ParaBody GS4 User manual

1
LEG PRESS ADAPTER KIT
CLASS H
PART#7362701
REV. A Revision: 11/01/02
USER’S GUIDE
WARNING:
Read and follow all directions
for each step to insure proper
assembly of this product.
FOR GS4 GYM SYSTEM
Version:GS4-LP5A-101

THERE IS A RISK ASSUMED BY INDIVIDUALS WHO USE THIS TYPE OF
EQUIPMENT. TO MINIMIZE RISK FOLLOW THESE RULES!
1. Before using, read all the warnings and instructions
on the use of this machine. Use only for intended
exercise. DO NOT modify the machine.
2. Obtain a medical exam before beginning any
exercise program.
3. Keep body and clothing free of all moving objects.
4. Inspect the machine before use. DO NOT use it if it
appears damaged. DO NOT attempt to fix a broken or
j
ammed machine. Notify your authorized ParaBody
dealer before use and have repairs made by an
authorized service technician.
5. Be certain that weight pin is completely inserted.
Use only the pin provided by the manufacturer. If
unsure, call your authorized ParaBody dealer.
6. Never pin the weights or prop plate into an elevated
position. DO NOT use the machine if found in this
condition. DO NOT attempt to fix. Notify your
authorized ParaBody dealer.
7. Inspect cables and their connections before using
machine. Pay particular attention to the cable ends.
DO NOT attempt to fix. Notify your authorized
ParaBody dealer before use and have repairs made by
an authorized service technician.
8. Make sure all spring loaded pull pins are fully
engaged in the adjustment position and fully tighten
thumbscrew before use.
9. Children must not be allowed near this machine.
Supervise teenagers.
.
IMPORTANT SAFETY INFORMATION
TABLE OF CONTENTS
Safety Statement.............2
General Notes..................3
Tools Required................3
NOTE: In a continual effort to improve our products, specifications are subject to change
2002 Life Fitness, a division of Brunswick Corporation. All rights reserved.
ParaBody is a trademark of Brunswick Corporation
www.parabody.com
2
Parts list..........................4
Assembly Instructions.....4-11
Insert-Registration Card
©

IMPORTANT NOTES
Please note:
Tools Required for Assembly
* Thank you for purchasing the ParaBody GS4 Leg Press Adapter Kit. Please read these
instructions thoroughly and keep them for future reference. This product must be assembled
on a flat, level surface to assure its proper function.
* 9/16” wrench
* Ratchet with 9/16” socket
*Adjustable wrench
* Tape measure
3
NOTE: BOLT LENGTH IS MEASURED FROM THE UNDERSIDE OFTHE HEAD OF THE BOLT.
BOLT LENGTH RULER:
* This product must be assembled on a flat, level surface to assure its proper function. DO NOT
securely tighten any frame connections until the entire frame has been assembled, unless
otherwise stated.
Bolt Length Ruler
0123456
1/2 1/2 1/2 1/2 1/2 1/2
BOLT LENGTH

PARTS LIST
4
NOTE: The LEG PRESSATTACHMENT (LP5) must be assembled before connecting it to the PARABODY GS1/GS2 GYM
SYSTEMS
PART #
ACU04-1525
ACU04-1526
ACU02-0055
ACU13-0149
ACU06-0024
ACUDA1E03853416NB
ACUDA1E03843416NB
ACUDA1E03833416NB
QTY
1
1
1
1
7
2
5
2
PART #
ACUDA1E03823416NB
ACUDA1E03813416NB
ACUDC1250100020B
ACUDB2E03811000B
ACU08-0085
ACU08-0076
ACU08-0079
DESCRIPTION
3/8X2-3/4”BOLT
3/8X1-3/4”BOLT
3/8”WASHER
3/8”LOCK NUT
STEPSPACER 19/32”
STEPSPACER1-9/16”
STEPSPACER1-11/16”
QTY
2
3
9
14
4
4
2
DESCRIPTION
CONNECTINGTUBE
PULLEYHOUSING
CABLERETAINER
LEGPRESSCABLE202-3/4
3-1/2PULLEY
3/8”X5-3/4” BOLT
3/8X4-3/4”BOLT
3/8”X3-3/4” BOLT
KEY
9
10
11
12
13
14
15
KEY
1
2
3
4
5
6
7
8
FIGURE 1
STEP 1:
• Remove the LEG CABLE and the BOLT, NUT andWASHER used to secure CABLE to base. Discard CABLE
DISCARD!
CABLE
• Remove END CAP and the bolts attaching the FRAME BRACE and insert new CONNECTING TUBE (1) using same BOLTS and re-
install endcap.
REMOVELOWER
PULLEY
1

5
0123456
1/2 1/2 1/2 1/2 1/2 1/2
• InstallPULLEYHOUSING (2)using two3/8 X5-3/4” BOLTS (6),four 3/8”WASHERS (11)and two 3/8” LOCK NUTS (12)
as shown in FIGURE 2
FIGURE 2
STEP 2:
3/8 X 5-3/4”
12
11
6
2

FIGURE 3
STEP 3:
• Assemblethe newLEG PRESSto the CONNECTINGTUBE (1) using two 3/8 X 3-3/4” BOLTS(8), four 3/8”WASHERS (11)
and two 3/8” LOCK NUTS (12) as shown in FIGURE 3
6
8 11
1
12
3/8 X 3-3/4”

FIGURE 4
7
2
5
CABLEGUIDE
0123456
1/2 1/2 1/2 1/2 1/2 1/2
STEP4:
• Assembleone3-1/2PULLEY(5)tothePULLEYHOUSING (2)usingone 3/8X1-3/4”BOLT(10)andone3/8”LOCK NUT(12)asshown
inFIGURE4(b). NOTE: CABLEMUSTBEPLACEDIN PULLEYHOUSINGBEFOREINSTALLING PULLEY
• Route the LEG PRESS CABLE (3) around one 3-1/2” PULLEY(5) and re-assemble the PULLEYto the FLOATING PULLEY PLATES
usingtheBOLT, NUTand PULLEY which wereremoved. See FIGURE4.
• Screwthe threadedend of the LEG PRESS CABLE (4) intothe end of the FLOATING PULLEYBRACKET. Secure the CABLGUIDE
inplace with the JAM NUT on the GUIDE CABLE. See FIGURE 4(a)
10
12
5
4(a)
4(b)
3/8X 1-3/4”

FIGURE 5
8
3
12 11
10 3/8 X1-3/4”
• Carefully route the LEG PRESS CABLE (4) around one 3-1/2” PULLEY(5) and SECURELYassemble the 3-1/2” PULLEY(5) to the
BRACKET(from 100 LEGPRESS kit) usingone 3/8 X 1-3/4” BOLT(10),one 3/8”WASHER (11),one “L” CABLERETAINER (3)
and one 3/8” LOCK NUT (12) as shown in FIGURE 5. Make sure the CABLE is in the grooves of all the pulleys.
• SECURELYattach the BRACKET(fromLP5 LEG PRESS)to the SEATFRAMEusing two 3/8”X 4-3/4”BOLTS(7),two 3/8”WASH-
ERS(11),andtwo3/8”LOCKNUTS(12).SeeFIGURE5.
7 3/8 X 4-3/4”
5
4
LEGPRESSBRACKET
STEP5:
FIGURE 6
STEP6:
• Carefully route the LEG PRESS CABLE (4) around one 3-1/2” PULLEY(5) and SECURELYassemble the 3-1/2” PULLEY (5) to the
bracket on the SEAT FRAME using one 3/8 X 1-3/4” BOLT (10) and one 3/8” LOCK NUT (12) as shown in FIGURE 6. Make sure the
CABLE is in the grooves of all the pulleys.
3/8X 1-3/4” 10
5
4
12
SEATFRAME

9
0123456
1/2 1/2 1/2 1/2 1/2 1/2
FIGURE 7
STEP7:
3/8X 4-3/4” 10
5
4
12
14
3/8 LOCKNUT
SEAT FRAME
• CarefullyroutetheLEGPRESSCABLE (4) around one 3-1/2”PULLEY(5)andSECURELYassemblethe3-1/2”PULLEY(5) to theSEAT
FRAMEusingone 3/8 X 4-3/4”BOLT(7),two STEPSPACERS1-9/16”(14)and one 3/8”LOCKNUT(12) asshownin FIGURE 7. Make
sure the CABLE is in the grooves of all the pulleys.
MAIN ARM
FIGURE 8
STEP8:
• Carefullyroute theLEG PRESS CABLE (4) around one 3-1/2” PULLEY(5) and SECURELYassemblethe 3-1/2” PULLEY(5) to the
MAINARM using one 3/8 X 2-3/4” BOLT (9), two STEPSPACERS 19/32” (13) and one 3/8” LOCK NUT (12) as shown in FIGURE
8. Make sure the CABLE is in the grooves of all the pulleys.
3/8X 2-3/4” 9
4
12
13
5

10
FIGURE 9
STEP9:
3/8X 4-3/4” 7
5
4
12
14
3/8” LOCKNUT
SEAT FRAME
• Carefullyroute theLEG PRESS CABLE (4) around one 3-1/2” PULLEY(5) andSECURELYassemble the 3-1/2” PULLEY(5) to the
SEAT FRAME using one 3/8 X 4-3/4” BOLT (7), two STEPSPACERS 1-9/16” (14), and one 3/8” LOCK NUT (12) as shown in
FIGURE 9. Make sure the CABLE is in the grooves of all the pulleys.
FIGURE 10
STEP10:
• CarefullyroutetheLEGPRESSCABLE(4)aroundone3-1/2”PULLEY(5)and SECURELYassemble the 3-1/2” PULLEY(5) to the MAIN
ARMusing one3/8 X 2-3/4” BOLT(9), two STEPSPACERS19/32” (13)and one 3/8” LOCK NUT(12) as shown in FIGURE 10. Make
sure the CABLE is in the grooves of all the pulleys.
3/8 X 2-3/4” 9
5
4
12
13
MAIN ARM

FIGURE 12
STEP12:
3/8X 4-3/4” 7
4
12
15
SEAT FRAME
11
• SECURELYassemble the swivel end ofthe LEGPRESS CABLE (4) to the SEATFRAME using one 3/8 X4-3/4” BOLT(15),two STEP
SPACERS1-11/16”(15)andone3/8”LOCK NUT(12). (NOTE:SECURELYtighten,thenbacknutoff1/4turn)
CABLE ROUTING DIAGRAM

FIGURE 13
STEP13:
• Before setting the correct amount of tension in the cables, push the HEAD PLATE down, insert the WEIGHT SELECTOR PIN,
and perform several repetitions at the leg press station. This will relax the cable system and prevent the HEAD PLATE from
lifting up.
THISCONCLUDESTHEASSEMBLYOFTHEGS4-LP5ALEGPRESSADAPTERKIT
12
Thankyouforpurchasingthe Parabody GS4-LP5ALeg PressAdapterKit.Ifunsureof properuse of equip-
ment,callyourlocalParabodydistributororcalltheParabodycustomerservicedepartmentat [phone].
ADJUST!
ADJUST!
