簡易指南/QUICK GUIDE
遙控器的準備 • Remote Control Preparation
21
3
1拉出後蓋 • Pull out
2裝入AAA或R03電池（可使用大約一年時間） •
InsertAAA or R03 batteries (can be used ~ 1 year)
3
關上後蓋 • Close the cover
MODE
AUTO HEAT
DRY COOL
Selectthe desired mode.
1
OFF/ON
Start/stopthe operation.
2
TEMP
Selectthe desired temperature.
3
AUTO
HEAT
COOL
DRY
FAN
SPEED
AIR
SWING
3
2
1
.
ENGLISH
Before operating the unit, read these operating
instructions thoroughly and keep them for future
reference.
F568013_cover.indd 1 2011-3-24 18:52:01
2
TABLE OF CONTENTS
SAFETY PRECAUTIONS ........................................................................................................... 16~17
REMOTE CONTROL .................................................................................................................. 18~19
INDOOR UNIT.................................................................................................................................... 20
TROUBLESHOOTING....................................................................................................................... 21
INFORMATION ........................................................................................................................... 22~23
PRODUCT SPECIFICATION ............................................................................................................. 24
QUICK GUIDE...............................................................................................................BACK COVER
ENGLISH Thank you for purchasing Panasonic Air Conditioner
NOTE: The illustrations in this manual are for explanation purposes only and may differ from the actual unit. It is
subjected to change without notice for future improvement.
..............................................................................................................
........................................................................................................................
..............................................................................................................................................
...............................................................................................................................................
...........................................................................................................................................
..................................................................................................................................
................................................................................................................
. :
.
~...........................................................................................................................
~..................................................................................................................................
............................................................................................................................................
.............................................................................................................................
~ ...........................................................................................................................................
.........................................................................................................................................
....................................................................................................................................
:
F568013_EN.indd 2 2011-3-24 19:16:46
3
* DBT: Dry bulb temperature
* WBT: Wet bulb temperature
OPERATION CONDITION
Use this air conditioner under the following temperature range
Temperature (°C) Indoor Outdoor
*DBT *WBT *DBT *WBT
COOLING Max. 32 23 43 26
Min. 16 11 16 11
HEATING Max. 30 - 24 18
Min. 16 - -5 -6
*WBT *DBT *WBT *DBT
26 43 23 32
11 16 11 16
18 24 - 30
-6 -5 - 16
:DBT *
:WBT *
*WBT *DBT *WBT *DBT
-
-- -
:DBT *
:WBT *
F568013_EN.indd 3 2011-3-24 19:16:47
.
) (
.
.
.
.
.
.
.
.
.
.
.
:
. •
. •
. •
•
.
F568013_AR_CS5.indd 4 2011-3-24 19:23:10
.
.
. ...
.
. ...
.
.
.
.
.
.
.
. .
/
.
.
.
.)Ni-Cd(
.
:
•
.
•
.
.
.
)RCD( )ELCB(
.
:
. •
•
.
.
) (
. •
. •
. •
. •
. •
. •
. •
. •
.
.
:
)IEC
.
.
:
. -
. -
. -
F568013_AR_CS5.indd 5 2011-3-24 19:23:11
AUTO
HEAT
COOL
DRY
FAN
SPEED
AIR
SWING
)
)
OFF
. ~ : •
. •
•
.
•
.
) -(
) +(
POWER
FAN SPEED
AUTO •
.
AIR SWING
AUTOCOOL
AUTOHEAT
AUTO
HEAT
COOL
DRY
FAN
SPEED
AIR
SWING
F568013_AR_CS5.indd 6 2011-3-24 19:23:11
12
. •
. •
. •
•
.
•
.
. •
.
F568013_AR_CS5.indd 7 2011-3-24 19:23:12
. •
. •
ON/OFF
•
AUTO OFF/ ON / •
.
:OFF/ON /
”AUTO OFF/ON“ » /«
.
OFF/ON /
.
:OFF/ON /
”AUTO OFF/ON“ » «
.
.
pH7
F568013_AR_CS5.indd 8 2011-3-24 19:23:13
◄
◄
◄
◄
◄
◄
◄
.
◄
◄
◄
◄
◄
◄
◄
◄
pH7
F568013_AR_CS5.indd 9 2011-3-24 19:23:13
10
11
) (
.
.
.
.
.
.
.
.
.
.
.
.
:
•
.
. •
. •
•
.
.
:
:
F568013_PER_CS5.indd 10 2011-3-24 19:23:36
10
11
.
.
.
.
.
.
.
.
.
.
.
.
.
/
.
.
.
.
.
.
:
•
.
•
.
.
.
)ELCB(
)RCD(
.
:
. •
•
.
.
) (
:
•
. )ELCB(
. •
. •
. •
•
.
. •
•
.
•
.
.
.
:
)IECv
.
.
:
. -
. -
. -
F568013_PER_CS5.indd 11 2011-3-24 19:23:38
12
13
) 3(
•
.
) 5(
. •
Auto / •
.
•
.
)OFF( •
.
. : •
•
.
. 28 26 :
. 24 20 :
. 2 1 :
-
•
.
•
.
•
.
2-(
)
2+(
)
23 27 25 23
20 24 22 23
19 23 21 20
-
. •
.
-
•
.
-
•
.
:
AUTO
HEAT
COOL
DRY
FAN
SPEED
AIR
SWING
)(
)(
AUTO
HEAT
COOL
DRY
FAN
SPEED
AIR
SWING
3
4
5
F568013_PER_CS5.indd 12 2011-3-24 19:23:39
12
13
•
. 5
.
.
.
•
.
.
.
.
.
•
.
•
.
•
.
•
.
•
.
. •
.
F568013_PER_CS5.indd 13 2011-3-24 19:23:40
14
15
•
. •
. •
. •
. •
•
.
•
.
. •
•
.
.
.
. AUTO OFF/ ON •
:
10 »AUTO OFF/ ON« 1
.
60 2
.
:
15 »AUTO OFF/ ON« 1
.
60 2
.
. •
•
.
. •
. •
5
6
7
4
3
. •
) ( •
.
. •
•
.
.
•
.
F568013_PER_CS5.indd 14 2011-3-24 19:23:42
14
15
. • ◄.
. • ◄.
•
. ◄.
. • ◄
.
. • ◄.
. • ◄. /
. • ◄.
. •
.
. 14 •
◄
.
•
.
.
. •◄.
. •
. •
. •
. •
◄. /
. •
. • ◄.
. •
. • ◄.
) (
. •
. • ◄.
. •
•
. .
◄.
. •
) ( •
.
. •
•
.
.
•
.
F568013_PER_CS5.indd 15 2011-3-24 19:23:42
16
SAFETY PRECAUTIONS
To prevent personal injury, injury to others, or property
damage, please comply the following.
Incorrect operation due to failure to follow instructions below
may cause harm or damage, the seriousness of which is
classied as below:
WARNING
This sign warns of death or serious injury.
CAUTION
This sign warns of injury or damage to property.
The instructions to be followed are classied by the following
symbols:
This symbol denotes an action that is
PROHIBITED
These symbols denote an action that is
COMPULSORY.
WARNING
INDOOR UNIT AND OUTDOOR UNIT
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety. Children should be supervised to
ensure that they do not play with the appliance.
Please consult authorized dealer or specialist to
clean the internal parts, repair, install, remove
and reinstall the unit. Improper installation and
handling will cause leakage, electric shock or
re.
Do not install the unit in a potentially explosive
or ammable atmosphere. Failure to do so could
result in re.
Do not insert your ngers or other
objects into the air conditioner indoor
or outdoor unit, rotating parts may
cause injury.
Do not touch the outdoor unit during lightning, it
may cause electric shock.
Do not expose yourself directly to cold air for a
long period to avoid excess cooling.
Do not sit or step on the unit, you
may fall down accidentally.
REMOTE CONTROL
Do not allow infants and small children to play
with the remote control to prevent them from
accidentally swallowing the batteries.
POWER SUPPLY
Do not use modied cord,
joint cord, extension cord or
unspecied cord to prevent
overheat and re.
To prevent overheating, re or electric shock:
• Do not share the same power outlet with other
equipment.
• Do not operate with wet hands.
• Do not over bend the power supply cord.
•Do not operate or stop the unit by inserting or
pulling out the power plug.
Air Inlet
Air Outlet
Air Outlet
Air Inlet
Remote
Control
Power
Supply
Indoor
Unit
Outdoor
Unit
F568013_EN.indd 16 2011-3-24 19:16:47
ENGLISH
17
CAUTION
INDOOR UNIT AND OUTDOOR UNIT
Do not wash the indoor unit with water,
benzene, thinner or scouring powder to avoid
damage or corrosion at the unit.
Do not use for preservation of precise equipment,
food, animals, plants, artwork or other objects.
This may cause quality deterioration, etc.
Do not use any combustible equipment in front
of the airow outlet to avoid re propagate.
Do not expose plants or pet directly to airow to
avoid injury, etc.
Do not touch the sharp aluminium n,
sharp parts may cause injury.
Do not switch ON the indoor unit when waxing
the oor. After waxing, aerate the room properly
before operating the unit.
Do not install the unit in oily and smoky areas to
prevent damage to the unit.
Do not dismantle the unit for cleaning purpose
to avoid injury.
Do not step onto unstable bench when cleaning
the unit to avoid injury.
Do not place vase or water container on the
unit. Water may enter the unit and degrade the
insulation. This may cause an electric shock.
Do not left the window open during Cool/Dry
mode operation to prevent water leakage.
Ensure drainage pipe is connected properly and
keep drainage outlet clear of gutters, containers
or does not immersed in water to prevent water
leakage.
After long period of use or use with any
combustible equipment, aerate the room
regularly.
After long period of use, make sure the
installation rack is not deteriorate to prevent the
unit from falling down.
REMOTE CONTROL
Do not use rechargeable (Ni-Cd) batteries.
It may damage the remote control.
To prevent malfunction or damage of the remote
control:
• Remove the batteries if the unit is not going to
be used for a long period of time.
• New batteries of the same type must be
inserted following the polarity stated.
POWER SUPPLY
Do not pull the cord to disconnect the plug to
prevent electric shock.
WARNING
POWER SUPPLY
If the supply cord is damage, it must be
replaced by the manufacturer, its service agent
or similarly qualied persons in order to avoid
a hazard.
It is strongly recommended to be installed
with Earth Leakage Circuit Breaker (ELCB)
or Residual Current Device (RCD) to prevent
electric shock or re.
To prevent overheating, re or electric shock:
• Insert the power plug properly.
• Dust on the power plug should be periodically
wiped with a dry cloth.
Stop using the product when any abnormality/
failure occurs and disconnect the power plug or
turn off the power switch and breaker.
(Risk of smoke/re/electric shock)
Examples of abnormality/failure
• The ELCB trips frequently.
• Burning smell is observed.
• Abnormal noise or vibration of the unit is
observed.
• Water leaks from the indoor unit.
• Power cord or plug becomes abnormally hot.
• Fan speed cannot be controlled.
• The unit stops running immediately even if it is
switched on for operation.
• The fan does not stop even if the operation is
stopped.
Contact immediately your local dealer for
maintenance/repair.
Replacement or installation of power plugs shall
be performed by authorized/qualied personnel
only. The wires in this mains lead are coloured
in accordance with the following code:
Wiring colour may vary depending on a country
wiring code’s standard.
This equipment must be earthed to prevent
electric shock or re.
Prevent electric shock by switching off the
power supply and unplug when:
- Before cleaning or servicing.
- Extended non-use.
- Abnormally strong lightning activity.
F568013_EN.indd 17 2011-3-24 19:16:47
18
REMOTE CONTROL
Press the remote control’s button
1TO TURN ON OR OFF THE UNIT
• Please be aware of the OFF indication on the remote
control display to prevent the unit from starting/stopping
improperly.
2TO SET TEMPERATURE
• Selection range: 16˚C~30˚C.
• Operating the unit within the recommended temperature
could induce energy saving.
COOL mode : 26˚C ~ 28˚C.
HEAT mode: 20˚C ~ 24˚C.
DRY mode : 1˚C ~ 2˚C lower than room temperature.
3TO SELECT OPERATION MODE
AUTO mode - For your convenience
• Unit selects the operation mode according to the room
temperature.
• Once auto mode is selected, the unit will operate at the
standard setting temperature.
• To change the standard setting temperature, press for
“ ” or for “ ”.
Room
temperature
Operation
mode
Standard setting
temperature
(+2°C)
(–2°C)
23°C & above Cool 25°C 27°C 23°C
Below 23°C Dry 22°C 24°C 20°C
Below 20°C Heat 21°C 23°C 19°C
HEAT mode - To enjoy warm air
• In heat mode, it may take a while for the unit to warm up.
The POWER indicator blinks during preheating.
COOL mode - To enjoy cool air
• Use curtains to screen off sunlight and outdoor heat to
reduce power consumption during cool mode.
DRY mode - To dehumidify the environment
• Unit operates at low fan speed to give a gentle cooling
operation.
4TO SELECT FAN SPEED (3 OPTIONS)
FAN SPEED
• For AUTO, the indoor fan speed is automatically adjusted
according to the operation mode.
5TO ADJUST VERTICAL AIRFLOW DIRECTION
(5 OPTIONS)
AIR SWING
• Keeps the room ventilated.
• In COOL mode, if AUTO is set, the louver swing up/down
automatically.
• In HEAT mode, if AUTO is set, the horizontal louver x at
predetermined position.
Maximum distances: 8m
AUTO
HEAT
COOL
DRY
FAN
SPEED
AIR
SWING
3
4
5
2
Remote Control display
AUTO
HEAT
COOL
DRY
FAN
SPEED
AIR
SWING
1
INDICATOR
(Green)
(Orange)
F568013_EN.indd 18 2011-3-24 19:16:48
ENGLISH
19
TO SET THE TIMER
( 12-HOUR TIMER SETTING)
• To turn ON or OFF the unit at a preset time.
DELAY OFF-TIMER
For example, to stop the air conditioner 5 hours later.
1 To select the Delay OFF-TIMER, press the
button once.
2 Press the button to select the delay hour.
3 Press the button to conrm the timer setting.
•The OFF-TIMER can only be set while the
air-conditioner is in operation.
DELAY ON-TIMER
For example, to start the air conditioner 2 hours later.
1 To select the Delay ON-TIMER, press the
button once.
2 Press the button to select the delay hour.
3 Press the button to conrm the timer setting.
•The ON-TIMER can only be set while the
air-conditioner is not in operation.
•To cancel ON or OFF timer, press .
•The timer indicator of the indoor unit will light up
during the timer operation.
•When ON Timer is set, the unit may start earlier
before the actual set time in order to achieve the
desired temperature on time.
•If you press operation button during
the timer setting operation, timer setting will be
cancelled.
•When a power failure occurs, the timer setting will
be cancelled. Once power is resumed, reset the
timer repeat above step.
F568013_EN.indd 19 2011-3-24 19:16:48
20
CAUTION
•Switch off the power supply before cleaning.
•Do not touch the aluminium n, sharp parts may cause injury.
1INDOOR UNIT
• Wipe the unit gently with a soft, dry cloth.
2FRONT PANEL
Remove Front Panel
• Raise and pull to remove the front panel.
• Wash gently and dry.
Close Front Panel
• Press down both ends of the front panel to close it securely.
3RECEIVER
4ALUMINIUM FIN
5HORIZONTAL AIRFLOW DIRECTION LOUVER
• Manually adjustable.
WARNING
Be carefull not to insert your ngers into
the unit to avoid injuring by cross-ow fan.
6VERTICAL AIRFLOW DIRECTION LOUVER
• Do not adjust by hand.
7AUTO OFF/ON BUTTON
• Use when remote control is misplaced or malfunction.
Action Mode
Press once. Auto
Press and hold until 1 beep is heard, then release. Cooling
Press and hold until you hear double
beep sound, then release. Heating
• To turn off, press the AUTO OFF/ ON button again.
Procedure of switching OFF/ON signal receiving sound:
1. Press and hold “AUTO OFF/ON” button for
approximately 10 seconds until you hear double beep
sound.
2. Repeat above step within 60 seconds , and then signal
receiving sound will be switched OFF/ON.
Procedure of switching OFF/ON auto restart control:
1. Press and hold “AUTO OFF/ON” button for
approximately 15 seconds until you hear triple beep
sound.
2. Repeat above step within 60 seconds , and then auto
restart control will be switched.
8AIR FILTERS
• Clean the lters regularly.
• Wash/rinse the lters gently with water to avoid damage
to the lter surface.
• Dry the lters thoroughly under the shade, away from
re or direct sunlight.
• Replace any damage lter.
2
5
6
7
1
4
3
8
INDOOR UNIT
WASHING INSTRUCTIONS HINT
• Do not use benzene, thinner or scouring powder.
• Use only soap ( pH7) or neutral household detergent.
• Do not use water hotter than 40°C.
• To ensure optimal performance of the unit, cleaning
maintenance have to be carried out at regular intervals.
Please consult authorized dealer.
NOTE
• If chemical cloth is used to wipe the unit, instruction for
the cloth should be followed.
F568013_EN.indd 20 2011-3-24 19:16:49
This manual suits for next models
15
Table of contents
Languages:
Other Panasonic Air Conditioner manuals
Panasonic
Panasonic CS-XV9UKD-3 User manual
Panasonic
Panasonic CS-PW18GKE User manual
Panasonic
Panasonic CS-TZ25ZKEW User manual
Panasonic
Panasonic CS-C9DKZW User manual
Panasonic
Panasonic CS-C9PKV User manual
Panasonic
Panasonic CS-MKE9NB4U Installation and user guide
Panasonic
Panasonic CS-A182KR User manual
Panasonic
Panasonic U-71PZH2E5 User manual
Panasonic
Panasonic CS-E12DKRW User manual
Panasonic
Panasonic CS-RE9HKE User manual
Panasonic
Panasonic CS-TE15HKE User manual
Panasonic
Panasonic CS-Z25YKEA User manual
Panasonic
Panasonic CS-E7GKEW User manual
Panasonic
Panasonic CS-WPU9XKH-8 User manual
Panasonic
Panasonic CSC28CKU - SPLIT A/C INDOOR User manual
Panasonic
Panasonic S-3650PF3E User manual
Panasonic
Panasonic CS-C9PKV User manual
Panasonic
Panasonic HQ-2051RH User manual
Panasonic
Panasonic CW-C50RU User manual
Panasonic
Panasonic CS-E12RB4UW User manual
Popular Air Conditioner manuals by other brands
Frigidaire
Frigidaire FAC064K7A2 Factory parts catalog
Soleus Air
Soleus Air GB-PAC-08E4 operating instructions
Sears
Sears Kenmore P/N93SR-D02 owner's manual
Friedrich
Friedrich WallMaster WS10 Installation and operation manual
Mitsubishi Electric
Mitsubishi Electric PUZ-ZM200YKA2-ET Service manual
Hitachi
Hitachi RAS-E10HB instruction manual
Hitachi
Hitachi RAM-55QH4 Service manual
Mitsubishi Electric
Mitsubishi Electric PLA-SP BA Series Operation manual
Crosley
Crosley 2020213A Use & care manual
Mitsubishi Electric
Mitsubishi Electric NTXFKs15a112a Series manual
Toshiba
Toshiba RAS-M10SMUV-E installation manual
Fujitsu
Fujitsu ART45L operating manual
EIC Solutions
EIC Solutions AAC-145A-4XT Series Installation and operation manual
Arcoaire
Arcoaire R4A3 installation instructions
ALPATEC
ALPATEC AC 12 FIT user manual
Convair
Convair ClimateMaster CM12RW instruction manual
EINHELL
EINHELL Split 3500 EQ C+H operating instructions
LG
LG PM12SP NSJ owner's manual
