Ozito CSL-018 User manual

Battery power: 18V
Charge time: 3 – 5 hours
No load speed: 2000/min
Stroke length: 13mm
Blade fitment: Universal (U-shaped) only
Maximum cutting capacity: Wood 20mm
Aluminium sheet 2mm
Non alloy steel 1mm
Battery: 18V - 1.3Ah Lithium Ion
Weight with 1 battery: 1.1kg
Blade fitment: Standard
Includes: 1 x Metal Cutting U Type Jigsaw Blade
1 x Wood Cutting U Type Jigsaw Blade
WARNING! The noise level of this machine can exceed 85dB(A).
Operators are recommended to use hearing protection devices.
42
10 9
11
SPECIFICATIONS – MODEL NO. CSL-018
1
KNOW YOUR PRODUCT
1. Tool-less blade clamp
2. Front shoe
3. On/Off trigger switch
4. Lock off button
5. Battery release button
6. Battery
7. Metal Cutting Blade
8. Wood Cutting Blade
9. Charging cradle
10. Charging adaptor
11. Charging jack
12. Tool-less blade clamp lever
13. Hand grip (with rubber over mould)
14. Rear hand grip (with rubber over mould)
!
!
5
7
8
3
1
13
14
6
1
12

2
TABLE OF CONTENTS
SPECIFICATIONS ………………………………………..
INTRODUCTION…………………………………………
ELECTRICAL SAFETY…………….………………………
GENERAL POWER TOOL SAFETY WARNINGS………
CUT SAW SAFETY WARNINGS!……………………….
LITHIUM ION BATTERY AND CHARGER
SAFETY FEATURES…………….…………………………
CHARGING YOUR LITHIUM ION BATTERY.………….
ASSEMBLY.……………………………………………….
CUT SAW OPERATION………………………………….
MAINTENANCE…………….……………………………
SPARE PARTS …………….……………………………...
DESCRIPTION OF SYMBOLS ………………………….
PACK CONTENTS ………………………………………
WARRANTY………………………………………………
Page 1
Page 3
Page 3
Page 4
Page 7
Page 8
Page 9
Page 11
Page 12
Page 15
Page 15
Page 16
Page 17
Page 18

INTRODUCTION
3
Congratulations on purchasing an Ozito Lithium Ion Cordless Cut
Saw. We aim to provide quality tools at an affordable price.
We hope you will enjoy using this tool for many years. Your
Lithium Ion Cordless Cut saw CSL-018 is an extremely versatile
tool designed to cut many different types of light material in many
varying situations.
It is designed to be used in a DIY (Do It Yourself) context or for
hobbyist purposes. It is ideal for light cutting applications ONLY.
The Cut Saw is supplied with a U Type Jigsaw wood cutting blade
and a U Type Jigsaw metal cutting blade. Blade changes are “tool-
free”. No tool is required to fit or remove a blade.
This unit does not accept Bayonet/Universal Jigsaw blades or
Standard Reciprocating Blades.
ELECTRICAL SAFETY
!
!WARNING! When using mains-powered tools, basic safety precautions,
including the following, should always be followed to reduce risk of fire,
electric shock, personal injury and material damage.
Read the whole manual carefully and make sure you know how to switch the tool
off, in an emergency, before operating the tool.
Save these instructions and other documents supplied with this machine for future
reference.
This tool is double insulated in accordance with AS/NZS 60335-1;
therefore no earth wire is required.
If the supply cord is damaged, it must be replaced by an electrician or a power tool
repairer in order to avoid a hazard.
Note: Double insulation does not take the place of normal safety precautions when
operating this tool. The insulation system is for added protection against injury
resulting from a possible electrical insulation failure within the tool.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool.
Before use, inspect the extension lead for signs of damage, wear and ageing.
Replace the extension lead if damaged or defective.
When using an extension lead on a reel, always unwind the lead completely. Use of
an extension lead not suitable for the power input of the tool or which is damaged
or defective may result in a risk of fire and electric shock.
It is recommended that the extension lead is a maximum of 25m in length. Do Not
use multiple extension leads

4
GENERAL POWER TOOL SAFETY WARNINGS
WARNING! Read all safety warnings and all instructions. Failure to
follow the warnings and instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and instructions for future reference.
The term “power tool" in all of the warnings refers to your mains-operated
(corded) power tool or battery-operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks which
may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions
can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way.
Do not use any adapter plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric shock if
your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power
tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging
the power tool. Keep cord away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual
current device (RCD) protected supply. Use of an RCD reduces the risk of
electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating
a power tool. Do not use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment of inattention while
operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective
equipment such as dust mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to power source and/or battery pack, picking up or carrying the
tool. Carrying power tools with your finger on the switch or energising power
tools that have the switch on invites accidents.
!
!
!
!

5
GENERAL POWER TOOL SAFETY WARNINGS
!
!
d) Remove any adjusting key or wrench before turning the power tool on. A
wrench or a key left attached to a rotating part of the power tool may result in
personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the rate
for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any
power tool that cannot be controlled with the switch is dangerous and must
be repaired.
c) Disconnect the plug from the power source and/or the battery pack from
the power tool before making any adjustments, changing accessories, or
storing power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to operate
the power tool. Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power
tool's operation. If damaged, have the power tool repaired before use.
Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with
these instructions, taking into account the working conditions and the
work to be performed. Use of the power tool for operations different from
those intended could result in a hazardous situation.
5) Service
a) Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power tool
is maintained.
b) If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.

6
BATTERY AND CHARGER SAFETY WARNINGS
!
!
THIS MANUAL CONTAINS IMPORTANT SAFETY AND OPERATING INSTRUCTIONS
FOR YOUR BATTERY CHARGER.
• Before using the charger read all instructions and cautionary markings on the
charger, battery pack and the product using the battery pack.
Danger! If the battery pack case is cracked or damaged, do not insert it
into charger. There is a danger of electric shock or electrocution.
WARNIING! Do not allow any liquid to get inside charger. Electric shock
may result. To facilitate cooling of the battery pack after use, avoid placing
the charger or battery pack in a warm environment such as in a metal shed,
or an uninsulated trailer.
• This charger is not intended for any uses other than charging rechargeable
batteries. Any other use may result in risk of fire, electric shock or electrocution.
• Do not place any object on top of the charger or place the charger on a soft
surface that may result in excessive internal heat. Place the charger in a position
away from any heat source.
• To reduce risk of damage to the electric plug and cord, pull by the plug rather
than the cord when disconnecting the charger.
• Make sure the cord is located so that it will not be stepped on, tripped over, or
otherwise subjected to damage or stress.
• An extension cord should not be used unless absolutely necessary. Use of an
improper extension cord could result in the risk of fire, electric shock or electrocution.
• Do not operate the charger if it has received a sharp blow, been dropped or
otherwise damaged in any way. Have it checked by an electrician or power
tool repairer.
• Do not disassemble charger. Take it to an electrician or power tool repairer when
service or repair is required. Incorrect reassembly may result in a risk of electric
shock, electrocution or fire.
• To reduce risk of electric shock, unplug the charger from the outlet before
attempting any cleaning. Removing the battery pack will not reduce this risk.
• Never attempt to connect 2 chargers together.
• DO NOT store or use the tool and battery pack in locations where the temperature
may reach or exceed 40ºC (such as inside sheds or metal buildings in summer).
•The charger is designed to operate on standard household electrical power (240
volts). Do not attempt to use it on any other voltage!
• The battery pack is not fully charged out of the carton. First read the safety
instructions and then follow the charging notes and procedures.
!
!
!
!

7
BATTERY AND CHARGER SAFETY WARNINGS
!
!
!
!
• The longest life and best performance can be obtained if the battery pack is
charged when the air temperature is between 18 - 24ºC. Do not charge the
battery pack in an air temperature below 10ºC or above 40ºC. This is
important and will prevent damage to the battery pack.
• Do not incinerate the battery pack even if it is seriously damaged or is
completely worn out. The battery can explode in a fire.
• Never attempt to open the battery pack for any reason. If the plastic housing
of the battery pack breaks or cracks, immediately discontinue use and do
not recharge.
• During charging, the battery must be placed in a well ventilated area.
• Hold power tool by insulated gripping surfaces, when performing an
operation where the cutting accessory may contact hidden wiring or its own
cord. Cutting accessory contacting a "live" wire may make exposed metal
parts of the power tool "live" and could give the operator an electric shock.
• Do not use the drill in wet or damp conditions.
•This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
• Recommendations for the use of a residual current device with a rated
residual current of 30mA or less.
•It is recommended that the extension lead is a maximum of 25m in length. Do
Not use multiple extension leads.
• Wear a hard hat (safety helmet), safety glasses and/or face shield. It is also highly
recommended that you wear a dust mask, ear protection and padded gloves.
•Check the blade carefully for cracks or damage prior to operation. Replace
cracked or damaged blades immediately.
• Hold the tool firmly during operation.
• Always hold the front shoe firmly to the work piece.
• Ensure no one is below you when using the tool in elevated conditions.
• Do not point the tool at anyone in the immediate vicinity.
WARNING! When making a "blind" cut (you can't see behind what is
being cut), be sure that hidden electrical wiring or water pipes are not
in the path of the cut. If wires are present, they must be disconnected
at their power source by a qualified person or avoided to prevent the
possibility of lethal shock or fire.
• Water pipes in "blind" areas must be drained and capped before cutting.
• If the blade hits against objects during operation, damage to the tool or
dangerous blade breakage may occur.
CUT SAW SAFETY WARNINGS!
!
!

8
CUT SAW SAFETY WARNINGS! (cont.)
!
!
!
!
LITHIUM ION BATTERY AND CHARGER SAFETY FEATURES
• Watch out for cut-off portions of the work piece being cut. They may fall and
cause injury to you or someone near you.
• When cutting metals, be cautious of hot flying debris.
• Do not touch the blade or the work piece immediately after operation; they may
be extremely hot and could potentially burn your skin.
• If you withdraw the blade from the work piece during operation, a strong reaction
could be produced, which could cause the blade to snap or cause you to lose
your grip and/or control of the saw. Always switch off the tool and wait until the
blade has come to a complete stop before withdrawing the blade from the work piece.
WARNING! Some dust created by sawing activities contain chemicals
known to cause cancer and other respiratory harm. Wear dust masks
designed for protection against dust and fumes.
Over Charging Protection
This feature ensures that the battery (6) is never overcharged. When the battery (6) has
reached its full charge capacity the charger will shut off protecting the internal
components of the battery (6) from being damaged.
Over Discharge Protection
The battery (6) includes an over discharge protector. This feature stops the battery (6)
from discharging beyond the recommended lowest safety voltage.
Over Heat Protection
The battery (6) has an internal thermal cut-out device that stops the charging cycle if
the battery (6) becomes hot during the charging process. This thermal cut-out device
also stops the battery (6) from operating should the battery (6) become too hot during
the operation of the tool. This can happen when the tool is overloaded or being used
for extended periods of time.
Up to 30 minutes cooling time may be required depending on ambient temperature
and the operation being performed.
Over Current Protection
If the battery (6) is overloaded and the maximum current draw is exceeded the battery
will temporarily stop working to protect the internal components. The battery (6) will
resume normal operation once the current draw has returned to its normal safe level.
This may take a few seconds.
Short Circuit Protection
If the battery (6) short circuits, the short circuit protector immediately stops the battery
(6) from operating.
This ensures that no internal components of the battery (6) or tool are damaged.

9
CHARGING YOUR LITHIUM ION BATTERY
The batteries (6) have been shipped in a low charge condition, and requires
charging prior to use.
• Connect the charging jack (11) to the charging
cradle (9) (see Fig. 1).
• Plug the charging adaptor (10) into a mains power
outlet.
• The green light on the charging cradle (9) will
illuminate showing that power is being supplied to
the charging cradle (9).
• With the charging cradle (9) sitting flat on a
bench/table, insert the battery (6) into the recess
of the battery terminals ensuring a firm connection
(see Fig. 2).
• The battery (6) fits in one direction only. If you
need to force the connection it means the
battery (6) is facing the wrong way.
• When the battery (6) is properly seated, the red
light on the charging cradle (9) will illuminate if the battery (6) is partially or fully
discharged, signifying that the battery (6) is charging.
• When the battery (6) is fully charged, the red light will extinguish signifying that
the battery (6) is fully charged.
• A battery takes 3 - 5 hours to charge. Charging starts automatically when the
battery is connected to the charger. Remove the battery (6) from the charging
cradle (9) after 5 hours.
Initial charge
• The battery (6) will not reach its full charge the first time it is charged.
• The green LED will remain illuminated until the charger is disconnected from the
mains power outlet.
•Allow several charging cycles of charging and then discharging (through use of
the tool) for the battery (6) to reach its maximum charge.
Caution: Disconnect the charger adaptor from the mains power when charger is
not in use.
Noted: If the light on the charging cradle (9) fails to come on:
- Check the charging adaptor (10) is securely plugged into the mains power
outlet and switched on.
- Check the battery (6) is firmly seated onto the charging cradle (9).
- Check the charging jack (11) is securely connected into the charging
cradle (9) socket.
Fig. 1
Fig. 2
Charger
jack

CHARGING YOUR LITHIUM ION BATTERY (cont.)
10
Subsequent charges
• After normal usage, approximately 3-5 hours of charging time is required to fully
recharge the battery (6).
• If the battery (6) is completely discharged, 5 hours or longer of charging time will
be required to fully recharge it.
Important charging notes
• The charging adaptor (10) and battery (6) may become warm to touch while
charging. This is a normal condition, and does not indicate a problem.
• Use the charger at normal room temperature whenever possible. To prevent
overheating, do not cover the charger and do not charge the battery (6) in direct
sunlight or near heat sources.
• If the battery (6) does not charge properly:
- Check current at mains power outlet by plugging in a lamp or other appliance.
- If charging problems persist, have the complete tool checked by an electrician or
a power tool repairer.
• If the light on the charging cradle (9) fails to come on:
- Check the charging cradle (9) is securely plugged into the mains power outlet
and is switched on.
- Check that the battery (6) is firmly seated onto the charging cradle (9).
- Check that the charging jack (11) is securely connected into the charging
cradle (9) socket.
Thermal Voltage Protection Indication
In the event that the thermal or voltage protection circuit has been activated the
battery (6) will cease to operate. This can happen when the tool has been used for
extended periods or worked hard with large drill bits or accessories.
If you place the battery (6) on the charging cradle (9) the LED Lights will give you the
appearance that the battery is fully charged. Leave the battery (6) In the charging
cradle (9) to charge for 3 -5 hours.
The battery (6) may take the full 5 hours to charge, as the battery (6) may need to cool
down or the protection circuits to be reset. This will allow the charger to begin
charging the battery (6) and resume normal operation.

Installing the battery
• Holding the cut saw upright and picking up the
battery (6) in your opposite hand. Insert the
battery (6) until it clicks into place (see Fig. 3).
• Do not use excessive force when inserting the
battery (6). If the battery (6) does not slide in
easily, it is not being inserted correctly and could
cause damage to the battery (6), battery
terminals or the cut saw.
• Do not operate the ON/OFF trigger switch (3)
whilst inserting the battery (6).
Removing the battery
Depress the battery release button (5) and pull the battery (6) down away from the
cut saw.
Getting the best performance from the battery
The length of service from each charging cycle will depend on the type of work
undertaken.
To obtain the longest possible battery life, we suggest the following:
•Store and charge your batteries in a cool area. Temperatures above or below
normal room temperature will shorten battery life.
•Never store batteries in a discharged condition. Recharge them immediately
after they are discharged.
•All batteries gradually lose their charge. The higher the temperature the
quicker they lose their charge. If you store your drill for long periods of time
without using it, recharge the batteries every month or two. This practice will
prolong battery life.
ASSEMBLY
11
Fig. 3

!
!
12
CUT SAW OPERATION
!
!
Selecting the right saw blade
Caution! The CSL-018 Cut Saw is designed to only accept Universal (u-shaped) style
jigsaw blade.
WARNING! Remove the battery (6) from the cut saw before inserting or
removing a blade or when making any adjustments to your saw.
Before installing a blade, remove any debris and foreign matter adhering to the blade
and within the tool-less blade clamp (1). Failure to do so may prevent the blade from
being properly secured and dislodging during use, resulting in a serious injury.
With the right blade, cut saws can cut non alloy steel, wood, plaster, fiberglass,
composites, plaster board. They are best suited for rough cutting and they are
especially useful when working in tight spaces or at awkward angles.
Cut saw blades come in a variety of sizes, materials and tooth designs, according to
the applications for which they are best suited.
Before purchasing new blades
Caution! The CSL-018 Cut Saw is designed to only accept Universal (u-shaped) style
jigsaw blade.
Please check on the blade packaging for the suitability of the blade for the job at hand.
WARNING! Remove the battery (6) from the cut saw before inserting or
removing a blade or when making any adjustments to your saw.
Installing the blade
Check that the blade you are inserting matches the material you are cutting.
Start with a sharp blade.
Depress the clamp lever (12) as far as it will go towards
the direction of the tool body (See Fig. 4).
Fig. 4

13
CUT SAW OPERATION (cont.)
!
!
Fully insert the new blade into tool-less blade clamp
(1) and release the tool-free blade clamp lever (12).
(See Fig. 5). Take care that the hole in the end of the
blade is inserted into the tool-less blade clamp (1).
Generally the teeth of the blade should face towards
the bottom of the cut saw, but the blade can be
reversed in the tool-less blade clamp (1) so the teeth
face upwards if the application requires it.
Check if the blade is correctly fitted by pulling on the
blade to see if it can be removed (See Fig. 6). If it
cannot be extracted from the tool-less blade clamp (1),
the blade has been inserted correctly.
WARNING! If the blade is not properly
secured it may be ejected unexpectedly
during operation. This could potentially
cause serious personal injury or injury to
others. Always ensure the blade is secured
properly before beginning operation.
Caution! Blades are sharp. Use gloves to avoid accidentally cutting yourself.
Blade removal
Depress the tool-less blade clamp lever (12) as far as it
will go towards the direction of the tool body and
remove the blade. (See Fig. 7). Release the tool-less
blade clamp lever (12).
Turning the tool on
To turn the tool on, slide down the lock off button (4)
then depressing the ON/OFF trigger switch (3) (See
Fig. 8).
The tool CAN NOT be locked in the ON position for
your safety.
Fig. 5
Fig. 6
Fig. 7
Fig. 8
slide
press

14
CUT SAW OPERATION (cont.)
Cutting procedure
The saw blade does most of its cutting as it travels towards the operator.
This can cause splintering on the top surface of the work piece.
Therefore, if possible, position yourself or the work piece so that the desired “good”
side of the work piece is facing away from you.
When you have finished cutting, release the ON/OFF trigger switch (3) to stop the saw.
During operation, always press the front shoe (2) firmly against the work piece. If the
front shoe (2) is held away from the work piece during operation, strong vibration
and/or kickback may occur, causing the blade to snap and creating danger for the
operator and others in the vicinity.
To achieve a secure hold of the saw during operation always use both hands to grip
the hand grip (13) and the rear handle (14) at the same time.
General cutting
Clamp your work piece if it is portable.
Press the front shoe (2) firmly against the work piece
without allowing the blade to make contact. (See Fig. 9)
Slide down the lock off button (4) then depressing the
ON/OFF trigger switch (3) to start the cut saw.
Gently apply downward force to begin cutting. Use a
rocking motion of the Cut saw to assist in the cutting of
the material.
Exert enough pressure in the direction of the cut to keep the blade cutting, and
enough forward pressure to keep the front shoe (2) pressed firmly against the work
piece at all times.
Do not force the cut or stall the cut saw.
Do not bend or twist the blade. Let the tool and the blade do the work. In general,
coarser blades are for wood, plastics, and composites, and finer blades are for cutting
metal. Chattering or vibration may indicate you need a finer blade or higher speed. If
the blade overheats or clogs, it may indicate you need a coarser blade or slower
speed setting.
Replace blades when they become dull. Dull blades will produce poor results and may
overheat the saw.
Metal cutting
Blades specifically designated for cutting metals must be used for this purpose. You
may use a light oil as a coolant when cutting metal; this will prevent overheating of
the blade, help the blade cut faster, and promote longer blade life.
Fig. 9

MAINTENANCE
15
SPARE PARTS
• When not in use, the cut saw should be stored in a dry, frost free location, out
of reach of children.
• Keep ventilation slots of the cut saw clean at all times and prevent any foreign
matter from entering.
• If the housing of the cut saw requires cleaning, do not use solvents but a moist
soft cloth only.
• Blow out the ventilation slots with compressed air periodically.
Note: Ozito Industries will not be responsible for any damage or injuries caused by
repair of the cut saw by an unauthorised person or by mishandling of the cut saw.
Limited spare parts are available subject to availability. Please contact your local
Bunnings Special Orders Desk to order the required spare parts.
Most common spare parts listed below
Spare Part Part No.
18V Battery Pack SPCDL018-37
Charging Stand SPCDL018-38
Charging Adaptor SPCDL018-39

DESCRIPTION OF SYMBOLS
16
Warning Read instruction manual
ø Diameter
mA Milliamperes
n o No load speed
Recycle battery Do not put in the rubbish
Polarity
Do not incinerate Donot get battery wet
Thermal cut-out protection
Transformer Energy
Rating (MEPS)
Double insulated
/min Revolutions or
reciprocation per minute Ah Amp hour
Indoor use only
Lithium Ion battery Do not use or store battery in
temperatures exceeding 50ºC
Electrical Emissions
Conformity (EMC)
VVolts Hz Hertz
ac/~ Alternating current WWatts
Direct current
dc/

CARING FOR THE ENVIRONMENT
17
1 x 18V Cordless Lithium Ion Cut Saw
2 x U Type jigsaw blades
1 x Instruction manual
AUSTRALIA (Head Office)
1 - 23 Letcon Drive, Bangholme, Victoria, Australia 3175
Telephone: [phone]
Facsimile: [phone]
Website: www.ozito.com.au
Email: [email protected]
Power tools that are no longer usable should not be
disposed of with household waste but in an environmentally
friendly way. Please recycle where facilities exist. Check with
your local council authority for recycling advice.
Recycling packaging reduces the need for landfill and raw
materials. Reuse of recycled material decreases pollution in the
environment. Please recycle packaging where facilities exist.
Check with your local council authority for recycling advice.
PACK CONTENTS
OZITO INDUSTRIES PTY LTD

WARRANTY
THIS WARRANTY FORM AND CONFIRMED BUNNINGS REGISTER RECEIPT SHOULD
BE RETAINED BY THE CUSTOMER AT ALL TIMES
The warranty is only made available by returning the product to your nearest
Bunnings Warehouse with a confirmed Bunnings register receipt.
PURCHASED FROM:________________________________________________
DATE PURCHASED: ________________________________________________
3 YEAR REPLACEMENT WARRANTY
Your Ozito tool is guaranteed for a period of 36 months from the original date of
purchase and is intended for DIY (Do it yourself) use only.
The Lithium Ion battery is covered by a 12 month warranty.
WARNING
The following actions will result in the warranty being void.
• Trade, professional, industrial or high frequency use.
• If the tool has been operated on a supply voltage other than that specified on
the tool.
•If the tool shows signs of damage or defects caused by or resulting from abuse,
accidents or alterations.
• If the tool is disassembled or tampered with in any way.
Note: Warranty excludes consumable parts such as carbon brushes, drill and driver
bits, blades and chucks.
YOUR WARRANTY FORM SHOULD BE RETAINED
BY YOU AT ALL TIMES.
SHOULD YOU HAVE ANY QUESTIONS PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY OR
REPAIR PLEASE TELEPHONE OUR CUSTOMER
SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL NUMBER
AND DATE OF PURCHASE AVAILABLE. AN OZITO CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL AND ANSWER ANY QUESTIONS
YOU MAY HAVE RELATING TO THE WARRANTY POLICY OR PROCEDURE.
