Panasonic VL-MV26 User manual

Operating Instructions
Thank you for purchasing a Panasonic product.
Please read this manual before using the product and save it for future reference.
Installation Guide is supplied separately.
This system is an auxiliary system; it is not designed to provide complete protection from property loss. Panasonic will not be
held responsible in the event that property loss occurs while this system is in operation.
VL-MV26
© Panasonic Corporation 2016
PNQX8102WA C0416HH2037
1006, Oaza Kadoma, Kadoma-shi, Osaka 571-8501, Japan
http://www.panasonic.com
Model name
Model No.
Main Monitor Station

1. Introduction
Introduction
1.1 Model composition ........................................3
1.2 Symbols, expressions, and styles .................3
1.3 Trademarks and registered
trademarks ....................................................3
2. Important information
Important information
2.1 For your safety ..............................................4
2.2 Privacy and rights of portrait .........................4
2.3 Others ...........................................................4
2.4 For Europe ....................................................5
3. Preparation
Preparation
3.1 Controls .........................................................6
3.2 Setting the date and time ..............................6
4. Operations
Operations
4.1 Displays .........................................................7
4.2 Answering calls .............................................7
4.3 Monitoring the outside with the lobby station or
camera ..........................................................8
4.4 Opening entrance doors ................................8
4.5 Lift permissions .............................................8
4.6 Calling extension telephones ........................8
4.7 Door bells ......................................................8
4.8 Emergency calls ............................................8
4.9 Recording images .........................................8
4.10 Playing recorded images ...............................9
4.11 Sound and display settings for calls and
monitoring .....................................................9
4.12 Ringtone settings ........................................10
4.13 System conditions and limitations ...............10
5. Additional functions
Additional functions
5.1 Function settings list ....................................11
6. Lobby station controls/
operations
Lobby station controls/operations
6.1 Controls .......................................................13
6.2 Operations ...................................................13
7. General information
General information
7.1 Cleaning ......................................................15
7.2 Specifications ..............................................15
8. Troubleshooting
Troubleshooting
8.1 Troubleshooting ..........................................16
8.2 Error messages ...........................................17
9. Index
9.1 Index............................................................18
2
Table of Contents

1.1 Model composition
Main Monitor Station (Main monitor*1)
VL-MV26
*1 Product name used in this manual.
RIn this manual, the suffix of each model number (e.g., the "BX" in "VL-MV26BX") is omitted unless necessary.
RWhen the suffixes are used to describe models (e.g., "BX models"), the suffixes refer to all models in the series.
RAll the functions listed in this manual are available for the supplied main monitor. However, the functions available
for the lobby station differ depending on the model of the lobby station. For more information about the lobby
station, see page 13.
Product figure
VL-MV26
RThe illustrations in the supplied manual(s) may vary slightly from the actual product.
Caution:
RBefore attempting to connect or operate this product, please read the label on the rear of the main monitor.
1.2 Symbols, expressions, and styles
The following symbols, expressions, and styles are used in this document.
Item How it is expressed Example
Text displayed on the
product’s display
Text is displayed in a special font,
usually enclosed in quotation
marks
“INITIALIZE SETTINGS”
Icons displayed on the
product’s display
Black-and-white illustration of
icon is used
Buttons with printing on
them
Button printing is displayed,
usually wrapped in thick brackets
M
/OFF
N
Soft keys (page 6) Black-and-white illustration of the
corresponding soft key icon is
used
Procedures Usually written in an abbreviated
style. The verb may be omitted.
Press ® select the desired device ®
.
(Meaning: Press the soft key, press the soft
keys under the and soft key
icons to select the desired device, and then press
the soft key under the soft key icon.)
1.3 Trademarks and registered trademarks
RThe software of this product is based in part on the work of the Independent JPEG Group.
RAll other trademarks identified herein are the property of their respective owners.
3
1. . Introduction
1. Introduction

2.1 For your safety
To prevent severe injury and loss of life/property, read
this section carefully before using the product to ensure
proper and safe operation of your product.
WARNING
Preventing fire and electric shock
RThe product shall be installed by qualified service
personnel.
RUse only the power supply unit VL-PS240.
RDo not place objects on the power cord. Install the
product where no one can step or trip on the cord.
RDo not allow the power cord to be excessively pulled,
bent or placed under heavy objects.
RMake sure all connections from the power source to
the power supply unit are secure.
RNever touch the power supply unit with wet hands.
RDo not use the power supply unit for outdoor
installations (it is for indoor use only).
RDo not disassemble this product. Refer servicing to
an authorised service centre when service is
required. Opening or removing covers may expose
you to dangerous voltages or other risks.
RDo not touch the product and the power supply unit
during an electrical storm. There may be a remote
risk of electric shock from lightning.
RNever push any objects through slots in this product.
RDisconnect this product from the power source and
refer servicing to an authorised service centre when
the following conditions occur:
– If it emits smoke, an abnormal smell or makes
unusual noise.
– If the power cord is damaged or frayed.
– If metal objects have been dropped inside the
product.
CAUTION
RMake sure you turn off the power at the breaker
before performing any wiring work.
RAlways connect AC or DC cables to the appropriate
connection terminals. Incorrectly connecting the AC
or DC cables may damage the power supply unit.
RTo prevent the power cables from disconnecting and
to prevent electric shock, secure the power cables
using the cable binders (accessory) and attach the
cable covers.
RInsert the power cables firmly all the way into the
terminals. If the cables are not inserted all the way,
heat may be generated.
RIf the wiring is outdoors, use a protection tube and a
surge protector.
RIf the wiring is underground, use a protection tube
and do not make any connections underground.
RInstall the product securely adhering to the
instructions in this manual to prevent it from falling off
the wall. Avoid installing onto low-strength walls,
such as gypsum board, ALC (autoclaved lightweight
concrete), concrete block, or veneer (less than
18 mm thick) walls.
RThe power supply unit is used as the main disconnect
device. Ensure that the power source is installed near
the product and is easily accessible.
RDo not put your ear(s) near the speaker, as loud
sounds emitted from the speaker may cause hearing
impairment.
RWhen using this product, basic safety precautions
should always be followed to reduce the risk of fire,
electric shock, or personal injury.
1. Do not use this product near water. For example,
near a bathtub, wash bowl, kitchen sink, or
laundry tub, in a wet basement, or near a
swimming pool, and the like.
2. Use only the power supply unit indicated in this
document.
SAVE THESE INSTRUCTIONS
2.2 Privacy and rights of portrait
When installing or using the product, please take into
consideration the rights of others with regard to privacy.
RIt is generally said that "privacy" means the ability of
an individual or group to stop information about
themselves from becoming known to people other
than those whom they choose to give the information.
"Rights of portrait" means the right to be safe from
having your own image taken and used
indiscriminately without consent.
2.3 Others
RWhen you leave the product unused for a long period
of time, unplug it from the power outlet.
RIf you stop using this product, remove it from the walls
to prevent it from falling off.
RWhen power fails, this product cannot be used.
RPanasonic may not be liable for damages due to
external factors such as power failures.
RThe recorded images may be lost when:
– Mishandled
– Electric shock or radio wave interference occurs.
– The power is turned off during use.
RTo the maximum extent permitted by law, Panasonic
assumes no responsibility for injuries or property
damage resulting from failures arising out of improper
installation or operation inconsistent with the
Operating Instructions.
4
2. . Important information
2. Important information

Note for product disposal, transfer, or return
RThis product can store your private/confidential
information.
To protect your privacy/confidentiality, we
recommend that you erase the information (recorded
images) from the memory before you dispose of,
transfer or return the product.
See page 11 for information about how to delete
recorded images.
Disposal of Old Equipment (Only for European Union
and countries with recycling systems)
1
This symbol (A) on the products, packaging, and/or
accompanying documents means that used electrical
and electronic products must not be mixed with general
household waste.
For proper treatment, recovery and recycling of old
products, please take them to applicable collection
points in accordance with your national legislation.
By disposing of them correctly, you will help to save
valuable resources and prevent any potential negative
effects on human health and the environment. For more
information about collection and recycling, please
contact your local municipality.
Penalties may be applicable for incorrect disposal of this
waste, in accordance with national legislation.
Information on Disposal in other Countries outside
the European Union
Above symbol (A) is only valid in the European Union.
If you wish to discard this product, please contact your
local authorities or dealer and ask for the correct method
of disposal.
2.4 For Europe
Ecodesign information
Ecodesign information under EU Regulation (EC) No.
1275/2008 amended by (EU) Regulation
No. 801/2013. From 1 January 2015.
Please visit here: http://www.ptc.panasonic.eu/erp
Click [Downloads]
® Energy related products information (Public)
Power consumption in networked standby and guidance
are mentioned in the web site above.
Authorised Representative in EU:
Panasonic Testing Centre
Panasonic Marketing Europe GmbH
Winsbergring 15, 22525 Hamburg, Germany
5
2. Important information

3.1 Controls
3.1.1 Main monitor
j
3
1
8
9
4 5 6 7
2
Display (page 7)
Microphone
Notification indicator (red)
Flashes when there is a recorded image that has not
been viewed. The indicator stops flashing when the
image is played.
Play button ( )
Press to display the image playing screen when the
main monitor is idle.
It can also be used as a soft key (page 6).
Monitor button ( )
Press to monitor the outside when the main monitor
is idle.
It can also be used as a soft key (page 6).
Information button ( )
Press to display the information screen when the
main monitor is idle.
It can also be used as a soft key (page 6).
Settings button ( )
Press to display the setting screen when the main
monitor is idle.
It can also be used as a soft key (page 6).
Speaker
TALK/OFF button (M
/OFF
N)
RESET button
If the main monitor cannot be correctly operated,
press the MRESETN button with a pointed object to
reset the main monitor. (Recorded images and
configured settings are not affected.)
3.1.2 Soft keys
1
CAMERA
C
1
2
D
Status icons (page 7)
Displayed image
Soft key icons
Indicate the item that will be selected when you press
the soft key directly under each icon. The icons that
are displayed vary depending on current screen and
operation.
Soft keys
Select the items displayed on the screen directly
above each soft key.
3.2 Setting the date and time
If the date and time are not set you will be prompted to
set them.
1Press or .
2Set the date and time.
RPress or to change the setting.
RPress to select the next item (i.e., year,
month, day, etc.).
3When finished, press .
RA beep sounds and the display turns off.
Changing the date and time
You change the date and time settings later if desired.
See page 11.
Note:
RThe date and time settings may be deleted when
there is a power outage. In this case, reconfigure the
settings.
RThe time may become out of sync over time (about
60 seconds per month).
6
3. . Preparation
3. Preparation

4.1 Displays
Image viewing screen
1
1
2
CAMERA
Status icons (page 7)
Soft key icons (page 6)
Status icons
1
Indicates which lobby is calling,
monitoring, or on a call.
("1" indicates the device number.)
1
Indicates which camera is monitoring.
("1" indicates the device number.)
Indicates that the main monitor is talking.
Indicates that the main monitor is
monitoring.
Indicates that images are being recorded
(page 8).
Indicates that "Press-to-talk" mode is on
(page 7).
Indicates that the lobby station’s LED lights
are on (page 9).
Settings screen
The settings screen is used to access and set the various
settings of the main unit. For information on available
settings see page 11.
Information screen
The information screen is used to display information
such as the current status of the main monitor.
RInformation is not updated while it is displayed.
4.2 Answering calls
4.2.1 Answering lobby station calls
When you receive a call from a lobby station, the main
monitor rings, and displays an image from the lobby
station.
To answer the call
Press M
/OFF
N.
RSpeak within about 50 cm of the microphone.
RSpeak alternatively with the visitor. If you and the
visitor speak at the same time, you will not hear each
other.
RCalls are disconnected after the pre-programmed
"timeout" time elapses.
To end the call
Press M
/OFF
N.
Note:
RThe displayed image is automatically recorded to the
main monitor (page 8).
Features available during incoming calls
– Monitoring feature (page 8)
Features available while talking
– Turn on or off the operation guide (page 9)
– Adjusting sound and display settings (page 9)
– Using "press-to-talk" (page 7)
4.2.2 Answering extension telephone calls
When you receive a call from an extension telephone,
the main monitor rings and displays the name of the
extension telephone.
1Press M
/OFF
N.
2When finished, press M
/OFF
N.
Features available while talking
– Adjusting sound settings (page 9)
– Using "press-to-talk" (page 7)
4.2.3 Press-to-talk mode
If it is difficult for you and the visitor to hear each other
due to noise, the "press-to-talk" mode can make
conversations easier to hear.
1While talking, activate press-to-talk mode by
pressing and holding M
/OFF
N for about
2 seconds.
RA beep sounds and is displayed.
2To speak to the visitor
Speak while pressing and holding M
/OFF
N.
To listen to the visitor
Release M
/OFF
N.
7
4. . Operations
4. Operations

Note:
RPress-to-talk mode is cancelled when the call ends.
4.3 Monitoring the outside with
the lobby station or camera
You can monitor the sounds and images from a lobby
station or camera.
1Press .
RIf there are multiple devices, select the desired
device ® .
RThe images from the device are displayed.
RIf a camera is connected to the lobby station, you
can alternate monitoring between the lobby
station and camera by pressing
CAMERA
or
LOBBY
.
2When finished, press M
/OFF
N.
Note:
RThe sound from your end will not be heard at the
lobby station.
RMonitoring sessions are disconnected after the
pre-programmed "timeout" time elapses.
RAfter finishing monitoring you cannot monitor again
for about 10 seconds.
RDepending on the composition of the system, some
lobby stations may not be able to be monitored from
main monitors. In this case, consult the installer or
your facility staff.
Features available while monitoring
– Recording lobby station images (page 9)
– Turn on or off the operation guide (page 9)
– Adjusting sound and display settings (page 9)
4.4 Opening entrance doors
An electric lock may be connected to the lobby station.
In this case, you can open the entrance door while talking
to a visitor or monitoring with a lobby station or camera.
To open the entrance door while talking or monitoring,
press .
4.5 Lift permissions
A lift controller may be connected to the system. In this
case, visitors will be allowed to use the lift to visit your
floor after you have opened the entrance door.
Depending on how the system is configured by the
building manager, the visitor will not be allowed to use
the lift to visit other floors.
4.6 Calling extension telephones
1Press M
/OFF
N.
2Select the desired extension telephone.
RUp to 4 extension telephones may be displayed.
3Press ® .
4When finished, press M
/OFF
N.
Note:
RFor information about the extension telephones
available in your building, contact the facility staff.
Features available while talking
– Adjusting sound settings (page 9)
– Using "press-to-talk" (page 7)
4.7 Door bells
A door bell may be connected to your main monitor. In
this case, the main monitor will ring when someone
presses the door bell button. See page 11 for door bell
settings.
Note:
RThe main monitor will not ring while the settings menu
is displayed.
4.8 Emergency calls
An emergency call button may be connected to your
main monitor. If the call button is pressed, your main
monitor can automatically call facility staff to alert them
to the situation. This is called an "emergency call".
When the emergency call is answered, you can talk with
the facility staff.
4.9 Recording images
The main monitor can record lobby station and camera
images (still images). It can save images from up to 30
calls or monitoring sessions.
4.9.1 Recording automatically (recording a
received call)
When a visitor calls you, the main monitor records 1
image automatically (whether you answer the call or not).
Recording starts about 2 seconds after you receive the
call.
When you do not answer a call
The recorded image is saved as an unplayed image, and
the notification indicator flashes.
When the memory is full (auto image updating)
When the memory is full, new images overwrite the
oldest images automatically. This occurs even if the
oldest images are unplayed images.
8
4. Operations

4.9.2 Recording manually (recording while
monitoring)
While monitoring, press . 1 image will be
recorded.
R is displayed on the screen when recording.
4.10 Playing recorded images
When there are new (i.e., unplayed) images recorded,
the notification indicator (page 6) flashes.
1Press .
2Select “UNPLAYED IMAGES” (for new images) or
“PLAYED IMAGES” (for images that have been
played) ® .
RThe most recent image of the selected type is
displayed.
3Browse the images.
4When finished, press M
/OFF
N.
Note:
RThe notification indicator stops flashing when
is pressed.
4.10.1 Image playing screen
Image playing screen
1
1
1
4
1 JANUARY 9:18
2
[ 4]
3
Device number
Image number
Recording date and time
Symbol that indicates that the image has not been
played
Status icons
1
1
Indicates the number of the device that
recorded the image.
Available soft keys
Plays the previous image
Plays the next image
Displays the options menu
4.10.2 Options available when playing
images
While playing images, you can press to display
the options menu and change the following settings.
To turn off the operation guide
® “GUIDE OFF” ® .
RWhile the guide is turned off, the soft keys are not
displayed but they can still operate their respective
features.
To turn on the operation guide
® ® “GUIDE ON” ® .
To adjust the screen brightness
® select “BRIGHTNESS” ® adjust the
brightness.
4.11 Sound and display settings
for calls and monitoring
While monitoring or on a call, you can press to
display the options menu and change sound and display
settings.
To adjust the incoming call volume*1
® “SOUND” ® ® “RECEIVER
VOLUME” ® adjust the volume.
To adjust the volume heard at the lobby station*1
® “SOUND” ® ® “OWNER’S VOICE
VOLUME” ® select the desired setting.
To turn off the operation guide
® “GUIDE OFF” ® .
RWhile the guide is turned off, the soft keys do not
operate their respective features. Press any soft key
to display the guide again briefly. During this time, the
soft keys can be operated as normal.
To turn on the operation guide
Press any soft key to display the guide ® ®
“GUIDE ON” ® .
To turn the LED lights on or off*2
® “DISPLAY” ® ®
“ILLUMINATION” ® select the desired setting.
R is displayed when the LED lights are on.
To adjust backlight compensation*2
® “DISPLAY” ® ® “BACKLIGHT
COMPENSATION” ® select the desired setting.
To adjust the screen brightness
® “DISPLAY” ® ® “BRIGHTNESS”
® select the desired setting.
*1 These settings cannot be changed during an
incoming call.
9
4. Operations

*2 These settings are only available when there is an
incoming call from the lobby station, or when talking
or monitoring with the lobby station.
4.12 Ringtone settings
4.12.1 Ringtone type and volume settings
You can change the ringtone type and volume that is
heard during an incoming call from a lobby station. You
can also change the ringtone type heard when the door
bell is pressed.
– For information about how to configure settings, see
page 11.
4.13 System conditions and
limitations
Please note the following system conditions and
limitations.
ROnly one call or monitoring session can be handled
at a time.
Subsequent calls will disconnect the current call (if
the current call has lower priority), or will not be
connected (if the current call has higher priority).
Low
priority Monitoring
Medium
priority
General calls (lobby station to
main monitor, main monitor to
PBX extension, etc.)
High
priority Emergency calls
RAll calls and monitoring sessions are disconnected
after the pre-programmed "timeout" time elapses.
Emergency calls are limited to 10 minutes.
10
4. Operations

5.1 Function settings list
You can change the settings to match how the main monitor is used.
1 ® select the desired item ® .
RRepeat this step as necessary to navigate to the desired setting.
2Select the desired setting if necessary ® .
3When finished, press M
/OFF
N.
Note:
RIf you do not perform any operations for 90 seconds while changing these settings, or if an incoming call is received,
the setting is cancelled and the screen turns off.
RIn the following table, default settings are indicated by < >.
RWhile changing settings, the currently selected item is highlighted.
Item name: “TIME AND DATE SETTINGS”
Item Settings
TIME AND DATE SETTINGS*1 2016/1/1 0:00
*1 When using the product for the first time, follow the on-screen instructions to configure this setting (page 6).
Item name: “RINGTONE SETTINGS”
Sub-menu
Settings
1 2
RING VOLUME
–
<LOUD>
NORMAL
QUIET
MUTE
RINGTONE LOBBY STATION <SOUND 1>
SOUND 1 (REPEAT)
SOUND 2
SOUND 2 (REPEAT)
SOUND 3
SOUND 3 (REPEAT)
DOOR BELL SOUND 1
SOUND 1 (REPEAT)
<SOUND 2>
SOUND 2 (REPEAT)
SOUND 3
SOUND 3 (REPEAT)
Item name: “DELETE ALL IMAGES”
Item Settings
DELETE ALL IMAGES DELETE ALL IMAGES
<BACK>
11
5. . Additional functions
5. Additional functions

Item name: “CONNECTED DEVICE SETTINGS”
Item Settings
<DOOR BELL> or EMERGENCY CALL*1 <ENABLE>
DISABLE
*1 Either "DOOR BELL" or "EMERGENCY CALL" is displayed depending on the pre-programmed setting.
Item name: “OTHER SETTINGS”
Sub-menu
Settings
1
PLAY LAMP FLASHING <ON>
OFF
INITIALIZE SETTINGS INIT+DEL ALL IMAGES
ONLY INITIALIZE SETTINGS
<BACK>
Item name: “OPERATING INSTRUCTIONS”
Item Settings
OPERATING INSTRUCTIONS Displays the web page for downloading the Operating
Instructions.
12
5. Additional functions

The following provides an explanation of the controls and operations for the lobby station.
6.1 Controls
6.1.1 Lobby station
G
H
I
J
K
A
C
B
D
E
F
AHeat sensor
Turns on the display when a visitor is detected.
BLens cover
CLight
Illuminates subjects in dark environments.
DDisplay
EKeypad
FSpeaker
GCamera lens
HMicrophone
ISearch buttons ( and )
Used to select items shown on the display.
JCancel button ( )
KCall button ( )
6.2 Operations
6.2.1 Calling a resident
Entering a room number
1. Enter the resident’s room number.
2. Press MN to call.
Searching by first letter of the name
1. Press MN.
2. Use the keypad to enter the first letter of the resident’s name.
RPress a key repeatedly to scroll through the letters assigned to that key.
RNote the hints displayed at the bottom of the screen.
3. Press M N or M N to search for the desired name.
4. Press M N to call.
Searching through all names
1. Press MN.
2. Press M N or M N to search for the desired name.
3. Press MN to call.
Switching the image displayed on the main monitor
While talking to the main monitor, press M#N to switch the image displayed on the main monitor from the lobby station
to the camera. To return to the lobby image, press MN.
13
6. . Lobby station controls/operations
6. Lobby station controls/operations

6.2.2 Calling a receptionist
1Press M N.
2Press MN or M N to search for the receptionist.
3Press M N to call.
6.2.3 Opening the door by entering an unlock code
1Press M#N.
2Enter the 4-digit unlock code.
3Press M N.
14
6. Lobby station controls/operations

7.1 Cleaning
Wipe the product with a soft, dry cloth.
For excessive dirt, wipe the product with a moist cloth.
Important:
RDo not use any cleaning products that contain
alcohol, polish powder, powder soap, benzine,
thinner, wax, petroleum, or boiling water. Also do
not spray the product with insecticide, glass
cleaner, or hair spray. This may cause a change
in colour or quality of the product.
7.2 Specifications
Main monitor (VL-MV26)
Power source Power supply unit (VL-PS240)
24 V DC, 0.5 A
Power
consumption
Standby: approx. 1.2 W
During operation: approx. 8 W
Dimensions
(mm) (height ´
width ´ depth)
Approx. 169´129´29
(excluding protruding sections)
Mass (weight) Approx. 330 g
Operating
environment
Ambient temperature: approx.
0 °C to +40 °C
Relative humidity
(non-condensing): up to 90 %
Display Approx. 8.9 cm (3.5 inches
colour display)
Talking method Hands-free
Installation
method
Wall mount (mounting bracket
supplied)
Power supply unit (VL-PS240) (indoor use only)
Power source Input: 220-240 V AC, 0.2 A,
50/60 Hz
Output: 24 V DC, 0.6 A
Dimensions
(mm) (height ´
width ´ depth)
Approx. 116´100´54
(excluding protruding sections)
Mass (weight) Approx. 230 g
Operating
environment
Ambient temperature: approx.
0 °C to +40 °C
Relative humidity
(non-condensing): up to 90 %
Installation
method
Attach to DIN rail
Directly mount to a wall
15
7. . General information
7. General information

8.1 Troubleshooting
Monitor display (lobby station images)
Problem Cause & Solution Page
Images appear distorted. RImages may appear distorted because of the characteristics of the
camera lens. This is not a malfunction. –
The image of the subject
is displayed in black and
white (or bluish-purple).
RAt night or when there is poor light in the area around the lobby station,
the image of the subject may be displayed in black and white (or
bluish-purple).
– The lobby station's LED lights may be turned off.
Turn on the LED lights when it is dark.
9
The background appears
greenish.
RAt night or when there is poor light in the area around the lobby station,
lights or white objects near the lobby station may appear greenish. This
is not a malfunction.
–
Images at night are dark
and faces cannot be
identified.
REven when the lobby station's LED lights are lit, because the light from
the LED lights cannot illuminate the edges of the visible area (the areas
directly next to the lobby station), faces of people may not be
identifiable even when they are close to the lobby station.
→ We recommend installing extra lights in the area around the lobby
station.
–
The images of people's
faces are dark.
RImages of people's faces appear dark when there is strong sunlight or
a backlight in the area around the lobby station.
→ Use the backlight compensation function.
9
Images are dirty or
unclear.
RImages are not in
focus.
RThere is dirt on the surface of the lobby station's lens.
→ Wipe the lens with a soft, dry cloth. 15
RThere is water condensation on the surface of the lobby station's lens.
→ Wait for the condensation to evaporate. –
Images are white or
black.
RThe brightness of the display is not correctly adjusted.
→ Adjust the brightness when images are displayed. 9
Images are white, or
white lines or circles are
shown on the display.
RStrong light such as sunlight is shining into the lens of the lobby station
causing images to be difficult to see on the display. (This is not a
malfunction.)
→ Locating the lobby station away from direct sunlight or changing
the angle that the lobby station is installed may help reduce this
problem.
–
There is a small black dot
in the background.
RIf the sun can be seen, its centre appears as a black dot. This is not a
malfunction. –
Images are flickering. RAC (alternating current) lights such as fluorescent lights are used near
the lobby station.
→ AC (alternating current) lights such as fluorescent lights may cause
flickering in dark environments. (This is not a malfunction.)
–
Ringtone
Problem Cause & Solution Page
The ringtone for the lobby
station does not sound.
RThe ringtone volume is muted.
→ Activate the sound for the ringtone. 11
16
8. . Troubleshooting
8. Troubleshooting

Others
Problem Cause & Solution Page
The product does not
work with correct
operations.
The product does not
work properly.
RPerform the following operations.
→ Press the MRESETN button on the bottom side of the main monitor
with a pointed object. (Recorded images and configured settings
are not affected.)
6
The main monitor does
not work properly.
RNothing is displayed
on the monitor.
RThe ringtone does not
sound.
RVoices cannot be
heard.
RCheck the power connection.
–
RIf the power is connected, there may be a problem with the electrical
wiring.
→ Contact an authorised service centre.
8.2 Error messages
When using devices for the first time or registering devices
Display Cause & Solution Page
SYSTEM IN USE RYou tried to monitor with the lobby station or call an extension
telephone while another main monitor in a separate apartment is
monitoring, talking, or receiving a call from the lobby station.
→ Try again later when the lobby station is not in use.
RYou tried to monitor with the lobby station again within about
10 seconds of finishing monitoring.
→ Wait until more than 10 seconds have passed before trying to
monitor with the lobby station.
–
17
8. Troubleshooting

9.1 Index
B
Backlight compensation: 9
Brightness
Image brightness: 9
Screen brightness: 9
C
Changing the volume
Owner’s volume: 9
Receiver volume: 9
Cleaning: 15
D
Display: 6
Door bells: 8
E
Emergency calls: 8
Entrance doors: 8
Extension telephones: 7, 8
F
Function settings
Delete all images: 11
Door bell: 12
Initialize settings: 12
Operating Instructions: 12
Play lamp flashing: 12
Ring volume: 11
Ringtone: 11
Time and date settings: 6, 11
I
Illumination settings : 9
Image playing screen: 9
Image viewing screen: 7
Images (recording)
Auto image updating: 8
Playing: 9
Information button: 6
Information screen: 7
L
Lift permissions: 8
Lobby station
Controls: 13
Operations: 13
M
Main monitor: 6
Main Monitor Station: 3
Microphone: 6
Monitor button: 6
Monitoring
Camera: 8
Lobby station: 8
N
Notification indicator: 6
O
Operation guide: 9
Owner’s volume: 9
P
Play button: 6
Playing recorded images: 9
Press-to-talk: 7
R
Recording images
Automatic recording: 8
Automatically updating recorded images: 8
Manually recording: 9
Reset: 6, 17
Reset button: 6, 17
S
Settings button: 6
Settings screen: 7
Soft keys: 6
Speaker: 6
Specifications: 15
Status icons: 7
T
Time: 6
Time and date settings: 6
V
Volume heard at lobby station: 9
18
9. Index
