Panasonic EW-DS13 User manual

© Panasonic Corporation 2012 Unauthorized copy-
ing and distribution is a violation of law.
Order Number PCD1208A65CE
Electric Toothbrush
Model No. EW-DS13
Product-Color P:Pink
PN:Pink Gold
VP:Vivid Pink
Asia
TABLE OF CONTENTS
PAGE PAGE
1 Warning -------------------------------------------------------------- 2
2 Specifications ----------------------------------------------------- 2
3 Exploded View and Replacement Parts List ------------ 3

2
1Warning
Caution:
• Pb free solder has a higher melting point than standard solder.
Typically the melting point is 50 - 70°F (30 - 40°C) higher.
Please use a soldering iron with temperature control and adjust it to 750 ± 20°F (400 ± 10°C).
In case of using high temperature soldering iron, please be careful not to heat too long.
• Pb free solder will tend to splash when heated too high (about 1100°F / 600°C).
2 Specifications
Power Source DC 1.5V AAA(LR03) Alkaline Battery x 1 (Sold separately)
Brush rotating speed Approx. 16,000 horizontal strokes/min.
Dimensions 14.5 mm (W) x 18 mm (Dr) x 145 mm (H)
Weight Approx. 30 g

3
3 Exploded View and Replacement Parts List
Safety Ref. No. Part No. Part Name & Description Q'ty Remarks
1 WEWDS13P3187 CAP 1 (P: Pink)
1 WEWDS13N3187 CAP 1 (PN: Pink Gold)
1 WEWDS13V3187 CAP 1 (VP: Vivid Pink)
2 WEWDS13P3178 BATTERY COVER 1 (P: Pink)
2 WEWDS13N3178 BATTERY COVER 1 (PN: Pink Gold)
2 WEWDS13V3178 BATTERY COVER 1 (VP: Vivid Pink)
3 WEWDS13L0467 DRIVING BLOCK 1
4 WEWDS13L0957 O-RING 1
5 WEW0958-W REPLACEMENT BRUSH 2/set Commercially available
- WEWDS13W8102 OPERATING INSTRUCTIONS 1
- WEWDS13P8000 INDIVIDUAL BOX 1 (P: Pink)
- WEWDS13N8000 INDIVIDUAL BOX 1 (PN: Pink Gold)
- WEWDS13V8000 INDIVIDUAL BOX 1 (VP: Vivid Pink)
