Panduit smartzone G5 User manual

Intelligent PDU User Manual v4.2

INTELLIGENT PDU USER MANUAL
2
Table of Contents
Section 1 – System Overview ........................................................................................ 9
PDU Controller ........................................................................................................... 9
Connecting the PDU via Ethernet Port ....................................................................... 9
Connecting the PDU to a Computer Serial Port ........................................................ 10
Section 2 – Web Graphical User Interface (GUI) Configuration.................................... 11
Internet Protocol (IP) Addressing.............................................................................. 11
Connecting to the PDU............................................................................................. 11
Web Configuration.................................................................................................... 11
Introduction to the Web GUI ..................................................................................... 15
Screen Resize Due to Multiple PDU Configuration ................................................... 17
Menu Dropdowns.................................................................................................. 18
Introduction to the Dashboard .................................................................................. 18
Network Settings ...................................................................................................... 19
System Management Information............................................................................. 21
Setting Time and Date on the PDU .......................................................................... 24
Outlet Power Management....................................................................................... 27
Outlet Power Sequence Setup ................................................................................. 28
Setting Metering Thresholds..................................................................................... 30
Email Setup.............................................................................................................. 42
Data Log .................................................................................................................. 46
Web Interface Access .............................................................................................. 47
Setting Up the System for RADIUS Authentication ................................................... 49
Configuring the system with LDAP Server Settings .................................................. 50
Section 3 – Simple Network Management Protocol (SNMP) ........................................ 55
SNMP Management Configuration ........................................................................... 55
Configuring Users for SNMP V1/V2c ........................................................................ 57
Configuring Users for SNMP v3................................................................................ 59

INTELLIGENT PDU USER MANUAL
3
Configuring SNMP Traps.......................................................................................... 61
Section 4 – Local Display............................................................................................. 64
Onboard Display and Network Controller ................................................................. 64
Control Buttons ..................................................................................................... 65
Network Controller Menu Structure .......................................................................... 66
Main Menu Selections........................................................................................... 66
Setup Menu .......................................................................................................... 67
Sensors Menu .......................................................................................................... 80
Section 5 – Daisy Chain Configuration......................................................................... 81
Daisy-Chain Overview .............................................................................................. 81
Daisy-Chain Setup ................................................................................................... 81
RNA (Redundant Network Access) Functionality...................................................... 81
RNA Setup ............................................................................................................... 82
Power Share ............................................................................................................ 84
Section 6 – SmartZone Security Handle ...................................................................... 87
Configuring Cabinet Access Control ......................................................................... 89
Adding a User for Local Rack Access....................................................................... 91
Configuring Rack Access Settings............................................................................ 92
Configuring Handle Settings. .................................................................................... 93
Configuring Keypad Settings .................................................................................... 94
Remote Controlling the Handle................................................................................. 95
Controlling the Beacon. ............................................................................................ 97
The Status LED ........................................................................................................ 99
Setting Status LED State........................................................................................ 100
Handle and Compatible Card Types....................................................................... 100
Section 7 – SmartZone G5 Accessories..................................................................... 101
Hardware Overview................................................................................................ 101
Configuring Temperature Scale.............................................................................. 103
Configuring Environmental Sensors ....................................................................... 103

INTELLIGENT PDU USER MANUAL
4
Warranty and Regulatory Information ........................................................................ 105
Warranty Information .............................................................................................. 105
Regulatory Information ........................................................................................... 105
Panduit Support and Other Resources....................................................................... 106
Accessing Panduit Support .................................................................................... 106
Acronyms and Abbreviations ..................................................................................... 107
Appendix A: Sensor Configuration ............................................................................. 109
Door Switch Sensor................................................................................................ 109
Dry Contact Input Sensor (side panel switch) ......................................................... 109
Temperature & Humidity Sensors........................................................................... 110
Configuring Environmental Sensors ....................................................................... 111
Appendix B: Firmware Upgrade Options .................................................................... 113
Web Interface Method ............................................................................................ 113
G5 Upgrade Utility (GUT) ....................................................................................... 113
USB Method........................................................................................................... 114
FTPs Method.......................................................................................................... 114
Appendix C: Bulk Management of PDUs.................................................................... 116
G5 Upgrade Tool (GUT) ......................................................................................... 116
Appendix D: System Reset or Password Recovery.................................................... 119
Appendix E: PDU Alarms ........................................................................................... 120
Trap Codes assigned to Alarms List ....................................................................... 122
Appendix F: Panduit Network Controller Replace or Rotate 180°............................... 128
Appendix G: Direct connect to the PDU by Changing Your PC’s IP Address ............. 130
Appendix H: Command Line Interface (CLI)............................................................... 136
CLI Commands ...................................................................................................... 139
Network Commands ............................................................................................... 141
User Commands .................................................................................................... 143
Device Commands ................................................................................................. 143
Power Commands.................................................................................................. 145

INTELLIGENT PDU USER MANUAL
5
Appendix I: RADIUS Server Configuration ................................................................. 148
Appendix J: Panduit G5 Accessories ......................................................................... 150
Appendix K: Compliance Model Number Details........................................................ 151
Appendix L: JSON API Web Service.......................................................................... 152

INTELLIGENT PDU USER MANUAL
6
Table of Figures
Figure 1: Ethernet Port for Network Connection............................................................. 9
Figure 2: Status LED & Serial In Port Identified............................................................ 10
Figure 3: Changing Your Password ............................................................................. 12
Figure 4: After Login .................................................................................................... 12
Figure 5: Change User Password ................................................................................ 13
Figure 6: Change Password......................................................................................... 13
Figure 7: Login Page.................................................................................................... 15
Figure 8: Landing Page/Dashboard ............................................................................. 15
Figure 9 - Resized Dashboard Screen ......................................................................... 17
Figure 10: Power Summary Page ................................................................................ 18
Figure 11: Outlet Monitoring Page ............................................................................... 19
Figure 12: Environmental Monitoring Page .................................................................. 19
Figure 13: Security Monitoring Page ............................................................................ 19
Figure 14: System Management .................................................................................. 21
Figure 15: System Management Configuration ............................................................ 22
Figure 16: Rack Location Configuration ....................................................................... 23
Figure 17: Power Panel & Core Location ..................................................................... 24
Figure 18: NTP Configuration ...................................................................................... 25
Figure 19: Daylight Saving Time Configuration ............................................................ 26
Figure 20: Control & Manage PDU............................................................................... 28
Figure 21: Outlet Control Enabled................................................................................ 29
Figure 22: Edit Outlets ................................................................................................. 29
Figure 23: One-Delay Time.......................................................................................... 30
Figure 24: Saved Sequence......................................................................................... 30
Figure 25: Power Threshold......................................................................................... 31
Figure 26: Energy Threshold........................................................................................ 33
Figure 27: Phase Current Alarm................................................................................... 34
Figure 28: Phase Voltage Alarm .................................................................................. 36
Figure 29: Load Segment Breaker ............................................................................... 38
Figure 30: Device Detection Threshold Information...................................................... 40
Figure 31: Outlet Information ....................................................................................... 41
Figure 32: Email Setup ................................................................................................ 43
Figure 33: SMTP Account Settings .............................................................................. 44
Figure 34: Email Recipients ......................................................................................... 45
Figure 35: Data Log ..................................................................................................... 46
Figure 36: Data Log Configuration ............................................................................... 47
Figure 37: User Settings .............................................................................................. 49

INTELLIGENT PDU USER MANUAL
7
Figure 38: RADIUS Configuration ................................................................................ 50
Figure 39: LDAP Configuration .................................................................................... 52
Figure 40: Enable Role Privileges ................................................................................ 53
Figure 41: Test LDAP Configuration ............................................................................ 54
Figure 42: SNMP Management.................................................................................... 55
Figure 43: SNMP General............................................................................................ 56
Figure 44: SNMP Port .................................................................................................. 57
Figure 45: Setup SNMP Port and Trap Port ................................................................. 57
Figure 46: Define SNMP V1/V2c User ......................................................................... 58
Figure 47: Edit V1/2c Manager .................................................................................... 58
Figure 48: SNMP V3 Manager ..................................................................................... 59
Figure 49: SNMP V3 Edit ............................................................................................. 60
Figure 50: SNMPv2 Configuration Information ............................................................. 61
Figure 51: SNMPv3 Trap Server Information. .............................................................. 62
Figure 52: Network Controller ...................................................................................... 64
Figure 53: Network Controller Menu Structure ............................................................. 66
Figure 54: Main Menu Selections................................................................................. 67
Figure 55: Setup Menu ................................................................................................ 67
Figure 56: Network Submenu ...................................................................................... 68
Figure 57: Device Submenu......................................................................................... 69
Figure 58: Screen Submenu ........................................................................................ 70
Figure 59: Language Submenu.................................................................................... 71
Figure 60: USB Submenu ............................................................................................ 72
Figure 61: Units Submenu ........................................................................................... 73
Figure 62: Alarms Menu............................................................................................... 74
Figure 63: Power Menu................................................................................................ 75
Figure 64: Device Submenu......................................................................................... 76
Figure 65: Phase Submenu ......................................................................................... 77
Figure 66: Breaker Submenu ....................................................................................... 78
Figure 67: Outlet Submenu .......................................................................................... 79
Figure 68: Sensors....................................................................................................... 80
Figure 69: Connection Diagram RNA Daisy Chain....................................................... 82
Figure 70: Connection Diagram Power Share & Daisy Chain....................................... 85
Figure 71: SmartZone Security Handles ...................................................................... 87
Figure 72: Connection Diagram for SmartZone Security Handle .................................. 88
Figure 73: Rack Access Control Web GUI ................................................................... 90
Figure 74: Rack Access Control Actions Web GUI....................................................... 90
Figure 75: Local Rack Access Web GUI ...................................................................... 92

INTELLIGENT PDU USER MANUAL
8
Figure 76: Rack Access Settings Web GUI.................................................................. 93
Figure 77: Handle Settings Web GUI ........................................................................... 94
Figure 78: Remote Control........................................................................................... 96
Figure 79: Beacon........................................................................................................ 97
Figure 80: Beacon Settings Web GUI .......................................................................... 98
Figure 81: Status LED Settings Web GUI .................................................................. 100
Figure 82: Sensor Ports for Vertical PDU................................................................... 102
Figure 83: Sensor Ports for Horizontal PDU............................................................... 103
Figure 84: User Settings ............................................................................................ 103
Figure 85:Celcius Setting ........................................................................................... 103
Figure 86: Fahrenheit Setting..................................................................................... 103
Figure 88: Door Switch Sensor Configuration ............................................................ 109
Figure 89: Dry Contact Cable..................................................................................... 110
Figure 90: Temperature and Humidity Sensors.......................................................... 111
Figure 91: Sensor Ports on controller......................................................................... 112
Figure 92: Upload Firmware....................................................................................... 113
Figure 93: G5 Upgrade Tool Interface........................................................................ 116
Figure 94: System Management Screen WebGUI ..................................................... 117
Figure 95: G5 Upgrade Tool Interface........................................................................ 117
Figure 96: Example CSV File..................................................................................... 118
Figure 97: G5 Upgrade Tool Interface........................................................................ 118
Figure 98: Screws on Network Controller................................................................... 128
Figure 99: Ribbon Cable for the Network Controller ................................................... 129
Figure 100: Control Panel .......................................................................................... 130
Figure 101: Network Status and Tasks ...................................................................... 131
Figure 102: Change Adapter Settings ........................................................................ 132
Figure 103: Properties ............................................................................................... 132
Figure 104: Ethernet Properties ................................................................................. 133
Figure 105: Internet Protocol Version 4...................................................................... 134
Figure 106: IP Settings for Direct Connection ............................................................ 135
Figure 107: Connect MA017 to the PDU In/Serial port ............................................... 137
Figure 108: Serial Cable Pinout ................................................................................. 138

INTELLIGENT PDU USER MANUAL
9
Section 1 – System Overview
PDU Controller
All Panduit G5 Intelligent PDUs feature a Rotatable or Hot Swappable PDU Controller.
This centralized piece of intelligent hardware receives an IP address, contains a
Graphical Web Interface and is addressable over the network.
Connecting the PDU via Ethernet Port
Connecting the PDU to a LAN provides communication through an Internet or Intranet
connection enabling monitoring and control over the intelligent power distribution unit.
1. Connect an Ethernet cable to the Ethernet port on the PDU (see Figure 1).
2. Connect the other end of the cable to the Ethernet port on the router (or another
LAN device).
Figure 1: Ethernet Port for Network Connection
From the factory the PDU defaults to DHCP and HTTPSconnection. If you are
connected to a network with a DHCP server, the PDU automatically receives an IP
address and will display it on the OLED screen. If there is no DHCP server after several
minutes, the PDU defaults to IP address is 192.168.0.1, which will be displayed on the
PDU OLED screen. If the network cable is unplugged and plugged back in, the PDU
will restart the DHCP server search process.
Network

INTELLIGENT PDU USER MANUAL
10
Connecting the PDU to a Computer Serial Port
If unable to connect to network, you can change the network setting using the serial
interface.
To configure the network setting, perform the following steps:
1. Serial connect the PDU to a computer’s serial port. Set baud rate for a terminal
emulation program.
2. Using a CLI command to enable DHCP or set a static IP.
3. Verify access to the Web interface. The Ethernet LED on the PDU front panel
provides communication status by color and display activity (see Figure 2).
Figure 2: Status LED & Serial In Port Identified
Additional details in Appendix G.
Status LED
Serial In

INTELLIGENT PDU USER MANUAL
11
Section 2 – Web Graphical User Interface (GUI)
Configuration
Internet Protocol (IP) Addressing
After the PDU receives an IP address, login to the Web interface to configure the PDU
and assign a static IP address (if desired).
Connecting to the PDU
1. Ethernet port on the PDU indicates solid green light on the right and a flashing
yellow light on the left. This indicates successful connectivity to the network.
2. Use the menu buttons to look up the IP address of the device on the OLED display
by selecting Setup > Network > IPv4 or IPv6 as applicable.
3. In a standard web browser, enter the PDU IP address (“https://IP ADDRESS”) and
proceed to configure the PDU as shown in the Web Configuration section.
Web Configuration
Supported Web Browsers
The supported Web browsers are Google Chrome (mobile and desktop), Mozilla
Firefox, Microsoft Edge and Apple Safari (mobile and desktop).
Changing Your Password
At initial login, you are required to change the default password:
1. Enter the current password and new password twice to confirm. By default,
passwords must be between 8 and 32 characters.

INTELLIGENT PDU USER MANUAL
12
Figure 3: Changing Your Password
2. Click Change Password to complete the password change.
After the initial login, change the password by the following steps:
Figure 4: After Login
2. The Change User Password window opens.

INTELLIGENT PDU USER MANUAL
13
Figure 5: Change User Password
Figure 6: Change Password
4. Click Change Password to complete the password change.
Logging in to the Web Interface
•Open a supported web browser and enter the IP address of the PDU (HTTPS)
•If browser displays “refused to connect” please double check that you are using
the “https://” protocol not “http://”

INTELLIGENT PDU USER MANUAL
14
oIf username and password have NOT been configured, use the default
username: admin and password: 12345678. For security purposes, a
change of password is required upon initial login.
oIf admin credentials are lost use Appendix D to factory reset the PDU.

INTELLIGENT PDU USER MANUAL
15
Introduction to the Web GUI
Login Page Note: https:// must be used (for initial login)
Figure 7: Login Page
Figure 8: Landing Page/Dashboard

INTELLIGENT PDU USER MANUAL
16
Number
Icon
Description
1
The home icon provides an
overview of the PDU with
access to the Dashboard,
Identification, and Control
& Manage.
2
The Alarm icon provides
details of the active critical
alarms and active warning
alarms.
3
This icon lets you select a
Language. There are
seven languages available
to choose from: English,
Chinese, French, Italian,
German, Spanish, Korean
and Japanese.
4
This icon provides the logs
of the PDU which can be
viewed and downloaded.
•The Data Log is a
log of the Power,
Environmental, and
Security values.
5
The settings icon allows a
user to setup the Network
Settings, System
Management, SNMP
Manager, Email Setup,
Event Notifications, Trap
Receiver, Thresholds, and
Rack Access Control.
6
The search icon allows you
to input key words and
search for the related
results.
7
Information about the PDU
can be found using this
icon. You also can also

INTELLIGENT PDU USER MANUAL
17
Number
Icon
Description
click user guide and
license to ask for help.
8
This icon shows who is
logged in (user or admin).
Account passwords can be
changed, and user
accounts managed
through this page.
Screen Resize Due to Multiple PDU Configuration
Resizing a Screen
Multiple PDUs can now cause the user to resize the screen to fit the information on the
dashboard due to the update.
Figure 9 - Resized Dashboard Screen

INTELLIGENT PDU USER MANUAL
18
Menu Dropdowns
Overview
Alarms
Help
Language
Logs
Settings
Admin
Introduction to the Dashboard
Power Summary Page
Figure 10: Power Summary Page

INTELLIGENT PDU USER MANUAL
19
Outlet Monitoring Page
Figure 11: Outlet Monitoring Page
Environmental Monitoring Page
Figure 12: Environmental Monitoring Page
Security Monitoring Page
Figure 13: Security Monitoring Page
Network Settings
The Network Settings allow management of IP Configuration, Web RESTapi Access
Configuration, SSH/FTPs Configuration, Network Time Protocol (NTP), Date/Time
Settings and Daylight-Savings Time.

INTELLIGENT PDU USER MANUAL
20
IP Configuration:
Web RESTapi Access Configuration can be used to set HTTP, HTTPS or Disable the
onboard Web GUI.
