Panasonic Aquarea PAW-HPM1 Guide

Aquarea Heat Pump Manager (HPM) 2014
Panasonic Aquarea
Heat Pump Manager (HPM)
Manual Part 1:
Installation and Commissioning

Notes:

3
Aquarea Heat Pump Manager (HPM) – Manual Part 1: Installation and Commissioning – 12/2014
Panasonic Aquarea
Heat Pump Manager (HPM)
Manual Part 1:
Installation and Commissioning
Translation of the Installation and Commissioning Instructions (English)
Documentation version: 12/2014
Software version: H1.1.18
COPYRIGHT
© Panasonic Marketing Europe GmbH 2014. All rights reserved.
Copyrights and intellectual property rights
The copyright of this manual remains with the manufacturer. No part of this manual may be reproduced or processed using
electronic systems, or distributed in any form without the written consent of Panasonic Marketing Europe GmbH. Infringements,
which contradict the above-mentioned information, makes you liable for damages. All trademarks mentioned in this manual are the
property of the respective manufacturers and are hereby acknowledged.

4Aquarea Heat Pump Manager (HPM) – Manual Part 1: Installation and Commissioning – 12/2014
Content
Table of Contents
1 General Information and Safety Notices............................................................ 6
1.1 About this Manual............................................................................................................... 6
1.2 Products covered................................................................................................................ 6
1.3 Intended Use........................................................................................................................ 6
1.4 Target Groups...................................................................................................................... 6
1.5 Structure and Meaning of Notices..................................................................................... 7
1.6 Safety Notices ..................................................................................................................... 8
2 Brief Instructions for the User ............................................................................ 9
3 Easy Setup Overview........................................................................................... 15
4 Scope of Delivery and Accessories ................................................................... 24
4.1 Scope of Delivery................................................................................................................ 24
4.2 Accessories......................................................................................................................... 25
5 Technical Data...................................................................................................... 26
6 Technical Description.......................................................................................... 28
6.1 Product Description............................................................................................................ 28
6.2 Models.................................................................................................................................. 28
6.3 Base...................................................................................................................................... 30
6.4 Interfaces ............................................................................................................................. 32
6.4.1 Interface “ext. Display”.............................................................................................. 33
6.4.2 “BUS” Interface ......................................................................................................... 33
6.4.3 “WEB” Interface ........................................................................................................ 33
6.4.4 “USB” Interface ......................................................................................................... 34
6.5 Operating Elements ............................................................................................................ 34
6.5.1 Basic Display ............................................................................................................ 34
6.5.2 Buttons...................................................................................................................... 35
6.6 Operating functions............................................................................................................ 36
6.6.1 Access Codes........................................................................................................... 36
6.6.2 Operating Mode Switch (Shortcut: button [+])........................................................... 39
6.6.3 System Survey (Shortcut: button [–])........................................................................ 41
6.6.4 PartyFunctions(Shortcut:button[▼])...................................................................... 42
6.6.5 Maintenance/Acknowledgement(Shortcut:button[▼]) ........................................... 43
6.6.6 MCR-BMS (Shortcut: [OK] button............................................................................. 43
6.6.7 Modify Basic Display................................................................................................. 45

5
Aquarea Heat Pump Manager (HPM) – Manual Part 1: Installation and Commissioning – 12/2014
Content
7 Installation and Terminal Assignments ............................................................. 46
7.1 Installation ........................................................................................................................... 46
7.1.1 Wall Installation......................................................................................................... 46
7.1.2 Control Cabinet Installation....................................................................................... 47
7.1.3 Rail Installation ......................................................................................................... 47
7.2 Terminal Assignment .......................................................................................................... 48
7.2.1 Mains voltage............................................................................................................ 49
7.2.2 Inputs ........................................................................................................................ 50
7.2.3 0–10V Inputs/Outputs (Universal terminals) ............................................................. 53
7.2.4 Outputs ..................................................................................................................... 54
7.2.5 Connections of the Heat Pumps ............................................................................... 58
8 Commissioning .................................................................................................... 65
8.1 Selecting the System Diagram in HPMtool....................................................................... 65
8.2 Loading the system diagram in the HPM controller ........................................................ 68
8.2.1 Initial loading............................................................................................................. 70
8.2.2 Repeat loading.......................................................................................................... 77
8.2.3 ExtendedConguration ............................................................................................ 79
8.2.4 Resetting the HPM controller.................................................................................... 88
8.2.5 ManualConguration................................................................................................ 89
8.3 Advanced Settings.............................................................................................................. 92
8.3.1 Aquarea Basic Settings (during communication with heat pump) ............................ 92
8.3.2 Heat source - strategy .............................................................................................. 93
8.3.3 Buffer tank – setpoints .............................................................................................. 95
8.3.4 Domestic Hot Water – Setpoints............................................................................... 95
8.3.5 Heat Circuits – Setpoints, Heat Characteristic, Setpoint Limitation .......................... 96
8.3.6 System – Time and Date .......................................................................................... 98
8.3.7 Occupation Times ..................................................................................................... 98
8.3.8 Function Check......................................................................................................... 103
8.3.9 Screed drying............................................................................................................ 104
9 Fault messages .................................................................................................... 106
10 Appendix............................................................................................................... 107
10.1 Heating Characteristics...................................................................................................... 107
10.2 Measured value table for sensors ..................................................................................... 109
10.3 Detailed Menu Structure..................................................................................................... 110
10.4 Communication-capable Aquarea Heat Pump Types ..................................................... 115
10.5 Index..................................................................................................................................... 117

6Aquarea Heat Pump Manager (HPM) – Manual Part 1: Installation and Commissioning – 12/2014
General Information and Safety Notices
1
1 General Information and Safety Notices
1.1 About this Manual
This manual contains information about the installation and commissioning of the Aquarea Heat
Pump Manager (HPM) made by Panasonic.
Described are the setup, operation, connection of sensors, pumps and valve drives, selection
and loading of the system diagram and settings to adjust the controller to the heating system
and heat pumps.
The appendix contains, among others, a presentation of the most commonly used heating
characteristics, a table of measured values of the sensors, the detailed menu structure of the
controller and an overview of communication-capable AQUAREA heat pump types.
Adetaileddescriptionofallparameterscanalsobefoundin→HPM Manual Part 2: Parameter
description.
1.2 Products covered
This manual covers the following Aquarea Heat Pump Manager models from Panasonic:
●PAW-HPM1
●PAW-HPM2
1.3 Intended Use
The HPM controller is available as an accessory for Panasonic AQUAREA heat pumps and
is exclusively intended for the control of heating and hot water systems including Panasonic
AQUAREA heat pumps. Adherence to the instructions in this manual, especially the safety
notices, is required for the intended use.
Anyotheruseisconsideredimproperandcanleadtosignicantdamages.
Panasonic assumes no liability for any damage as a result of improper use.
1.4 Target Groups
InstallationandCommissioningoftheHPMcontrollermayonlybecarriedoutbyqualied
technicians.
The operation of the HPM controller can also be done by private persons.

7
Aquarea Heat Pump Manager (HPM) – Manual Part 1: Installation and Commissioning – 12/2014
General Information and Safety Notices
1
1.5 Structure and Meaning of Notices
Safety Notices
WARNING
Indicates a possibly dangerous situation. If not avoided, death or severe irreversible injuries can
be the consequence.
CAUTION
Indicates a possibly dangerous situation. If not avoided, minor or slight reversible injuries can be
the consequence.
CAUTION
Indicates a possibly dangerous situation. If not avoided, the device or something in its
environment can be damaged.
Danger symbols used
Warning of electric shock
Further information
Important Notice
Important notices that require adherence.
Notice
Notice for further useful information.
!
i

8Aquarea Heat Pump Manager (HPM) – Manual Part 1: Installation and Commissioning – 12/2014
General Information and Safety Notices
1
Text representations
►indicates an operating step; a sequence with several operational steps must be
executed in the order specied
4indicates the result of an operating step
●indicates a list
[Button] indicates the name of a button
Option indicates an option of the HPMtool or the HPM controller
Menu » Option denotes a sequence of several options that must be selected in sequence
Accentuation indicates the most important terms and text passages
(1) indicates references to captions mentioned in continuous text
→Cross-reference indicates a cross-reference
www.Beispiel.de indicates internet address (without hyperlink function)
1.6 Safety Notices
WARNING
Electric shock from electrical voltage!
The device is operated using 230 V AC voltage: Danger to life from electric shock due to
improper installation.
►Switch off power supply before separating the controller from the base.
CAUTION
Electric shock from electrical voltage!
Installationandcommissioningmayonlybecarriedoutbyqualiedtechnicians.
Opening up the device and accessories is forbidden. Repairs may only be done by the
manufacturer.

9
Aquarea Heat Pump Manager (HPM) – Manual Part 1: Installation and Commissioning – 12/2014
Brief Instructions for the User
2
2 Brief Instructions for the User
Important notice
This Chapter is mainly intended for the end-user of the heating system. Only the most important
user functions and settings are described in the brief instructions.
► Installationandcommissioningmayonlybecarriedoutbyqualiedtechnicians.
The information and procedures required for this are described in Chapter
3 to 10.
Information for using the brief instructions
The following brief instructions are a compilation of the most important user functions for the
end user. Each section contains a reference to the detailed description in the following chapters.
Theusermustcontactanexperiencedinstallerordealerifthisinformationisnotsufcientto
operate the controller.
Operating elements
Fig. 2.1:
12 3
4
5
6
7B
A
D
E
C
Operating elements – Basic Display (left) and Buttons (right)
Basic Display
1 Time
2 Week day
3 Date
4 Operating mode switch
5 Status for WEB interface
6 HPM model
7 Maintenance function (here, none is shown)
Buttons
A Button [▲] (up)
B Button [–] (Minus)
C Button [OK]
D Button [+] (Plus)
E Button [▼] (down)
For all operating procedures described in this manual, the basic display of the display is the
start(→Operating Elements, P. 34).
!

10 Aquarea Heat Pump Manager (HPM) – Manual Part 1: Installation and Commissioning – 12/2014
Brief Instructions for the User
2
Operating mode switch: Select operating mode of the system
In the menu for the operating mode switch, the operating mode for the heating circuit, the
domestic hot water circuit and the heat source can be set. The following parameters are shown
here:
●Operating mode switch (oMod-Sw)
●Main switch of the heat pumps (mSw-HPx)
●Selector switch for the operating mode “Cooling” (Cooling), if a heat pump is
used with cooling operation
Procedure to change a switch setting (short):
►Starting from the basic display: press the [+] button.
►Using the [▲] and [▼] buttons, select the desired switch.
►Change the switch position using the [+] and [–] button.
The possible switch positions of the controller and the heat pumps are listed
and explained in the following table.
► Conrmsettingwiththe[OK] button.
 Theswitchpositionismodied.
If the operating mode selector switch of the controller or the heat pumps is not set to Auto, then
the following fault message is shown on the display: System fault switch not Auto.
Switch positions of the controller
Switch position Heating circuits Domestic hot water circuits Heat source
Off Off: Valve setting unchanged,
pump switched off
Off: Valve setting unchanged,
pump switched off
Off
Auto* Automatic operation: automatic setpoint selection dependent
on set occupation times (day/night)
Automatic operation:
Setpoint selection
dependent on demand
Summer* Standby mode: valve closed,
pump switched off, frost
protection remains active
Automatic operation: automat-
ic setpoint selection depen-
dent on occupation times
Vacation / public
holiday
Reduced operation / backup mode: setpoints of non-occupation
time NOT (night) apply
Duration* Nominal operation: setpoints of occupation time 1 (OT1) apply
Manual Manual operation: valves and pump operated as set in the Manual operation menu
* Once the cooling operation is activated, switch-over to cooling operation occurs automatically if the set outside
temperature limit is exceeded.
Switch positions of the heat pumps
Switch position mSw-HPx = mSw-HP1 / mSw-HP2/ mSw-HP3
Off Heat pump is switched off
Auto Heat pump is controlled by the controller
Force Heat pump is switched on in emergency mode (electric heating element in the
inside unit is active)
Detaileddescription:→Operating Mode Switch, P. 39

11
Aquarea Heat Pump Manager (HPM) – Manual Part 1: Installation and Commissioning – 12/2014
Brief Instructions for the User
2
System Survey: viewing and adjusting important parameters
The system survey provides a quick overview of the current state of the system (operating state,
fault state and setpoint / current values of respective system parts) and an option for adjusting
the following setpoints:
●in the system part heatC. 1 and heatC. 2:
●Room temperature setpoint for occupation time 1 and 2 (roomOT1,
roomOT2)
●Room temperature setpoint for the non-occupation period (roomNO), e.g. to
lower for nighttime, vacation/absences, etc.
●in the system part domestic hot water:
●Domestic hot water setpoint for occupation time 1 and 2 (SP-OT1, SP-OT2)
●Domestic hot water setpoint for the non-occupation period (SP-NO)
Procedure to change the parameters (short):
►Starting from the basic display: Press the [–] button.
►Using the [▲] and [▼] button, select the desired system part:
HeatC. 1, heatC. 2 or domestic hot water. Only the installed system parts are
displayed.
►Using the [▲] and [▼] button, select the desired parameter.
The possible parameters are listed above. Only the parameters of the installed
system parts are displayed.
►Change parameter using the [+] and [–] buttons.
► Conrmsettingwiththe[OK] button.
 The parameter is shown with the changed value.
Detaileddescription:→System Survey, P. 41
Party functions: extend occupation times once
The occupation time can be extended once for a special event without having to change the
regular occupation times. Such a deviation from the normal operation is called a party function
and is available for the following consumer circuits:
●Heating circuits (PartyHC2, PartyHC2)
●Domestic hot water circuitsLoading DomHotWater)
Procedure to change the party function (short):
►Starting from the basic display: Press the [▼] button.
►Using the [▲] and [▼] buttons, select the desired consumer circuit.
The possible consumer circuits are listed above.
►Modify the setting using the [+] and [–] buttons.
► Conrmsettingwiththe[OK] button.
 The party function is displayed with the changed setting.
Detaileddescription:→Party Functions, P. 42

12 Aquarea Heat Pump Manager (HPM) – Manual Part 1: Installation and Commissioning – 12/2014
Brief Instructions for the User
2
Maintenance/acknowledgement: acknowledge faults and start
maintenance operation
If a fault occurs, a fault message is shown on the display alternating with the basic display.
The fault message can be reset (“acknowledged”) in the maintenance/acknowledgement menu
and the maintenance function can be started.
Procedure for resetting fault messages (short):
►Starting from the basic display: Press the [▲] button.
►Using the [▲] and [▼] buttons, select the acknowledgement parameter of the
respective heat pump (RESET HPx).
Only the parameters of the installed heat pumps are displayed.
►Modify the setting using the [+] button to ON.
► Conrmsettingwiththe[OK] button.
 The fault of the heat pump is then acknowledged and will no longer be
displayed.
Contact customer service if the fault can not be remedied by resetting. In this case, the
informationspeciedintheSystem Survey menu will be passed on to customer service
(→System Survey (Brief Instructions), P. 11).
The maintenance function may only be actuated if so instructed by customer service.
Procedure to actuate the maintenance function (short):
►Starting from the basic display: Press the [▲] button.
►Using the [+] and [–] buttons, change the setting for the operation of the
system to ON (resp. after completion of the maintenance operation to OFF).
► Conrmsettingwiththe[OK] button.
 The parameter is now shown with the changed settings.
Detaileddescription:→Maintenance/Acknowledgement, P. 43
Access codes: release further operating functions
Only the most important menus and parameters are visible to the user. The access to other
menus,parametersandoperatingfunctionsmustrstbereleasedbyenteringanaccesscode.
Procedure to enter the access codes (short):
►Starting from the basic display: Keep pressing the [OK] button until the prompt
to enter the access code is shown.
►Using the [+] and [–] buttons, enter the numbers of the access code 1111
individuallyandconrmeachwiththe[OK] button.
The display will automatically switch to the next digit in the display and the
previouslyconrmeddigitisthenshownasastar(*).
 After completed input of the access code, the display shows the respective
access level for a few seconds (Access code 2: user) and then changes to the
basic display.
The desired menu must be opened immediately, as the release expires after
a certain time if no further operating processes are implemented. The access
code will need to be entered again.
Detaileddescription:→Access Codes, P. 36

13
Aquarea Heat Pump Manager (HPM) – Manual Part 1: Installation and Commissioning – 12/2014
Brief Instructions for the User
2
MCR-BMS menu: adjust setpoints
In the MCR-BMS menu, the most important parameters and setpoints of the heating circuits and
domestic hot water circuits can be changed after entering the access code 1111 (operator).
Procedure to change the setpoints(short):
►Starting from the basic display: Enter access code 1111
(→Access codes (Brief Instructions), P. 12).
►Starting from the basic display: Press the [OK] button.
►Using the [▼] button in the MCR-BMS menu, select the desired consumer
circuit (domestic hot water, heating circuits »heatC. 1, heating circuits »
heatC. 2)andconrmwiththe[OK] button.
Only the installed consumer circuits are displayed.
►Using the [▼] button, select the Setpointssub-menuandconrmusingthe
[OK] button.
►Using the [▲] and [▼] button, select the desired parameter.
►Modify the setting using the [+] and [–] buttons.
► Conrmsettingwiththe[OK] button.
 The parameter is now shown with the changed settings.
Detaileddescription:→MCR-BMS, P. 43
System clock: setting the Time and Date
The correct setting of the system clock is a prerequisite for setting the occupation and non-
occupation times for the heating circuit and the hot water circuit.
Procedure to set the system clock (short):
►Starting from the basic display: Enter access code 1111
(→Access codes (Brief Instructions), P. 12).
►Starting from the basic display: Press the [OK] button.
►Using the [▼] button in the MCR-BMS menu, select the Timers sub-menu and
conrmbypressingthe[OK] button.
►Using the [▼] button, select the Timer servicesub-menuandconrmusing
the [OK] button.
►Using the [▼] button, consecutively select the submenus Time and Date,
then set the parameters curTime (current time) and curDate (current date)
correctly.
► Conrmsettingsusingthe[OK] button.
 The system clock is correctly set. Subsequently settings can be made for
occupation time.
Detaileddescription:→System – Time and Date, P. 98
Clock channels: set regular occupation times
The occupation times of the respective system components are set as so-called “Timer
channels”. There is a total of 4 timer channels: one timer channel for each consumer loop
(domHotWater, heatC. 1, heatC. 2) and another timer channel for the "silent operation" (Quiet)
of the heat pump.

14 Aquarea Heat Pump Manager (HPM) – Manual Part 1: Installation and Commissioning – 12/2014
Brief Instructions for the User
2
Procedure to set occupation times (short):
►Starting from the basic display: Enter access code 1111
(→Access codes (Brief Instructions), P. 12).
►Starting from the basic display: Press the [OK] button.
►Using the [▼] button in the MCR-BMS menu, select the Timers sub-menu and
conrmbypressingthe[OK] button.
►Using the [▼] button, select the Timer channel selection sub-menu and
conrmusingthe[OK] button.
Only the clock channels of the installed system parts are displayed.
►Using the [▼]button,selectthedesiredtimerchannelandconrmwiththe
[OK] button.
►Using the[▼] button, select the area in which the setting requires adjustment
(week program, special non-occupation times or special occupation times) and
conrmwiththe[OK] button.
►Using the [▲] and [▼] button, select the desired parameter.
►Modify the setting using the [+] and [–] buttons.
► Conrmsettingsusingthe[OK] button.
 The parameter is now shown with the changed settings.
Detaileddescription:→Occupation Times, P. 98

15
Aquarea Heat Pump Manager (HPM) – Manual Part 1: Installation and Commissioning – 12/2014
Easy Setup Overview
3
3 Easy Setup Overview
Important notice
Thischapterisexclusivelyintendedforqualiedtechnicianswiththenecessaryexperiencein
dealing with the HPM controller. It contains only the most important commissioning steps and
settings to enable the experienced installers rapid commissioning. It should not be addressed
without reference to the following chapters, since they contain important notes about the
commissioning process and for selecting the optimal parameter values.
Information for using the overview
The following table summarizes the key steps and settings for easy setup of the HPM controller.
For each step, references to the detailed descriptions are provided in the following chapters or
in the "HPM Manual Part 2: Parameter Description".
Step 1
Determining system diagram and terminal assignment in the HPMtool
Remark
1-1 Select system diagram →www.hpmtool.eu
1-2 Determine SD-No.
1-3 Print or save terminal assignment
→Selecting the System Diagram in HPMtool, P. 65
Step 2
Install controller and wire according to terminal assignment
Remark
2-1 Installing the HPM controller
2-2 Perform wiring according to terminal connection diagram
→Installation and Terminal Assignments, P. 46
Step 3
Enter system diagram and prepare easy setup
Remark
3-1 Enter SD no. for system diagram in the HPM controller
3-2 Activate Easy setup (easySetup= 1)
3-3 Adjust parameter values as required as described in steps 4 to 7
→Loading the system diagram in the HPM controller, P. 68
!
1
2
3

16 Aquarea Heat Pump Manager (HPM) – Manual Part 1: Installation and Commissioning – 12/2014
Easy Setup Overview
3
Step 4
Perform settings for “Heat pump”¹
Name Information text Standard
setpoint
Remark
4-1 maxSP maximum setpoint 70 °C accept this value when activating
therm. disinfection
4-2 boost.hCu Heating circuits boost 0 °C gradually adapt this value when
pulsing the heat pump
4-3 BoosterH Domestic hot water E-heating
element
0 must be activated for the therm.
disinfection
0: not activated; 1: activated
4-4 BoostDel Time delay domestic hot water
E-heating element
60 min is only displayed if BoosterH= 1
(E-heating element activated)
4-5 Cooling Cooling mode 0 only on model generation “F”
0: not activated; 1: activated
4-6 pumpRo-
tRate
Pump rotation speed 4 only on model generation “F”; adjust
respectively to hydraulic pressure
drop so that ΔT = 5 K
4-7 CAPRAN-
WP1
– – only on All in One models (type-HP1
= ADCx): set the type and perfor-
mance of the outdoor unit;
D03/05/07/09/12/16: High Perfor-
mance range, X09/12/16: T-CAP
range
1 Perform settings in Step 4 for heat pumps 2 and 3 (if available).
→HPM Manual Part 2, Chapter 2: Heat pump
Step 5
Perform settings for “Buffer tank”
Name Information text Standard
setpoint
Remark
5-1 boostZ1 Boost demand buffer zone1 2.0 °C gradually adapt this value when
pulsing the heat pump
→HPM Manual Part 2, Chapter 4: Buffer tank
4
5

17
Aquarea Heat Pump Manager (HPM) – Manual Part 1: Installation and Commissioning – 12/2014
Easy Setup Overview
3
Step 6
Perform settings for “Domestic hot water”
Name Information text Standard
setpoint
Remark
6-1 SP-OT1 Setpoint OT1* 50 °C is always used when no other tem-
perature setpoints for domestic hot
water are available or apply.
6-2 SP-OT2 Setpoint OT2* 50 °C Use during timer function
6-3 SP-NO Setpoint NO* 2.0 °C Use during timer function, e.g. night-
time lowering
6-4 maxSP max. setpoint tank temperature 70 °C accept this value when activating
therm. disinfection
6-5 maxDemFl-T max. ow temp. requirement 70 °C accept this value when activating
therm. disinfection
6-6 thermDes Therm. Disinfection 0: no 1:
Automatic
0
if 6-6 thermDes = 1 (autom. therm. Dis.):
6-6.1 SP-DHWta Tank setpoint Therm.Disinfec-
tion
70 °C Setpoint for domestic hot water tank1
6-6.2 SP-loadFl Loading ow setpoint therm.
disinfection
85 °C Setpoint is transferred to the HP
during the thermal disinfection
6-6.3 day 0: daily 1-7: Monday-Sunday 1 Day for thermal disinfection
6-6.4 time Time start thermal disinfection 01:00
6-6.5 maxDuration maximum duration therm.
disinfection
240 min Time within which the setpoint temp.
in tank must be reached, otherwise:
error message
6-6.6 thermDOn Therm. Disinfection relay
output BoosterH
0 assign free output terminal, such as
terminal 11; release for additional
heat source or signal contact, max.
load of terminal: 1 A
* OT = occupation time; NO = Non-occupation time
1 If the temperature setpoint for the domestic hot water tank has not been reached during the thermal disinfection, then
the respective message is displayed. If this message output should be suppressed, go to the menu MCR-BMS »
domestic hot water » Function » Message and set the parameter ThermDes to 0.
Perform advanced settings for the “Domestic hot water”, if solar system is installed
Name Information text Standard setpoint Remark
6-7 TDiffSolOn Temp. difference solar pump on 8.0 K
6-8 TDiffSolOff Temp. difference solar pump off 2.0 K
6-9 maxTSolTa max. temperature solar tank
sensor
70 °C
6-10 maxTcoll max. temperature collector
sensor
110 °C
6-11 collFrLim Frost.lim collector –10.0 °C
→HPM Manual Part 2, Chapter 5: Domestic hot water
6

18 Aquarea Heat Pump Manager (HPM) – Manual Part 1: Installation and Commissioning – 12/2014
Easy Setup Overview
3
Step 7
Perform settings for “Heating circuit”¹
Name Information text Standard
setpoint
Remark
7-1 Room com-
pensation
0: no; 1: Thermostat; 2: Ed-
Sensor/SP-poti
0
if 7-1 room compensation = 1 (room thermostat installed):
7-1.1 system System main switch 0 Assign terminal: terminal 25 or 26
if 7-1 room compensation = 2 (room thermostat installed):
7-1.2 room Room temperature 110 Assign available input terminal
(17 - 24) e.g. terminal 24;
110: sensor for ext. display (PAW-
HPMED)
if 7-1 room compensation = 2 (SP potentiometer installed):
7-1.3 SPPoti Setpoint potentiometer 0 Assign available input terminal
(17 - 24) e.g. terminal 23;
7-2 hCu-slope Characteristic curve gradient 0.5 Slope of heating characteristic;
0.5: Floor heating at –15 °C outside
temp., about 35 °C ow temp.
0.7: Low temperature heating
element at –15 °C AT, about 45 °C
ow temp.
1.0: Standard heating element at
–15 °C AT, about55 °C ow temp.
1.3: Standard heating element at
–15 °C AT, about 65 °C ow temp.
7-3 hCu-exp Heating element exponent 1.30 1.10: Floor heating (up to 35 °C)
1.20: Low temperature heating
element (up to 45 °C)
1.20 to 1.40: Radiators and pan-
el-type radiator (up to 55 °C)
1.40 to 1.66: Convectors (up to
65 °C)
7-4 roomOT1 Setpoint OT1 22.0 °C Room temperature, which can be
achieved according to the heating
characteristic
7-5 roomOT2 Setpoint OT2 22.0 °C Is only shown during activated timer
function
7-6 roomNO Setpoint NO 15 °C
7-7 maxFl max. ow temp. 65.0 °C
(Continue on next page)
1 All settings for the “Heating circuit” must also be performed for heating circuit 2 (if available).
7

19
Aquarea Heat Pump Manager (HPM) – Manual Part 1: Installation and Commissioning – 12/2014
Easy Setup Overview
3
Continue Step 7¹
(continued from previous page)
Name Information text Standard
setpoint
Remark
7-8 cooling 0: no 1: Automatic 2: demCool
3: 1+2
0
if 7-8 cooling = 1 (Automatic):
7-8.1 SP-cool Cooling setpoint 16.0 °C
7-8.2 threshOT Release limit outside tempera-
ture
24.0 °C Start cooling mode at 24 °C
if 7-8 cooling = 2 (external demand cooling):
7-8.3 SP-cool Cooling setpoint 16.0 °C
7-8.4 demCool Cooling demand 161 Assign cooling demand via ext.
contact: terminal 25 or 26;
161: via ext. display (PAW-HPMED)
if 7-8 cooling = 3 (automatic + external demand cooling):
7-8.5 SP-cool Cooling setpoint 16.0 °C
7-8.6 threshOT Release limit outside tempera-
ture
24.0 °C Start cooling mode at 24 °C
7-8.7 demCool Cooling demand 161 Assign cooling demand via ext.
contact: terminal 25 or 26;
161: via ext. display (PAW-HPMED)
7-9 condensation Condensation 0 Assign contact input for
PAW-DEWPOINTSENSOR
1 All settings for the “Heating circuit” must also be performed for heating circuit 2 (if available).
→HPM Manual Part 2, Chapter 6: The heating circuit
Step 8
Load system diagram with adjusted setpoints
Remark
8-1 Perform cold start (cold start = 1) System diagram and adjusted
setpoints are loaded
→Performing cold start, P. 72
The easy setup is now completed. Further settings can be performed subsequently in the
MCR-BMS »Extended congur. menu, as described in Step 9.
7
8

20 Aquarea Heat Pump Manager (HPM) – Manual Part 1: Installation and Commissioning – 12/2014
Easy Setup Overview
3
Step 9
Open “Extended congur.” menu
To open the Extended conguration menu, access level 3 (technician) with access code 4444
andaboveisrequired(→Access Codes, P. 36).
Approach (short):
►Basic Display» keep button [OK] pressed » with the [+] and [–] button enter
the Access code 4444 » Button [OK] » Display of the released access level and
subsequent change to basic display
►Basic display press » button [OK] » display of menu MCR-BMS » press button
[▼] » Sub menu Extended congur. » press button [OK]
 Thefunctionsfortheextendedcongurationareshown.
→Extended Conguration, P. 79
Perform settings for “Bivalence” (if available)
Name Information text Standard
setpoint
Remark
9-1 HP-Biv Bivalence output 0 assign free output terminal, e.g.
terminal 9; on system diagrams
with bivalence (4xxxx) terminal 1 is
assigned
9-2 type Bivalence type 1 1: parallel; 2: alternative; 3: parallel
on demand
if 9-2 type 3 (parallel on demand):
9-2.1 dem-HC Buffer tank demand 1 Dependence on heating demand
can be activated
9-2.2 Xw-HC Control deviation buffer tank 6.0 K Minimum value of the deviation
between setpoint and current value
of ow temperature
9-2.3 dem-DHW Domestic hot water demand 1 Dependence on DHW demand can
be activated
9-2.4 Xw-DHW Controller deviation domestic
hot water
6.0 K Minimum value of the deviation
between setpoint and current value
of ow temperature
9-3 limit Limit temperature 0.0 °C
→Heat pumps Bivalence, P. 81
Perform settings for “add. heat source” (if available) (only in cascade)
Name Information text Standard
setpoint
Remark
9-4 addHS Add. heat source 0 assign available output terminal: e.g.
terminal 9
9-5 swOnDel Delayed switch-on 60 min
9-6 swOffDel Delayed switch-off 0 min
→Strategy additional heat source, P. 81
9
