Panasonic KX-NTV150 Operating manual

Thank you for purchasing this Panasonic product. Please read this
Important Information carefully before using this product and save
this manual for future use.
Related Documentation
R User’s Manual
Describes information about the installation and operation of the
product.
R Installation Wizard User’s Manual
Describes information about the software installation
(Installation Wizard).
Operations depend on the model and version of the PBX and the
version of the KX-NTV150/KX-NTV160.
You can confirm compatibility and download related documentation
on the Panasonic Web site at:
https://panasonic.net/cns/pcc/support/pbx/
Note
R In this manual, the suffix of each model number (e.g.,
KX-NTV150NE) is omitted unless necessary.
Important Information
Communication IP Camera
IP Video Doorphone
Model No. KX-NTV150
Model No. KX-NTV160

For Your Safety
To reduce the risk of injury, loss of life, electric shock, fire, malfunction, and
damage to equipment or property, always observe the following safety precautions.
Explanation of symbols
The following symbols classify and describe the level of hazard and injury caused
when the denotation is disregarded and improper use is performed.
WARNING
Denotes a potential hazard that
could result in serious injury or
death.
CAUTION
Denotes a hazard that could
result in minor injury or
damage to the product or other
equipment.
The following symbols are used to classify and describe the type of
instructions to be observed.
This symbol is used to alert users to a specific operating
procedure that must not be performed.
This symbol is used to alert users to a specific operating
procedure that must be followed in order to operate the unit
safely.
WARNING
RFor safety reasons, do not physically modify the product or any optional
equipment.
RTo reduce the risk of fire, electric shock or damage to the product, do not
disassemble or modify this product. Only qualified service personnel should
install or service this product. Opening or removing covers may expose you to
dangerous voltages or other risks. Incorrect reassembly can cause electric
shock.
2
For Your Safety

RDo not insert objects of any kind into this product through openings, as they may
touch dangerous voltage points or short out parts that could result in a risk of fire
or electric shock. Never spill liquid of any kind on or in the product.
RDo not connect or disconnect the power plug with wet hands.
RDo not touch the product, AC adaptor, AC adaptor cord or power cord during a
lightning storm.
RWhen installing or testing a product with an external AC adaptor, the AC adaptor
should be plugged into a wall outlet or floor-mounted AC outlet. Do not connect
the AC adaptor to a ceiling-mounted AC outlet, as the weight of the AC adaptor
may cause it to become disconnected.
RDo not make power connections that exceed the ratings for the AC outlet or
power equipment. If the power rating of a surge protector, etc. is exceeded, it
can cause a fire due to heat buildup.
RDo not touch the AC adaptor for extended periods of time. Doing so can lead to
low-degree burns.
RTo prevent possible fire or electric shock, do not expose this product to rain or
moisture.
RDo not install or mount the product in any other way than described in relevant
manuals.
RDo not allow anything to rest on the AC adaptor cord, power cord or Ethernet
cable. Do not locate the product where the AC adaptor cord, power cord or
Ethernet cable may be stepped on or tripped on.
RDo not stretch or bend the cables. Also, do not allow anything to rest on the
cables.
RDo not place the product on an unstable surface, as a fall may cause serious
internal damage.
RUnplug the AC adaptor from the AC outlet and contact your phone system
dealer/service provider in the following cases. If the power is supplied from the
network to the product (Power-over-Ethernet), disconnect the Ethernet cables.
A. When the power cord or power plug is damaged or frayed.
B. If liquid has been spilled into the product.
C. If the product has been exposed to rain or water.
D. If the product does not operate according to the manuals. Adjust only the
controls that are explained in the manuals. Improper adjustment of other
controls may result in damage and may require service by qualified service
personnel to restore the product to normal operation.
E. If the product has been dropped or damaged.
F. If product performance deteriorates.
3
For Your Safety

G. If the product emits smoke, an abnormal smell or makes an unusual noise.
These conditions can cause fire or electric shock.
H. If water has been splashed on the AC adaptor, the AC adaptor cord or the
power cord, or if they are wet. Doing so can result in fire, electric shock, or
injury.
I. If damage to the product exposes any internal parts.
RCompletely insert the power plug into the AC outlet. Failure to do so may cause
electric shock and/or excessive heat resulting in a fire.
RThe AC adaptor should only be connected to the type of electric power supply
specified on the product label. If you are not sure of the type of power supply to
your home, contact your phone system dealer/service provider.
RUse a specified Panasonic AC adaptor.
RMake sure that the wall that the product (approx. 0.4 kg [14.1 oz]) will be
attached to is strong enough to support the product. If not, it is necessary for the
wall to be reinforced.
ROnly use the specified wall-mounting equipment.
RIt is advisable to unplug the product during thunderstorms as the warranty does
not cover any damage resulting from lightning strikes and power surges.
Lightning protection is advised.
RThis equipment is only to be connected to PoE networks without routing to
outside plants.
RFor KX-NTV150, KX-NTV150NE
– Operating near 2.4 GHz electrical appliances may cause interference. Move
away from the electrical appliances.
RThis equipment must be installed and operated in accordance with
provided instructions and spacing as possible must be provided between
antenna and all person’s body (excluding extremities of hands, wrist and
feet) during wireless modes of operation.
RThis transmitter must not be co-located or operated in conjunction with any
other antenna or transmitter.
– Consult the manufacturer of any personal medical devices, such as
pacemakers, to determine if they are adequately shielded from external RF
(radio frequency) energy. (The unit operates in the frequency range of
2.412 GHz - 2.462 GHz, and the output peak power level is less than
35.5 mW [KX-NTV150], 2.412 GHz to 2.472 GHz, and the output peak power
level is less than 35.5 mW [KX-NTV150NE].)
CAUTION
4
For Your Safety

RThe product and the cables should never be placed near or over a radiator or
other heat source.
RThe product should not be placed outdoors (use indoors).
RThe product should not be placed near high-voltage equipment.
RThe product should not be placed on a metal object.
RDo not use a microwave oven to dry this product.
RDo not use the AC adaptor if it has been submerged in water.
RDo not bundle cables that are connected to the product with the power cords of
machines located nearby.
RNever touch uninsulated Ethernet cables or LAN terminals unless the LAN has
been disconnected at the network interface.
RDo not place the unit in high humidity environments.
RThe AC adaptor is used as the main disconnect device. Ensure that the AC
adaptor is located near the product and is easily accessible.
RWhen left unused for a long period of time, disconnect the product from the AC
outlet and detach it from the wall. When the product receives power from a PoE
power supply, disconnect the Ethernet cable.
RClean the power plug periodically with a soft, dry cloth to remove dust and other
debris.
RThe product may not operate in the event of a power failure.
RWhen driving the screws into the wall, be careful to avoid touching any metal
laths, wire laths or metal plates in the wall.
RUse cables that are fire-resistant or fireproof.
Important Safety Instructions
When using your product, basic safety precautions should always be followed to
reduce the risk of fire, electric shock and injury to persons, including the following:
RDo not use this product near water for example, near a bathtub, washbowl,
kitchen sink or laundry tub, in a wet basement or near a swimming pool.
RAvoid using a product during an electrical storm. There may be a remote risk of
electric shock from lightning.
RDo not use the product to report a gas leak in the vicinity of the leak.
SAVE THESE INSTRUCTIONS
5
For Your Safety

6
Notes

7
Notes

Copyright Notice and License Information
This product incorporates the following software:
PNQX7928YA-VB PP1115MK1037
software developed independently by or for Panasonic
Corporation,
software owned by a third party and licensed to Panasonic
Corporation,
software licensed under the GNU General Public License,
Version 2.0 (GPL V2.0),
software licensed under the GNU LESSER General Public
License, Version 2.1 (LGPL V2.1), and/or
open source software other than the software licensed under the
GPL V2.0 and/or LGPL V2.1.
(1)
(2)
(3)
(4)
(5)
The software categorized as (3) - (5) are distributed in the hope that it
will be useful, but WITHOUT ANY WARRANTY, without even the
implied warranty of MERCHANTABILITY or FITNESS FOR A
PARTICULAR PURPOSE. Please refer to the detailed terms and
conditions thereof shown in our website below.
At least three (3) years from delivery of this product, Panasonic
Corporation will give to any third party who contacts us at the contact
information provided below, for a charge no more than the cost of
physically performing source code distribution, a complete, machine-
readable copy of the corresponding source code covered under GPL
V2.0. LGPL V2.1 or other licenses with the obligation to do so, as well
as the respective copyright notice thereof.
https://panasonic.net/cns/pcc/support/pbx/
