Palram PROLEAFY Operating instructions

Rev A | Doc P/N: 460966-8080Copyright © 2021 Palram, all rights reserved.
INDOOR HYDROPONIC GROW CABINET
INSTALLATION AND OPERATION GUIDE
PROLEAFY

2. Indoor Hydroponic Grow Cabinet | Installation and Operation Guide Rev A | Doc P/N: 460966-8080
SAFETYHOME GETTING
STARTED
PLANTING AND
GROWING
TROUBLE-
SHOOTING
INTRODUCTION
WWW
TABLE OF CONTENTS
zSAFETY
Safety Overview
Cautions and Warnings
zINTRODUCTION
System Overview
Water Circulation System
Lighting System
Air Circulation System
Control Panel
zGETTING STARTED
Unpacking
Placing the Cabinet
Setting Up the Cabinet
Connecting with Mobile App
Preparing Nutrient Solution
Filling Reservoir with Nutrient Solution
zPLANTING AND GROWING
Planting
Germination
Maintaining Nutrient Solution Quality
Monitoring Growth
Harvesting
Emptying the Reservoir
zTROUBLESHOOTING
zSYSTEM SPECIFICATIONS
zWARRANTY
zCOPYRIGHT

3. Indoor Hydroponic Grow Cabinet | Installation and Operation Guide Rev A | Doc P/N: 460966-8080
SAFETYHOME GETTING
STARTED
PLANTING AND
GROWING
TROUBLE-
SHOOTING
INTRODUCTION
WWW
THIS CHAPTER REVIEWS GROW
CABINET SAFETY CONCERNS
AND INCLUDES:
Safety Overview
Cautions and Warnings

Safety Overview
4. Indoor Hydroponic Grow Cabinet | Installation and Operation Guide Rev A | Doc P/N: 460966-8080
SAFETYHOME GETTING
STARTED
PLANTING AND
GROWING
TROUBLE-
SHOOTING
INTRODUCTION
WWW
The Palram indoor hydroponic grow cabinet has been
designed to meet all known safety requirements.
During normal operation, the grow cabinet presents
no hazards to the operator. However, in certain circumstances,
the following potential hazards exist:
zElectrical shock (110/220 VAC)
zMechanical hazards (moving parts, pinch points, etc.)
zSlipping hazard
zHeavy object hazard
The information and instructions presented in this document are
intended to help the
operator work with the grow cabinet in a safe, effective, and
efficient manner.
1. SAFETY OVERVIEW
WARNING: The grower is responsible
for the safe and proper planting, growing, and
harvesting of the plants (see Cautions and
Warnings)
Safety conventions employed in this manual are as follows:
NOTE: Indicates additional information to
help the user obtain optimum performance.
Notes are not related to safety of equipment or
personnel
TIP: Indicates useful information to simplify
steps or procedures
CAUTION: Indicates that the equipment
or environment can be harmed, or data can be
corrupted
WARNING: Indicates a potentially
hazardous situation, which if not avoided could
result in injury or death

Cautions and Warnings
5. Indoor Hydroponic Grow Cabinet | Installation and Operation Guide Rev A | Doc P/N: 460966-8080
SAFETYHOME GETTING
STARTED
PLANTING AND
GROWING
TROUBLE-
SHOOTING
INTRODUCTION
WWW
GENERAL SAFETY CONCERNS
zThe grow cabinet is for home use only
zChildren under eight should not use the grow cabinet without adult
supervision
zThe grow cabinet is not a toy
zDo not operate the pump if cassettes are not in the cabinet
zDo not fill water in the reservoir above MAX. This ensures there is no
spill over when the pump stops operating
zDo not pour water into the cassettes. It should be poured directly into
the reservoir
HARVESTING AND EATING SAFETY CONCERNS
zWash what has been harvested prior to eating
zEat only what is fresh and looks healthy
zDo not eat anything that was in direct contact with the water,
especially the roots
zAdd water suitable for drinking only
zAfter water has been added to the reservoir it is no longer suitable for
drinking
zIf there's a bad odor, treat the problem immediately (see
Troubleshooting)
STORAGE SAFETY
zThroughly clean and dry the grow cabinet before placing it in storage
ELECTRICAL SAFETY CONCERNS
zDo not install electrical heating or cooling equipment inside
the grow cabinet
zDo not remove parts from the cabinet structure.
This may lead to injury or electrification
zIn case of spillage in and around the grow cabinet, immediately
unplug the cabinet and clean up the spill
PHYSICAL SAFETY CONCERNS
zDo not look directly at the lights
zAt least two people are required to assemble and move
the grow cabinet
zThe grow cabinet must be placed on a level, stable,
and sturdy surface
zSome of the grow cabinet parts may be sharp. Handle with care
zThere is a danger of slipping during cabinet maintenance,
as water may have spilled on the floor.
PROHIBITED USES
zDo not insert objects or equipment into the grow cabinet which have
not been expressly permitted for use by the manufacturer
zDo not install the grow cabinet outside or in a place that receives
direct sunlight.
2. CAUTIONS AND WARNINGS

Introduction
6. Indoor Hydroponic Grow Cabinet | Installation and Operation Guide Rev A | Doc P/N: 460966-8080
SAFETYHOME GETTING
STARTED
PLANTING AND
GROWING
TROUBLE-
SHOOTING
INTRODUCTION
WWW
3. INTRODUCTION
THIS CHAPTER REVIEWS THE GROW CABINET
AND INCLUDES:
zSystem Overview
zControl Panel
zWater Circulation System
zLighting System

System Overview
7. Indoor Hydroponic Grow Cabinet | Installation and Operation Guide Rev A | Doc P/N: 460966-8080
SAFETYHOME GETTING
STARTED
PLANTING AND
GROWING
TROUBLE-
SHOOTING
INTRODUCTION
WWW
4. SYSTEM OVERVIEW
Hit odipsum sequam raecto
con re vero dis et rest, sed
millupt aturio mintora
Water Circulation System
Water continually circulates
through the cabinet,
ensuring the plants receive
the water and nutrients they
need
Sturdy legs ensure the
cabinet remains stable and
level with the ground
A transparent door allows
for easy viewing of the
growing chamber
Lighting System
LED lights provide the
proper spectrum of light
required for healthy plant
growth.
Air Circulation System
Fans expel excess moisture
and heat from the unit, while
air screens keep the cabinet
free of insects
Control Panel
Switches turn on and off the
pump, fans, and lights
TIP: Growing mediums include perlite,
coir (coconut fiber), peat, and mineral
wool
Cassettes
Plants are placed directly into the cassette
holes, with the roots touching the water that
is continually flowing along the bottom of the
cassette. Cups and growing medium are optional

Control Panel
8. Indoor Hydroponic Grow Cabinet | Installation and Operation Guide Rev A | Doc P/N: 460966-8080
SAFETYHOME GETTING
STARTED
PLANTING AND
GROWING
TROUBLE-
SHOOTING
INTRODUCTION
WWW
THE CONTROL PANEL CONSISTS OF THE FOLLOWING SWITCHES:
5. CONTROL PANEL
LIGHTS
FANS
PUMP

Control Panel | Water Circulation System
9. Indoor Hydroponic Grow Cabinet | Installation and Operation Guide Rev A | Doc P/N: 460966-8080
SAFETYHOME GETTING
STARTED
PLANTING AND
GROWING
TROUBLE-
SHOOTING
INTRODUCTION
WWW
Palram's hydroponic grow cabinet employs the nutrient film technique (NFT), in
which roots are always in contact with water circulating through the cabinet. The
water contains all the nutrients the plants need to grow, while its continual
circulation oxygenates the water and prevents the roots from rotting.
5.1 WATER CIRCULATION SYSTEM
Water flows back
into the reservoir
6
Water is pumped out of the
reservoir to the top of the
grow cabinet
1
Water drips into the cassettes
2
Water flows to the front of
the cassettes, wetting the
plant roots along the way.
Proprietary filters ensure
water level is maintained in
each growing section
3
Water drops to a lower level
in the cassettes and flows to
the back of the cassettes and
into a funnel
4
Water flows through the
middle and lower cassettes
in the same manner
5
The water system can be
switched off manually
1
2
4
5
3

Control Panel | Lighting System
10. Indoor Hydroponic Grow Cabinet | Installation and Operation Guide Rev A | Doc P/N: 460966-8080
SAFETYHOME GETTING
STARTED
PLANTING AND
GROWING
TROUBLE-
SHOOTING
INTRODUCTION
WWW
5.2 LIGHTING SYSTEM
The grow cabinet is equipped with full-spectrum LED light strips which ensure plants receive
the exact wavelengths of light needed for optimum growth.
The lights can be switched
between off and timer mode
Each row of cassettes is lit
by two LED strips
In timer mode, lights are
programmed to turn on and
off automatically based on a
set schedule defined using
a mobile app
TIP: To provide the best growing environment,
program the lights to be on for 14 hours every day

Control Panel | Air Circulation System
11. Indoor Hydroponic Grow Cabinet | Installation and Operation Guide Rev A | Doc P/N: 460966-8080
SAFETYHOME GETTING
STARTED
PLANTING AND
GROWING
TROUBLE-
SHOOTING
INTRODUCTION
WWW
5.3 AIR CIRCULATION SYSTEM
Three fans blow heat
and moisture out of the
cabinet
Air screens ensure insects
cannot enter the cabinet
The fans can be switched
on and off manually
The grow cabinet's air circulation system
ensures the growing chamber is maintained
at the proper temperature and humidity
level, thus creating an ideal environment for
the plants to thrive.

Getting Started | Air Circulation System
12. Indoor Hydroponic Grow Cabinet | Installation and Operation Guide Rev A | Doc P/N: 460966-8080
SAFETYHOME GETTING
STARTED
PLANTING AND
GROWING
TROUBLE-
SHOOTING
INTRODUCTION
WWW
6. GETTING STARTED
This chapter reviews setting up the
hydroponic grow cabinet for use
and includes:
zUnpacking
zPlacing the Cabinet
zSetting Up the Cabinet

Getting Started | Unpacking
13. Indoor Hydroponic Grow Cabinet | Installation and Operation Guide Rev A | Doc P/N: 460966-8080
SAFETYHOME GETTING
STARTED
PLANTING AND
GROWING
TROUBLE-
SHOOTING
INTRODUCTION
WWW
Item Qty
Hydroponic grow cabinet 1
Adjustable legs 4
Gutters 10
Growing cassettes 14
Growing cassette with measuring slot 1
Planting cups 60
Water level meter 1
Manual pH meter 1
Manual EC meter 1
Gutters
Adjustable legs
Growing cassettes
Water level meter
6.1 UNPACKING
Planting cups
Manual pH meter
Manual EC meter
Growing cassette with measuring slot
Open the grow cabinet box and verify all parts listed below
are included.

Getting Started | Placing the Cabinet
14. Indoor Hydroponic Grow Cabinet | Installation and Operation Guide Rev A | Doc P/N: 460966-8080
SAFETYHOME GETTING
STARTED
PLANTING AND
GROWING
TROUBLE-
SHOOTING
INTRODUCTION
WWW
Follow these guidelines when placing the cabinet:
6.2 PLACING THE CABINET
CAUTION: Do not place the cabinet near a
heat source (e.g., ovens, heaters, etc.)
CAUTION: Do not place the cabinet on a
surface which can be damaged by water
Verify that the sides of
the cabinet are at least 10
cm from the wall and that
there is enough space to
fully open the door
Place the cabinet in an
area with Wi-Fi signal
Place the cabinet within
reach of a wall outlet
Keep the room
temperature between
16°C and 30°C
Do not place the
cabinet in an area
which receives direct
Place the cabinet on
a sturdy and level
surface
10 cm
cabinet

Getting Started | Setting Up the Cabinet
15. Indoor Hydroponic Grow Cabinet | Installation and Operation Guide Rev A | Doc P/N: 460966-8080
SAFETYHOME GETTING
STARTED
PLANTING AND
GROWING
TROUBLE-
SHOOTING
INTRODUCTION
WWW
6.3 SETTING UP THE CABINET
Verify the pump
switch is in the off
position
If the legs are not
attached, place the
cabinet on its side
and connect the legs
to the bottom of the
cabinet
Place the cabinet
upright and twist the
legs until it is level
with the ground
Verify the gutters are
attached to the back
wall of the cabinet
Verify the cassettes
are properly placed
inside the cabinet
Connect the power
cord to an AC outlet
CAUTION: At least two people are required
to move the grow cabinet
1
2
3
4
5
6

Getting Started | Connecting with Mobile App
16. Indoor Hydroponic Grow Cabinet | Installation and Operation Guide Rev A | Doc P/N: 460966-8080
SAFETYHOME GETTING
STARTED
PLANTING AND
GROWING
TROUBLE-
SHOOTING
INTRODUCTION
WWW
A mobile application is used to program the on/off cycle of the cabinet lights. Perform the following steps to set up the application on a mobile device:
6.4 CONNECTING WITH MOBILE APP
Tap the +button to
add the cabinet to
the app
Tap Compatible
mode
Tap Next when
the green indicator
light starts blinking
repeatedly
Follow the instructions
on the screen to begin
the pairing process
eWeLink app
2
3
4
5
Install and open the
eWeLink app:
(tap to open)
1

Getting Started | Connecting with Mobile App
17. Indoor Hydroponic Grow Cabinet | Installation and Operation Guide Rev A | Doc P/N: 460966-8080
SAFETYHOME GETTING
STARTED
PLANTING AND
GROWING
TROUBLE-
SHOOTING
INTRODUCTION
WWW
Navigate to the
mobile device's Wi-Fi
settings and connect
to ITEAD-XXX. If
requested, enter
"12345678" as the
password
Wait for the cabinet
to connect to the
home Wi-Fi network
Rename the device
and add to a room
(optional)
Tap Done. The app
can now be use to
set up the lighting
schedule
On the next screen
type in the home
wireless network
name and password
and click Next
6
7
8
9
10

Getting Started | Filling Reservoir With Water
18. Indoor Hydroponic Grow Cabinet | Installation and Operation Guide Rev A | Doc P/N: 460966-8080
SAFETYHOME GETTING
STARTED
PLANTING AND
GROWING
TROUBLE-
SHOOTING
INTRODUCTION
WWW
Perform the following steps to
treat the water and fill the reservoir:
6.5 FILLING RESERVOIR WITH WATER
Fill a bucket with
water treated by
reverse osmosis
CAUTION: Follow manufacturers'
instructions prior to using pHDown,fertilizer,
and the pH and EC meters
TIP: Water treated by reverse osmosis
removes many of the minerals that impair
plant growth. Using untreated water may
require additional analysis to achieve the ideal
growing conditions, depending on water source
NOTE: The water reservoir can hold
20 liters of water
Add pHDown
and stir until
the pH meter
displays 6.5-7
Verify the pump
is switched off
CAUTION: Exceeding MAX on the water
gauge will cause the water to overflow and spill
onto the floor
Pour the water
into the reservoir,
repeating steps 2
and 3 until MAX
level is reached
1
2
3
4

Getting Started | Filling Reservoir With Water
19. Indoor Hydroponic Grow Cabinet | Installation and Operation Guide Rev A | Doc P/N: 460966-8080
SAFETYHOME GETTING
STARTED
PLANTING AND
GROWING
TROUBLE-
SHOOTING
INTRODUCTION
WWW
Turn on the pump and
wait for the water to
circulate in the cabinet
Measure the EC level
and note the value.
This is the baseline
Add fertilizer until the
EC level reaches 1.5
above the baseline
value
NOTE: It takes about ten minutes for the EC
level to stabilize after adding fertilizer
TIP: Keep the pH and EC meter tips in a cup
of fresh water between uses, or wash well after
every use
5
6
7

Planting and Growing | Filling Reservoir With Water
20. Indoor Hydroponic Grow Cabinet | Installation and Operation Guide Rev A | Doc P/N: 460966-8080
SAFETYHOME GETTING
STARTED
PLANTING AND
GROWING
TROUBLE-
SHOOTING
INTRODUCTION
WWW
7. PLANTING AND GROWING
This chapter reviews the steps involved
in planting, growing, and harvesting
vegetables and includes:
zPlanting
zGermination
zMaintaining Water Quality
zMonitoring Growth
zHarvesting
zEmptying the Reservoir
