Ozito SSB-405 User manual

405mm Variable Speed
Scroll Saw
120W
Instruction Manual
3 Year Replacement Warranty
SSB-405
WARNING! Read all safety warnings and all instructions. Failure to follow
the warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
To view the full range visit: www.ozito.com.au
0312

SPECIFICATIONS - MODEL NO. SSB-405
KNOW YOUR PRODUCT
1
Motor: 120W (S1:50W S2:5min)
Input: 230-240V~50Hz
No load speed: 400-1600/min
Depth of Throat: 405mm (16”)
Max. thickness of cut: 50mm
Blade length: 127mm
Stroke: 15mm
Table tilt: 0-45° Left
Table size: 413 x 253mm
Fuse: 3.15 Amp
Insulation: Class 1 Earthed Appliance
Weight (tool only): 9.90kg
1. Blade Tension Knob
2. Work Piece Holder Lock Knob
3. Saw Arm Lever
4. Upper Blade Holder
5. Sawdust Blower
6. Table Insert
7. Table
8. Speed Selector Dial
9. On/Off Switch
10. Dust Extraction Port
11. Table Bevel Lock Knob
12. Bevel Scale
13. Cover Panel
14. Work Piece Holder
15. Pin Type Blade
16. Fuse Holder
12
3
4
5
6
7
8
9
11
12
13
14
15
10
16

TABLE OF CONTENTS
2
SPECIFICATIONS ………………………………………..
INTRODUCTION…………………………………………
ELECTRICAL SAFETY…………….………………………
GENERAL POWER TOOL SAFETY WARNINGS………
SCROLL SAW SAFETY WARNINGS ……………………
ASSEMBLY…………………………………………………
OPERATION………………………………………………
MAINTENANCE…………….……………………………
SPARE PARTS …………….……………………………...
DESCRIPTION OF SYMBOLS ………………………….
PACK CONTENTS ………………………………………
WARRANTY………………………………………………
Page 1
Page 3
Page 3
Page 4
Page 6
Page 8
Page 9
Page 15
Page 18
Page 18
Page 19
Page 21

INTRODUCTION
3
Congratulations on purchasing an Ozito 405mm Variable
Speed Scroll Saw. We aim to provide quality tools at an
afordable price.
We hope you will enjoy using this tool for many years. Your
405mm Variable Speed Scroll Saw SSB-405 has been designed
for precise straight and curved cuts in wood, plastic and plaster.
It is intended for DIY use only.
ELECTRICAL SAFETY
WARNING! When using mains-powered equipment, basic safety precautions,
including the following, should always be followed to reduce risk of fire,
electric shock, personal injury and material damage.
Read and understand the manual prior to operating this tool.
Save these instructions and other documents supplied with this tool for future reference.
The electric motor has been designed for 230V and 240V only. Always check that the
power supply corresponds to the voltage on the rating plate.
Note: The supply of 230V and 240V on Ozito tools are interchangeable for
Australia and New Zealand.
If the supply cord is damaged, it must be replaced by a qualified electrician or a
power tool repairer in order to avoid a hazard.
If operating a power tool in a damp location is unavoidable use a residual current
device (RCD) protected supply Use of an RCD reduces the risk of electric shock.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool. Be-
fore use, inspect the extension lead for signs of damage, wear and ageing. Replace
the extension lead if damaged or defective. When using an extension lead on a reel,
always unwind the lead completely. Use of an extension lead not suitable for the
power input of the tool or which is damaged or defective may result in a risk of fire
and electric shock.

GENERAL POWER TOOL SAFETY WARNINGS
4
WARNING! Read all safety warnings and all instructions. Failure to
follow the warnings and instructions may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in all of the warnings refers to your mains-operated
(corded) power tool or battery-operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks which
may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions
can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way.
Do not use any adapter plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric shock
if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power
tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging
the power tool. Keep cord away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual
current device (RCD) protected supply. Use of an RCD reduces the risk of
electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating
a power tool. Do not use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment of inattention while
operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective
equipment such as dust mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to power source and/or battery pack, picking up or carrying the
tool. Carrying power tools with your finger on the switch or energising power
tools that have the switch on invites accidents.

5
d) Remove any adjusting key or wrench before turning the power tool on. A
wrench or a key left attached to a rotating part of the power tool may result in
personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables
better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewellery or long
hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used. Use of dust collection
can reduce dust-related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application.
The correct power tool will do the job better and safer at the rate for which it
was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power
tool that cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the
power tool before making any adjustments, changing accessories, or
storing power tools. Such preventive safety measures reduce the risk of starting
the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power
tool. Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired before use. Many
accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these
instructions, taking into account the working conditions and the work to be
performed. Use of the power tool for operations different from those intended
could result in a hazardous situation.
5) Service
a) Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power tool
is maintained.
b) If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
GENERAL POWER TOOL SAFETY WARNINGS

SCROLL SAW SAFETY WARNINGS
6
Hold power tool by insulated gripping surfaces, when performing an operation
where the cutting accessory may contact hidden wiring or its own cord. Cutting
accessory contacting a “live” wire may make exposed metal parts of the power tool
“live“ and could give the operator an electric shock.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by
a person responsible for their safety.
Children should be supervised to ensure that they don’t play with the appliance.
Recommendatins for the use of a residual current device with a rated residual
current of 30mA or less.
Pull out all nails in the material before starting to saw. Cutting nails may damage
your tool.
Do not operate your scroll saw until it is completely assembled and installed
according to the instructions and until you have read and understood all of the
instructions.
Do not touch moving parts with your fingers or hands.
Ensure that you have tightened the blade prior to starting the machine.
When finishing sawing, wait until the saw blade has ceased moving prior to
removing it from the material.
Do not touch the saw blade immediately after use. Allow time for the blade to
cool, otherwise it could burn you due to the heat generated during sawing.
Always check accessories to ensure that they are suitable for the operating
speeds of this tool.
Incorrect accessories can break apart at high speed and cause serious damage
or personal injury.
Never turn your scroll saw on before clearing the table of all objects (tools,
scraps of wood, etc.) except for the workpiece.
Hold the work firmly against the table.
Do not feed the material too fast while cutting. Only feed the material fast
enough so that the blade will cut.
Never leave the scroll saw running unattended. Always turn the saw off, make
sure that it has come to a complete stop, and then remove plug from the
power supply before leaving the work area.
Use caution when cutting off material which is irregular in cross section as it could
pinch the blade before the cut is completed. A piece of moulding, for example,
must lay flat on the table and not be permitted to rock whilst being cut.
•
•
•
•
•
•
•
•
•
•
•
•
•

SCROLL SAW SAFETY WARNINGS (cont.)
7
WARNING! Some dust created by sanding, sawing, grinding, drilling and
other construction activities contain chemicals known to cause cancer, birth
defects or other reproductive harm.Some examples of these chemicals are:
• Lead from lead-based paints;
• Crystalline silica from bricks, cement and other masonry products, and;
• Arsenic and chromium from chemically-treated timber.
The risk from such exposures vary depending on how often you do this type of work.
To reduce your exposure to these chemicals; work in a well ventilated area, and
work with approved safety equipment, such as those dust masks that are specifically
designed to filter out microscopic particles.
Always wear eye protection and a dust mask for dusty applications and when drilling/
chiselling overhead. Sanding particles can be absorbed by your eyes and
inhaled easily and may cause health complications.
Caution: Always Wear safety goggles, ear protection and a respiratory mask.

ASSEMBLY
8
Unpacking
Open carton and remove top packing material
Carefully lift the variable speed scroll saw from the packaging and place it on a
level work surface.
By applying paste wax (not included) in thin coats to the entire saw table (7) will
allow the work piece to glide smoothly across the work surface. Let dry then
use a clean piece of cloth to buff the surface out. Reapply as necessary for a
smooth finish.
Mounting to a workbench
The variable speed scroll saw features four holes in the base for mounting to a
workbench or worktable. This is recommended to gain maximum stability and
reduce noise and vibration. It is best to attached the variable speed scroll saw to a
stable, flat surface at a convenient working height. Each hole in the base should be
bolted securely using bolts, lock washers and nuts (not supplied).
If you are using the variable speed scroll saw in several different places, it is
recommended you fasten it permanently to a mounting board that can be clamped
to a workbench or worktable. The mounting board should be large enough to
prevent the variable speed scroll saw from tipping while in use and be a minimum
19mm thickness is recommended.
Note: It may be necessary to countersink the bolt head on the bottom side of
mounting board.
Reducing noise and vibration
By placing foam pad or a piece of carpet between the variable speed scroll saw
and the workbench to further reduce noise and vibration. The size should be
approximately 610mm x 305mm x 13mm thick. If padding is to be used do not
overtighten the mounting bolts.
•
•
•

OPERATION
9
Blades
The variable speed scroll saw accepts 127mm pin end scroll saw blades. The blade
width, thickness and the number of teeth per inch will be determined by the material
and size of the radius being cut. Very fine narrow blades should be used to scroll cut
in thin material, 6mm thick or less. Wider blades cannot cut curves as tight or as small
as thinner blades. To cut thicker material, use wider blades with fewer teeth.
Blade Selection
Teeth/Inch Width Thickness Speed Material
10 2.5mm 0.4mm 1200-1600 Hard & soft woods 6mm up
to 51mm. Plastic, paper, felt,
etc.
15 2.5mm 0.4mm 600-1200 Wood, plastic, thin cuts
2.4mm up to 13mm thick
20 2.5mm 0.4mm 400-600 Tight radius work 2.4mm
up to 13mm thick. Wood,
veneer, fibre, plastic, etc.
When cutting wood, best results are achieved with pieces less than 25mm thick
When cutting wood thicker than 25mm, the user should guide the workpiece
very slowly into the blade, taking extra care not to bend or twist the blade
while cutting.
Teeth on scroll saw blades wear out quickly and must be replaced frequently for
best cutting results. Scroll saw blades generally keep sharp for approximately
30 minutes up to 2 hours of cutting , depending on the type of material and
speed of operation.
Fitting & Removing Blades
WARNING! Prior to fitting or replacing blades, ensure you switch the
machine off and disconnect from mains power supply.
Turn the blade tension knob (1) anti-clockwise,
“Release” direction to reduce the blade tension
(Fig. 1).
Loosen the work piece holder lock knob (2) and
raise the work piece holder (14) to provide access
to the table insert (6).
•
•
•
1.
2.
Fig. 1

OPERATION (cont.)
10
Remove the table insert (6), by pushing up from
under the saw table (7) (Fig. 2).
Fittting Blades:
Place the new blade through the opening in the
saw table (7), teeth to the front of the saw
pointing downwards. Gently fit the pins of the
blade into the V-notch of the lower blade holder
(Fig. 3). Keeping slight upward pressure on the
blade to ensure the blade is locked in place.
With the lower blade securely attached to the
lower blade holder, keeping a slight upward
pressure. With your other hand gently press the
saw arm lever (3) down, insert the pins of the
blade in the V-notch in the upper blade holder (4)
(Fig. 4).
Removing Blades:
Gently pull up on the blade and push down on
the saw arm lever (3) to disengage the upper pins
in the V-notch of the upper blade holder (4) (Fig. 5).
Gently pull down the blade to disengage the
lower pins in the V-notch of the lower blade
holder and remove the blade.
Increase the tension of the blade by turning the blade tension knob (1)
clockwise, “Tension” direction to hold the blade in place. The tension of the
blade should be adjusted as required when the cutting operation is undertaken.
Replace the table insert (6) to the position required for straight cutting or bevel
cutting as described in “Adjusting the table insert”, page 11.
3.
4.
5.
6.
7.
8.
9.
Fig. 2
Fig. 3
Fig. 4
Fig. 5
Note: Alternatively you can gain access to the lower blade holder by removing the
cover panel (13). Refer to page 13 of this manual for instructions.

OPERATION (cont.)
11
Adjusting the table insert
WARNING! Always ensure that the variable speed scroll saw is switch off
and disconnect from mains power supply before making any adjustments.
The table insert (6) requires to be positioned depending if a straight cut or bevel
cut is required. Incorrect positioning can result in damaging the table insert (6) and
damaged or broken blades.
For a straight cut the table insert (6) opening
requires to be positioned to the left (Fig. 6).
For a bevel cut the table insert (6) opening requires
to be positioned to the right (Fig. 7).
Remove the table insert (6), by pushing up from the
bottom of the table (7).
Position the opening of the table insert (6) to the
left or to the right depending on the
cutting application required.
Align the 4 grooves in the table insert (6) with the
lugs on the table (Fig. 8) and gently push into place.
On/Off Switch (9)
To turn the machine on, press the green On (I)
button (Fig. 9).
To turn the machine off, press the red Off (O) button.
Note: This variable speed scroll saw is automatically
turned off in the event of a power failure, accidently
unplugged or turned off at the mains power supply.
You will need to push the green On (I) button again to
restart the variable speed scroll saw.
•
•
•
•
•
•
•
Fig. 6
Fig. 7
Fig. 8
Fig. 9

OPERATION (cont.)
12
Work Piece Holder
Adjusting the height:
To prevent the workpiece from lifting, the work piece
holder (14) should be adjusted so it just sits on top of
the workpiece. The work piece holder (14) should not
be adjusted so tightly that the workpiece drags.
Loosen the work piece holder lock knob (2) (Fig. 10).
Lower or raise the work piece holder (14) to the
desired position.
Retighten the work piece holder lock knob (2).
Adjusting the angle:
When bevel cutting the work piece holder (14) requires to be adjusted so its parallel
to the table (7). (as described in “Bevel Cutting” page 14).
Sawdust Blower
The variable speed scroll saw features a sawdust blower (5) to direct air to the most
effected point on the cutting line. Make sure the work piece holder (14) is properly
adjusted, as explained above, to secure the workpiece and direct air at the cutting
surface.
Caution: Do not overtighten, damage could occur to sawdust blower (5).
Adjusting Blade Tension
Tension (or tighten) the blade by turning the blade tension knob (1) clockwise.
Release (or loosen) the blade by turning the blade tension knob (1) anti-clockwise.
Check tension by the sound the blade makes when plucking the blade, simular to
plucking a guitar string. This requires good knowledge of your scroll saw.
Pluck the back edge of the blade while turning the blade tension knob (1).
The sound should be a musical note. The sound becomes less flat as tension
increases. The sound level will decrease with too much tension.
Note: Be careful as over tension may cause the blade to break as soon as you start
cutting. Too little tension may cause the blade to bend or break.
•
•
•
•
•
•
Fig. 10

13
Speed Setting
The speed can be adjusted by turning the speed
selector dial (8) (Fig. 11). Adjust to suit the work piece/
material being cut. The saw’s speed can be adjusted
from 400 to 1,600 SPM (strokes per minute).
Turn the machine On by pressing the green
On ( I ) button (9)
Rotate the speed selector dial (8) clockwise
direction “H” for a higher or faster speed.
Rotate the speed selector dial (8) anti-clockwise direction “L” for a lower or
slower speed.
Turn the machine Off by pressing the red Off (O) button (9).
Note: By using a scrap piece of timber to determine the optimum speed by making
a trial cut will increase the life of the saw blade.
Dust Extraction Port
This feature will allow attachment (I/D 31mm; O/D 35mm) of a vacuum hose for easy
sawdust collection. Over time a build up of sawdust can accumulate behind the dust
port (10) if dust extraction is not used, this should be checked periodically.
WARNING! Always ensure that the variable speed scroll saw is switch off
and disconnect from mains power supply before making any adjustments.
Loosen, not remove the screw on the right holding
the cover panel (13) in place (Fig. 12).
Remove the remaining screw on the left holding
the cover panel (13) in place.
The cover panel (13) can know be removed from
the body of the saw.
Using a brush or vacuum clean away the sawdust
and any broken blades that may have accumulated.
Replace cover panel (13) when finished cleaning.
Note: Removing the cover panel (13) gives easy access to the lower blade holder,
and will aid in the fitting of blades. Always replace cover panel (13) before operating
the saw.
•
•
•
•
•
•
•
•
OPERATION (cont.)
Fig. 12
Fig. 11

OPERATION (cont.)
14
Bevel cutting
WARNING! Always ensure that the variable speed scroll saw is switch off
and disconnect from mains power supply before making any adjustments.
Remove the table insert (6) by gently pushing up
from under the saw table (7) and rotate to the
slots of the table inserts are facing down and
to the right as shown in Fig. 13 (as described in
“Adjusting the table insert”).
Loosen the table lock knob (11) to allow the saw
table (7) to be tilted to the left. (Fig. 14). The saw
table (7) can be locked at any angle from 0° to a
45° angle to the left for bevel cutting.
A bevel scale (12) is located under the saw table (7)
as a convenient guide for setting the appropriate
table angle for bevel cutting (Fig. 15). The bevel
scale is a guide only, make a practice cut on scrap
material and adjust the saw table (7) as necessary
for your desired setting.
Loosen the screw at the front of the work piece
holder (14) (Fig.16) and then tilt so that it is
parallel to the saw table (7). Tighten the screw to
secure the work piece holder (14) in place.
1.
2.
3.
4.
Note: When bevel cutting, the work piece holder (14) should be adjust so its parallel
to the saw table (7).
Fig. 13
Fig. 14
Fig. 15
Fig. 16

15
Keep the ventilation vents of the tool clean at all times, if possible, prevent
foreign matter from entering the vents.
After each use, blow air through the tool housing to ensure it is free from all
dust particles which may build up. Build up of dust particles may cause the tool
to overheat and fail.
If the enclosure of the tool requires cleaning do not use solvents but a moist soft
cloth only. Never let any liquid get inside the tool; never immerse any part of
the tool into a liquid.
The motor mount screws could work loose over time, periodically inspect and
when required tighten the screws.
Squaring The Table To The Blade
Loosen the table bevel lock knob (11) to allow the saw table (7) to be
approximately at a right angle to the blade.
Place a square on the saw table (7) next to the
blade to check if the table is at a 90° angle to the
blade (Fig. 17). If not than adjustment is required,
change the bevel angle until the saw table (7) is at
a 90° angle to the blade and tighten the table
bevel lock knob (11).
Loosen the screw holding the scale pointer (Fig. 18),
move the pointer to the 0° position and tighten
the screw.
•
•
•
•
•
•
•
MAINTENANCE
Fig. 17
Fig. 18

16
Carbon brushes
Fig. 19
MAINTENANCE (cont.)
Oiling Arm Bearings
Lubricate the arm bearings (Fig. 19) every 50 hours
of use or whenever there is a squeak coming from
the bearings.
WARNING! Failure to unplug your variable speed scroll saw could result
in accidental starting causing possible serious personal injury.
Carefully place the saw on its side and remove the rubber caps from the upper
and lower arm of the saw.
Squirt a few drops of SAE 20 oil on the end of the shaft and bearings.
Leave the saw in this position overnight to allow the oil time to soak in.
Replace the rubber caps and repeat the above procedure on the opposite side
of the saw.
Carbon brushes
When the carbon brushes wear out the tool will spark
and/or stop. Discontinue use as soon as this happens.
They should be replaced prior to recommencing use of the
tool. Carbon brushes are a wearing component of the tool
therefore not covered under warranty. Continuing to use
the tool when carbon brushes need to be replaced may
cause permanent damage to the tool. Carbon brushes will
wear out after many uses but when the carbon brushes need
to be replaced take the tool to an electrician or a power tool repairer for a quick and
low cost replacement. Always replace both carbon brushes at the same time.
Inspecting or Replacing the Fuse
When required inspect or replace blown fuse.
Switch off and disconnect variable speed scroll saw from mains power supply.
Using a Phillips head screwdriver, remove the fuse holder (16) together with
the fuse.
Remove fuse from fuse holder (16), inspect and replace with new 3.15 amp fuse
if required. A blown fuse is when the filament (thin silver wire) is broken or out
of is place (not centred). Always replace a fuse with the same amperage rating
as the one that came out.
Refit fuse holder (16) together with fuse.
Note: Ozito Industries will not be responsible for any damage or injuries caused by
repair of the scroll saw by an unauthorised person or by mishandling.
•
•
•
•
•
•
•
•

17
WARNING! Failure to unplug your variable speed scroll saw could result
in accidental starting causing possible serious personal injury.
Problem Cause Remedy
Motor will not run Problem with On-Off
switch, power cord or
outlet.
Check plugged in and switched
On at mains power supply.
Check with another appliance to
ensure power is being supplied
to outlet. Have worn parts
replaced before using your saw
again. Have a proper outlet
installed by a qualified electrician
Motor defective Do not attempt any repair. Have
it repaired by a qualified service
technician.
Blown fuse Refer to fuse replacement page 16
Blades breaking Blade over tensioned Adjust tension, refer to adjusting
the tension page 12
Feeding too quickly Reduce feed rate
Incorrect blade Use narrow blades for cutting
thin wood or tight corners and
curves. Use wide blades for
thicker wood or wide curves,
refer to blade selection page 9.
Blade twisting in wood Reduce side pressure on blade,
check blade tension.
Vibration (there is
always a certain
amount of vibration
when saw is running.
Improper mounting
of saw
Check mounting
Improper bracing. Check saw mounting instructions
Loose table or table
resting against motor
Tighten table lock knob
Loose motor mounting Tighten motor mounting screws.
Work piece holder (14)
incorrectly positioned
Refer to adjusting the work piece
holder (14) pages 12 & 14
Blade runout (blade
not properly aligned
with arm motion
Blade holders out of
line
Realign blade holders and blade
TROUBLE SHOOTING

Limited spare parts are available subject to availability. Please contact your local
Bunnings Special Orders Desk to order the required spare parts.
Most common spare parts listed below
Spare Part Part No.
Carbon Brush (Pair) SPSSB405-83
Carbon Brush Cap (Pair) SPSSB405-84
Fuse (Pack of 4) SPSSB405-73
Table Insert (Pack of 4) SPSSB405-43
SPARE PARTS
V Volts
~ Altemating current
Hz Herts
W Watts
/min Revolutions or reciprocation per minute
Regulator compliance mark
Read instruction manual
Wear eye, breathing, ear protection
Warning
DESCRIPTION OF SYMBOLS
18

CARING FOR THE ENVIRONMENT
Petrol tools that are no longer usable should not be disposed
of with household waste but in an environmentally friendly way.
Please recycle where facilities exist. Check with your local council
authority for recycling advice.
Recycling packaging reduces the need for landfill and raw
materials. Reuse of recycled material decreases pollution in the
environment. Please recycle packaging where facilities exist.
Check with your local council authority for recycling advice.
1 x Variable Speed Scroll Saw
6 x Blades
1 x Hex Key
1 x Instruction manual
PACK CONTENTS
19
