Ozito CPS-200 User manual

1
Power Paint Scraper
200W
Instruction Manual
3 Year Replacement Warranty
CPS-200
WARNING! Read all safety warnings and all instructions. Failure to follow
the warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
To view the full range visit: www.ozito.com.au
0512

2
SPECIFICATIONS - MODEL NO. CPS-200
KNOW YOUR PRODUCT
Motor Size:
Input:
No-load speed:
Weight:
200W
230-240V~50Hz
6,500/ 7,500/ 8,500 min-1
1.20kg
Tool Holder
Tool Lock
On/Off Switch
Spatula Attachment
1.
2.
3.
4.
Cranked Scraper Attachment
Straight Chisel Attachment
Gouge Chisel Attachment
Flat Scraper Attachment
5.
6.
7.
8.
1
2
3
8
7
56
4

3
TABLE OF CONTENTS
SPECIFICATIONS ………………………………………..
KNOW YOUR PRODUCT ……………………………….
INTRODUCTION………………………………………….
ELECTRICAL SAFETY…………….………………………
GENERAL POWER TOOL SAFETY WARNINGS………
POWER PAINT SCRAPER SAFETY WARNINGS……....
PREPARATION & SET-UP………………………………...
OPERATION………………………………………………
MAINTENANCE…………….…………………………….
TROUBLESHOOTING...................................................
SPARE PARTS …………….……………………………....
DESCRIPTION OF SYMBOLS …………………………..
PACK CONTENTS ……………………………………….
WARRANTY……………………………………………….
Page 2
Page 2
Page 4
Page 4
Page 5
Page 7
Page 8
Page 9
Page 10
Page 11
Page 12
Page 12
Page 13
Page 14

4
Read and understand the manual prior to operating this tool.
Save these instructions and other documents supplied with this tool for future reference.
The electric motor has been designed for 230V and 240V only. Always check that the power
supply corresponds to the voltage on the rating plate.
Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and
New Zealand.
This tool is double insulated in accordance with AS/NZS 60745-1; therefore no
earth wire is required.
If the supply cord is damaged, it must be replaced by a qualified electrician or a power tool
repairer in order to avoid a hazard.
If operating a power tool in a damp location is unavoidable use a residual current device
(RCD) protected supply. Use of an RCD reduces the risk of electric shock.
Note: Double insulation does not take the place of normal safety precautions when
operating this tool. The insulation system is for added protection against injury resulting
from a possible electrical insulation failure within the tool.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool. Before use,
inspect the extension lead for signs of damage, wear and ageing. Replace the extension
lead if damaged or defective. When using an extension lead on a reel, always unwind the
lead completely. Use of an extension lead not suitable for the power input of the tool or
which is damaged or defective may result in a risk of fire and electric shock.
INTRODUCTION
Congratulations on purchasing an Ozito Power Paint Scraper.
We aim to provide quality tools at an affordable price. We
hope you will enjoy using this tool for many years.
Your Ozito Power Paint Scraper CPS-200 has been designed
to make scraping paint easier and faster. It can also be used to
scrape glue or other light advesive material and is intended
for DIY use only.
ELECTRICAL SAFETY
WARNING! When using mains-powered equipment, basic safety
precautions, including the following, should always be followed to reduce
risk of fire, electric shock, personal injury and material damage.

5
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks which
may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions
can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric shock if
your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power
tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging
the power tool. Keep cord away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric
shock.
f) If operating a power tool in a damp location is unavoidable, use a residual
current device (RCD) protected supply. Use of an RCD reduces the risk of
electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating
a power tool. Do not use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment of inattention while
operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective
equipment such as dust mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to power source and/or battery pack, picking up or carrying the
tool. Carrying power tools with your finger on the switch or energising power
tools that have the switch on invites accidents.
WARNING! Read all safety warnings and all instructions. Failure to
follow the warnings and instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and instructions for future reference. The term “power
tool” in all of the warnings refers to your mains-operated (corded) power tool
or battery-operated (cordless) power tool.
GENERAL POWER TOOL SAFETY WARNINGS

6
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or
a key left attached to a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better
control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and
gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in
moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities,
ensure these are connected and properly used. Use of dust collection can reduce dust-
related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application. The
correct power tool will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool
that cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the power
tool before making any adjustments, changing accessories, or storing power tools.
Such preventive safety measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the power tool’s operation. If
damaged, have the power tool repaired before use. Many accidents are caused by
poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these
instructions, taking into account the working conditions and the work to be
performed. Use of the power tool for operations different from those intended could
result in a hazardous situation.
5) Service
a) Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
b) If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
GENERAL POWER TOOL SAFETY WARNINGS

7
POWER PAINT SCRAPER SAFETY WARNINGS
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Recommendations for the use of a residual current device with a rated residual
current of 30mA or less.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool.
Before use, inspect the extension lead for signs of damage, wear and ageing.
Replace the extension lead if damaged or defective.
When using an extension lead on a reel, always unwind the lead completely. Use of
an extension lead not suitable for the power input of the tool or which is damaged
or defective may result in a risk of fire and electric shock.
It is recommended that the extension lead is a maximum of 25m in length. Do Not
use multiple extension leads.
Always wear eye and ear protection
Wear a dust mask for detail work as fine particleds can be inhaled easily and
may cause health complications.
•
•

8
PREPARATION & SET-UP
Make sure your power paint scraper is unplugged before performing any of the
preparation and setup operations described in this manual.
WARNING! Failure to unplug your power paint scraper could result in
accidental starting causing possible serious personal injury.
Inserting an Accessory
Slide the tool lock (2) forward towards the tool holder to
unlock (Fig. 1).
1.
Removing an Assessory
Slide the tool lock (2) forward towards the tool holder to unlock.
Then remove the blade.
1.
2.
Fig. 1
2. Insert the accessory into the tool holder (1) as far as it
will go and slide the tool lock (2) to the ‘lock’ position to
lock the accessory (Fig. 2).
Note: Lightly jiggle the accessory to ensure that the
accessory has been secured.
Fig. 2

9
On/Off Switch
Caution: Please wear eye and ear protection
Caution: Please wear gloves as gear box can be hot to touch after prolonged use.
Turning On
The power paint scraper has 3 speeds that you can select.
Speed 1 for the slowest speed and 3 for the fastest speed.
Turn the power paint scraper on by sliding the on/off
switch (3) forward to a suitable speed for your
application (Fig. 3).
Turning Off
To turn off, slide the on/off switch (3) to ‘0’ position.
1.
1.
Fig. 3
OPERATION

10
MAINTENANCE
Cleaning
Make sure your power paint scraper is unplugged before performing any maintenance.
The power paint scraper must be clean, dry and free of oil and grease at all times.
Make sure that the ventilation slots are always clear. Use a soft bristle brush to
clean the ventilation slots after each use.
Clean the blade holder with a soft bristle brush or moist cloth.
There must not be any liquid entering the motor housing
Use a soft moist cloth to clean the tool housing after each use.
Never use solvents or cleaning agents that can damage plastic to clean the motor
housing.
Note: Ozito Industries will not be responsible for any damage or injuries caused by the
repair of the tool by an unauthorized person or mishandling of the tool.
1.
2.
3.
4.
5.
6.
WARNING! Failure to unplug your power paint scraper could result in
accidental starting causing possible serious personal injury.

11
TROUBLESHOOTING
Problem Cause Remedy
Power paint scraper is not
scraping properly
Accessory is blunt Change accessory
Does not start No supply voltage Check the mains power,
power cord, extension
cord, plug and house
fuse.
Contact Ozito customer
service
On/Off switch broken
Motor Defective
Power paint scraper works
intermittently
Damaged electricity
power cord
Check power cable. If
damaged, contact Ozito
customer service.
On/Off switch may be
damaged
Contact Ozito customer
service

12
SPARE PARTS
Limited spare parts are available subject to availability. Please contact your local Bunnings
Special Orders Desk to order the required spare parts.
Most common spare parts listed below
Spare Part Part No.
On/Off Button SPCPS200-24
Spatula Attachment SPCPS200-30
Cranked Scraper Attachment SPCPS200-29
Straight Chisel Attachment SPCPS200-28
Gouge Chisel Attachment SPCPS200-32
Flat Scraper Attachment SPCPS200-31
Carbon Brushes (Pair) SPCPS200-10
V Volts
~ Alternating current
Hz Hertz
W Watts
/min Revolutions or reciprocation per minute
Double insulated
Regulatory Compliance Mark
Read instruction manual
Wear eye, breathing, ear protection
Warning
DESCRIPTION OF SYMBOLS
Wear safety gloves

13
CARING FOR THE ENVIRONMENT
1 x Power Paint Scraper (CPS-200)
1 x Spatula Attachment
1 x Flat Scraper Attachment
1 x Cranked Scraper Attachment
1 x Straight Chisel Attachment
1 x Gouge Chisel Attachment
1 x Kit Box
1 x Instruction Manual
AUSTRALIA (Head Office)
1 - 23 Letcon Drive, Bangholme, Victoria, Australia 3175
Telephone: [phone]
Facsimile: [phone]
Website: www.ozito.com.au
Email: [email protected]
Power tools that are no longer usable should not be disposed
of with household waste but in an environmentally friendly way.
Please recycle where facilities exist. Check with your local council
authority for recycling advice.
Recycling packaging reduces the need for landfill and raw
materials. Reuse of recycled material decreases pollution in the
environment. Please recycle packaging where facilities exist.
Check with your local council authority for recycling advice.
PACK CONTENTS
OZITO INDUSTRIES PTY LTD

3 YEAR REPLACEMENT WARRANTY
Your Ozito tool is guaranteed for a period of 36 months from the original date of purchase
and is intended for DIY (Do It Yourself) use only. If a product is defective it will be replaced in
accordance with the terms of this warranty. Warranty excludes consumable parts, for example:
included accessories.
WARNING
The following actions will result in the warranty being void.
Professional, Industrial or high frequency use.
If the tool has been operated on a supply voltage other than that specified on the tool.
If the tool shows signs of damage or defects caused by or resulting from abuse, accidents
or alterations.
Failure to perform maintenance as set out within the instruction manual.
If the tool is disassembled or tampered with in any way.
OZITO
Australia/New Zealand (Head Office)
1-23 Letcon Drive, Bangholme, Victoria, Australia 3175
•
•
•
•
•
OW5
WARRANTY
YOUR WARRANTY FORM SHOULD BE RETAINED BY YOU AT ALL TIMES. IN ORDER
TO MAKE A CLAIM UNDER THIS WARRANTY YOU MUST RETURN THE PRODUCT TO
YOUR NEAREST BUNNINGS WAREHOUSE WITH YOUR BUNNINGS REGISTER RECEIPT.
PRIOR TO RETURNING YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE OUR
CUSTOMER SERVICE HELPLINE:
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL NUMBER AND DATE OF
PURCHASE AVAILABLE. A CUSTOMER SERVICE REPRESENTATIVE WILL TAKE YOUR CALL
AND ANSWER ANY QUESTIONS YOU MAY HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
The benefits provided under this warranty are in addition to other rights and remedies which
are available to you at law.
Our goods come with guarantees that cannot be excluded at law. You are entitled to a
replacement or refund for a major failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if
the goods fail to be of acceptable quality and the failure does not amount to a major failure.
Generally you will be responsible for all costs associated with a claim under this warranty,
however, where you have suffered any additional direct loss as a result of a defective product
you may be able to claim such expenses by contacting our customer service helpline above.
`Australia 1800 069 486
New Zealand 0508 069 486
