Ozito DBS-095 User manual

DRILL BIT
SHARPENER
95W
INSTRUCTION MANUAL
SPECIFICATIONS
Voltage: 220-240V ~ 50Hz
Input Power: 95W
No Load Speed: 1,350/min
Working Capacity: 3mm-12mm
(1/8”-15/32”)
Weight: 1kg
WHAT’S IN THE BOX
Drill Bit Sharpener
IN ORDER TO MAKE A CLAIM UNDER THIS
WARRANTY YOU MUST RETURN THE PRODUCT
TO YOUR NEAREST BUNNINGS WAREHOUSE WITH
YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY
PLEASE TELEPHONE OUR CUSTOMER SERVICE
HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
3 YEAR REPLACEMENT WARRANTY
Your product is guaranteed for a period of 36 months from
the original date of purchase and is intended for DIY (Do It
Yourself) use only. If a product is defective it will
be replaced in accordance with the terms of this warranty.
Warranty excludes consumable parts, for example: carbon brushes.
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other
than that specified on the tool.
• If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the
instruction manual.
• If the tool is disassembled or tampered with in any way.
• Professional, industrial or high frequency use.
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE
HAVE THE MODEL NUMBER AND DATE OF
PURCHASE AVAILABLE. A CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL
AND ANSWER ANY QUESTIONS YOU MAY
HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
The benefits provided under this warranty are in addition
to other rights and remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded
at law. You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Generally you will be responsible for all costs associated with
a claim under this warranty, however, where you have suffered
any additional direct loss as a result of a defective product you
may be able to claim such expenses by contacting our customer
service helpline above.
ozito.com.au
0418
DBS-095

ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
1 On/o󰀨Switch
2 Drill Bit Template Guide
3 Grinding Stone Adjustment Dial
DRILL BIT SHARPENER
KNOW YOUR PRODUCT
1. ADJUSTING THE GRINDING STONE
3. Turn the drill bit
sharpener on.
1. Lower the grinding
stone as far as possible
by turning the grinding
stone adjustment knob
anticlockwise.
2. Insert the drill bit into
the same sized template
guide hole.
SETUP & PREPARATION
The tool is recommended for use with a residual current
device with a rated residual current of 30mA or less.
4. Raise the grinding
stone by turning
the grinding stone
adjustment knob
clockwise until it can
be heard touching
the drill bit.
NOTE: RAISING THE GRINDING STONE WILL
PRODUCE AN AGGRESSIVE GRIND AND ROUGH
EDGE. LOWERING THE GRINDING STONE WILL
PRODUCE A FINER GROUND EDGE.

2. CONTROLS 3. SHARPENING PROCEDURE
1. To turn on, press the on/
o󰀨switchintothe“I”
position.
Turn the grinding stone
adjustment dial anti-clockwise
to lower the grinding stone.
2. Toturno󰀨,presstheon/
o󰀨switchintothe“O”
position.
Turn the grinding stone
adjustment dial clockwise to
raise the grinding stone.
OPERATION
Turning on/o󰀨
Grinding Stone Adjustment Dial
1. Ensure the drill bit that
requires sharpening is
in the smallest template
guideitts.
2. Turn the drill bit sharpener
on.
3. Press down slightly
on the drill bit while
rotating the bit back
and forth between your
ngers.
4. Turn the drill bit sharpener
o󰀨,removethedrillbitand
examine the cutting edge
is sharp.
5. Rotate the drill bit 180º
and reinsert into the drill
bit sharpener.
180°
6. Repeat steps 2-5. Ensure that both sides of the drill bit are
sharpened for the same amount of time, using the same
amount of pressure.

DBS-095
4. MAINTENANCE
Changing the Grinding Stone
The grinding stone will need to be changed when grooves or
ridges mar the evenness of the grinding surface.
2. Loosen the two screws
on the top of the drill bit
sharpener.
3. Remove the Index head
assembly.
4. Remove the stone
assemby, ensuring the
spring stays in place.
5. Insert a new grinding
wheel assembly onto the
drive shaft. Rotate until it
locates into place.
6. Replace the index head
assembly, fasten by
tightening the two screws.
1. Raise the grinding stone.

MAINTENANCE
DESCRIPTION OF SYMBOLS
CARING FOR THE ENVIRONMENT
TROUBLESHOOTING
Power tools that are no longer usable should not be disposed of
with household waste but in an environmentally friendly way. Please
recycle where facilities exist. Check with your local council authority
for recycling advice.
Recyclingpackagingreducestheneedforlandllandrawmaterials.
Reuse of recycled material decreases pollution in the environment.
Please recycle packaging where facilities exist. Check with your
local council authority for recycling advice.
• Keep the ventilation vents of the drill bit sharpener clean at all times, if possible,
prevent foreign matter from entering the vents.
• After each use, blow air through the drill bit sharpener housing to ensure it is
free from all dust particles which may build up. Build up of dust particles may
cause the drill bit sharpener to overheat and fail.
• If the enclosure of the drill bit sharpener requires cleaning, do not use solvents
but a moist soft cloth only. Never let any liquid get inside the drill bit sharpener;
never immerse any part of the drill bit sharpener into a liquid.
Carbon Brushes
When the carbon brushes wear out, the drill bit
sharpener will spark and/or stop. Discontinue use
as soon as this happens. They should be replaced
prior to recommencing use of the drill bit sharpener.
Carbon brushes are a wearing component of the drill
bit sharpener therefore not covered under warranty.
Continuing to use the drill bit sharpener when carbon
brushes need to be replaced may cause permanent
damage to the drill bit sharpener. Carbon brushes will wear out after many uses
but when the carbon brushes need to be replaced, take the drill bit sharpener
to an electrician or a power tool repairer for a quick and low cost replacement.
Always replace both carbon brushes at the same time.
Note: Ozito Industries will not be responsible for any damage or injuries
caused by the repair of the drill bit sharpener by an unauthorised person or by
mishandling of the drill bit sharpener.
Sparking visible through the housing air vents
A small amount of sparking may be visible through the housing vents.
This is normal and does not indicate a problem.
Excessive sparking visible through the housing
air vents and/or the drill bit sharpener failing to
operate
May indicate the carbon brushes have worn out and need to be replaced. Carbon
brushesshouldonlybereplacedbyaqualiedelectricianorpowertoolrepairer.
The tip of my drill bit is turning blue
This is because the drill bit is overheating. You will need to reduce the amount of
pressure and sharpening time, cool the drill bit in water in between sharpening.
One edge of my drill bit is longer than the other (the centre
point is therefore not centred)
One side of the drill bit has been sharpened for longer than the other. You will
need to sharpen the shorter side for more time and ensure that both sides
are always sharpened for the same amount of time using the same amount of
pressure.
My drill bit is broken (rather than blunt)
The DBS-3100 is not suitable for sharpening broken drill bits. A drill bit in this
condition will take a substantial amount of time to sharpen. Rough the drill bit into
shaperstusingabenchgrinder.
The motor turns on but the grinding stone does not spin
Forthistohappenthegrindingstoneassemblymaynotbealignedwiththeats
ontheshaft.Checkthatthegrindingstoneassemblyisalignedwiththeatson
the shaft (see maintenance section).
The drill bit sharpener does not start
The grinder stone may not be moving freely. Turn the grinding stone adjustment
knob anticlockwise to move the grinding stone downwards, this will allow the
grinding stone to turn freely.
Spare parts can be ordered from the Special Orders Desk
at your local Bunnings Warehouse.
For further information, or any parts not listed here, visit
www.ozito.com.au or contact Ozito Customer Service:
Australia 1800 069 486
New Zealand 0508 069 486
E-mail: [email protected]
SPARE PARTS
V Hz
~ W
/min
n o
Volts
Alternating current
Revolutions or
reciprocation per minute
Double insulated
Warning
Hertz
Watts
No load speed
Regulator compliance mark

This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning use of
the appliance by a person responsible for their safety.
Recommendations for the use of a residual current device with a rated residual
current of 30mA or less.
Thisapplianceisnotintendedforusebyyoungorinrmpersonsunlesssupervised
by a responsible person to ensure that they can use the appliance safely.
Young children should be supervised to ensure that they do not play with the
appliance.
• Always wear eye, ear and breathing protection.
• Never operate the drill bit sharpener with cracked or damaged grinding stones.
Always replace cracked or damaged grinding stones immediately.
• Always disconnect the drill bit sharpener from the power supply prior to making
any adjustments.
• Alwaysusesafetyequipmentincludingearmu󰀨s,goggles,gloves,hatand
clothing when operating the drill bit sharpener.
• Check and ensure that all the fastening screws, bolts and nuts are securely
tightened prior to operating the drill bit sharpener.
• Never use an object to slow or stop the grinding stone whilst in motion.
• Ensure the eye shields and tool rests are properly adjusted.
• Always use the eye shields and tool rests.
• Don’t use grinding wheels for cutting purposes.
• Ensure the drill bit sharpener speed doesn’t exceed the operating speed
marked on replacement grinding stones.
• Wear protective glasses.
• Do not use damaged or misshaped stones.
• The adjustment of the spark arrestor shall be made frequently, so as to
compensate the wear of the stone, keeping the distance between the guard
and the stone as small as possible, but in any case not greater than 2mm.
DRILL BIT SHARPENER SAFETY WARNINGS
The electric motor has been designed for 230V and 240V only. Always check that the power supply
corresponds to the voltage on the rating plate.
Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand.
This tool is double insulated; therefore no earth wire is required.
If the supply cord is damaged, it must be replaced by an electrician
or a power tool repairer in order to avoid a hazard.
Note: Double insulation does not take the place of normal safety precautions when operating this tool. The
insulation system is for added protection against injury resulting from a possible electrical insulation failure
within the tool.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool. Before use, inspect the
extension lead for signs of damage, wear and ageing. Replace the extension lead if damaged or defective.
When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not
suitableforthepowerinputofthetoolorwhichisdamagedordefectivemayresultinariskofreandelectric
shock.
GENERAL POWER TOOL SAFETY WARNINGS
ELECTRICAL SAFETY
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and
instructionsmayresultinelectricshock,reand/orseriousinjury.
Save all warnings and instructions for future reference. The term “power tool” in the warnings
refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause you to lose
control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.Unmodiedplugsandmatchingoutletswillreduceriskof
electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk
of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk
of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a power tool. Do
not use a power tool while you are tired or under the inuence of drugs, alcohol or medication. A
moment of inattention while operating power tools may result in serious personal injury.
b. Use personal protective equipment. Always wear eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the o󰀨-position before connecting to power
source and/or battery pack, picking up or carrying the tool. Carryingpowertoolswithyourngeron
the switch or energising power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the
power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities, ensure these
are connected and properly used. Use of dust collection can reduce dust-related hazards.
h. Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore
tool safety principles. A careless action can cause severe injury within a fraction of a second.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct power tool
will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and o󰀨. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power tool before
making any adjustments, changing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the
power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of
untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and
any other condition that may a󰀨ect the power tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking
into account the working conditions and the work to be performed. Use of the power tool for
operationsdi󰀨erentfromthoseintendedcouldresultinahazardoussituation.
h. Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.
5. Service
a. Have your power tool serviced by a qualied repair person using only identical replacement parts.
This will ensure that the safety of the power tool is maintained.
