panthera S3 User manual

Panthera AB, Gunnebogatan 26, SE-163 53 Spånga, Sweden, [phone], www.panthera.se
ASSEMBLY INSTRUCTIONS
art.nr. mont-kryckkäppshållare-S3-eng
Rev.2018-03
CRUTCH HOLDER S3
1) Take the crutch apart 2) Remove the plastic hose from the up-
per part of the crutch.
3) Slide the upper attachment onto the
upper part of the crutch. The upper at-
tachment ts tube diameter 19,2 to 23
mm, including the plastic bushings.
Assembly instructions for:
Crutch holder S3
art.no. 9900301
NOTE! The mounting could vary depending on type of crutch.
Tools needed:
Small Philips head screw driver (Bits PH 0)
4) Tighten one of the screws slightly.
With a small philips head screw driver.
(Bits PH 0)
5) Remount the plastic hose. 6) Remove the rubber shoe from the lo-
wer part of the crutch.
Link to assembly
video
Link to user manual

Panthera AB, Gunnebogatan 26, SE-163 53 Spånga, Sweden, [phone], www.panthera.se
7) Slide the lower, magnetic, attachment
onto the lower part of the crutch. The lo-
wer attacment ts tube diameter 16,5 to
19,2 mm, including the plastic bushings.
Don´t tighten the screws yet.
8) Remount the crutch. 9) Hang the crutch with the upper at-
tachment on the backrest tube. Turn
the crutch until the handle of the crutch
points backwards, away from the wheel-
chair.
10) Tighten the screws by turns with a
small philips head screw driver (Bits PH
0). Use moderate force when tightening
the screws.
11) Adjust the lower, magnetic, attach-
ment in height until it is level with the
chassis tube.
12 Tighten the screws by turns with a
small philips screw driver. Use moderate
force when tightening the screws.
13) Attach the crutch to the wheelchair
with its mounted attachments.
Repeat the procedure on the other
crutch, if there is one.
