Panduit CBH15L50-V6 User manual

Stainless Steel Trefoil Cable Cleat
Cable Cleat for the Protection and Support
of Insulted Power Cables in Trefoil Arrangement
RW316
Rev. 00 [05-
2019]
INSTALLATION INSTRUCTIONS
© Panduit Corp. 2019
TO REDUCE THE RISK OF INJURY, USER
MUST READ INSTALLATION INSTRUCTIONS
BEFORE ATTEMPTING TO INSTALL
NOTE: In the interest of higher quality and value, Panduit products are
continually being improved and updated. Consequently, pictures
may vary from the enclosed product.
NOTE: Updates to this Installation Instructions may be available. Check
www.panduit.com for the latest version of this manual.

© Panduit Corp. 2019
INSTALLATION INSTRUCTIONS
RW316
Rev. 00 [05-2019]
DOC#: RW316 Page 2of 8 Rev 00 [05-2019]
Email:
[email protected]
EU Website:
www.panduit.com/emea
EU Email:
emeatoolservicecenter
@panduit.com
www.panduit.com
Panduit Corp.
USA Technical Support
Tel: [phone]
Panduit Europe • EMEA Service Center
Tel: [phone] • Fax: [phone]
Preparing for Order
Step
Description
1
Contact Panduit Sales for
assistance with cleat and
hardware selection.
2
Measure actual diameter of
the cables. Select a cleat part
number based on the actual
diameter of the cables.
3
Measure height of the ladder
rung. If using a bracket,
reference chart below. If using
a bolt, procure M8 or 5/16”
carriage bolts, washers, and
nylon locknuts with sufficient
length to pass through the
ladder rung.
Rung Height
Bracket Family Number
15mm (.59”) or less
CBH15L50-V6
15mm (.59”) to 20mm
(.79”)
CBH20L50-V6
20mm (.79”) to 25mm
(.98”)
CBH25L50-V6
25mm (.98”) to 30mm
(1.16”)
CBH30L50-V6

© Panduit Corp. 2019
INSTALLATION INSTRUCTIONS
RW316
Rev. 00 [05-2019]
DOC#: RW316 Page 3of 8 Rev 00 [05-2019]
Cable Cleat Nomenclature
Cleat Clamshell Top
Fastening Bolt, Washer, and
Locknut (Included in Package)
Securing Bolt, Washer,
and Locknut
Cleat Clamshell Bottom
Bottom Plastic Spacer
Top Plastic Spacer
Mounting Bracket
Swing Bolt with
Flanged Nut
Slotted Ladder Rack/Rung
Unslotted Ladder Rack/Rung
Cables, Trefoil Configuration

© Panduit Corp. 2019
INSTALLATION INSTRUCTIONS
RW316
Rev. 00 [05-2019]
DOC#: RW316 Page 4of 8 Rev 00 [05-2019]
Mounting Method 1: Bracket
Step
Description
1
OR
Measure the cable diameter.
Remove top plastic spacer
depending on cable
diameter. See table on page
8.
2
Insert bracket into slot in
lower plastic spacer of cable
cleat.
3
Slide cleat over rung until
centered, with bracket
encompassing the rung.

© Panduit Corp. 2019
INSTALLATION INSTRUCTIONS
RW316
Rev. 00 [05-2019]
DOC#: RW316 Page 5of 8 Rev 00 [05-2019]
4
Rotate swing bolt until the
carriage head rests within
the matching opening in the
top of the bracket. Tighten
flange nut to 60 in-lbs
[6.8Nm].
5
Open top clamshell and
place trefoil cables in the
opening in a trefoil
configuration. Close top
clamshell around the cables.
6
Assemble included nut and
washer onto the securing
bolt. Tighten to 15 ft-lbs
[20.3Nm].

© Panduit Corp. 2019
INSTALLATION INSTRUCTIONS
RW316
Rev. 00 [05-2019]
DOC#: RW316 Page 6of 8 Rev 00 [05-2019]
Mounting Method 2: Bolt
Step
Description
1
Remove top plastic spacer
to allow access to the bolt
hole.
2
Position cleat over the
appropriate hole in the rung.
Assemble securing carriage
bolt through the hole in the
bottom of the cleat.
3
Tighten securing bolt to 120
in-lbs [13.6Nm].

© Panduit Corp. 2019
INSTALLATION INSTRUCTIONS
RW316
Rev. 00 [05-2019]
DOC#: RW316 Page 7of 8 Rev 00 [05-2019]
4
OR
Measure the cable diameter.
Remove top plastic spacer
depending on cable
diameter. See table on page
8.
5
Open top clamshell and
place cables in the opening
in a trefoil configuration.
Close top clamshell around
the cables.
6
Assemble included nut and
washer onto the securing
bolt. Tighten to 15 ft-lbs
[20.3Nm].

© Panduit Corp. 2019
INSTALLATION INSTRUCTIONS
RW316
Rev. 00 [05-2019]
DOC#: RW316 Page 8of 8 Rev 00 [05-2019]
Spacer Decision Table
Part Number
Cable
Range
Use Top
Spacer
Discard Top
Spacer
CCSSTR2025-X
20 –25mm
20 –22.5mm
22.5 –25mm
CCSSTR2328-X
23 –28mm
23 –25.5mm
25.5 –28mm
CCSSTR2632-X
26 –32mm
26 –29mm
29 –32mm
CCSSTR3036-X
30 –36mm
30 –33mm
33 –36mm
CCSSTR3440-X
34 –40mm
34 –37mm
37 –40mm
CCSSTR3844-X
38 –44mm
38 –41mm
41 –44mm
CCSSTR4248-X
42 –48mm
42 –45mm
45 –48mm
CCSSTR4652-X
46 –52mm
46 –49mm
49 –52mm
CCSSTR5057-X
50 –57mm
50 –53.5mm
53.5 –57mm
CCSSTR5461-X
54 –61mm
54 –57.5mm
57.5 –61mm
CCSSTR5865-X
58 –65mm
58 –61.5mm
61.5 –65mm
CCSSTR6269-X
62 –69mm
62 –65.5mm
65.5 –69mm
