Panasonic AFP0HC32ET User manual

SAFETY PRECAUTIONS
To prevent accidents or personal injuries, please be sure to comply with the following items.
Prior to installation, operation, maintenance and check, please read this manual carefully for proper use.
Before using, please fully understand the knowledge related to the equipment, safety precautions and all
other precautions.
Safety precautions are divided into two levels in this manual: Warning and Caution.
WARNING
Incorrect operation may lead to death or serious injury.
● Take appropriate safety measures to the external circuit of the product to ensure the security of
the whole system in case of abnormalities caused by product failure or external.
● Do not use this product in areas with inflammable gases.
Otherwise it may lead to an explosion.
● Do not put this product into a fire.
Otherwise it could cause damage to the battery or other electronic parts.
● Do not impact, charge or heat the lithium battery, and do not put it into a fire.
Otherwise it may lead to fire or damage.
CAUTION
Incorrect operation may lead to injury or material loss.
● To prevent the excessive exothermic heat or smoke generation of the product, a certain margin is
required for guaranteed characteristics and performance ratings of relative products.
● Do not decompose or transform it.
Otherwise it will lead to the excessive exothermic heat or smoke generation of the product.
● Do not touch terminal blocks during power-on.
Otherwise it may result in an electric shock.
● Set an emergency stop and interlock circuit in the external devices.
● Connect wires and connectors reliably.
Otherwise it may lead to the excessive exothermic heat or smoke generation of the product.
● Do not undertake construction (such as connection and disconnection) while the power supply is on.
It could lead to an electric shock.
● If the equipment is used in a manner not specified by the Panasonic, the protection provided by the
equipment may be impaired.
● This product has been developed/produced for industrial use only.
Description on Copyright and Trademarks
● The copyright of this manual is owned by Panasonic Industrial Devices SUNX Co., Ltd.
● Unauthorized reproduction of this manual is strictly prohibited.
● Windows is a registered trademark of Microsoft Corporation in the U.S. and other countries.
● Ethernet is a registered trademark of Fuji Xerox Co., Ltd. and Xerox Corporation.
● EtherNet/IP is a registered trademark of ODVA (Open DeviceNet Vendor Association).
● Other company and product names are trademarks or registered trademarks of their respective companies.
PLC_BAT_ET_FP0H

Introduction
Thank you for buying a Panasonic product. Before you use the product, please carefully read
the installation instructions and the users manual, and understand their contents in detail to
use the product properly.
Types of Manual
•This manual describes the "EtherNet/IP communication function" implemented in FP0H
Control Unit.
•There are different types of user’s manual for the FP0H series. Please refer to a relevant
manual for the unit and purpose of your use.
•The manuals can be downloaded on our website:
https://industrial.panasonic.com/ac/e/dl_center/manual/
Unit name or purpose of
use Manual name Manual code
FP0H Control Unit
FP0H User’s Manual (Basic) WUME-FP0HBAS
FP Series Programming Manual ARCT1F313E
FP0H Instruction Manual (SD Card Access
Instructions) WUME-FP0HSD
Positioning
Function/PWM
Output/High-speed
Counter Function
FP0H User’s Manual
(Positioning/PWM Output/High-speed Counter) WUME-FP0HPOS
Serial Communication
Function FP0H User’s Manual (COM Communication) WUME-FP0HCOM
Ethernet Communication
Function FP0H User’s Manual (Ethernet Communication) WUME-FP0HET
EtherNet/IP
Communication Function FP0H User’s Manual (EtherNet/IP) WUME-FP0HEIP
Logging trace function FP0H User’s Manual (Logging/Trace Function) WUME-FP0HLOG
FP0H Extension
(Communication) Cassette FP0H User’s Manual (COM Communication) WUME-FP0HCOM
FP0H Positioning Unit RTEX FP0H Positioning Unit RTEX User’s Manual
（FPWIN GR7）WUME-FP0HRTEXGR7

Glossary
ii
Glossary
The following terms are used in this manual and the EtherNet/IP setting tool.
Term
Description
Originator The side which opens the connection of the cyclic communication is called
originator, i.e. controllers such as PLC.
Target The side which the connection is opened is called target, such as PLC, I/O devices.
Scan List
Connection setting with targets registered in FP0H. Information required for the
communication with the targets and the device allocation of own unit are registered.
For FP0H, the connection with targets are established according to the scan list.
I/O map Information required for the transmission from the own unit (FP0H) to other PLCs
and the device allocation of the own unit are registered.
EDS file
(Electric data sheet)
EDS files are provided for each product by each vendor. This file contains the
information on the communication for registering targets in the scan list.
The EDS files of each target should be registered for constructing the scan list with
the setting tool.
Node no.
A node number is set when a target is registered in the scan list.
Numbers that do not overlap are allocated in the scan list as node numbers.
Node numbers are not used in the cyclic communication, however, as each target is
recognized by these numbers, they are used for monitoring the communication
state of each node or controlling the start/stop of the communication.
Connection setting The details of the connections with targets registered in the scan list are set.
Node name Arbitrary node names can be given.
Device name Device names of targets. The device name is registered in the EDS file.
Connection Name The type of the connection manager registered in the EDS file is selected by the
name. By selecting this, the application type (communication method) is changed.
Application Type
The communication method can be selected by the application type.
Three communication methods are available;
1: Exclusive Owner (Two-way communication)
2: Input Only
3: Listen Only
Although "Exclusive Owner" and "Input Only" are independent connections, "Listen
Only" can be connected only when either of the above connections is established,
and it will be automatically cut if the independent connection is disconnected.
Also, it will be reconnected automatically when the above independent connection
is reconnected.
When FP0H is used as a target, "Input Only" can be selected.
Compatibility Check
Set the operation method of "Compatibility Check" , which checks the information of
the connected target device against the revision of the EDS file.
Three verification methods are available. The default is "Follow Adapter(Target)
Rule".
1: Check
2: Not check
3: Follow Adapter(Target) Rule

Glossary
iii
Term Description
Communication Method
(Tag/Instance)
For connecting from an originator to target, there are two methods to specify the
device area of the target.
- by specifying numbers (Instance)
- by specifying symbols (Tag).
When setting connections, the methods available for each target are displayed.
For using the FP0H as a target, either method can be selected.
However, the selectable instance numbers for the instance method are 100 to 199.
Input Send Trigger
The transmission timing is selected from Cyclic or COS (Change of state).
However, COS depends on devices.
COS is basically a cyclic communication, however, it also performs transmission
when sent data changes.
The FP0H does not support COS.
COS Transmission
Disable Time
Transmission disable time (RPI of input information x 1/4) is displayed when "Input
Send Trigger" is set to "Change of State (COS)".
Even if the unit detects the change in data, it is not sent within the transmission
disable time.
Timeout Period
In the cyclic communication, transmission data is sent as UDP packet. The timeout is
judged on a receiver side.
The timeout period is selected from 4, 8, 16, 32, 64, 128, 256 and 512 times of RPI.
The timeout period should be 10 msec or more.
RPI can be specified for T>O direction and O>T direction separately, so each timeout
period may be different values.
Input Information (T>O) This is the setting for the transmission from a target to the FP0H (originator).
Output Information
(O>T) This is the setting for the transmission from the FP0H (originator) to a target.
RPI
(Requested Packet
Interval)
Set the transmission interval for the cyclic communication. Set a value within the
communication capacity of a target. The usable RPI range depends on devices.
For the FP0H, it is 1 ms to 10 s (by 0.5 ms).
Point to Point
(1:1 communication)
One to one communication is performed between an originator and a target.
Transmitted packets are received only by each other.
Other devices connected to the same HUB do not receive those transmission
packets.
Multicast
(Multicast
communication)
Transmission data is sent as a multicast packet. By connecting multiple originators to
one target, one multicast packet can be received by multiple originators.
(Note) Multicast packets are basically received by all devices connected to the same
HUB which includes the devices unrelated to the communication, and it leads to an
unnecessary communication load.
When using the multicast communication, set not to exceed 100% by the load factor
calculation of the setting tool.
TTL TTL (Time To Live) is used to set the hierarchies of the network in which transmission
packets can exist when sending multicast packets to other PLCs.
Instance ID/Tag name Set an instance ID or tag name according to the communication method of the
selected connection.
Data Size The data sizes of the originator and target for the cyclic communication must be the
same. When they do not match, the communication cannot be performed.
Parameter setting Data size, instance ID and other parameters that can be changed in the EDS file can
be changed.
PPS performance index
(Packet per sec) This is an index of sent/received packets processed in one second.

Glossary
iv
Term
Description
Normal packet and
large packet
The packet whose size is within 510 bytes is called normal packet. The packet whose
size is 511 bytes to 1444 bytes is called larget packet.
The maximum communication performance varies according to the data size used for
communication.
Performance index of FP0H
For 510 bytes or less: Max. 5000 pps
For 511 bytes or more: Max. 2500 pps
Protocol used for
cyclic communication The cyclic communication is performed using UDP. The used port number is 2222.
Heartbeat
For "Input Only" or "Listen Only", a packet called heartbeat whose data size is zero is
sent from the originator (FP0H). For the RPI of the heartbeat, the value 16 times of the
RPI of transmitted data from a target is automatically applied.
The heartbeat is used for confirming the continuation of the connection on the target
side. It is used for detect the timeout.
Forward open This is a command for opening the connection of EtherNet/IP and sent using TCP. The
used port number is 44818.
Large forward open This is a command for opening the connection when sending/receiving data whose
size is larger than 511 bytes.
RUN/IDLE bit
Operation state flag (RUN/IDLE) sent by connected devices in cyclic communication.
RUN ：1
IDLE ：0
When the RUN/IDLE bit of the originator does not change to RUN, the target may not
operate properly. For details, refer to "5.2.3 RUN/IDLE Bit".
•Do not use "2222" and "44818" for the port numbers set to the connections
of Ethernet communication.

Table of Contents
v
Table of Contents
1. FP0H EtherNet/IP Function................................................ 1-1
1.1 What is EtherNet/IP?............................................................................. 1-2
1.1.1 Overview of EtherNet/IP..........................................................................1-2
1.1.2 FP0H EtherNet/IP Function.....................................................................1-2
1.2 Names and Functions of Parts .............................................................. 1-4
1.2.1 Control Unit .............................................................................................1-4
1.2.2 LED Displays When PLC Operates ........................................................1-5
1.3 Restrictions ........................................................................................... 1-7
2. Cyclic Communication....................................................... 2-1
2.1 Cyclic Communication Function ............................................................ 2-2
2.1.1 Overview of Cyclic Communication.........................................................2-2
2.1.2 Operation of Cyclic Communication........................................................2-3
2.1.3 Data Refresh of Cyclic Communication ..................................................2-4
2.1.4 Data Area Specifications Using Tag/Instance.........................................2-5
2.2 Cyclic Communication of FP0H............................................................. 2-6
2.2.1 Connection using FP0H as originator .....................................................2-6
2.2.2 Connection Using FP0H as Target .........................................................2-7
2.2.3 Example of Configuration When FP0H is Originator and Target ............2-8
3. Setting Procedure .............................................................. 3-1
3.1 Overview of Settings ............................................................................. 3-2
3.1.1 System Example .....................................................................................3-2
3.1.2 Setting Procedure....................................................................................3-3

Table of Contents
vi
3.2 Initial Setting of Ethernet /IP ..................................................................3-4
3.2.1 Ethernet Settings.....................................................................................3-4
3.2.2 Starting EtherNet/IP Setting Screen........................................................3-5
3.2.3 EtherNet/IP Basic Configuration .............................................................3-6
3.2.4 Items of Ethernet /IP Basic Configuration ...............................................3-7
3.3 Settings of Connection Using FP0H as Originator .................................3-8
3.3.1 Settings....................................................................................................3-8
3.3.2 Registering EDS File of Target Device ...................................................3-9
3.3.3 Adding Target in Scan List ....................................................................3-10
3.3.4 Setting IP Address of Target .................................................................3-11
3.3.5 Setting Tag/Instance .............................................................................3-12
3.3.6 Specifying Data Area Corresponding to Tag/Instance..........................3-14
3.3.7 Reference: Setting of Target [FP0H(B)] ................................................3-15
3.4 Settings of Connection Using FP0H as Target.....................................3-16
3.4.1 Settings..................................................................................................3-16
3.4.2 Adding I/O Map to Scan List..................................................................3-17
3.4.3 Registering Tag Name/Instance ID .......................................................3-18
3.4.4 Registering Data Area Corresponding to Tag/Instance ........................3-19
3.4.5 Reference: Setting of Originator [FP7] ..................................................3-20
3.5 Confirmation of Load Factor Calculation..............................................3-21
3.5.1 Load Factor Calculation ........................................................................3-21
3.5.2 Displaying Load Factor Calculation.......................................................3-21
3.6 Saving EtherNet/IP Settings ................................................................3-22
3.6.1 Saving EtherNet/IP Settings in Project..................................................3-22
3.6.2 Saving/Reading EtherNet/IP Settings in File.........................................3-22
3.6.3 Writing EtherNet/IP Settings to FP0H ...................................................3-23
4. Tool Operation ................................................................... 4-1
4.1 Scan List Window..................................................................................4-2
4.1.1 Display Contents of Scan List Window ...................................................4-2
4.1.2 Operations in Scan List Window .............................................................4-3

Table of Contents
vii
4.2 Device List Window............................................................................... 4-7
4.2.1 Display Contents of Device List Window.................................................4-7
4.2.2 Operations from EDS File Menu .............................................................4-8
4.3 Various Setting Screens........................................................................ 4-9
4.3.1 Operations in Device Setting Screen ......................................................4-9
4.3.2 Operations in Connection Setting Screen.............................................4-10
4.3.3 Operations in I/O Map Setting Screen ..................................................4-14
4.3.4 Display Contents of Calculate Load Factor Screen ..............................4-15
4.3.5 Display Contents of Device Property Screen ........................................4-17
4.3.6 Switching Tabs in Each Setting Screen ................................................4-18
5. Startup and Operation ....................................................... 5-1
5.1 Startup Operation of Cyclic Communication.......................................... 5-2
5.1.1 When FP0H is Originator ........................................................................5-2
5.1.2 When FP0H is Target..............................................................................5-4
5.2 Checking EtherNet/IP Communication State......................................... 5-5
5.2.1 Unit Annunciation Relays ........................................................................5-5
5.2.2 Cyclic Communication State Tables of EtherNet/IP................................5-5
5.2.3 RUN/IDLE Bit ..........................................................................................5-6
5.3 Judgement and Operation of Abnormality ............................................. 5-7
5.4 Delay Time of Communication Data...................................................... 5-8
5.4.1 Delay time of sent data ...........................................................................5-8
5.4.2 Delay Time of Reception Data ................................................................5-9
6. Instruction References ...................................................... 6-1
6.1 High-level Instructions Used for EtherNet/IP Control ............................. 6-2
6.1.1 Information Acquisition of EtherNet/IP (F465 ETSTAT)..........................6-2

Table of Contents
viii
7. Reference Information....................................................... 7-1
7.1 Calculation Method of Load Factor ........................................................7-2
7.2 Cyclic Communication: List of Abnormal Statuses.................................7-5
7.3 PLC Link and Ethernet Switch ...............................................................7-7
8. Appendix ............................................................................ 8-1
8.1 Supported Data Types...........................................................................8-2

1
FP0H EtherNet/IP Function

FP0H EtherNet/IP Function
1-2
1.1 What is EtherNet/IP?
1.1.1 Overview of EtherNet/IP
EtherNet/IP (Ethernet Industrial Protocol) is an industrial multi-vendor realtime Ethernet
system for executing the communication protocol for CIP (Common Industrial Protocol) control
in an application layer on standard Ethernet.
Cyclic communication can be performed among devices compatible with EtherNet/IP. In cyclic
communication, devices compatible with EtherNet/IP send or receive data between "specified
data areas" in a "specified cycle". Even when the number of nodes increases, the cycle does
not increase.
For information on CIP, refer to the documents of ODVA.
1.1.2 FP0H EtherNet/IP Function
The FP0H can perform the cyclic communication with PLCs and I/O devices compatible with
EtherNet/IP on the EtherNet/IP network.
The send and receive areas are allocated from the device area of the FP0H for the cyclic
communication. Data is sent/received from the allocated area with specified intervals (RPI).
The EtherNet/IP function of FP0H is set from the "EtherNet/IP settings" menu of programming
software FPWIN GR7.
Originator and Target
In each connection (communication line) of cyclic communication, there are "originator" which
opens each connection and "target" which a connection is opened.
The PLC (FP0H) can be set as the both originator and target.
For the communication between the FP0H and a PLC, the settable connection is "Input Only"
(i.e. data can be sent in one direction, from target to originator). By using two connections,
data can be sent and received.
FP0H Connection 1
Connection 2
: Opens connection. : Sends cyclic data.
PLC
Originator
Target Originator
Target

1.1 What is EtherNet/IP?
1-3
For the communication between the FP0H and other I/O devices, the FP0H is the originator.
According to devices, the data transmissions by "Input Only" (from target to originator) and
"Exclusive Owner" (two-way) may be available.
FP0H Connection
Input Only
: Opens connection. : Sends cyclic data.
I/O device
Originator Target
FP0H Connection
Exclusive Owner I/O device
Originator Target

FP0H EtherNet/IP Function
1-4
1.2 Names and Functions of Parts
1.2.1 Control Unit
①
②
Names and Functions of Parts
Number
Name
Description
①LAN port
It is mounted to the FP0H Control Unit (Ethernet type). It is used for connecting
to Ethernet and EtherNet/IP.
The IP address and MAC address are common to the LAN ports 1 and 2. The
wiring can be simplified by using the two ports.
The MAC address is printed on the side face of the unit.
②Operation monitor
LED
IP MS: Displays the operating condition of the unit.
IP NS: Displays the communication status of network.

1.2 Names and Functions of Parts
1-5
1.2.2 LED Displays When PLC Operates
The state of the PLC can be confirmed from the lighting state of the LEDs when the PLC is
operating. The PLC states indicated by the LEDs are as follows.
MS (Module status indicator) <Green/Red>
LED display
PLC state
LED OFF The EtherNet/IP function is disabled.
Green ON The EtherNet/IP function is normally activated.
Green Flashing This state does not exist.
Red ON Unrecoverable fault occurs.
Red Flashing Recoverable fault occurs. (such as a setting that load factor exceeds)
NS (Network status indicator) <Green/Red>
LED display
PLC state
LED OFF The EtherNet/IP function is disabled or IP address is not established.
Green ON More than one connection is established.
Green Flashing Connection is not established, but IP address is acquired.
Red ON IP address duplication is detected.
Red Flashing This state does not exist.

FP0H EtherNet/IP Function
1-6
LED displays when PLC is started
The MS and NS LEDs turn on in the following order when the FP0H is started.
Each lighting time of the lighting order 1 to 4 is 0.25 seconds.
Lighting order
Lighting state
MS
NS
1 Green ON OFF
2 Red ON OFF
3 Green ON Green ON
4 Green ON Red ON
5 Green ON OFF

1.3 Restrictions
1-7
1.3 Restrictions
Connecting to External Devices
LAN ports 1 and 2 have the same IP address and MAC address.
•Do not connect the cables from the two LAN ports to the same switching HUB.
•When performing dasiy chain connection, do not connect devices in a ring shape.
HUB
Number of connections
For the FP0H, the total number of connections of Ethernet communication and EtherNet/IP
communication should be 9 or less. For the details of the setting of the number of connection,
refer to “3.2.1 Ethernet Settings”.
(The no. of user connections of Ethernet communication) + (EtherNet/IP communication) ≤9
connections
Restrictions by FP0H specifications
Item
Specifications
RPI 1 to 10000 ms (In 0.5 ms unit)
Cyclic communication allowable
communication band
5000 pps (Packet size: 2 to 510 bytes)
2500 pps (Packet size: 511 to 1450 bytes)
Usable devices WX, WY, WR, WL, DT, LD
Device specification of each tag/instance Max. 8 devices

FP0H EtherNet/IP Function
1-8

2
Cyclic Communication

Cyclic Communication
2-2
2.1 Cyclic Communication Function
2.1.1 Overview of Cyclic Communication
The cyclic communication is a function to perform data transmission with constant intervals
(RPI) between PLC and PLC or PLC and I/O device on the EtherNet/IP network.
In the cyclic communication, one device opens a communication line which is called
connection for a destination device. The side which opens the connection (communication
line) is called "originator", and the side which the connection is opened is called "target".
Opens connections.
PLC PLC I/O device
Originator Target
Connection information on the cyclic communication is set in the originator. The originator
connects to the target according to the connection information. The tag/instance required for
the connection from the originator is registered in the target.
Once the connection is open, the cyclic communication begins according to the settings of the
connection information.
Cyclic communication
PLC PLC I/O device
Originator Target
Comparison of originator and target
Item Originator Target
Applicable model PLC PLC, I/O device
When starting
communication
Opens connections.
(Connects to targets.)
Connection is opened.
(Connected from originator.)
Connection
information
Target connection information
- IP address
- Tag/Instance
Cyclic communication information
- RPI
- Communication method, etc.
Connected from originator
- Tag/Instance
