Panasonic AW-RP50E User manual

3TR006603DAA
Operating Instructions
<Operations and Settings>
Remote Camera Controller
Model No. AW-RP50E
РУССКИЙ
FRANÇAIS DEUTSCH ENGLISHITALIANOESPAÑOL

1 (E)
Contents
Before use................................................................. 2
Overview ....................................................................................2
Trademarks and registered trademarks .....................................2
About copyright and licence.......................................................2
Concerning the ratings display...................................................2
Disclaimer of warranty................................................................2
Network security.........................................................................2
How to turn the power of the remote cameras on
and off................................................................... 3
Setting and operating the preset memories .......... 6
Registering data in the preset memories ...................................6
Executing the preset data ..........................................................7
Deleting the preset memory data...............................................7
Selecting the settings for a selected remote
camera................................................................... 8
Setting the gain ..........................................................................8
Setting the pedestal ...................................................................8
Setting the white balance...........................................................9
Setting the black balance .........................................................12
Setting the shutter speed .........................................................13
Setting the detail ......................................................................13
Setting the shooting mode .......................................................14
Specifying the colour bars........................................................14
Operating the menu items of the selected remote
camera................................................................ 15
Setting the USER buttons...................................... 16
Tally settings........................................................... 17
How the model’s Operating Instructions manuals are configured
 The manual of this Remote Camera Controller (hereafter, “the unit”) is divided into two manuals: one is the
<Operations and Settings> (this manual in the CD-ROM), and the other is the <Basics>.
Before installing the unit, be sure to read the <Basics> to ensure that the unit is installed correctly.
 For the purposes of this manual, the model numbers of the units are given as listed in the table below.
Model number of
unit Model number given in manual Model number of unit Model number given in manual Model number of unit Model number given in manual
AW-HS50E AW-HS50 AW-E650E AW-E650 AW-PH650L AW-PH650
AW-HE50HE AW-HE50 AW-E750E AW-E750 AW-IF400G AW-IF400
AW-HE50SE AW-HE50 AW-E860L AW-E860
AK-HC1500 G AK-HC1500
AW-HE100E AW-HE100 AW-PH360L AW-PH360
AK-HC1800 G AK-HC1800
AW-HE870E AW-HE870 AW-PH400E AW-PH400
AW-E350E AW-E350 AW-PH405E AW-PH405
 In these instructions, the phrases “pan-tilt head and camera combination” and “camera integrated with a pan-tilt head” are
both referred to collectively as “remote camera” except in places where specific equipment is mentioned.
Setting the functions.............................................. 18
Setting the remote camera operations.....................................19
Setting the speed at which to move to the position set by the
preset memory....................................................................21
Setting the operations to be performed when a preset operation
is executed..........................................................................21
Returning the remote cameras to their home position .............21
Adjusting the panning, tilting, zooming and focusing speed.....21
Setting the movement range of the remote camera
(limiter function) ..................................................................22
Controlling the peripheral devices connected to the remote
cameras.............................................................................24
Adjusting the minimum lens zoom start speed.........................25
Exercising external control over the preset memory data ........25
Locking the button operations ..................................................26
Adjusting the LCD panel backlight ...........................................26
Setting linkup with the switcher............................ 27
Switcher network settings ........................................................27
Link setting...............................................................................28
Setting the functions when the unit is linked with
the switcher ........................................................ 29
Setting the image output and image input................................29
Switcher settings......................................................................30
Setting for the information to be displayed on the OSD ...........33
Checking the equipment alarm information......... 35
Returning the unit to its factory status ................ 36
Control interface for external devices .................. 37
Setup Software ....................................................... 38
Installing the software ..............................................................38
IP settings ................................................................................38
Saving and loading data...........................................................41
Referencing the network environment......................................42
Table of menu items ............................................... 43
ENGLISH VERSION

2 (E)
ENGLISH
Before use
 Overview
This unit is a controller which is designed to control remote
cameras (cameras integrated with pan-tilt heads) and
pan-tilt head systems (which consist of pan-tilt heads and
the cameras which are mounted on them).
By means of an IP connection, an operating environment
where the unit is tied in with the AW-HE50 HD integrated
camera and AW-HS50 compact live switcher is achieved.
When IP connections are used, the unit can be used to
control up to 100 remote cameras.
When serial connections are used, up to five remote
cameras and pan-tilt head systems can be controlled.
 Trademarks and registered
trademarks
 Microsoft, Windows, Windows Vista, Windows 7 and
Internet Explorer are either registered trademarks or
trademarks of Microsoft Corporation in the United States
and other countries.
 Intel and Intel Core are trademarks or registered
trademarks of Intel Corporation in the United States and
other countries.
 Adobe and Reader are either registered trademarks or
trademarks of Adobe Systems Incorporated in the United
States and/or other countries.
 Other names of companies and products contained
in these Operating Instructions may be trademarks or
registered trademarks of their respective owners.
 About copyright and licence
Distributing, copying, disassembling, reverse compiling,
reverse engineering, and also exporting in violation of export
laws of the software provided with this unit are expressly
prohibited.
 Concerning the ratings display
The unit’s name, model number and electrical ratings are
indicated on its bottom panel.
 Disclaimer of warranty
IN NO EVENT SHALL Panasonic Corporation BE LIABLE
TO ANY PARTY OR ANY PERSON, EXCEPT FOR
REPLACEMENT OR REASONABLE MAINTENANCE OF
THE PRODUCT, FOR THE CASES, INCLUDING BUT NOT
LIMITED TO BELOW:
ANY DAMAGE AND LOSS, INCLUDING WITHOUT
LIMITATION, DIRECT OR INDIRECT, SPECIAL,
CONSEQUENTIAL OR EXEMPLARY, ARISING OUT
OF OR RELATING TO THE PRODUCT;
PERSONAL INJURY OR ANY DAMAGE CAUSED BY
INAPPROPRIATE USE OR NEGLIGENT OPERATION
OF THE USER;
UNAUTHORIZED DISASSEMBLE, REPAIR OR
MODIFICATION OF THE PRODUCT BY THE USER;
INCONVENIENCE OR ANY LOSS ARISING WHEN
IMAGES ARE NOT DISPLAYED, DUE TO ANY
REASON OR CAUSE INCLUDING ANY FAILURE OR
PROBLEM OF THE PRODUCT;
ANY PROBLEM, CONSEQUENTIAL
INCONVENIENCE, OR LOSS OR DAMAGE,
ARISING OUT OF THE SYSTEM COMBINED BY
THE DEVICES OF THIRD PARTY;
ANY INCONVENIENCE, DAMAGES OR LOSSES
RESULTING FROM ACCIDENTS CAUSED BY
AN INADEQUATE INSTALLATION METHOD OR
ANY FACTORS OTHER THAN A DEFECT IN THE
PRODUCT ITSELF;
LOSS OF REGISTERED DATA CAUSED BY ANY
FAILURE;
ANY DAMAGES, CLAIMS, ETC. DUE TO LOSS OR
LEAKAGE OF THE SETTING DATA SAVED ON THIS
UNIT OR IN A PERSONAL COMPUTER.
 Network security
As you will use this unit connected to a network, your
attention is called to the following security risks.
Leakage or theft of information through this unit
Use of this unit for illegal operations by persons with
malicious intent
Interference with or stoppage of this unit by persons
with malicious intent
It is your responsibility to take precautions such as those
described below to protect yourself against the above
network security risks.
 Use this unit in a network secured by a firewall, etc.
 If this unit is connected to a network that includes PCs,
make sure that the system is not infected by computer
viruses or other malicious entities (using a regularly
updated antivirus programme, anti-spyware programme,
etc.).
 Refrain from connections that use public lines.

3 (E)
How to turn the power of the remote cameras on and off
 How to turn the power of the
remote cameras on
Follow one of the procedures below to turn on the power of
the remote cameras.
 Turning on the power one camera at a time
 Turning the power of the cameras on simultaneously as
the unit’s power is turned on
 Turning on the power of a multiple number of cameras
• Turning on the power of all the cameras
• Turning on the power of the selected group of cameras
Each of these procedures is described in turn below.
Turning on the power one camera at a time
1 Select the remote camera.
When the corresponding CAMERA STATUS/
SELECTION button is held down, the name of the
remote camera is displayed on the top line of the LCD
panel and POWER OFF is displayed on the bottom line.
2 Turn the F2 dial to select “ON”, and press the
F2 dial.
The power of the selected remote camera is turned on.
POWER ALARM F1 CAMERA
OSD
R/B GAIN R/B PED
SYSTEMSETUPCAMERA
SCENE/MODE
DETAIL
DELETESTORE
PAGEMENU F2 EXIT
USER2USER1
PT ACTIVEAUTOIRIS CAMERA STATUS / SELECTION
PRESET MEMORY / MENU
GAIN/PED
F2
F1
123
AWB/ABB
4
SHUTTER
5
12345
678910
CAM100<AW-HE50 >
POWER: ON
1
2
Turning the power of the cameras on simultaneously
as the unit’s power is turned on
1 Set the MENU button to ON.
Press the MENU button to light its indicator.
2 Set PRESET MEMORY/MENU 8 button
(CAMERA) to ON.
When the button is pressed and its indicator is lit, the
[CAMERA] menu is displayed on the LCD panel.
[1]GROUP ▼
3 Turn the F1 dial to display the [POWER] menu,
and press the F1 dial.
[2]POWER
1.CAM POWER ▼
ALL OFF
Press the F1 dial.
4 Turn the F1 dial to display the [AUTO ON]
menu.
2.AUTO ON ▲
On
1.CAM POWER ▼
ALL OFF
Turn the F1 dial.
5 Turn the F2 dial to select “On”, and press the
F2 dial.
When “Serial” or “Network” has been selected as the
CAMERA CTL item on the [SYSTEM] menu for any
of the remote cameras, the power of those remote
cameras will be turned on simultaneously as the unit’s
power is turned on.
Depending on the number of cameras connected, it may
take some moments for the unit’s operation to take effect.
Note

4 (E)
ENGLISH
How to turn the power of the remote cameras on and off
Turning on the power of a multiple number of cameras
1 Set the MENU button to ON.
Press the MENU button to light its indicator.
2 Set PRESET MEMORY/MENU 8 button
(CAMERA) to ON.
When the button is pressed and its indicator is lit, the
[CAMERA] menu is displayed on the LCD panel.
[1]GROUP ▼
3 Turn the F1 dial to display the [POWER] menu,
and press the F1 dial.
[2]POWER
1.CAM POWER ▼
ALL OFF
Press the F1 dial.
Turning on the power of all the cameras
4 Turn the F2 dial to select “ALL ON”, and press
the F2 dial.
1.CAM POWER ▼
ALL ON
The power of all the remote cameras is now turned on.
Turning on the power of the selected group of
cameras
4 Turn the F2 dial to select “GROUP ON”, and
press the F2 dial.
1.CAM POWER ▼
GROUP ON
The power of the selected group of remote cameras is
turned on.

5 (E)
How to turn the power of the remote cameras on and off
 How to turn the power of the
remote cameras off
Follow one of the procedures below to turn off the power of
the remote cameras.
 Turning off the power one camera at a time
 Turning off the power of a multiple number of cameras
• Turning off the power of all the cameras
• Turning off the power of the selected group of cameras
Each of these procedures is described in turn below.
Turning off the power one camera at a time
1 Select the remote camera.
When the corresponding CAMERA STATUS/
SELECTION button is held down, the name of the
remote camera is displayed on the top line of the LCD
panel and POWER ON is displayed on the bottom line.
2 Turn the F2 dial to select “OFF”, and press the
F2 dial.
The power of the selected remote camera is turned off.
POWER ALARM F1 CAMERA
OSD
R/B GAIN R/B PED
SYSTEMSETUPCAMERA
SCENE/MODE
DETAIL
DELETESTORE
PAGEMENU F2 EXIT
USER2USER1
PT ACTIVEAUTOIRIS CAMERA STATUS / SELECTION
PRESET MEMORY / MENU
GAIN/PED
F2
F1
123
AWB/ABB
4
SHUTTER
5
12345
678910
CAM100<AW-HE50 >
POWER:OFF
1
2
Turning off the power of a multiple number of cameras
1 Set the MENU button to ON.
Press the MENU button to light its indicator.
2 Set PRESET MEMORY/MENU 8 button
(CAMERA) to ON.
When the button is pressed and its indicator is lit, the
[CAMERA] menu is displayed on the LCD panel.
[1]GROUP ▼
3 Turn the F1 dial to display the [POWER] menu,
and press the F1 dial.
[2]POWER
1.CAM POWER ▼
ALL OFF
Press the F1 dial.
Turning off the power of all the cameras
4 Turn the F2 dial to select “ALL OFF”, and press
the F2 dial.
1.CAM POWER ▼
ALL OFF
The power of all the remote cameras is now turned off.
Turning off the power of the selected group of
cameras
4 Turn the F2 dial to select “GROUP OFF”, and
press the F2 dial.
1.CAM POWER ▼
GROUP OFF
The power of the selected group of remote cameras is
turned off.

6 (E)
ENGLISH
Setting and operating the preset memories
This unit is provided with a function for registering the
positions to be shot by the remote cameras and the settings
of the remote cameras in the remote cameras themselves.
Up to 100 sets of data (presets) can be registered in these
memories.
The positions and settings listed below can be registered.
 Pan/tilt positions
 Zoom positions
 Focus positions
 Lens iris settings
(manual iris only)
 White balance mode
settings
The number of position and setting data which can be
registered as preset memory data differ from one remote
camera to another.
For further details, check the Operating Instructions of
the model concerned.
Note
 Registering data in the preset
memories
1 Press one of the CAMERA STATUS/SELECTION
buttons 1 to 5 to select the remote camera to
be operated.
2 Output the images to be shot by the camera to
the monitor.
The camera angle to be registered is determined by
operating the PAN/TILT lever and ZOOM button.
If necessary, adjust the focus and iris as well.
3 Press the STORE button.
4 After pressing the PAGE button, press the
PRESET MEMORY/MENU button to specify the
“Page number” to be registered.
In this step, the “Page number” to be registered as the
preset memory is specified.
 For details on the relationship between the “Preset
number”, “Page number” and “Number on the page”,
refer to the section entitled <Preset numbers and
registered pages>.
5 Hold down the PRESET MEMORY/MENU
button to specify the “Number on the page”.
The preset memory data is registered at the same time
as the “Number on the page” is specified.
When specifying the “Number on the page”, hold down
the PRESET MEMORY/MENU button.
Note
R/B GAIN R/B PED
SYSTEMSETUPCAMERA
SCENE/MODE
DETAIL
DELETESTORE
PAGEMENU F2 EXIT
USER2USER1
PT ACTIVEAUTOIRIS CAMERA STATUS / SELECTION
PRESET MEMORY / MENU
GAIN/PED
123
AWB/ABB
4
SHUTTER
5
12345
678910
1
4, 5
43
To register more data, repeat steps 2 to 5 .
 When specifying a different “Number on the page” on the
same “Page number”, it is registered by skipping step
4
and carrying out the operation in step
5 only.
 The PRESET MEMORY/MENU button corresponding to
the preset number lights when preset memory data has
been registered in the AW-HE50.
<Preset numbers and registered pages>
Preset number Page number Number on the page
1 to 10 1 1 to 10
11 to 20 2 1 to 10
21 to 30 3 1 to 10
31 to 40 4 1 to 10
41 to 50 5 1 to 10
51 to 60 6 1 to 10
61 to 70 7 1 to 10
71 to 80 8 1 to 10
81 to 90 9 1 to 10
91 to 100 10 1 to 10
Memo 
Example: When specifying preset 21
Press the following buttons in the order given:
PAGE button PRESET MEMORY/MENU 3 button 
PRESET MEMORY/MENU button 1.

7 (E)
Setting and operating the preset memories
 Executing the preset data
1 Press one of the CAMERA STATUS/SELECTION
buttons 1 to 5 to select the remote camera to
be operated.
Select the remote camera which is to be pointed at the
camera angle registered in the preset memory.
2 After pressing the PAGE button, press the
PRESET MEMORY/MENU button to specify
the registered “Page number” of the preset
memory.
In this step, specify the registered “Page number” of the
preset memory.
 For details on the relationship between the “Preset
number”, “Page number” and “Number on the page”,
refer to the section entitled <Preset numbers and
registered pages>.
3 Press the PRESET MEMORY/MENU button to
specify the “Number on the page”.
The preset memory data is executed at the same time
as the “Number on the page” are specified.
R/B GAIN R/B PED
SYSTEMSETUPCAMERA
SCENE/MODE
DETAIL
DELETESTORE
PAGEMENU F2 EXIT
USER2USER1
PT ACTIVEAUTOIRIS CAMERA STATUS / SELECTION
PRESET MEMORY / MENU
GAIN/PED
123
AWB/ABB
4
SHUTTER
5
12345
678910
1
2,3
2
 When the preset memory data is executed, the preset
number is displayed on the right side of the top level of
the LCD panel.
PRESET 1
PAGE:1 (1-10)
The preset number display is cleared when the power of
the unit or remote camera has been turned off or when
the camera group has been switched.
 In the case of the AW-HE50, the corresponding PRESET
MEMORY/MENU button will go off, and then it will light
again when preset memory data is executed.
In the case of another remote camera connected serially,
the corresponding PRESET MEMORY/MENU button will
simply just light.
 Deleting the preset memory
data
This function does not work with the AW-PH400.
Note
1 Press one of the CAMERA STATUS/SELECTION
buttons 1 to 5 to select the remote camera to be
operated.
Select the remote camera whose preset memory data is
to be deleted.
2 Press the DELETE button.
3 After pressing the PAGE button, press the
PRESET MEMORY/MENU button to specify the
“Page number” of the preset memory data to
be deleted.
In this step, specify the “Page number” of the preset
memory data to be deleted.
 For details on the relationship between the “Preset
number”, “Page number” and “Number on the page”,
refer to the section entitled <Preset numbers and
registered pages>.
4 Hold down the PRESET MEMORY/MENU
button to specify the “Number on the page”.
The preset memory data is deleted at the same time as
the “Number on the page” is specified.
When specifying the “Number on the page”, hold down
the PRESET MEMORY/MENU button.
Note
R/B GAIN R/B PED
SYSTEMSETUPCAMERA
SCENE/MODE
DETAIL
DELETESTORE
PAGEMENU F2 EXIT
USER2USER1
PT ACTIVEAUTOIRIS CAMERA STATUS / SELECTION
PRESET MEMORY / MENU
GAIN/PED
123
AWB/ABB
4
SHUTTER
5
12345
678910
1
2
3, 4
3

8 (E)
ENGLISH
Selecting the settings for a selected remote camera
The following settings and adjustments can be performed for
a selected remote camera directly from this unit.
• Gain
• Pedestal
• R and B gain values
• R and B pedestal values
• White balance
• Black balance
• Shutter speed
• Detail
• Shooting mode selection
• Colour bar selection
It is not possible to perform operations for those
functions which are not supported by the model
concerned.
For further details, refer to the “Table of menu items”.
Note
 Setting the gain
In places which are too dark, increase the gain level;
conversely, in places which are too light, reduce the gain
level.
When “Auto” is selected, the light quantity is adjusted
automatically.
When the gain is increased, the noise level also increases.
1 Set the MENU button to ON.
Press the MENU button to light its indicator.
2 Set the PRESET MEMORY/MENU 1 button
(GAIN/PED) to ON.
When the button is pressed and its indicator lights, the
[GAIN/PED] menu is displayed on the LCD panel.
3 Turn the F1 dial to select the setting.
GAIN : 0dB
PED : ±0
GAIN : 3dB
PED : ±0
Turn the F1 dial.
The settings will differ depending on the remote camera
connected.
For further details, check the Operating Instructions of
the model concerned.
Note
 Setting the pedestal
Perform the black level (pedestal) adjustment in order to
make it easier to see the very dark parts of the images.
Adjustment in the “–” direction makes the parts closer to
black; conversely, adjustment in the “+” direction makes the
parts closer to white.
1 Set the MENU button to ON.
Press the MENU button to light its indicator.
2 Set the PRESET MEMORY/MENU 1 button
(GAIN/PED) to ON.
When the button is pressed and its indicator lights, the
[GAIN/PED] menu is displayed on the LCD panel.
3 Turn the F2 dial to select the setting.
GAIN : 0dB
PED : ±0
GAIN : 0dB
PED : +5
Turn the F2 dial.
The settings will differ depending on the remote camera
connected.
For further details, check the Operating Instructions of
the model concerned.
Note

9 (E)
Selecting the settings for a selected remote camera
 Setting the white balance
The ratio between RGB (three primary colours) is adjusted
so that white will be reproduced accurately.
If the white balance is off, not only will white be reproduced
poorly but the colour tone of the entire picture will also
deteriorate.
The white balance must be adjusted when using a remote
camera for the first time or when the remote camera has
not been used for a prolonged period of time. It must also
be adjusted when changes have been made in the lighting
conditions or brightness.
The white balance can be adjusted automatically or
manually (fine adjustment after automatic adjustment).
In addition, preset values or the “auto tracking white
adjustment (ATW)” which continues to adjust the white
balance automatically all the time can be selected.
The results of white balance adjustments can be stored
in memory A or memory B when “AWB A” or “AWB B” has
been selected for the white balance.
Selecting the white balance mode
Follow the steps below to set the white balance mode.
1 Set the MENU button to ON.
Press the MENU button to light its indicator.
2 Set the PRESET MEMORY/MENU 4 button
(AWB/ABB) to ON.
When the button is pressed and its indicator lights, the
[AWB/ABB] menu is displayed on the LCD panel.
3 Turn the F1 dial to select the white balance
mode.
AWB MOD: AWB B
SET : AWB
The modes which can be selected differ depending on the
remote camera connected.
Remote
camera Mode Remote camera status
AW-HE50
AWB A
The status of the white balance
registered in remote camera
memory A is established.
AWB B
The status of the white balance
registered in remote camera
memory B is established.
ATW
In this mode, the white balance is
automatically adjusted continuously
all the time and automatically
compensated even when the light
source or colour temperature has
changed.
AW-HE100
AW-HE870
AW-E860
AW-E750
AW-E650
AW-E350
AWB A
The status of the white balance
registered in remote camera
memory A is established.
AWB B
The status of the white balance
registered in remote camera
memory B is established.
3200K
The status of the white balance
which was adjusted at a brightness
of 3200K is established.
5600K
The status of the white balance
which was adjusted at a brightness
of 5600K is established.
ATW
In this mode, the white balance is
automatically adjusted continuously
all the time and automatically
compensated even when the light
source or colour temperature has
changed.
AK-HC1500
AK-HC1800  

10 (E)
ENGLISH
Selecting the settings for a selected remote camera
Automatically adjusting the white balance
Set the automatic adjustment if the colouring appears
unnatural under certain light sources or other conditions.
If the white serving as the reference can be recognized, it is
possible to shoot with natural colouring.
Memo 
When the white balance is adjusted, the R and B GAIN
values are set to “±0”.
1 Set the MENU button to ON.
Press the MENU button to light its indicator.
2 Set the PRESET MEMORY/MENU 4 button
(AWB/ABB) to ON.
When the button is pressed and its indicator lights, the
[AWB/ABB] menu is displayed on the LCD panel.
3 Turn the F1 dial to select the place where the
white balance is to be stored.
Select “AWB A” or “AWB B” to select the place where
the white balance is stored.
AWB MOD: AWB A
SET : AWB
 This step need not be taken when the AK-HC1500 or
AK-HC1800 is used as the remote camera.
4 Turn the F2 dial to select AWB, and press the
F2 dial.
The remote camera now automatically adjusts the white
balance, and registers it at the place selected in step
3 .
When automatic adjustment is performed, the following
details are displayed on the LCD panel.
AWB ACTIVE:
This appears while AWB is being executed.
AWB OK:
This appears for 3 seconds after AWB is completed
successfully.
AWB NG:
This appears for 3 seconds after AWB is completed
unsuccessfully.
(AWB was executed while ATW, 3200K or 5600K was
selected.)
 If it was not possible to adjust the white balance properly,
change the brightness, iris, subject, light source or other
aspect, and try adjusting it again.
The settings will differ depending on the remote camera
connected.
For further details, check the Operating Instructions of
the model concerned.
Note

11 (E)
Selecting the settings for a selected remote camera
Manually adjusting the white balance
(Setting the R and B gain values)
1 As with the automatic adjustment, fill the
screen with a white subject.
2 Connect a waveform monitor or colour monitor
to the video output connector on the currently
selected remote camera.
3 Set the MENU button to ON.
Press the MENU button to light its indicator.
4 Set the PRESET MEMORY/MENU 2 button
(R/BGAIN) to ON.
When the button is pressed and its indicator lights, the
[R/BGAIN] menu is displayed on the LCD panel.
5 Turn the F1 dial to select the R gain setting;
similarly, turn the F2 dial to select the B gain
setting.
R GAIN : ±0
B GAIN : ±0
F1 dial
F2 dial
The settings will differ depending on the remote camera
connected.
For further details, check the Operating Instructions of
the model concerned.
Note
Auto tracking white adjustment (ATW)
This function provides compensation automatically so that
the white balance is adjusted even when the light source or
colour temperature changes during shooting, so that images
that appear the least odd (that is, the most natural looking)
are produced.
1 Set the MENU button to ON.
Press the MENU button to light its indicator.
2 Set the PRESET MEMORY/MENU 4 button
(AWB/ABB) to ON.
When the button is pressed and its indicator lights, the
[AWB/ABB] menu is displayed on the LCD panel.
3 Turn the F1 dial to select ATW.
AWB MOD: ATW
SET : AWB
 If there is no white on the screen, it may not be possible
to compensate the white balance properly.
Similarly, under certain light source and colour
temperature conditions, it may not be possible to
compensate the white balance properly.
The settings will differ depending on the remote camera
connected.
For further details, check the Operating Instructions of
the model concerned.
Note

12 (E)
ENGLISH
Selecting the settings for a selected remote camera
 Setting the black balance
The black balance must be adjusted when using a remote
camera for the first time or when the remote camera has not
been used for a prolonged period of time.
It must also be adjusted when significant changes have
occurred in the ambient temperature or at the change of the
seasons.
If the camera is used with the same settings and under the
same conditions, the black balance need not be adjusted
again.
When the black balance is adjusted again, the previous
memory data will be erased and replaced with the new black
balance settings.
When the black balance is set, the R and B pedestal
adjustment settings are returned to ±0.
Automatically adjusting the black balance
1 Set the MENU button to ON.
Press the MENU button to light its indicator.
2 Set the PRESET MEMORY/MENU 4 button
(AWB/ABB) to ON.
When the button is pressed and its indicator lights, the
[AWB/ABB] menu is displayed on the LCD panel.
3 Turn the F2 dial to select ABB, and press the
F2 dial.
AWB MOD: AWB B
SET : ABB
The remote camera now automatically adjusts the black
balance.
When automatic adjustment is performed, the following
details are displayed on the LCD panel.
ABB ACTIVE:
This appears while ABB is being executed.
ABB OK:
This appears for 3 seconds after ABB was completed
successfully.
ABB NG:
This appears for 3 seconds after ABB was completed
unsuccessfully.
The settings will differ depending on the remote camera
connected.
For further details, check the Operating Instructions of
the model concerned.
Note
Manually adjusting the black balance
(Setting the R and B pedestal)
1 Connect a waveform monitor or colour monitor
to the video output connector on the currently
selected remote camera.
2 Set the MENU button to ON.
Press the MENU button to light its indicator.
3 Set the PRESET MEMORY/MENU 3 button
(R/BPED) to ON.
When the button is pressed and its indicator lights, the
[R/BPED] menu is displayed on the LCD panel.
4 Turn the F1 dial to select the R pedestal
setting; similarly, turn the F2 dial to select the
B pedestal setting.
R PED : ±0
B PED : ±0
F1 dial
F2 dial
The settings will differ depending on the remote camera
connected.
For further details, check the Operating Instructions of
the model concerned.
Note

13 (E)
Selecting the settings for a selected remote camera
 Setting the shutter speed
The shutter mode and shutter speed of the remote camera
can be selected.
1 Set the MENU button to ON.
Press the MENU button to light its indicator.
2 Set the PRESET MEMORY/MENU 5 button
(SHUTTER) to ON.
When the button is pressed and its indicator lights, the
[SHUTTER] menu is displayed on the LCD panel.
3 Turn the F1 dial to select the shutter mode.
When “Step” has been selected as the shutter mode,
the shutter speed can be selected by turning the F2 dial.
SHUTTER: Step
SPEED : 1/100
F1 dial
F2 dial
 The settings will differ depending on the remote
camera connected.
For further details, check the Operating Instructions of
the model concerned.
 When a remote camera connected serially is selected
and its shutter speed is set, and then a remote
camera in another group is assigned to the CAMERA
STATUS/SELECTION button, the shutter speed will
be set to “1/100” when a menu operation is next
performed.
Notes
 Setting the detail
The image detail (image sharpness) can be adjusted.
1 Set the MENU button to ON.
Press the MENU button to light its indicator.
2 Set the PRESET MEMORY/MENU 6 button
(DETAIL) to ON.
When the button is pressed and its indicator lights, the
[DETAIL] menu is displayed on the LCD panel.
3 Turn the F1 dial to select On or Off.
4 Turn the F2 dial to select the detail level.
DETAIL : On
LEVEL : LOW
F1 dial
F2 dial
The settings will differ depending on the remote camera
connected.
For further details, check the Operating Instructions of
the model concerned.
Note

14 (E)
ENGLISH
Selecting the settings for a selected remote camera
 Setting the shooting mode
Select the shooting mode that matches the shooting
conditions.
Select the mode according to the shooting conditions and
your preferences.
1 Set the MENU button to ON.
Press the MENU button to light its indicator.
2 Set the PRESET MEMORY/MENU 7 button
(SCENE/MODE) to ON.
When the button is pressed and its indicator lights, the
[SCENE/MODE] menu is displayed on the LCD panel.
3 Turn the F1 dial to select the shooting mode.
SCENE : MANU1
MODE : CAM
The settings will differ depending on the remote camera
connected.
For further details, check the Operating Instructions of
the model concerned.
Note
 Specifying the colour bars
The images to be output from the remote camera can be
switched between the “camera images” and “colour bars”.
1 Set the MENU button to ON.
Press the MENU button to light its indicator.
2 Set the PRESET MEMORY/MENU 7 button
(SCENE/MODE) to ON.
When the button is pressed and its indicator lights, the
[SCENE/MODE] menu is displayed on the LCD panel.
3 Turn the F2 dial to select “CAM” (camera
image) or “BAR” (colour bars).
SCENE : MANU1
MODE : BAR

15 (E)
Operating the menu items of the selected remote camera
The menu operations of the remote cameras can be operated from the unit for the remote camera which is now selected.
The CAMERA OSD button, F1 dial and F2 dial are used to perform the operations.
When the CAMERA OSD button is held down, its indicator lights, and the on-screen menu of the selected remote camera is
displayed as the output image of the remote camera.
When the button is held down again while its indicator is lit, the menu is cleared, and the indicator goes off.
POWER ALARM F1 CAMERA
OSD
R/B GAIN R/B PED
SYSTEMSETUPCAMERA
SCENE/MODE
DETAIL
DELETESTORE
PAGEMENU F2 EXIT
USER2USER1
PRESET MEMORY / MENU
GAIN/PED
F2
F1
123
AWB/ABB
4
SHUTTER
5
678910
Table of operations
Remote camera Menu ON/OFF Dial operation Menu operation
AW-HE50
Hold down the
CAMERA OSD
button.
Turn the F1 dial.
(Turn it clockwise.)
 Moves (downward) to an item.
 Changes (increments) the setting.
Turn the F1 dial.
(Turn it counterclockwise.)
 Moves (upward) to an item.
 Changes (decrements) the setting.
Press the F1 dial. Enters the setting.
AK-HC1500
AK-HC1800
AW-HE870
Hold down the
CAMERA OSD
button.
Turn the F1 dial.
(Turn it clockwise.)
 Moves (downward) to an item.
 Changes (decrements) the setting.
Turn the F1 dial.
(Turn it counterclockwise.)
 Moves (upward) to an item.
 Changes (increments) the setting.
Press the F1 dial. Enters the setting.
AW-E350
AW-E650
AW-E750
AW-E860
AW-HE100
Hold down the
CAMERA OSD
button.
Turn the F1 dial.
(Turn it clockwise.) Moves (downward) to an item.
Turn the F1 dial.
(Turn it counterclockwise.) Moves (upward) to an item.
Press the F1 dial. Enters the setting.
Turn the F2 dial.
(Turn it clockwise.)
 Enters the setting.
 Changes (increments) the setting.
Turn the F2 dial.
(Turn it counterclockwise.) Changes (decrements) the setting.
 The “on” and “off” of the indicator in the CAMERA OSD button may not correspond exactly to the menu display and
menu non-display when another remote camera has been selected while remote camera menu operations are being
performed from the unit or when the CAMERA OSD function is set to OFF by a remote camera.
In addition, the menu operations may not be performed properly.
 The operations differ depending on the remote camera model.
For details on the menu items which are displayed, check the Operating Instructions of the model concerned.
Notes

16 (E)
ENGLISH
Setting the USER buttons
Menu items can be assigned to the two USER buttons
(USER1, USER2).
The target function can be activated simply by pressing the
USER button (USER1 or USER2).
POWER ALARM F1 CAMERA
OSD
R/B GAIN R/B PED
SYSTEMSETUPCAMERA
SCENE/MODE
DETAIL
DELETESTORE
PAGEMENU F2 EXIT
USER2USER1
PRESET MEMORY / MENU
GAIN/PED
F2
F1
123
AWB/ABB
4
SHUTTER
5
678910
Menu item Details of operation performed
SWLINK This sets the link control
between the unit and switcher.
On: Enable
Off: Disable
BUSCONT This is the bus switching
setting.
On: Enable
Off: Disable
FASIST This sets the focus assist
function.
On: Enable
Off: Disable
CAMSEL This displays icons at the
bottom left of the images from
the remote camera selected
by the unit on the multi view
display of the switcher.
On: Display
Off: Non-display
TALLY_IP This sends the tally information
sent periodically by UDP from
the switcher to the remote
camera.
On: Enable
Off: Disable
CAMINF This sends the camera
information of the remote
camera selected to the
switcher.
On: Enable
Off: Disable
AWB AWB is executed when the USER button, in which
AWB has been assigned, is pressed.
When AWB is executed successfully, the indicator
of the button goes off; conversely, when it is not
executed successfully, it blinks.
ABB ABB is executed when the USER button, in which
ABB has been assigned, is pressed.
When ABB is executed successfully, the indicator
of the button goes off; conversely, when it is not
executed successfully, it blinks.
POWER OFF When the USER button in which POWER OFF
has been assigned is held down, the indicator of
the button lights for an instant, and power OFF is
requested for all the remote cameras connected.
 Registering functions in the
USER buttons
1 Set the MENU button to ON.
Press the MENU button to light its indicator.
2 Set the PRESET MEMORY/MENU 9 button
(SETUP) to ON.
When the button is pressed and its indicator lights, the
[SETUP] menu is displayed on the LCD panel.
[1]USER ▼
3 Press the F1 dial.
4 Turn the F1 dial to display [USER1] or [USER2].
1.USER1 ▼
SWLINK
5 Turn the F2 dial to select the item to be
assigned, and press the F2 dial.
1.USER1 ▼
SWLINK
1.USER1 ▼
BUSCONT
Turn the F2 dial, and then press
it.

17 (E)
Tally settings
Set enable (On) or disable (Off) for tally ON which provides
the tally instructions to the remote camera in response to
tally requests received via the GPI and network.
1 Set the MENU button to ON.
Press the MENU button to light its indicator.
2 Set PRESET MEMORY/MENU 8 button (CAMERA)
to ON.
When the button is pressed and its indicator is lit, the
[CAMERA] menu is displayed on the LCD panel.
[1]GROUP ▼
3 Turn the F1 dial to display the [TALLY] menu, and
press the F1 dial.
[3]TALLY ▲
1.TALLY OUT
Off
Press the F1 dial.
4 Turn the F2 dial to select On or Off, and then
press the F2 dial to enter the selection.
1.TALLY OUT
Off
1.TALLY OUT
On
Turn the F2 dial, and then press
it.

18 (E)
ENGLISH
Setting the functions
This section describes how the unit’s functions are set.
The following functions can be set.
 Setting of the remote camera operations
 Registration of functions in the USER buttons
 Setting the speed at which to move to the preset memory
setting position
 Setting the control items used when preset data is
executed
 Controlling the peripheral devices connected to the
remote cameras
• ND filter
• AC adapter
(AW-PS300A)
• Defroster
• Wiper
• Heater, fan
• Halogen lamp
 Assignment of preset data when emergency interrupts
occur
 Locking of button operations
The settings are established using the [SETUP] menu.
First, the basic menu operations will be described.
1 Set the MENU button to ON.
Press the MENU button to light its indicator.
2 Set the PRESET MEMORY/MENU 9 button
(SETUP) to ON.
When the button is pressed and its indicator lights, the
[SETUP] menu is displayed on the LCD panel.
[1]USER ▼
3 Turn the F1 dial to display the target menu
item, and press the F1 dial.
For details on the [SETUP] menu items, refer to the
“Table of menu items”.
[4]OPERATE
1.PAN DIR ▼
NORMAL
Press the F1 dial.
4 Turn the F1 dial to select the target menu item.
2.TILT DIR
NORMAL
1.PAN DIR ▼
NORMAL
Turn the F1 dial.
5 Turn the F2 dial to select the setting.
Then press the F2 dial to change the setting.
2.TILT DIR
NORMAL
2.TILT DIR
REVERSE
Turn the F2 dial, and then press
it.

19 (E)
Setting the functions
 Setting the remote camera
operations
Set these operations by selecting the [SETUP] menu
followed by the [OPERATE] menu.
[4]OPERATE
 Setting the pan, tilt, zoom and focus
operation directions
Set the directions in which the remote camera is to move
when the panning, tilting, zooming or focusing operation has
been initiated from the unit.
Setting the panning direction
From the [SETUP] menu, select [OPERATE] and display
[PAN DIR]. Then select either “NORMAL” or “REVERSE”.
1.PAN DIR ▼
NORMAL
This sets the operation of the remote camera in the
horizontal direction in response to the horizontal
manipulation of the PAN/TILT lever.
When “NORMAL” is selected as the setting, the remote
camera will move to the left when the PAN/TILT lever is
leaned toward the left and, conversely, it will move to the
right when the lever is leaned toward the right.
When “REVERSE” is selected, the remote camera will move
in the opposite directions.
Setting the tilting direction
From the [SETUP] menu, select [OPERATE] and display
[TILT DIR]. Then select either “NORMAL” or “REVERSE”.
2.TILT DIR
NORMAL
This sets the operation of the remote camera in the vertical
direction in response to the vertical manipulation of the
PAN/TILT lever.
When “NORMAL” is selected as the setting, the remote
camera will move upward when the PAN/TILT lever is leaned
away from you and, conversely, it will move downward when
the lever is leaned toward you.
When “REVERSE” is selected, the remote camera will move
in the opposite directions.
Setting the zooming direction
From the [SETUP] menu, select [OPERATE] and display
[ZOOM DIR].Then select either “NORMAL” or “REVERSE”.
3.ZOOM DIR
NORMAL
This sets the zooming operation of the lens in response to
the operation of the ZOOM button.
When “NORMAL” is selected as the setting, the lens zooms
toward the tele end when the TELE side of the ZOOM button
is pressed and, conversely, it will zoom toward the wide end
when the WIDE side is pressed.
When “REVERSE” is selected, the lens will move in the
opposite directions.
Setting the focusing direction
From the [SETUP] menu, select [OPERATE] and display
[FOCUS DIR]. Then select either “NORMAL” or “REVERSE”.
4.FOCUS DIR
NORMAL
This sets the focusing operation of the lens in response to
the operation of the FOCUS/PUSH OTAF dial.
When “NORMAL” is selected as the setting, the lens focus
moves toward the far end when the dial is turned clockwise
and, conversely, it will move toward the near end when the
dial is turned counterclockwise.
When “REVERSE” is selected, the lens will move in the
opposite directions.
