Panasonic KX-TD7580 User manual

DECT Portable Station
Operating Instructions
Model KX-TD7580
– Thank you for purchasing a DECT Handset (= Portable Station PS).
– Charge the battery for about 15 hours before initial use.
– This manual is designed to be used with your Handset and a Panasonic
KX-TD816/KX-TD1232 system.
– In this manual, the last letter of each model number is omitted.
Accessories (included)
Setting Up.................................2
Turning the Power On and
Display......................................3
Operation.................................. 4
Using the Phonebook............... 6
Handset Programming.............13
Important Information...............18
Specifications........................... 20
English...............................21-40
Deutsch..............................41-60
Français..............................61-80
Nederlands.......................81-100
Svensk.............................101-120
Contents
To attach
AC Adaptor
Handset Cover
Belt Clip
Charger
Batteries
Operating Instructions
Français
Nederlands
English Deutsch Svensk
The handset supports the single line telephone (SLT) features.
Please refer to the appropriate section in the User Manual for
the KX-TD816/1232 system to operate the handset.
Some of the features are not available.

2
7
1
0
3
2
4
6
8
9
5
R
INT INT
7
1
0
3
2
6
8
9
5
C
4
Setting Up
Handset (PS)
Display
Charge Contact
Microphone
(Function/OK)
Button
Charge Contact
Navigator Key
( , , , )
Headset Jack (Please
use only a Panasonic
headset.)
(Talk)
Button
(Speakerphone)
Button
(Phonebook)
Button
(Capital Change)
Button
(OFF/Power)
Button
Receiver
(Clear)
Button
C
R
(Recall) Button
Speaker
Insert and charge the batteries for about 15
hours as shown below.
Mount the charger
securely on the wall.
Use the template below for wall
mounting.
To power
outlet AC Adaptor
Back
Screws
30 mm
30 mm
(Pause)
Button

3
Turning the Power On and Display
Shows the battery strength.
During charging the battery,
battery icon is as shown below.
Displays when storing
or viewing phonebook
items.
Fully charged.
Low
Medium
Needs to be
charged.
High
(Flashing)
(Flashing)
(Flashing)
(Flashing)
ABCDEFGHIabcdefg
1234567890123456
In-range icon
Talk icon
Displays when:
making or
answering a call.
receiving an outside
call.
Displays when the
handset is:
in range.
out of range.
(Flashing)
Full <During charge>
Characters
P is pressed while dialling.
F is pressed while dialling.
R
Flashes when receiving
the internal call.
To turn the power ON, press and hold .
Before using the handset, turn the power ON.
Base 1
15.05 13:58
The current connected base unit number:
You can choose whether to display the
base unit number, extension number or no
display in the standby mode by
programming (p. 13).
The current date and time
● To turn the power OFF, press and hold until a beep sounds.
● To change the display language, see page 13.
Battery Strength
Phonebook icon
Intercom icon

4
● While talking, you can switch back and forth between the hands-free phone
conversation (press ) and the receiver (press ).
● Predialling : You can dial first, and then go off-hook.
Operations
Basic Calling
● Quick Answer: If you set the quick answer feature ON (p. 13), you can answer
a call by lifting the handset off the charger without pressing a button.
● When receiving a call from a caller registered in the phonebook, the caller's
name and phone number will appear on the display.
Receiving Calls
/
09
–/
//
Transferring Calls
To an extension
To an outside party
/
08
—8
R
While talking
8 1
phone no.
extension no.
/
To an extension
To an outside party
/
08
—8
8 1
phone no.
extension no.
/ /
Select "Redial."
Redialling
//
Select the redial number
To redial the last number
To redial using the redial list
Notes
● If you misdial, press . To cancel, press and hold or press .
● You can also hang up by placing the handset on the charger.
CC

5
Clearing the Number in the Redial Memory
Adjusting the Receiver/Speaker Volume
● The ringer will turn back on for the next call.
● This function will not work when the handset is on the charger.
To clear the selected number
To clear all numbers
/
Select the redial
number.
/
Select "Clear."
/
Select "All Clear."
/
While talking /
(to increase) (to decrease)
Turning the Handset Ringer off Temporarily
While ringing
(press and hold.)
Select "Go to TONE."
While dialling
Tone Signalling
During an outside call, you can transmit tone signals automatically using the
keypad (e.g., to control answering system remotely).
/
To set
(press and hold.)
Setting the Key Lock
You can lock the handset dialling buttons. Only incoming calls are accepted until
the key lock is cancelled. While locked, "[X]" will be shown on the display.
To cancel
(press and hold.)

6
Using the Phonebook
You can store up to 100 names and phone numbers in the phonebook. All
phonebook items are sorted by the first word in alphabetical order. Using the
phonebook, you can make a call by selecting a name on the display.
● If the phonebook is locked (p. 6), enter the 4-digit handset PIN to go to the
phonebook list.
●You can exit the phonebook setting mode anytime by pressing .
●When programming is completed, a beep sounds.
Storing Names and Numbers in the Phonebook
*1If the display shows ''Memory Full,'' the display will return to the standby
mode. Clear other stored items in the phonebook (p. 10).
*2See the steps for entering names and symbols (p. 7).
Enter the 4-digit
handset PIN.
Select "New
Phonebook."
Enter the phone
number
(max. 24 digits).
Select the desired
private category
number or OFF.
Handset PIN name
<If required>
*1
*2
Enter name
(max. 16
characters).
*2
phone no.
If a pause is required for dialling, press .
A space can be stored in a phone number counting as one digit.
Select "Save."
Using the Private Category Feature
You can select the display backlight colour and ringer type for each private
category (p. 13). When receiving a call, you can easily figure out who has called.
(For example, Category 1 for family, Category 2 for friends and Category 9 for
business.)
If you do not assign an item to any private category number, the handset will ring
in the preset ringer type and light in the preset colour when receiving a call.
/
/ /

7
Entering Characters
The dialling buttons can be used to enter letters and character symbols. The
letters are printed on the dialling buttons.
Selecting the Character Mode
For example, to enter "Anne'':
Select the desired
Character Mode. See the "Character
Mode Table" on the
next page.
While entering a name
ABC
0-9
ΑΒΓ
AÄÅ
Alphabet
Numeric
Greek
Extended
A n en
2336666
Storing a Redial or Predial Number
Enter the 4-digit
handset PIN.
Select the desired
redial number. Select "Save
Phonebook."
Select "Save."
Select the desired
private category
number or OFF.
Handset PIN
<Redial number>
Enter name
(max. 16
characters).
*2
<If required>
phone no.
Enter the desired
phone number.
<Predial Number>
name
Confirm the number.
//
/
/
/

8
Character Mode Table
1
C
Buttons ABC (Alphabet) 0-9 (Numeric) ABC (Greek) AÄÅ (Extended)
# & ’ ( ) , – . / # & ’ ( ) , – . / # & ’ ( ) , – . /
# & ’ ( ) , – . /# & ’ ( ) , – . /# & ’ ( ) , – . /
1
1
2A B C
a b c
ΑΒΓ
ΑΒΓ
A À Á Â Ã Ä Å Æ B C Ç
a à á â ã ä å æ b c ç
2
2
3D E F
d e f
∆ΕΖ
∆ΕΖ
3
3
4G H I
g h i
ΗΘΙ
ΗΘΙ
4
4
5J K L
j k l
ΚΛΜ
ΚΛΜ
J K L
j k l
5
5
6M N O
m n o
ΝΞΟ
ΝΞΟ
M N Ñ O Ò Ó Ô Õ Ø
m n ñ o ò ó ô õ ø
6
6
7P Q R S
p q r s
ΠΡΣ
ΠΡΣ
7
7
P Q R S S ß
p q r s s ß
8T U V
t u v
ΤΥΦ
ΤΥΦ
8
8
T U Ù Ú Û Ü U V
t u ù ú û ü u v
9W X Y Z
w x y z
9
9
W X Y Z
w x y z
0blank
blank
blank
blank
0
0
blank
To move the cursor to the left.
blank
To erase the character. To erase all characters, press and hold.
To move the cursor to the right. (To enter another character using the
same dialling button, move the cursor to the next space.)
To shift from capital to lower case, press . Each time you press ,
the mode will change.
ΧΨΩ
ΧΨΩ
D E È É Ê Ë E F
d e è é ê ë e f
G G H I Ì Í Î Ï I
g g h i ì í î ï

9
*1If ''No Numbers Stored'' is displayed, the phonebook is empty. The handset
will return to the standby mode.
*2All phonebook items are sorted in the following order:
Character Symbol Number
Press the dialling
button for the first
letter of the
desired name.
Enter the
Handset PIN.
Handset PIN
<If required> <To search for a name by initial>
01 –
Finding Items in the Phonebook
Ex.To find "Felix," press repeatedly
until the first item under "F" is displayed.
3
Select the desired
name.*2
●To dial, go to Option 1.
●To edit an item, go to Option 2.
●To clear an item, go to Option 3.
Option 1: Dialling from the Phonebook
/
/

10
Option 2: Editing an Item in the Phonebook
Select "Edit."
Select the desired
category number
or OFF.
Enter the name*
(max. 16 characters).
namename
<To edit the name>
Enter the phone
number
(max. 24 digits).
phone no.
<To edit the number>
* See the steps for entering names and symbols (p. 7).
Option 3: Clearing an Item from the Phonebook
Select "YES."
Select "Clear."
Select "Save."
After a few seconds, the display will show
the next item.
/ /
/ /
/
