CAUTION
Failure to verify readiness for use before putting into operation
Tipping, falling due to incorrect adjustment or installation
►Before you start using the wheelchair for the first time, check the chosen wheelchair settings with the support
of qualified personnel.
►After every assembly, check for proper mounting of the drive wheels. The quick-release axles must be
securely locked in the receiver bushings.
►Pay particular attention to the stability against tipping, free running of the drive wheels and correct function of
the brakes/wheel locks.
INFORMATION
On the topic of disassembly/transport: see Page50.
It only takes a few simple steps to prepare the wheelchair for use:
1) Attach the drive wheels to the receiver bushings (see fig.3):
→Press the button on the quick-release axle.
→Attach the drive wheel to the receiver bushing and release the button on the quick-release axle.
14
Delivery
Motus CV, Motus CS

→The quick-release axles must not be removable after releasing the push-button.
2) Unfold the wheelchair:
→Loosen the safety strap.
→Push the wheelchair apart with the flat of your hand (see fig.4, see fig.5).
3) Pull the flap of the back support upholstery up and attach it to the seat upholstery with the hook-and-loop
fastener (see fig.6).
4) Motus CV only: If necessary: Attach the leg supports (see Page33).
5) Fold down the foot plates (see Page34).
6) If necessary: Fit the seat cushion (see Page35).
3 4
5 6
7 Settings and assembly instructions
7.1 Prerequisites
WARNING
Making incorrect adjustments
Tipping over, falling or malposition of the user due to incorrect adjustments
►Adjustment and assembly work may be carried out only by qualified personnel.
►Only the adjustments described in these instructions for use may be carried out.
►Settings may only be changed within the allowable adjustment ranges; otherwise, the stability of the product
may be impaired (see this section and the “Technical data” section). If you have questions, contact the
manufacturer’s service department (see inside back cover for addresses).
►Only conduct tests in the presence of an assistant.
►Unless expressly described, you may not change any settings with a person sitting in the product.
►Secure the user against falling out during all tests.
►Before testing setting changes with the user seated, firmly tighten all screw connections.
►Check for safe function before delivering the product.
15Motus CV, Motus CS
Settings and assembly instructions

CAUTION
Unsecured screw connections
Pinching, crushing, tipping over, falling of user due to assembly errors
►Always firmly re-tighten the mounting screws and nuts after changing settings. Observe the specified torques
in doing so.
►Any time you loosen a screw connection with thread lock, replace it with a new screw connection with thread
lock or secure the old screw connection with medium strength thread locker (e.g.Loctite241).
►Always replace self-locking screws and nuts with new self-locking screws and nuts after disassembly.
Fine-tuning and adjustments should always be carried out in the presence of the user. The user should be sitting
upright in the wheelchair while making adjustments.
All parts of the product should be cleaned thoroughly before adjustments are made.
The tools required for adjustments and maintenance tasks as well as the torque values for screw connections are
listed in the section "Appendices" (see Page64).
7.2 Safety Instructions for Assembly
WARNING
Changed diameter/installation position of the wheels
Tipping, falling over of the user due to blocked wheels
►Modification of the size and position of the front wheels and of the drive wheel size can lead to wobbling of the
front wheels at higher speeds. If changes are required, verify the horizontal alignment of the wheelchair frame
(see the section "Adjusting the drive wheels", "Adjusting the caster wheels").
WARNING
Improper assembly of removable wheels
Tipping, falling over of the user due to wheels coming off
►After each assembly, verify the proper fit of the removable wheels. The quick-release axles must be firmly
locked in the wheel attachment.
CAUTION
Use of unsuitable tools
Pinching, crushing or damaging the product due to use of unsuitable tools
►When completing the tasks, only use tools that are suitable for the conditions at the place of work and for
which safety and the protection of health are assured with proper use.
►Observe the specifications in the section "Required Tools".
NOTICE
Tipping or falling of the product
Damage to product due to lack of attachment
►When you work on the product, secure it so that it cannot tip over or fall over.
►Use a clamping fixture to secure the product whenever you work on it at a workbench.
7.3 Adjusting the drive wheels
WARNING
Lack of fine adjustment of the drive wheels
Tipping over, falling of the user due to incorrect adjustment
►Check the standard adjustments of the wheelchair for stability against tipping and function of the drive
wheels. Avoid any extreme settings.
16
Settings and assembly instructions
Motus CV, Motus CS

WARNING
Incorrectly adjusted wheelbase
Tipping over, falling of the user due to unstable settings
►Please note that with the drive wheel in a more forward mounting position and with an unfavourable body pos
ition, the user may tip backwards even on level ground.
►Use an anti-tipper for inexperienced users and with extreme settings of the drive wheel.
►Be sure to position the drive wheels towards the rear for transfemoral amputees. This improves the stability of
the wheelchair.
INFORMATION
Changing the drive wheel position can also change the angle between the caster wheel journal and the ground.
However, this must always be approx. 90° and thus readjusted accordingly. The knee lever wheel lock also has
to be readjusted.
7.3.1 Setting the drive wheels horizontally
The horizontal position of the drive wheels is adjusted by moving the fitting horizontally in the drive wheel adapter.
Changing the drive wheel position has the following effects:
Position of drive wheel Effects
Move backwards (passive setting) • Larger wheelbase
• Larger turning circle
• Greater stability of the wheelchair
• Wheelchair is harder to tip backwards when crossing obstacles
• Position recommended for inexperienced users
Move forwards (active setting) • Smaller wheelbase
• Less load on caster wheels = greater manoeuvrability
• Less stability of the wheelchair
• Wheelchair is easier to tip backwards when crossing obstacles
INFORMATION: An anti-tipper should be installed if necessary.
• Setting recommended only for experienced users
The drive wheel can be installed at 4 depth positions in the drive wheel adapter.
1) Remove the wheels.
2) Loosen the hexagon nut (see fig.7, item1) from the fitting and remove the fitting towards the inside.
3) Slide the fitting back on in the desired position and tighten the hexagon nut slightly.
4) Check the toe-in and adjust as needed (see Page20).
5) If necessary: The distance between the drive wheel and the side panel can be continuously adjusted by turn
ing the counter nut on the fitting.
6) Tighten the hexagon nut (see fig.7) and the counter nut on both sides of the fitting to 50Nm.
INFORMATION: After adjustment, the distance of the left and right fittings to the side panel must be
the same.
7) Check the depth setting. Both sides must be positioned exactly the same. Readjust if required.
8) If necessary: Readjust the height and alignment of the caster attachment device as well as the wheel locks
(see information at the start of the section).
7.3.2 Adjusting the drive wheels vertically
The vertical position of the drive wheels can be changed by vertically moving the drive wheel adapter in the frame.
Combined with adjusting the height of the caster wheels, this also allows the seat height to be optimally adjusted to
individual requirements.
Changing the drive wheel position has the following effects:
Drive wheel position Effects
Move upwards • The higher the drive wheel position, the more the seat surface is tilted to
the rear
• Wheelchair is easier to tip backwards when crossing obstacles
17Motus CV, Motus CS
Settings and assembly instructions

Drive wheel position Effects
• The change in the centre of gravity results in a lower, more stable seat
position in the wheelchair
• The seat height can be further adjusted in combination with a height
adjustment of the caster wheels.
Move downwards • The lower the drive wheel position, the less the seat surface is tilted to the
rear
• Wheelchair is harder to tip backwards when crossing obstacles
• The seat height can be further adjusted in combination with a height
adjustment of the caster wheels.
The drive wheel can be installed at 4 height positions.
1) Remove the wheels.
2) Remove the Allen head screws/counter nuts (see fig.8).
3) Push the drive wheel adapter to the desired position.
4) If necessary: Additional drive wheel positions can be obtained by turning the drive wheel adapter by 180°.
→In this case, the fitting also has to be installed again (see previous section).
→The toe-in has to be readjusted as well (see Page20).
5) Insert and tighten the Allen head screws/counter nuts to 8Nm (see fig.8).
6) Only after rotating the drive wheel adapter: Tighten the screw connection on the fitting to 50Nm.
→Once changed, the left and right drive wheel adapters must both have the same vertical position in the frame.
7 8
7.3.3 Adjusting the drive wheel camber
The modular system of the product offers camber washers for different sloped settings of the drive wheels.
The drive wheel camber is adjusted by exchanging the camber washers in the fitting (quick-release axle mounting).
This has the following effects:
Position of drive wheel Effects
0° position • Narrow track, excellent straight-line stability
• Low rolling resistance
Wheel camber • Wheelchair becomes more manoeuvrable, turns faster and tips less easily
to the side
• The wheel position protects the hands when turning the handrim
• Overall width increases
• Increased rolling resistance
The drive wheel camber can be set to 0° or 2.5° (1° or 3.5° with drive wheel attachment device for 3.5° wheel cam
ber).
The settings can be configured with a corresponding alignment of the camber washers:
Drive wheel camberPosition on the drive wheel
adapter 2.5° (3.5°) 0° (1°)
Exterior 1x camber washer (see fig.9)
Alignment B1)
---
18
Settings and assembly instructions
Motus CV, Motus CS

Drive wheel camberPosition on the drive wheel
adapter 2.5° (3.5°) 0° (1°)
1x camber washer (see fig.10,
item1)
Alignment A1)
Inside ---
1x camber washer (see fig.10,
item2)
Alignment B2)
1) Alignment A: The thicker/heavier side of the camber washer is on top.
2) Alignment B: The thinner side of the camber washer is on top.
9 10
INFORMATION
►Please be aware that with a larger negative camber the overall width of the wheelchair increases and the drive
wheels are subjected to higher stress.
Adjusting the drive wheel camber
1) Remove the wheels.
2) Loosen the hexagon nut on the inside from the fitting (see fig.11, item1) and remove the fitting to the outside.
3) Slide the camber washers onto the quick-release axle receiver bushing according to the table and align them.
4) Slide the fitting back on and tighten the hexagon nut slightly (see fig.11, item1). Readjust the toe-in before
tightening (see Page20).
5) If necessary: The distance between the drive wheel and the side panel can be continuously adjusted by turn
ing the counter nut.
6) Tighten the hexagon nut and the counter nut on both sides of the fitting to 50Nm.
INFORMATION: After adjustment, the camber of the left and right drive wheels must have the same
angle.
7) If necessary: Readjust the height and alignment of the caster attachment device as well as the wheel locks
(see information at the start of the section).
11
19Motus CV, Motus CS
Settings and assembly instructions

7.3.4 Adjusting the track
INFORMATION
►The track setting must be checked and, if necessary, adjusted after the following adjustments have been
made:
→Adjusting the vertical position of the drive wheels
→Adjusting the horizontal position of the drive wheels
►The track setting must be adjusted after the following adjustments have been made:
→Adjusting the drive wheel camber
→Adjusting the track
INFORMATION
►Always make the track adjustment on both sides and check both sides.
►With each track adjustment, always check the symmetry of the track width setting.
►The caster wheel journal angle should be checked immediately after every adjustment to the track (see
Page21).
1) Slightly loosen the hexagon nut (see fig.11, item1) and the counter nut (not illustrated) on the fitting.
2) Loosen the oval head head screw on the plate for track correction (see fig.11, item2).
3) With the help of the adjustment aid (spirit level), adjust the track by slightly turning the camber washers (see
fig.11, item3).
4) Tighten the hexagon nuts on both sides of the fitting to 50Nm.
→Once changed, the left and right fittings must both have the same vertical position in the drive wheel adapter.
7.3.5 Adjusting the quick-release axle
The quick-release axle should be set so the wheel is correctly engaged, with no play on the axle.
1) Hold the quick-release axle by the head (wrench size: 19mm) and by the tip (wrench size: 11mm) with a ring
and open-ended wrench respectively.
2) Adjust the play by turning the nut on the end of the quick-release axle (see fig.12, item1) in or out.
12
7.3.6 Adjusting the handrims
INFORMATION
This section does not apply to standard wheels.
All handrims are designed for a spacing from the drive wheel of 15mm (standard setting) and 25mm.
1) Loosen/remove the handrim screw connection from the rim (see fig.14).
2) Tightly screw the handrims onto the rim in narrow or wide installation position.
20
Settings and assembly instructions
Motus CV, Motus CS
