ParaBody 916101 User manual

:~erious Steel
I II I 916101 ST DUMBELL RACK
L
ASSEMBLY INSTRUCTIONS
Part # 6691101 1 Revision: 05/05/97

iIMPORTANT NOTES
I
The~reis a risk assumedby individuals whouse this type of equipment.Tominiraize risk, please
followthese rules:
1. Consult your physician before beginning any exercise program.
2. Inspect equipmentdaily. Tighten all loose connectionsand replace wornp~a’ts immediately.
Failure to doso mayresult in serious injury.
3. Donot allow minorsor children to play on or aroundthis equipment.
4. Exercisewithcare., to avoidinjury.
5. If unsureof properuse of equipment,call yourlocal Parabodydistributor or call the
Parabodycustomer service department at [phone].
Please note:
* Thankyou for purchasing the Parabody916101STDumbbell.Please read these
instructions thoroughly and keep themfor future reference. This product mustbe assembled
ona flat, level surfaceto assureits properfunction.
* Werecommendcleaning your product (pads and frame) on a regular basis, using warmsoapy
water. Touch-uppaint can be purchasedfrom your Parabodycustomerservice representative
at [phone].
ITools Requi,red for Assembly
I
*3/4" wrench
* Ratchet with 3/4"
* Tape measure socket
Bolt LengthRuler
NOTE: BOLT LENGTH IS MEASURED FROM THE UNDERSIDE OF THE HEAD OF THE BOLT.
0123456

PARTS LIST ’,’1
KEY PART# DESCRIPTION QTY
16688301 UPRIGHTFRAME 2
26688701 TOP TIER 1
36689001 BOTfOMTIER 1
4 3202103 1/2-13 X 4" BOLT 8
5 3102502 1/2" WASI-~R 8
63102801 1/2" LOCKNUT 8
STEP 1: Loosely attach BoTroMTIER (3) between the UPRIGHTFRAMES(1) using fi)ur 1/2
BOLTS(4) four 1/2" WASHERS(5), and four 1/2" LOCKNUTS(6) as showr~ in figure
(NOTE: BoTroM TIER (3) is wider than TOP TrER (2).
FIGURE 1
1/2 X4"
I 1/2 I

STEP2: Loosely attach TOPTIER(2) between the UPRIGHTFRAMES(1) using lobar 1/2
BOLTS(4), four 1/2" WASHERS(5), and four 1/2" LOCKNUTS(6) as shc,wn in figure
(NOTE:BOTTOMTIER (3) is wider than TOPTIER (2).
FIGURE 2
STEP 3: SECURELN TIGHTEN ALL BOLT CONNECTIONS.
3[ I I I
0 [ I I I
I I 4
