Installation Guide
AT-UHD-SW-510W
4K/UHD Five-Input Universal Switcher with Wireless
Presentation Link
AT-UHD-SW-510W
The Atlona AT-UHD-SW-510W is a 5×1 multi-format switcher with wireless presentation
capability. It provides universal BYOD (bring your own device) compatibility with HDMI,
DisplayPort, and USB-C inputs, plus wireless connectivity for mobile devices. The SW-510W
is HDCP 2.2 compliant, and features an HDMI output and a mirrored HDBaseT™ output that
can be used with the Atlona AT-UHD-EX-100CE-RX-PSE HDBaseT receiver. It also includes
automatic input switching and automatic display control capability, both applicable to wired and
wireless source connections. Additionally, the SW-510W can be integrated with an occupancy
sensor to automatically power up the unit and display (available in rmware 1.1 or greater).
This unique multi-format switcher and wireless gateway provides a universal connectivity solution
for presentation devices in a wide range of professional AV applications.
IMPORTANT: Visit http://www.atlona.com/product/AT-UHD-SW-510W for the latest
rmware updates and User Manual.
1 x AT-UHD-SW-510W
1 x Captive screw connector, 5-pin
1 x Captive screw connector, 4-pin
2 x Captive screw connector, 3-pin
2 x Wi-Fi antenna modules
1 x USB-C cable, 2 meters
1 x 24 V DC power supply
2 x Mounting plates
4 x Mounting screws
1 x Installation Guide
Package Contents

2
Installation Guide
AT-UHD-SW-510W
1 Input Indicators
Displays the currently selected input.
2 INPUT
Press this button to cycle through each input. This button is also used to toggle the IP
mode. Refer to page 10, for details.
3 IP
Press this button to display the IP address of the AT-UHD-SW-510W on the connected
display.
4 POWER
Press and hold this button for ve seconds to power-o the AT-UHD-SW-510W. To power-
on the unit, disconnect and reconnect the power cord on the rear panel.
5 DISPLAY
Press this button to toggle the power state of the display or can be used to reset the unit.
Refer to page 8, for details.
Front
Panel Descriptions
LAN DC 24V
HDBaseT OUT
HDMI OUTHDMI IN
DP IN
USB-C IN
2 3 4
1
RELAY RS-232
TRIGGER I/O
MIRACASTWiFi AUX
AUDIO
OUT
L R
IN
USB +
C1 COM C2 RX
PTX
+
+
USB
USB
USB
USB-C
DP
HDMI 3
HDMI 4
BYOD
DISPLAY
INPUT POWER
AT-UHD-SW-510W
IP
2 3 4 51

3
Installation Guide
AT-UHD-SW-510W
1 AUDIO IN
Connect a 3.5 mm mini-stereo cable from an analog audio source to this connector.
2 AUDIO OUT
Use the included captive screw connector to connect a balanced audio device.
3 USB
Connect the included Wi-Fi antenna to these ports. The AUX port is reserved. Refer to
Installation on page 9 for more information.
4 RELAY
Connect one of the included 3-pin captive screw connectors to this port to control screens,
drapes, lights, or other devices.
5 TRIGGER I/O
Connect voltage-controlled device to this port. A 4-pin captive screw connector is required.
6 RS-232
Use the included captive screw connector to connect an RS-232 controller or automation
system.
7 USB-C
Connect a USB-C cable from this port to a USB-C source.
8 DP IN
Connect a DisplayPort device to this port.
9 HDMI IN
Connect an HDMI cable from each of these ports to a UHD/HD source.
10 HDMI OUT
Connect an HDMI cable from this port
to an HD/UHD display.
11 HDBaseT OUT
Connect to a locally powered HDBaseT receiver such as the AT-UHD-EX-100CE-RX-PSE.
12 LAN
Connect an Ethernet cable from this port to the network.
13 DC 24V
Connect the included power supply to this power receptacle.
Panel Descriptions
LAN DC 24V
HDBaseT OUT
HDMI OUTHDMI IN
DP IN
USB-C IN
2 3 4
1
RELAY RS-232
TRIGGER I/O
MIRACASTWiFi AUX
AUDIO
OUT
L R
IN
USB +
C1 COM C2 RX
PTX
+
+
USB
USB
USB
USB-C
DP
HDMI 3
HDMI 4
BYOD
DISPLAY
INPUT POWER
AT-UHD-SW-510W
IP
1 2 3 4 5 6
7 8 910 11 12 13
Rear

4
Installation Guide
AT-UHD-SW-510W
The AT-UHD-SW-510W provides an RS-232 port which allows communication between an
automation system and an RS-232 device. This step is optional.
1. Use wire strippers to remove a portion of the cable jacket.
2. Remove at least 3/16” (5 mm) from the insulation of the RX, TX, and GND wires.
3. Insert the TX, RX, and GND wires into correct terminal using one of the included 3-pin
captive screw connectors.
NOTE: Typical DB9 connectors use pin 2 for TX, pin 3 for RX, and pin 5 for ground.
On some devices functions of pins 2 and 3 are reversed.
RS-232
GND
RX
TX
The AT-UHD-SW-510W provides the ability to output two-channel balanced analog audio on the
AUDIO OUT port, using the included 5-pin captive screw connector. This step is optional.
Use wire strippers to remove enough insulation to allow each wire to be securely fastened
to each terminal of the captive screw connector block and connect the wires as shown.
Unbalanced audio is not supported.
Audio
Balanced XLR audio
2 1
3
2 1
3
GND GND
-
+
Rear View Rear View
-
+

5
Installation Guide
AT-UHD-SW-510W
Relay
The AT-UHD-SW-510W provides a RELAY port, allowing the control of screens, curtains, and
other devices. Use a 48 V DC relay with no more than 1 A current draw.
When the AT-UHD-SW-510W is powered-on or rebooted, C1 and C2 are set to the Normally
Open (NO) state.
C2
COM
C1
Trigger
The TRIGGER I/O port allows voltage-controlled devices, such as an occupancy sensor,
to be connected to the AT-UHD-SW-510W. Use the included 4-pin captive screw connector to
connect the device. Voltage range is 3 to 30 V DC.
Powered sensor
Passive sensor
Control (Set HIGH)
+12 V DC
Passive sensor
- + P
Common (Set LOW)
Control (Set HIGH)
Powered sensor
30 V (max.)
- + P
GND

6
Installation Guide
AT-UHD-SW-510W
Mounting Instructions
The AT-UHD-SW-510W can be mounted in dierent ways, based on the number of units that are
being installed. The AT-UHD-SW-510W can be mounted in a rack or on/under any at surface.
Single-unit rack installation
1. Attach the included small rack ear (sold separately) to one side of the AT-UHD-SW-510W,
using the included screws.
2. Attach the included longer rack ear (sold separately) to the opposite side of the AT-UHD-
SW-510W using the included screws.
NOTE: AT-UHD-510W-RM rack ears are sold separately. Contact Atlona for more
information.
AT-RON-444
+
USB-C
DP
HDMI 3
HDMI 4
BYOD
DISPLAYINPUT IP POWER
AT-UHD-SW-510W

7
Installation Guide
AT-UHD-SW-510W
Dual-unit rack installation
1. Turn both units upside-down on a at surface, next to each other, as shown.
2. Position the included mounting plates over the holes on the bottom of the enclosure.
When attaching mounting plates, the countersink bevels on the mounting plate should face
upward.
3. Turn the attached units over and install the rack ears (sold separately) to one side of each
enclosure using the included screws.
USB-C
DP
HDMI 3
HDMI 4
BYOD
DISPLAY
INPUT
AT-UHD-SW-510W
IP POWER
USB-C
DP
HDMI 3
HDMI 4
BYOD
DISPLAY
INPUT
AT-UHD-SW-510W
IP POWER
USB-C
DP
HDMI 3
HDMI 4
BYOD
DISPLAY
INPUT
AT-UHD-SW-510W
IP POWER
USB-C
DP
HDMI 3
HDMI 4
BYOD
DISPLAY
INPUT
AT-UHD-SW-510W
IP POWER
Countersink bevel
AT-RON-444
+
USB-C
DP
HDMI 3
HDMI 4
BYOD
DISPLAYINPUT
AT-UHD-SW-510W
IP POWER
USB-C
DP
HDMI 3
HDMI 4
BYOD
DISPLAYINPUT
AT-UHD-SW-510W
IP POWER
AT-RON-444

8
Installation Guide
AT-UHD-SW-510W
Flat surface
1. Turn the unit upside down on a at surface.
2. Position the included mounting plates over the pre-drilled holes on the bottom of the
enclosure. When attaching mounting plates, the countersink bevels on the mounting plates
should face upward.
3. Mount the unit using the circular holes, on each mounting plate. If using a drywall surface,
a #6 drywall screw is recommended. Mounting screws are not included.
NOTE: The unit can also be mounted under a at surface, such as a table, by
turning the unit upside down.
USB-C
DP
HDMI 3
HDMI 4
BYOD
DISPLAY
INPUT
AT-UHD-SW-510W
IP POWER
USB-C
DP
HDMI 3
HDMI 4
BYOD
DISPLAY
INPUT
AT-UHD-SW-510W
IP POWER
USB-C
DP
HDMI 3
HDMI 4
BYOD
DISPLAY
INPUT
AT-UHD-SW-510W
IP POWER
Countersink bevel
AT-RON-444
+
USB-C
DP
HDMI 3
HDMI 4
BYOD
DISPLAYINPUT
AT-UHD-SW-510W
IP POWER

9
Installation Guide
AT-UHD-SW-510W
Installation
1. Connect a USB-C cable from a source to the USB-C (1) port.
2. Connect a DisplayPort cable from a source to the DP IN (2) port.
3. Connect up to two UHD/HD sources, using HDMI cables, to the HDMI IN (3) and HDMI IN
(4) ports.
4. Connect an HDMI cable from the HDMI OUT port to a UHD/HD display.
5. Connect up to two USB wireless antenna modules to the identied USB (WiFi) ports, below.
Two USB wireless antennas are included. WiFi (1) supports Google Cast™ and Apple
AirPlay®. The MIRACAST port (2) only supports Miracast™. The AUX port is reserved for
obtaining the IP address of the unit. Refer to Obtaining the IP Address on page 10 for more
information.
6. Connect the relay leads from the control motors of the projection screen, blinds, or curtains,
to the relay outputs to the RELAY port, using the included 3-pin captive screw connector.
Use a 48 V DC relay with no more than 1 A current draw.
7. Connect a trigger device, such as an occupancy sensor switch, to the TRIGGER I/O port.
A 4-pin captive screw connector is required. Voltages from 3 to 30 V are supported.
8. Connect a 3.5 mm analog audio cable from an analog source to the AUDIO IN port.
This audio source can be used to embed analog audio on any of the input sources.
9. Connect an Ethernet cable from the LAN port to the Local Area Network (LAN).
10. Connect an Ethernet cable from the HDBaseT port to an HDBaseT receiver unit, such as
the AT-UHD-EX-100CE-RX-PSE.
11. Connect the included green 5-pin captive screw connector to the AUDIO OUT connector.
12. Connect the included power supply to the DC 24V connector and connect the power cord
to an available electrical outlet.
13. Follow the on-screen instructions to complete the set-up procedure.
USB-C
DP
HDMI 3
HDMI 4
BYOD
DISPLAY
INPUT
AT-UHD-SW-510W
LAN DC 24V
HDBaseT OUT
HDMI OUTHDMI IN
DP IN
USB-C IN
2 3 4
1
RELAY RS-232
TRIGGER I/O
MIRACASTWiFi AUX
AUDIO
OUT
L R
IN
USB +
C1 COM C2 RX
PTX
+
+
USB
USB
USB
21
IMPORTANT: Only use Atlona Wi-Fi USB modules. Other Wi-Fi modules may
not be supported by this product.
Resetting the Factory-Default Settings
Press and hold the DISPLAY button for 15 seconds to reset the AT-UHD-SW-510W to factory-
default settings. Note that the AT-UHD-SW-510W will be placed in DHCP mode, as part of the
reset procedure.

10
Installation Guide
AT-UHD-SW-510W
By default, the AT-UHD-SW-510W is set to DHCP mode, allowing a DHCP server (if present) to
assign the unit an IP address. If a DHCP server is not found within 15 seconds, then the unit
will be placed in Auto IP mode and use a self-assigned IP address within the range of 169.254.
xxx.xxx. If DHCP or Auto IP mode are not desired, the unit can be placed into static IP mode by
using the INPUT button on the front panel.
Once the desired IP mode is set, refer to Obtaining the IP Address, on the next page, for
information on retrieving the IP address of the unit.
IP Conguration
Connection Diagram
Press and hold the INPUT button for approximately 15 seconds. Release the INPUT button.
All the front-panel LED indicators will begin to ash, then the unit will reboot. The number of
ashes will indicate the currently selected IP mode:
LED ashes Description
Two DHCP mode
Four Factory Static IP mode (IP address set to 192.168.1.254)
Switching the IP mode
USB-C
DP
HDMI3
HDMI4
BYOD
DISPLAY
INPUT IP POWER
AT-UHD-SW-510W
DC48V RS-232 HDBaseTIN HDMIOUT
RXTX
AT-UHD-EX-100CE-RX-PSE
HDMI
UHD/HD Display
DisplayPort
AT-UHD-SW-510W
Ethernet / PoE
Ethernet / PoE
HDBaseT
USB-C
Ethernet
LAN
Laptop
Tablet
(BYOD)
Laptop
Laptop
AT-VGW-250
Miracast™
USB-C AUDIOOUT
Velocity
TM
USB
USB USB USB
AT-VTP-800-WH

11
Installation Guide
AT-UHD-SW-510W
1. Make sure the unit is powered.
2. Connect a display from the HDMI OUT port on the AT-UHD-SW-510W to a display.
Obtaining the IP Address
Accessing the webGUI
The AT-UHD-SW-510W includes a built-in webGUI, which allows easy management and control
of all features. Follow the instructions below to access the webGUI.
1. Make sure that an Ethernet cable is connected between the LAN port on the AT-UHD-SW-
510W and the network.
2. Launch a web browser and enter the IP address of the unit. If the default static IP address
is being used, enter 192.168.1.254.
3. The AT-UHD-SW-510W Login page will be displayed.
4. Enter the following information on the Login page.
Login: admin
Password: Atlona
5. Click the Login button.
6. Refer to User Manual for detailed operation of the webGUI.
NOTE: Refer to the IT Deployment Guide for detailed information on conguring
network modes.
LAN DC 24V
HDBaseT OUT
HDMI OUTHDMI IN
DP IN
USB-C IN
2 3 4
1
RELAY RS-232
TRIGGER I/O
MIRACASTWiFi AUX
AUDIO
OUT
L R
IN
USB +
C1 COM C2 RX
PTX
+
+
USB
USB
USB
USB-C
DP
HDMI 3
HDMI 4
BYOD
DISPLAY
INPUT POWER
AT-UHD-SW-510W
IP
NOTE: The HDBaseT OUT port can also be used as an output port. To do
this, a compatible receiver, such as the AT-UHD-EX-100CE-TX-PSE, must be
connected between the HDBaseT OUT port on the AT-UHD-SW-510W and the
HDBaseT IN port on the receiver. Connect the display to the receiver unit.
3. Press and release the IP button on the front panel to display the IP address of the AT-UHD-
SW-510W on the connected display.

12
Installation Guide
AT-UHD-SW-510W
Troubleshooting
Problem Solution
The source image is not
displayed.
• Check all cable connections between the AT-UHD-SW-
510W and the source(s) and display.
• Check the input indicators on the front panel to make
sure that the correct input is selected. Press and release
the INPUT button to cycle through each input.
• Try switching to another input to verify all source
connections.
Auto-switching is not
working.
• Check all cable connections between the AT-UHD-SW-
510W and source devices. If the cable between the
source and the AT-UHD-SW-510W is damaged or is not
secure, then this will prevent auto-switching from working
correctly.
• Verify that audio switching is set to ON, under the
Conguration menu in the webGUI.
The USB-C port is not
charging my USB device.
• Check that the USB cable is not damaged and provides
a secure connection between the AT-UHD-SW-510W and
the USB device.
• Check the voltage rating of the connected device to
make sure it is compatible. Maximum power and voltage
ratings for the USB-C port are as follows: 60 W at 20 V,
36 W at 12 V, and 15 W at 5 V.
The AT-UHD-SW-510W is
not controlling the display.
RS-232
• Verify the wiring of the RS-232 captive screw connector.
• Make sure that the proper command syntax is being
used; use an RS-232 terminal emulator to verify the
command.
• Check that the baud rate is set to 9600. Also verify that
the device ID, control method for the display, and control
settings for the AT-UHD-SW-510W are correct.
IP
• Make sure that the AT-UHD-SW-510W is on the same
network as the display.
• Ping the display to verify that it is reachable.
• Verify that proper command syntax is being used.
CEC
• Check CEC settings on the display.
• Verify that proper command syntax is being used.

13
Installation Guide
AT-UHD-SW-510W
Notes

14
Installation Guide
AT-UHD-SW-510W
Notes

15
Installation Guide
AT-UHD-SW-510W
Notes

16
Installation Guide
AT-UHD-SW-510W
Version 3
© 2019 Atlona Inc. All rights reserved. “Atlona” and the Atlona logo are registered trademarks of Atlona Inc. All other brand names and trademarks or registered
trademarks are the property of their respective owners. Pricing, specications and availability subject to change without notice. Actual products, product images, and
online product images may vary from images shown here.
Toll free US International
atlona.com •877.536.3976 •41.43.508.4321
