Zener Diodes
Publication date: October 2008 SKE00047AED 1
This product complies with RoHS Directive (EU 2002/95/EC).
MALHxxxYG Series
Silicon planar type
For constant voltage, constant current, waveform clipper and surge absorption circuit
Features
Extremely low noise voltage caused from the diode
Extremely good rising performance (in the low-current range)
Independent wiring of two element
Absolute Maximum Ratings Ta= 25°C
Parameter Symbol Rating Unit
Repetitive peak forward current IFRM 200 mA
Total power dissipation *PT150 mW
Junction temperature Tj150 °C
Storage temperature Tstg –55 to +150 °C
Note) *: PT= 150 mW achieved with a printed circuit board.
Common Electrical Characteristics Ta= 25°C±3°C
Parameter Symbol Conditions Min Typ Max Unit
Forward voltage VFIF= 10 mA 0.9 1.0 V
Zener voltage *1VZIZSpecified value V
Zener rise operating resistance RZK IZSpecified value Refer to the list of the
electrical characteristics
within part numbers
W
Zener operating resistance RZIZSpecified value W
Reverse current IRVRSpecified value mA
Temperature coefficient of zener voltage *2SZIZSpecified value mV/°C
Note) 1. Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7031 measuring methods for diodes.
2. Absolute frequency of input and output is 5 MHz.
3. The temperature must be controlled 25°C for VZmesurement.
VZvalue measured at other temperature must be adjusted to VZ(25°C)
4. *1 : VZguaranted 20 ms after current flow.
*2: Tj= 25°C to 150°C
Package
Code
SMini4-F2
Pin Name
1: Anode 1 3: Cathode 2
2: Anode 2 4: Cathode 1
Marking symbol
Refer to the list of the electrical
characteristics within part numbers

MALHxxxYG Series
2SKE00047AED
This product complies with RoHS Directive (EU 2002/95/EC).
Electrical Characteristics within Part Numbers Ta= 25°C±3°C
Part number
Zener voltage
VZ(V)
Reverse
current
IR( mA)
Zener
operating
resistance
RZ(W)
Zener rise
operating
resistance
RZK (W)
Temperature
coefficient of
zener voltage
SZ(mV/°C)Marking symbol
IZ
(mA)
VR
(V)
IZ
(mA)
IZ
(mA)
IZ
(mA)
Min Typ Max Max Max Max Typ
MALH024YGL 2.28 2.40 2.60 5 120 1.0 100 5 –1.6 5 2.4
MALH027YGL 2.50 2.70 2.90 5 120 1.0 110 5 –2.0 5 2.7
MALH030YGL 2.80 3.00 3.20 5 50 1.0 120 5 –2.1 5 3.0
MALH033YGL 3.10 3.30 3.50 5 20 1.0 130 5 –2.4 5 3.3
MALH036YGL 3.40 3.60 3.80 5 10 1.0 130 5 –2.4 5 3.6
MALH039YGL 3.70 3.90 4.10 5 10 1.0 130 5 –2.5 5 3.9
MALH043YGL 4.00 4.30 4.60 5 10 1.0 130 5 –2.5 5 4.3
MALH047YGL 4.40 4.70 5.00 5 2 1.0 80 5 800 1 –1.4 5 4.7
MALH051YGL 4.80 5.10 5.40 5 1 2.0 60 5 500 1 – 0.8 5 5.1
MALH056YGL 5.30 5.60 6.00 5 0.5 2.5 40 5 200 0.5 1.2 5 5.6
MALH062YGL 5.80 6.20 6.60 5 0.2 4.0 30 5 100 0.5 2.3 5 6.2
MALH068YGL 6.40 6.80 7.20 5 0.1 4.0 20 5 60 0.5 3 5 6.8
MALH075YGL 7.00 7.50 7.90 5 0.1 5.0 20 5 60 0.5 4 5 7.5
MALH082YGL 7.70 8.20 8.70 5 0.1 5.0 20 5 60 0.5 4.6 5 8.2
MALH091YGL 8.50 9.10 9.60 5 0.1 6.0 20 5 60 0.5 5.5 5 9.1
MALH100YGL 9.40 10.00 10.60 5 0.05 7.0 30 5 60 0.5 6.4 5 10
MALH110YGL 10.40 11.00 11.60 5 0.05 8.0 30 5 60 0.5 7.4 5 11
MALH120YGL 11.40 12.00 12.70 5 0.05 9.0 30 5 80 0.5 8.4 5 12
MALH130YGL 12.40 13.00 14.10 5 0.05 10.0 35 5 80 0.5 9.4 5 13
MALH150YGL 13.90 15.00 15.60 5 0.05 11.0 40 5 80 0.5 11.4 5 15
MALH160YGL 15.30 16.00 17.10 5 0.05 12.0 50 5 80 0.5 12.4 5 16
MALH180YGL 16.90 18.00 19.10 5 0.05 13.0 60 5 80 0.5 14.4 5 18
MALH200YGL 18.80 20.00 21.20 5 0.05 15.0 80 5 100 0.5 16.4 5 20
MALH220YGL 20.80 22.00 23.30 5 0.05 17.0 80 5 100 0.5 18.4 5 22
MALH240YGL 22.80 24.00 25.60 5 0.05 19.0 100 5 120 0.5 20.4 5 24
MALH270YGL 25.10 27.00 28.90 2 0.05 21.0 120 2 120 0.5 23.4 2 27
MALH300YGL 28.00 30.00 32.00 2 0.05 23.0 160 2 160 0.5 26.6 2 30
MALH330YGL 31.00 33.00 35.00 2 0.05 25.0 200 2 200 0.5 29.7 2 33
MALH360YGL 34.00 36.00 38.00 2 0.05 27.0 250 2 250 0.5 33 2 36
MALH390YGL 37.00 39.00 41.00 2 0.05 30.0 300 2 300 0.5 35.6 2 39

MALHxxxYG Series
SKE00047AED 3
This product complies with RoHS Directive (EU 2002/95/EC).
SMini4-F2 Unit: mm
43
12
+0.05
0.02
0.30
+0.05
0.02
0.13
2.00 0.10
1.30 0.10
2.10 0.100.70 0.10
0 to 0.10
(0.15)
1.25 0.10
(0.425)
(5)
(5)
