Panduit SmartZone EP042 User manual

Release 1.0
Issue 2
SmartZone™ Gateway EP042
User Manual

SmartZone Gateway EP042 User Manual
-2-
Copyright © 2014 Panduit Corp. All rights reserved. No part of this book shall be reproduced, stored in a retrieval system, or transmitted
by any means, electronic, mechanical, photocopying, recording or otherwise, without written permission from Panduit. No patent liability
is assumed with respect to the use of the information contained herein.
Although every precaution has been taken in the preparation of this book, Panduit assumes no responsibility for errors or omissions.
Neither is any liability assumed for damages resulting from the use of the information contained herein.

SmartZone Gateway EP042 User Manual
-3-
Table of Contents
Introduction 7
Overview 7
Safety and Installation Statement 7
Grounding 7
Servicing 8
Waste Electrical and Electronic Equipment (WEEE) Statements 8
Disposal of Waste Equipment by Users in Private Households in the European
Union 8
SmartZone Gateway Applications 10
Remote Temperature and Humidity Sensing 10
Power Monitoring 10
SmartZone Gateway EP042 Package 11
Front of Gateway EP042 11
LEDs 11
Buttons 11
Rear of Gateway EP042 12
110VAC ~ 230VAC Version 12
-48v DC Version 13
Ports 13
Installation Requirements 15
Rack Mounting 15
Additional Equipment Required 15
Before You Begin 15
Installation Warnings 15
Attaching the Brackets 16
Initial Setup 18
Default Settings 18
Connecting to the Web Management Interface 18
Changing your PC's IP Address 18
Connecting to the SmartZone Gateway Web Management Interface 23
Initial Network Setup 25
Entering NMS Details 25
Entering Trap Receiver Details 25
Adding Users 26
Changing the Unit IP Address 27
Setup - IP Configuration 29
System Name 29
System Location 29
Contact Name 30
IP Address 30
Subnet Mask 30

SmartZone Gateway EP042 User Manual
-4-
Gateway 30
Setup - HTTP 31
Setup – LDAP Servers 32
Disabled 32
Primary 32
Secondary 33
Both 33
Credential Cache 33
Display Name 33
IP Address 33
Unit Base DN 33
Users Base DN 1 33
Users Base DN 2 33
Setup - SNMP NMS 34
IP Address 34
Community String 34
NMS Access 34
Setup - SNMP Trap Receivers 35
IP Address 35
Community String 35
Receive Traps 35
Setup - Modbus 36
Setup - Users 37
Username 37
Password 37
Level 37
Setup - Email Alerts 38
Setup - Time Settings 39
Time Adjustments 39
Setup - Syslog Servers 40
Setup - Preferences 40
Setup – Restart 41
Restart Unit 42
Restart Now 42
Reset to Factory Defaults 42
Sensor Inputs – Configuration and Status 43
Status 43
Status Indicators 43
Input Sensors – Defaults 43
Calibration Offset 44
Hysteresis Value 44
Limits and Traps 45
Repeat Timer 45
Normal State 46

SmartZone Gateway EP042 User Manual
-5-
Trigger Type 46
Level 46
Normal to Non-Normal (Positive Edge) 46
Non-Normal to Normal (Negative Edge) 46
Input Sensors - Configure 47
Name 47
Type 47
PDUs – Configuration and Status 49
PDU Status 49
Status Indicators 49
Configuring PDUs 50
Control Method 51
HTTP + SNMP 51
HTTP Only 51
SNMP Only 51
RS232 Only 51
Cycle Up/Down Delay 51
Repeat Timer (on Comms Failure) 51
Reboot Delay 51
Abort Cycle Delay 51
Power – Configure Menu 52
RMS Volts 53
RMS Current 54
Total Power 54
PDU Outlets 54
PDUs – Control 54
Switching Individual Sockets 55
Switching an Entire PDU 56
LDAP 56
SmartZone Gateway LDAP Overview 56
SmartZone Gateway LDAP Structure 57
Group Membership and Access Level 58
Gateway AdminUsers 58
Gateway ControlUsers 59
Gateway ViewUsers 59
SmartZone Gateway Unit Configuration 59
Temperature Sensor Adapter Installation 61
New Installations 61
Existing Installations. 62
Fitting the Adapter In-line. 62
Troubleshooting 64
Resetting the SmartZone Gateway to Factory Default Settings 64
Problem: The NMS Cannot Poll the SmartZone Gateway Unit 64
Technical Support 65

SmartZone Gateway EP042 User Manual
-6-
Appendix A: Technical Details 66
Factory Default Settings 66
Operating Information 66
Unit DimensionsAC) 67
Unit Dimensions (-48VDC) 67
Appendix B: Hysteresis Demystified 68
Appendix C: Encryption and Security 70

SmartZone Gateway EP042 User Manual
-7-
Introduction
Overview
The SmartZone Gateway EP042 is a compact device used to monitor up to two PDUs
within a rack enclosure, along with four input sensors (Temperature, Humidity, and
Digital or Analog voltage).
The unit comprises an Simple Network Management Protocol (SNMP) interface and a
secure web-based interface for monitoring and management.
Gateway EP042 unit features include:
lSecure web management and configuration interface.
lSNMP enabled
lFour sensor channels
lMonitoring of up to two PDUs
lOptional LCD Status module
Safety and Installation Statement
Grounding
This is a Class II product that uses double insulation to provide electrical safety of the
product from the main power source.
To ensure correct operation, compliance with Class A and Class B electromagnetic emis-
sion standards, and optimal safety, connect the 4mm grounding stud (labeled “Earth” on
rear face of unit) to an electrical ground.
If the network covers an area served by more than one PDU, be sure their electrical
safety grounds are securely interconnected.
Network cabling may occasionally be subject to hazardous transient voltages (such as
lightning or disturbances in the electrical utilities power grid). Handle exposed metal
components of the installation with caution.

SmartZone Gateway EP042 User Manual
-8-
Servicing
There are no user-serviceable parts inside these products. Any maintenance or repair
must be performed by approved service-trained personnel.
This product does not have a power switch; it is powered on when the adapter’s power
cord is plugged in.
Waste Electrical and Electronic Equipment
(WEEE) Statements
Disposal of Waste Equipment by Users in Private House-
holds in the European Union
This product must not be disposed of with your other household waste. It is your respons-
ibility to dispose of your WEEE equipment by handing it over to a designated collection
point for the recycling of waste electrical and electronic equipment.
For more information about where you can drop off your waste equipment for recycling,
please contact your local city or council office, your household waste disposal service or
the organization where you purchased the product.
EC Declaration of Conformity
In accordance with EN ISO 17050-1:2005
In accordance with the following Directives:
2006/95/EC The Low Voltage Directive
2004/108/EC The Electromagnetic Compatibility Directive
2002/95/EC The Restriction of the Use of certain Hazardous Substances in Electrical
and Electronic Equipment (RoHS)
1907/2006/EC The Registration, Evaluation, Authorization & Restriction of Chemicals.
(REACH)
The equipment:SmartZone Gateway
Is in conformity with the applicable requirements of the following documents

SmartZone Gateway EP042 User Manual
-9-
Ref No. Title
BS EN 55022:2010 Information technology equipment. Radio disturbance char-
acteristics. Limits and methods of measurement. Class A.
BS EN 55024:2010 Information technology equipment. Immunity characteristics.
Limits and methods of measurement.
BS EN 60950-
1:2006+A12: 2011
Information technology equipment. Safety. General require-
ments.

SmartZone Gateway EP042 User Manual
-10 -
SmartZone Gateway Applications
Remote Temperature and Humidity Sensing
The SmartZone Gateway monitors temperature and humidity and raises alarms or takes
action if a user-configured threshold is crossed.
Power Monitoring
This equipment allows around-the-clock monitoring of the electrical power environment
of the rack.

SmartZone Gateway EP042 User Manual
-11 -
SmartZone Gateway EP042 Package
The standard Gateway EP042 package contains a Gateway EP042 unit with supporting
hardware:
lGateway EP042 l Unit
lMains voltage cable (AC version only)
lRack mounting kit
lSupporting CD-ROM including MIB file and manuals
Front of Gateway EP042
LEDs
Three LEDs can be found on the front of the Gateway EP042.
lCPU: Indicates system activity.
lAlarm: Indicates that there is an alarm present on the unit.
lPower - On: Illuminates when unit is powered.
Buttons
Also found on the front of the Gateway EP042, are the following two buttons.

SmartZone Gateway EP042 User Manual
-12 -
lReset: Allows the user to reboot the unit.
lMode: The mode select switch is used to reset the unit to factory defaults.
Rear of Gateway EP042
110VAC ~ 230VAC Version
The following images show the rear panel of the Gateway EP042 unit:

SmartZone Gateway EP042 User Manual
-13 -
-48v DC Version
Ports
lPower Feed: Connection for Mains or -48v DC voltage.
lEarth: Grounding stud.
lIntelligent PDU Ports 1 and 2: Connect up to two power devices (such as Gate-
way-Enabled Rack PDUs, Inline Meters, and Clamp Meters).

SmartZone Gateway EP042 User Manual
-14 -
lAuto-Detect Sensors 1 through 4: Connect up to four sensors (such as Tem-
perature, Humidity, Water, Door Contacts, and more).
lSerial Port: Attach optional devices (such as an LCD Status Monitor Unit).
lNetwork Port: An RJ-45 connection provides Ethernet and Fast Ethernet con-
nectivity to the Gateway EP042.

SmartZone Gateway EP042 User Manual
-15 -
Installation Requirements
lSmartZone Gateway unit
lMain power cable (supplied)
l10/100baseT network connection
lNetwork-connected computer system to setup the Gateway
l1 x network crossover cable
lScrewdrivers
Rack Mounting
This section covers the rack-mounting of the SmartZone Gateway unit.
Additional Equipment Required
Along with the installation requirements listed above, you need a number-1 and a num-
ber-2 Phillips screwdriver to rack-mount the SmartZone Gateway unit.
Before You Begin
When determining where to install the Gateway, verify that these guidelines are met:
lAirflow around the Gateway unit is unrestricted.
lFront-panel LEDs can be easily read.
lAccess to ports is sufficient for unrestricted cabling.
lAC/DCpower cord can reach the Gateway unit.
lThe 10/100 network cabling does not exceed 100 meters from the Gateway unit to
the Network switch.
lTemperature around the Gateway unit does not exceed 40° C.
lRelative humidity around the Gateway unit does not exceed 90 %.
Installation Warnings
lOnly trained and qualified personnel should be allowed to install, replace, or ser-
vice this equipment.
lTo prevent the Gateway unit from overheating, do not operate in an area that
exceeds the maximum recommended ambient temperature of 40° C.

SmartZone Gateway EP042 User Manual
-16 -
lInstallation of the Gateway unit must comply with local and national electrical
codes.
lTo prevent personal injury when mounting or servicing the Gateway unit, ensure
that the rack or cabinet is adequately secured so that the system remains stable.
lCircuit Overloading - Consult the equipment nameplate ratings when connecting
the equipment to the supply circuit to avoid overloading of circuits, which can
adversely affect current protection and supply wiring.
lMaintain reliable grounding of rack-mounted equipment. Particular attention should
be given to supply connections other than direct connections to the branch circuit
(for example, the use of PDUs)..
Attaching the Brackets
lThe Gateway EP042 is not a full 1RU. It is recommended that the Gateway be
mounted to the rack vertically using mounting brackets.
lUsing a Phillips number-1 screwdriver, use the screws supplied with the Gateway
EP042 bracket.Place the mounting bracket on the ends of the Gateway EP042
and secure using the two screws.
lHold the Gateway EP042 and attach the bracket to the rack using two 12-24
screws.

SmartZone Gateway EP042 User Manual
-17 -

SmartZone Gateway EP042 User Manual
-18 -
Initial Setup
Default Settings
The SmartZone Gateway unit in factory default condition has the following network con-
figuration. Advanced users may wish to make use of these settings to access the Gate-
way unit's Web Management Interface immediately and proceed with configuration.
Users who do not know how to do this should proceed through this section for inform-
ation on how to configure the Gateway unit.
IP Address 192.168.0.253
Subnet Mask 255.255.255.0
Default Gateway 192.168.0.1
Web Management Address http://192.168.0.253/
Default username admin
Default password admin
Note: Password entries are case-sensitive.
Connecting to the Web Management Interface
The SmartZone Gateway monitoring solution can be configured entirely using the built-
in Web Management Interface.
You may need to change the IP address of the PC to connect to the Web Management
Interface for the first time. The following section details how to change the IP address
and connect to the Web Management Interface.
Changing your PC's IP Address
Note: Instructions refer specifically to Windows 7. Please refer to your operating system
documentation if you are not using Windows 7.
1. Click the Windows button and select Control Panel.

SmartZone Gateway EP042 User Manual
-19 -
2. In the Control Panel window, select View network status and tasks under the Net-
work and Internet heading.

SmartZone Gateway EP042 User Manual
-20 -
3. Select Change adapter settings from the menu on the left.
