Ozito ZLMFTS-012 User manual

MULTI
FUNCTION
TOOL
12V Lithium Ion
INSTRUCTION MANUAL
ZLMFTS-012
WHAT’S IN THE BOX
Multi Function Tool
ozito.com.au
Accessories x 6
SPECIFICATIONS
Input: 12V
Fitment: 4 Pin
No Load Speed: 6,000-16,000/min
Oscillating Angle: 3.2º
Weight: 0.74kg
Hex Key
IN ORDER TO MAKE A CLAIM UNDER THIS
WARRANTY YOU MUST RETURN THE PRODUCT
TO YOUR NEAREST BUNNINGS WAREHOUSE WITH
YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY
PLEASE TELEPHONE OUR CUSTOMER SERVICE
HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
3 YEAR REPLACEMENT WARRANTY
Your product is guaranteed for a period of 36 months from the
original date of purchase and is intended for DIY (Do It Yourself)
use only. If a product is defective it will be replaced in accordance
with the terms of this warranty. Lithium Ion batteries and chargers
are covered by a 12 month warranty. Warranty excludes
consumable parts, for example: sanding pad, paper, blades etc.
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other
than that specified on the tool.
• If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the
instruction manual.
• If the tool is disassembled or tampered with in any way.
• Professional, industrial or high frequency use.
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE
HAVE THE MODEL NUMBER AND DATE OF
PURCHASE AVAILABLE. A CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL
AND ANSWER ANY QUESTIONS YOU MAY
HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
The benefits provided under this warranty are in addition
to other rights and remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded
at law. You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Generally you will be responsible for all costs associated with
a claim under this warranty, however, where you have suffered
any additional direct loss as a result of a defective product you
may be able to claim such expenses by contacting our customer
service helpline above.
0817

ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
KNOW YOUR PRODUCT SETUP & PREPARATION
1. FITTING & REMOVING ACCESSORIES
ACCESSORIES
WARNING! ENSURE THE TOOL IS SWITCHED OFF
AND THE BATTERY IS DISCONNECTED BEFORE
PERFORMING ANY OF THE FOLLOWING TASKS.
Removing Accessories
Fitting Accessories
2 Remove the accessory.
2 Place the accessory onto the
spindle making sure to align
the accessory with the pins on
the spindle.
1 Remove the drive
spindle hex screw and
washer by rotating anti-
clockwise using the hex
key.
1 Remove the drive spindle hex
screw and washer by rotating
anti-clockwise using the hex
key.
3 Screw the washer and hex screw into the drive spindle and tighten
with the hex key to secure the accessory in place.
1 2 3 4 5
6 7 8 9
CORDLESS MULTI FUNCTION TOOL
1 Accessory
2 Accessory Drive Spindle
3 On/Off Switch
4 Variable Speed Controls
5 Battery Seating
6 Sanding Pad
7 Sanding Sheets x 3
8 Scraper Blade
9 Straight Blade
10 Hex Key
10
BATTERY & CHARGER
This tool is compatible with all batteries and chargers from the
Ozito Home-12volt range.

2. BATTERY & CONTROLS 3. APPLICATIONS
OPERATION
Variable Speed Controls
Installing and Removing the Battery
1 To increase the speed
of the tool, press the “+”
variable speed button.
2 To decrease the speed
of the tool, press the “-”
variable speed button.
1 Slide the battery into the tool
until it clicks into place.
2 To remove, please the battery
release button and then slide
out of the tool.
1
2
3
4
5
Sanding
1 Ensure the accessory is
secure, and then start the tool
by pushing the on/off switch
forward.
2 Place the multi
function tool at on
the workpiece.
Note: Do not apply heavy pressure to the tool or tilt the sanding base
as this will wear out the sanding paper and may damage the
sanding pad.
With the sanding pad and sanding paper attached, the multi function
tool can be used on materials such as wood, plastic and painted
surfaces.
Changing Sand Paper
1. Align paper to pad and press
rmly to attach.
2. Carefuly peel paper off pad
from on of the corners.
On/Off Switch
1 To start the tool, push the on/
off switch forward, into the on
position.
2 To stop the tool, push the on/
off switch backward, into the
off position.

ZLMFTS-012
Sawing Scraping
1 Ensure the workpiece is
securely held down.
3 If plunge cutting, use a slight
pendulum motion.
1 Turn the multi function tool
on and select the desired
speed.
2 Turn the multi function tool
on.
2 Position the tool on the workpiece at an angle of 10o-15o.
Note: Allow the scraper to do the work; do not apply heavy pressure to
the multi function tool. This may cause the multi function tool to
overload or cut into the surface of the workpiece.
When sawing, the multi function tool can be used on wood, plastics and
sheet metal.
Note: Ensure blades are not blunt or damaged in any way before
commencing.
When being used as a scraper, the multi function tool can remove
materials such as fabric, adhesives or vinyl, from materials such as
wood, plastic, metal and painted surfaces.
10 - 15º

Power tools that are no longer usable should not be disposed of
with household waste but in an environmentally friendly way. Please
recycle where facilities exist. Check with your local council authority for
recycling advice.
Recycling packaging reduces the need for landll and raw materials.
Reuse of recycled material decreases pollution in the environment.
Please recycle packaging where facilities exist. Check with your local
council authority for recycling advice.
MAINTENANCE
DESCRIPTION OF SYMBOLS CARING FOR THE ENVIRONMENT
TROUBLESHOOTING
1. When not in use, the tool should be stored in a dry, frost free
location, keep out of children’s reach.
2. Keep ventilation slots of the tool clean at all times and prevent
anything from entering.
3. If the housing of the tool requires cleaning, do not use solvents.
Use of a cloth only is recommended.
4. Blow out the ventilation slots with compressed air periodically.
Note: Ozito Industries will not be responsible for any damage or
injuries caused by repair of the tool by an unauthorised person or by
mishandling.
Spare parts can be ordered from the Special Orders Desk
at your local Bunnings Warehouse.
For further information, or any parts not listed here, visit
www.ozito.com.au or contact Ozito Customer Service:
Australia 1800 069 486
New Zealand 0508 069 486
E-mail: [email protected]
SPARE PARTS
LED lights do not illuminate on charger
Check the charging adaptor is securely plugged into the wall
outlet.
Check the battery is rmly connected to the charging cradle.
Check that the charging jack is securely connected to the
charging cradle.
The battery has a short run time
Ensure the battery is properly charged. It will take 4-5 charging
cycles before the battery reaches optimum charge and run time.
Multi function tool has cut out during use
It is likely that the battery’s thermal voltage protection has been
activated. This can happen when the tool has been used for
extended periods.
Place the battery on the charging cradle for 2-3 hours. It will need
this time to cool down and for the protection circuits to be reset.
Sparking visible through the housing air vents
A small amount of sparking may be visible through the housing
vents. This is normal and does not indicate a problem.
Warning
Wear eye protection
Read instruction manual
Ah
n0
Amp hour
Regulator compliance
mark (RCM)r
No load speed
VVolts Hz Hertz
ac/~ Alternating current
Direct current
dc/
/min
Diameter
Revolutions or
reciprocation per minute

WARNING! Hold power tool by the insulated gripping surfaces, when
performing an operation where the cutting accessory may contact
hidden wiring or its own cord. Cutting accessory contacting a “live” wire may
make exposed metal parts of the power tool “live” and could give the operator an
electric shock.
WARNING! Some dust created by power sanding, sawing, grinding,
drilling and other construction activities contain chemicals known to
cause cancer, birth defects or other reproductive harm. Some examples of
these chemicals are:
• Lead from lead-based paints
• Crystalline silica from bricks and cement and other masonry products
• Arsenic and chromium from chemically treated timber
Your risk from exposure to these chemicals varies, depending on how often you
do this type of work. To reduce your exposure to these chemicals: work in a well
ventilated area and work with approved safety equipment, such as dust masks that
are specially designed to lter out microscopic particles.
MULTI FUNCTION TOOL SAFETY WARNINGS
GENERAL POWER TOOL SAFETY WARNINGS
ELECTRICAL SAFETY
WARNING! When using mains-powered tools, basic safety precautions, including the
following, should always be followed to reduce risk of re, electric shock, personal injury and
material damage.
Read the whole manual carefully and make sure you know how to switch the tool off in an emergency, before
operating the tool.
Save these instructions and other documents supplied with this tool for future reference.
The manufacturer cannot accept any liability for damage or accidents which arise due to a failure to follow these
instructions and the safety information.
This charger has been designed for 230V and 240V only. Always check that the power supply corresponds to
the voltage on the rating plate.
Note: The supply of 230V and 240V is interchangeable for Australia and New Zealand.
This tools charger is double insulated therefore no earth wire is required.
The power supply for this products charger should be protected by a residual current device (rated at 30mA or
less). A residual current device reduces the risk of electric shock.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualied
persons in order to avoid a hazard.
Note: Double insulation does not take the place of normal safety precautions when operating this tool. The
insulation system is for added protection against injury resulting from a possible electrical insulation failure
within the tool.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool. Before use, inspect the
extension lead for signs of damage, wear and ageing. Replace the extension lead if damaged or defective.
When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not
suitable for the power input of the tool or which is damaged or defective may result in a risk of re and electric
shock.
WARNING! Read all safety warnings, instructions, illustrations and
specications provided with this power tool. Failure to follow all
instructions listed below may result in electric shock, re and/or serious
injury.
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning use
of the appliance by a person responsible for their safety.
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, re and/or serious injury.
Save all warnings and instructions for future reference. The term “power tool” in the
warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power
tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause you to
lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way.
Do not use any adapter plugs with earthed (grounded) power tools. Unmodied plugs and matching
outlets will reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock
if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the
risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase
the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a power tool. Do
not use a power tool while you are tired or under the inuence of drugs, alcohol or medication. A
moment of inattention while operating power tools may result in serious personal injury.
b. Use personal protective equipment. Always wear eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your
nger on the switch or energising power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on.
A wrench or a key left attached to a rotating part of the power tool may result
in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the
power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust collection can reduce dust-related hazards.
h. Do not let familiarity gained from frequent use of tools allow you to become complacent and
ignore tool safety principles. A careless action can cause severe injury within a fraction of a second.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct power tool
will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power tool before
making any adjustments, changing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the
power tool or these instructions to operate the power tool. Power tools are dangerous in the hands
of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and
any other condition that may affect the power tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking
into account the working conditions and the work to be performed. Use of the power tool for
operations different from those intended could result in a hazardous situation.
h. Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.
5. Service
a. Have your power tool serviced by a qualied repair person using only identical replacement
parts. This will ensure that the safety of the power tool
is maintained.
