Panasonic WV-QCA500A User manual

Operating Instructions
Included Installation Instructions
RJ45 Ethernet Cable For professional use only.
Model No. WV-QCA500A (1 pc.)
WV-QCA500APK (10 pcs.)
󱾀Before attempting to connect or install this product,
please read these instructions carefully
and save this manual for future use.
󱾀The external appearance and other parts shown in this manual may differ from the actual
product within the scope that will not interfere with normal use due to improvement of the
product.
󱾀Also read the Operating Instructions for the camera you are using.
Panasonic i-PRO Sensing Solutions Co., Ltd. assumes no responsibility for injuries or
property damage resulting from failures arising out of improper installation or
operation inconsistent with this documentation.
© Panasonic i-PRO Sensing Solutions Co., Ltd. 2021
Fs0421-0
Printed in China
For U.S. and Canada:
Panasonic i-PRO Sensing Solutions
Corporation of America
8550 Fallbrook Drive, Suite 200 Houston, Texas 77064
https://i-pro.com/
Panasonic Canada Inc.
5770 Ambler Drive, Mississauga, Ontario, L4W 2T3 Canada
1-877-495-0580
https://www.panasonic.com/ca/
For Europe and other countries:
Panasonic Corporation
http://www.panasonic.com
Panasonic i-PRO Sensing Solutions Co., Ltd.
Fukuoka, Japan
Authorised Representative in EU:
Panasonic Testing Centre
Panasonic Marketing Europe GmbH
Winsbergring 15, 22525 Hamburg, Germany
Preface
This product is an Ethernet extension cable with a waterproofing grommet. By using an RJ45
waterproof jack to convert the RJ45 network connector on an outdoor camera, it is possible to
easily replace a past model that uses a waterproof connector.
For the latest information about the supported cameras, refer to our support website
(https://security.panasonic.com/training_support/support/info/<Control No.:C0501>).
Specifications
Power source*1: PoE (IEEE802.3af compliant)
Ambient operating temperature: –40 °C to +60 °C {–40 °F to +140 °F}
Ambient operating humidity: 10 % to 100 % (no condensation)
Storage temperature: –30 °C to +60 °C {–22 °F to +140 °F}
Storage humidity: 10 % to 95 % (no condensation)
Network*1: 10BASE-T / 100BASE-TX / RJ45 connector
Mass: Approx. 35 g{0.08 lbs}
*1 The specifications of the network camera body apply.
Precaution
Do not attempt to disassemble or modify this product.
Failure to observe this may cause fire or electric shock. Consult the dealer for the repair or
inspections.
Refer installation work to the dealer.
Installation work requires technique and experience. Failure to observe this may cause fire,
electric shock, injury, or damage to the product. Be sure to consult the dealer.
Turn the power off when do wiring of this product.
Failure to observe this may cause electric shock. In addition, short circuit or wrong wiring may
cause fire.
Correctly perform all wiring.
Short circuits in the wiring or incorrect wiring may cause fire or electrical shock.
WV-QCA500A_PGQX2459ZAC1_英.indd 1 2021/04/23 10:04:59

Caution:
󱾀This product is a professional equipment.
󱾀Before attempting to connect or operate this product, please read these instructions
carefully.
Standard accessories
Operating Instructions (this document) 1 pc. RJ45 waterproof connector cover 1 pc.
RJ45 waterproof connector cap 1 pc.
Precautions for installation
Make sure to remove this product if it will no longer be used.
Installation
This product is used when attaching outdoor type network cameras using waterproof
connectors. The outdoor dome type camera is used as an example when describing
attachment procedures in these instructions.
Step 1
Step 2 If the waterproof connector part of an existing camera is
broken, rework the network cable and attach the included
waterproof connector.
(Refer to the Installation Guide for the existing camera.)
WV-QCA500A
(RJ45 Ethernet cable)
2
1
WV-QCA500
Jack portion
RJ45
Waterproof jack
RJ45
plug
Waterproof connector part
of the existing camera
RJ45 waterproof
connector cover
RJ45 waterproof
connector cap
Tighten until no gap is present
Align “ ” with “ ” and then
rotate until “ ” aligns with “ ”
View from inside the camera
Inside
Outside
