Transistors
1
Publication date: May 2007 SJC00375AED
This product complies with the RoHS Directive (EU 2002/95/EC).
2SD1823G
Silicon NPN epitaxial planar type
For low-frequency amplification
■Features
•High forward current transfer ratio hFE
•Low collector-emitter saturation voltage VCE(sat)
•High emitter-base voltage (Collector open) VEBO
•Low noise voltage NV
•S-Mini type package, allowing downsizing of the equipment
and automatic insertion through the tape packing and the maga-
zine packing.
■Absolute Maximum Ratings Ta=25°C
Parameter Symbol Rating Unit
Collector-base voltage (Emitter open) VCBO 50 V
Collector-emitter voltage (Base open) VCEO 40 V
Emitter-base voltage (Collector open) VEBO 15 V
Collector current IC50 mA
Peak collector current ICP 100 mA
Collector power dissipation PC150 mW
Junction temperature Tj150 °C
Storage temperature Tstg −55 to +150 °C
Parameter Symbol Conditions Min Typ Max Unit
Collector-base voltage (Emitter open) VCBO IC=10 µA, IE=050V
Collector-emitter voltage (Base open) VCEO IC=1 mA, IB=040V
Emitter-base voltage (Collector open) VEBO IE=10 µA, IC=015V
Collector-base cutoff current (Emitter open) ICBO VCB =20 V, IE=0 0.1 µA
Collector-emitter cutoff current (Base open) ICEO VCE =20 V, IB=01µA
Forward current transfer ratio *hFE VCE = 10 V, IC= 2 mA 400 2 000 
Collector-emitter saturation voltage VCE(sat) IC=10 mA, IB=1 mA 0.05 0.20 V
Transition frequency fTVCB =10 V, IE=−2 mA, f =200 MHz 120 MHz
■Electrical Characteristics Ta=25°C ±3°C
Note) 1. Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7030 measuring methods for transistors.
2. *: Rank classification
Rank R S T
hFE 400 to 800 600 to 1 200 1 000 to 2 000
■Package
•Code
SMini3-F2
•Marking Symbol: 1Z
•Pin Name
1: Base
2: Emitter
3: Collector

2SD1823G
2SJC00375AED
This product complies with the RoHS Directive (EU 2002/95/EC).
VCE(sat) IChFE ICfTIE
PCTaICVCE ICVBE
Cob VCB
0 16040 12080
0
200
160
120
80
40
Collector power dissipation PC(mW)
Ambient temperature Ta(°C)
012108264
0
160
120
40
80
T
a
=25°C
20 µA
30 µA
40 µA
50 µA
60 µA
70 µA
80 µA
90 µA
10 µA
I
B
=100 µA
Collector current I
C
(mA)
Collector-emitter voltage V
CE
(V)
0 2.01.60.4 1.20.8
0
120
100
80
60
40
20
V
CE
=10 V
T
a
=75°C−25°C
25°C
Base-emitter voltage VBE (V)
Collector current IC(mA)
0.1 1 10 100
0.01
0.1
1
10
100 I
C
/ I
B
=10
25°C
−25°C
T
a
=75°C
Collector-emitter saturation voltage V
CE(sat)
(V)
Collector current I
C
(mA)
0.1 1 10 100
0
1 800
1 500
1 200
900
600
300
V
CE
=10 V
T
a
=75°C
25°C
−25°C
Forward current transfer ratio h
FE
Collector current I
C
(mA)
−0.1 −1−10 −100
0
250
200
150
100
50
V
CB
=10 V
T
a
=25°C
Transition frequency f
T
(MHz)
Emitter current I
E
(mA)
1 10 100
0
8
6
2
4
I
E
=0
f =1 MHz
T
a
=25°C
Collector-base voltage VCB (V)
Collector output capacitance (Common base, input open circuited) C
ob
(pF)

This product complies with the RoHS Directive (EU 2002/95/EC).
SMini3-F2 Unit: mm
0.30 +0.05 −0.02
0.13 +0.05 −0.02
2.00 ±0.20
(0.89)
0.90 ±0.10
(0.65)(0.65)
1.30 ±0.10
1.25 ±0.10
2.10 ±0.10
0.425 ±0.050
(0.49)
0 to 0.10
(5°)
(5°)
3
12
