Panasonic CZ-RD517C User manual

ACXF55-33860
Operating Instructions
Wired Remote Controller
Model No. CZ-RD517C
12:00,Mon
SET TEMP.
FAN SPEED
25.0
FLAP
AUTO
AUTO
MODE
AUTO
Operating Instructions Wired Remote Controller 2-15
English
Before operating the unit, please read these operating instructions thoroughly and keep them for future
reference. Before installation, the installer should: Read the Installation Instructions, then request the customer
keep them for future reference.
Comment utiliser l’appareil Télécommande filaire 16-29
Français
Avant d’utiliser l’appareil, veuillez lire ce mode d’emploi dans son intégralité et conservez-le pour toute
référence ultérieure. Avant de commencer l’installation, l’installateur doit: Lire les instructions d’installation, puis
demander au client de les conserver pour plus tard.
Instrucciones de funcionamiento Mando a distancia con cable 30-43
Español
Antes de utilizar la unidad, sírvase leer atentamente estas instrucciones de funcionamiento y conservarlas
para futuras consultas. Antes de la instalación, el instalador debe: Lea las Instrucciones de instalación y pida
al cliente que las conserve para futuras consultas.
Bedienungsanleitung Kabelfernbedienung 44-57
Deutsch
Bevor Sie das Gerät in Betrieb nehmen, lesen Sie bitte diese Bedienungsanleitung aufmerksam durch und
bewahren Sie sie als künftige Referenz auf. Vor der Installation sollte der Installateur Folgendes tun:
Die Installationsanleitung lesen und den Kunden bitten, diese als künftige Referenz aufzubewahren.
Istruzioni di funzionamento Telecomando con filo 58-71
Italiano
Prima di utilizzare l’unità, leggere attentamente le istruzioni e conservare questo opuscolo per potervi fare
riferimento in futuro. Prima dell’installazione, l’installatore deve: Leggere le istruzioni d’installazione, quindi
richiedere al cliente di conservarle per riferimento futuro.
ACXF55-33860.indb 1ACXF55-33860.indb 1 8/19/2022 7:20:31 PM8/19/2022 7:20:31 PM

2
Table of Contents
Safety Precautions ……………………………………………………………………………… 2-3
Remote Controller buttons and display ………………………………………………………… 4
Initialization ………………………………………………………………………………………… 5
Quick Guide ………………………………………………………………………………………… 6
Quick Menu ……………………………………………………………………………………… 7-9
Main Menu …………………………………………………………………………………… 10-13
Troubleshooting …………………………………………………………………………………… 14
Information ………………………………………………………………………………………… 15
Thank you for purchasing Panasonic product.
Any translation into other language shall be deemed as reference and English version shall prevail in any case.
Safety Precautions
WARNING
This sign warns of death or serious injury.
CAUTION
This sign warns of injury or damage to
property.
To prevent personal injury, injury to others or property damage, please comply with the
following:
Incorrect operation due to failure to follow instructions below may cause harm or damage, the
seriousness of which is classified as below:
This appliances is not intended for accessibility by the general public.
The instructions to be followed are classified by the following symbols:
This symbol denotes an action
that is PROHIBITED. These symbols denote actions COMPULSORY.
The illustrations in this manual are for explanation purposes only and may differ from the
actual unit. They are subject to change without notice.
ACXF55-33860.indb 2ACXF55-33860.indb 2 8/19/2022 7:20:31 PM8/19/2022 7:20:31 PM

3
English
Safety Precautions
WARNING
This can cause electric shock or ignition.
• Do not disassemble or modify.
• Do not touch with wet hands.
• Do not wipe with wet cloths or wash in water.
This application is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless under supervision or instruction concerning use of the
appliance by a person responsible for their safety. Children should be supervised
to ensure they do not play with the appliances.
Request installation only from the place of purchase or an installer.
• Not doing so may cause electric shock or ignition.
Shut off power supply when installing CNT cable.
• Not doing so may cause electric shock or ignition.
Use only the specified parts when installing CNT cable and perform the
installation correctly by following the instructions.
• Not doing so may cause electric shock or ignition.
Ensure cables are installed properly so that external forces cannot affect them.
• Not doing so may lead to overheating which can lead to ignition.
Stop use as soon as any problems or malfunctions are detected and shut off the
electric supply to connected appliances.
• Not doing so may cause smoke, ignition, electric shock, or burns.
• Examples of problems and malfunctions:
- There is a burning smell
- Water or foreign objects have gotten inside
- Immediately request repair from the place of purchase or the installer.
CAUTION
Before connecting wires and cables, discharge any static electricity.
• Not doing so may cause malfunction.
Check the following requirements in advance:
• There should be no abnormality in the air conditioner such as change of airflow.
Ensure no object(s) which may be displaced easily due to the airflow blowing
directly at it. The fallen or moved object(s) might lead to danger such as fire,
injury etc.
ACXF55-33860.indb 3ACXF55-33860.indb 3 8/19/2022 7:20:31 PM8/19/2022 7:20:31 PM

4
Remote Controller buttons and display
Buttons / Indicator
1Quick Menu button
2Back button
Returns to the previous screen
3LCD Display
4Main Menu button
For function setup
5ON/OFF button
Starts/Stops operation
6
Operation indicator
Illuminates during operation, blinks
during alarm.
Press centre
No glove
No pen
2
3
1
4
5
6
Cross key buttons
Selects an item.
Enter button
Fixes the selected content.
Up
Down
Left Right
12:00,Mon
SET TEMP.
FAN SPEED
25.0
FLAP
AUTO
AUTO
MODE
AUTO
ACXF55-33860.indb 4ACXF55-33860.indb 4 8/19/2022 7:20:31 PM8/19/2022 7:20:31 PM

5
English
Initialization
Please initiate the Remote Control by selecting the language of operation and set the date
and time accordingly before setting up the operation menu preferences.
During first power ON, Remote Controller will automatically prompt setting screen as default.
It can also be access from Personal Setup in the Main Menu.
Blinking
12:00,Mon
Initialization
Initializing
12:00,Mon
Default data
EEPROM setup
12:00,Mon
Start
12:00,Mon
Language
Select Confirm
ENGLISH
ESPAÑOL
ITALIANO
NEDERLANDS
12:00,Mon
Clock format
Select Confirm
24h
am/pm
12:00,Mon
Date & Time
Year/Month/Day Hour : Min
12 : 00 pm
/ 01 / 01
Select Confirm
2021
12:00,Mon
Set temp. unit
Select Confirm
˚C
˚F
12:00,Mon
Heat mode
Select Confirm
Enable
Disable
12:00,Mon
Start
Selecting the language
Wait while the display is initializing.
When initializing screen ends, it turns to
normal screen.
When any button is pressed, language setting
screen appears.
1Scroll with and to select the language.
2Press to confirm the selection.
Setting the clock
1Select with or to display the time, either
24h or am/pm format (for example, 15:00 or
3:00 pm).
2Press to confirm the selection.
3Use and to select year, month, day, hour
and minutes. (Select and move with and
press to confirm.)
4Once the time is set, time and day will appear
on the display even if the Remote Controller is
turned OFF.
Setting the temperature unit
1Scroll with and to select the unit.
Selecting the Heat mode
1Scroll with and to select Enable or
Disable.
ACXF55-33860.indb 5ACXF55-33860.indb 5 8/19/2022 7:20:31 PM8/19/2022 7:20:31 PM

6
Quick Guide
1Press to start/stop the
operation.
2Press to select either
mode, set temperature, fan speed or
air swing section.
•Use or to select setting.
•Press to confirm the selection.
Mode section
Default setting for Mode is Auto.
AUTO HEAT COOL
DRYFAN
Stand-alone operation.
To access nanoe™ stand-alone while operation
is OFF, press (Quick Menu) and select
(nanoe™).
Note:
Set temperature is disabled and not displayed.
Set temperature section
Selection range:
16.0 °C ~ 30.0 °C / 60 °F ~ 86 °F.
Fan speed section
• When FAN AUTO is selected, the fan
speed is adjusted automatically according
to the operation mode.
• Select the lowest fan speed to have a low
noise operation.
AUTO
Flap (Air swing) section
• Do not adjust the flap by hand.
Up/Down Air Swing
(Wall Mounted)
(Floor Console)
*not applicable
Left/Right Air Swing
Note:
• Not applicable for Floor Console.
• To change the horizontal airflow direction
for Floor Console, move the vertical vane
manually before starting operation.
Basic operation
12:00,Mon
SET TEMP.
FAN SPEED
25 .0
FLAP
AUTO
AUTO
MODE
AUTO
1
2
ACXF55-33860.indb 6ACXF55-33860.indb 6 8/19/2022 7:20:31 PM8/19/2022 7:20:31 PM

7
English
Quick Menu
1Press .
2Use to select quick menu.
3Press to turn on/off the select mode.
To return to the Main Screen, Press
or .
Select each setting and confirm the setting according to the instructions displayed at the bottom of
the screen. (The icons refer to each selection key.)
Quick Menu
nanoe™ Powerful Quiet Weekly timer Filter check reset
LED intensity dim R/C Lock AC Reset RC Reset
nanoe™ *1
Select this icon to operate nanoe™ mode.
Press to confirm your selection.
When nanoe™ mode is selected, an icon will appear on top left of Main Screen.
* Refer to "Remote Controller buttons and display"
• nanoe™ is OFF
• nanoe™ is ON
Powerful *1
Select this icon to operate Powerful mode.
Press to confirm your selection.
When Powerful mode is selected, an icon will appear on top left of Main Screen.
* Refer to "Remote Controller buttons and display"
• Powerful is OFF
• Powerful is ON: To reach desired temperature quickly
Note:
Powerful is automatically stop after 20 minutes.
Powerful will be disabled in below conditions:-
• when fan speed is changed,
• when Quiet is enabled.
2 3
1
SetSelect
*1Not available when 'Duty rotation' is turned on.
ACXF55-33860.indb 7ACXF55-33860.indb 7 8/19/2022 7:20:31 PM8/19/2022 7:20:31 PM

8
Quiet *1
Select this icon to enjoy quiet operation. Quiet mode reduces airflow noise.
Press to confirm your selection.
When Quiet mode is selected, an icon will appear on top left of Main Screen.
* Refer to "Remote Controller buttons and display"
• Quiet is OFF
• Quiet is ON
Note:
Quiet is disabled when fan speed is changed or Powerful is enabled.
Weekly timer *1
Select this icon to delete (cancel) or change the pre-set Weekly Timer.
Press to confirm your selection.
When Weekly Timer mode is selected, an icon will appear on top left of Main Screen.
* Refer to "Remote Controller buttons and display"
• Timer is OFF.
• Timer is set.
After 1 sec delay.
Yes No
Do you want to edit
Weekly timer pattern?
Select “Yes”.
• If you select “No”, the screen will return to the Quick Menu Screen.
Timer setup
Timer copy
• Timer setup: Select Timer setup to edit the Weekly Timer.
• Timer copy: Select to copy a timer setting.
Sun Mon Tue Wed Thu Fri Sat [Example of a Timer setup]
Select the day(s) which you wish to edit using buttons.
Sun
1. 6:00am ON 25.0˚C
2. 8:00am ON 25.0˚C
3. 10:00am ON 25.0˚C
Mon Tue Wed Thu Fri Sat
12 3 4 5
12:00,Mon
Weekly timer 1Select pattern “1” ~ “6”.
2Set the hour and minutes of the Timer.
3Select ON/OFF of the Timer.
4Select the operation mode.
/ / / /
5Set the temperature.
All 6 patterns are not set!
Do you want to edit?
Yes No
If all 6 patterns are not set in a day, this screen will be displayed.
Note:
If all entries are found to be reset to default, this could be due to 'Heat mode' setting is
disable.
Quick Menu
*1Not available when 'Duty rotation' is turned on.
ACXF55-33860.indb 8ACXF55-33860.indb 8 8/19/2022 7:20:31 PM8/19/2022 7:20:31 PM

9
English
Filter check reset *1
Filter Check Reset mode is disable by default. will appear on top left of remote control when
air conditioner is operated at accumulated operation time and required to clean the filter.
•It is recommended to clean the air filter every 6 weeks.
•After the air filter is cleaned, press at the Quick Menu to reset.
LED intensity dim *1
Select this icon to dim or restore the indicators’ brightness on the unit.
R/C Lock
Select this icon to lock the Remote Controller.
Press to confirm your selection.
(When the mode has been accepted, below screen will be displayed.)
Yes No
Do you want to
lock remote control?
Select “Yes”.
(The Main Screen will be locked.)
• If “No” is selected, the screen will return to the Quick Menu Screen.
To unlock the Remote Controller
Press any key.
(When the mode has been accepted, below screen will be displayed.)
Press or to scroll and choose the digits. Press or to move to
adjacent digit. Press to confirm the four-digit code. (if the number is
correct, the screen will be unlocked).
To reset forgotten password
Press , and continuously for 5 seconds.
(When the mode has been accepted, below screen will be displayed.)
12:00,Mon
Reset password
Confirm
Request
Press .
12:00,Mon
Reset password
Confirm
Request
Password is reset to 0000
and remote control
unlocked
Password will be reset after 3 seconds.
Main screen will be unlocked.
AC Reset *1
Select this icon to reset the air conditioner and turn it off.
RC Reset
Select this icon to reset the remote controller and perform initialization again.
*1Not available when 'Duty rotation' is turned on.
ACXF55-33860.indb 9ACXF55-33860.indb 9 8/19/2022 7:20:32 PM8/19/2022 7:20:32 PM

10
Main Menu
Select menus and determine settings according to
the system available in the household.
• After initial installation, you may manually adjust
the settings.
• The initial setting remains active until the user
changes it.
• The Remote Controller can be used for multiple
installations.
• The system may not work properly if set wrongly.
Please consult an authorised dealer.
To display <Main menu>:
To select content:
To confirm the selected content:
Press to return to main screen
Menu Default Setting Setting Options / Display
1Function setup
1.1 Model type *1 / *2
To select model type.
Wall mounted
12:00,Mon
Model type
Select Confirm
Wall mounted
Floor console
Cassette
Ducted
1.2 Heat mode *1 / *2 / *3
To enable or disable
heat mode. Enable Enable
Disable
1.3 Fan mode *1 / *2
To enable or disable
Fan mode. Enable Enable
Disable
1.4 Left/Right swing *1 / *2
To enable or disable
left/right swing. Enable Enable
Disable
1.5 nanoe™ *1 / *2
To enable or disable
nanoe™ mode. Enable Enable
Disable
12:00,Mon
Main menu
Select Confirm
Function setup
System check
Personal setup
Service contact
*1Not available when 'Duty rotation' is turned on.
*2This function will become hidden when unit is turned on.
*3'Heat mode' becomes hidden when 'Weekly timer' is activated and has entries with heat mode inside.
ACXF55-33860.indb 10ACXF55-33860.indb 10 8/19/2022 7:20:32 PM8/19/2022 7:20:32 PM
