ParaBody GS6 User manual

1
WT. STACK SHROUD FOR GS6/GS8
CLASSH
PART #7309601
REV.A Revision: 07/15/02
USER’S GUIDE
WARNING:
Read and follow all directions
for each step to insure proper
assembly of this product.
Version: GS6-SHR-101

THERE IS A RISK ASSUMED BY INDIVIDUALS WHO USE THIS TYPE OF
EQUIPMENT. TO MINIMIZE RISK FOLLOW THESE RULES!
1. Before using, read all the warnings and instructions
on the use of this machine. Use only for intended
exercise. DO NOT modify the machine.
2. Obtain a medical exam before beginning any
exercise program.
3. Keep body and clothing free of all moving objects.
4. Inspect the machine before use. DO NOT use it if it
appears damaged. DO NOT attempt to fix a broken or
j
ammed machine. Notify your authorized ParaBody
dealer before use and have repairs made by an
authorized service technician.
5. Be certain that weight pin is completely inserted.
Use only the pin provided by the manufacturer. If
unsure, call your authorized ParaBody dealer.
6. Never pin the weights or prop plate into an elevated
position. DO NOT use the machine if found in this
condition. DO NOT attempt to fix. Notify your
authorized ParaBody dealer.
7. Inspect cables and their connections before using
machine. Pay particular attention to the cable ends.
DO NOT attempt to fix. Notify your authorized
ParaBody dealer before use and have repairs made by
an authorized service technician.
8. Make sure all spring loaded pull pins are fully
engaged in the adjustment position and fully tighten
thumbscrew before use.
9. Children must not be allowed near this machine.
Supervise teenagers.
.
IMPORTANT SAFETY INFORMATION
TABLE OF CONTENTS
Safety Statement.............2
General Notes..................3
Tools Required................3
Parts List.........................4
NOTE: In a continual effort to improve our products, specifications are subject to change
2002 Life Fitness, a division of Brunswick Corporation. All rights reserved.
ParaBody is a trademark of Brunswick Corporation
www.parabody.com
2
Assembly Instructions.....4-5
General Maintenance......6
Warranty Statement........7
Product Services............8
Insert-Registration Card
©

IMPORTANT NOTES
Please note:
Tools Required forAssembly
* Thank you for purchasing the ParaBody WT. STACK SHROUD FOR GS6/GS8. Please read
these instructions thoroughly and keep them for future reference.
* 9/16” wrench
* Ratchet with 9/16” sockets
* 7/32”Allen wrench
3
NOTE:BOLTLENGTHIS MEASURED FROMTHEUNDERSIDE OFTHEHEADOFTHEBOLT.
BOLT LENGTH RULER:
* This product must be assembled on a flat, level surface to assure its proper function. DO NOT
securely tighten any frame connections until the entire frame has been assembled, unless
otherwise stated.
Bolt Length Ruler
0123456
1/2 1/2 1/2 1/2 1/2 1/2
BOLT LENGTH

4
PARTS LIST
PART #
7157409
7157509
7114909
7115009
KEY
1
2
3
4
QTY
1
1
1
1
PART #
3202401
3228501
3235210
3114702
DESCRIPTION
3/8 X 1” BUTTON HEAD BOLT
3/8” BLACK SAEWASHER
3/8 X 2-1/2” BOLT
3/8” LOCK NUT
QTY
8
8
2
2
DESCRIPTION
LEFT SHROUD
RIGHT SHROUD
TOPSHROUDBRACKET
BOTTOMSHROUD BRACKET
KEY
5
6
7
8
FIGURE 1
• SECURELY assemble the TOP SHROUD BRACKET (3) to the BOOM BRACKET using two 3/8 X 2-1/2” BOLTS (7) and two
3/8” LOCK NUTS (8) as shown in FIGURE 1. The BOTTOM SHROUD BRACKET (4) was previously inserted under the weight
stack in the GYM ASSEMBLYINSTRUCTIONS.
STEP 1:
3/8 X 2-1/2” 7
BOOM BRACKET
8
3
4

0123456
1/2 1/2 1/2 1/2 1/2 1/2
FIGURE 2
5
STEP 2:
• This completes the assembly of the WT. STACK SHROUD FOR GS6/GS8.
3/8 X 1” 5
BUTTON
HEAD
2
6
1
• SECURELYassemble the LEFT SHROUD (1) and RIGHT SHROUD (2) to theTOP(3) and BOTTOM (4) SHROUD BRACKETS
using eight 3/8 X 1” BUTTON HEAD BOLTS (5) and eight 3/8” BLACK SAE WASHERS (6) as shown in FIGURE 2. (NOTE:
Assemble LEFT SHROUD (1) by inserting top of shroud first, then lift up and swing the bottom of shroud into place.)
• If the GS8 SECOND STACK OPTION was purchased, repeat STEPS 1 & 2 to assemble the SHROUDS (1 & 2) to the
SECOND STACK.

MAINTENANCE
MODEL #________________________
SERIAL #_________________________
DATE OF PURCHASE: _____________
DEALERS NAME: _________________
DEALERS PHONE #_______________
6
* We recommend cleaning your product (pads and frame) on a regular basis, using warm soapy
water. Touch-up paint can be purchased from your ParaBody customer service representative
at [phone].
* Inspect equipment daily. Tighten all loose connections are replace worn parts immediately.
Failure to do so may result in serious injury
ThankyouforpurchasingtheParaBodyWt. Stack ShroudforGS6/GS8.
Please note:
* PLEASE RECORD THE INFORMATION REQUESTED BELOW. IN THE EVENT
YOU MAY NEED SERVICEYOU WILLBEASKED FOR THIS INFORMATION.
REMEMBER TO FILL OUTYOUR WARRANTY REGISTRATION CARD AND
MAIL BACK.
SERIALNUMBERLOCATION

7
NOTES:
LIMITEDWARRANTY
ParaBodyextends the following LIMITED WARRANTYto the original owner of the ParaBody products. The Warranty terms apply to IN HOME USE ONLY.
1. LIMITEDWARRANTYON FRAMEANDWELDS. If theframe ofthe ParaBodyproduct or a weld should crack or break, itwill berepaired
or replaced by ParaBody. Terms: Lifetime – for so long as the Customer owns the ParaBody product.
2. LIMITEDWARRANTYON PARTS. Ifthefollowing partsaredefective inmaterial or workmanship,ParaBody will supplyreplacement parts:
all bolts, nuts, washers, bearings, bushings, pulleys, thumbscrews, collars, cable retaining clips, adjustable pre-stretch slides, roller pad
shafts, allen head bolts, weight selector pin, weight stack shaft, set screws, protector caps, adjustment chain, cotter pin, plunger, spring
and knob. Terms: Lifetime – for so long as the Customer owns the ParaBody product.
3. LIMITED WARRANTY ON CABLESAND UPHOLSTERY. If the coated cables or upholstery are defective in material or workmanship,
ParaBody will repair or replace them, at its option. Terms: Three (3) years.
4. CONDITIONSAND EXCEPTIONS. Any product misuse, abuse or alteration, any attempt to repair by a person other than an authorized
ParaBody Service Center, any improper assembly, accident, or any other condition resulting from occurrences beyond the control of
ParaBody will void this Limited Warranty.
5. REPLACEMENTAND REPAIR EXPENSES. ParaBody will provide only replacement parts or repair under this warranty. The Owner is
responsiblefor all other costs. Such costsmay include,but are notlimited to: a.labor charges for service, removal,repair orreinstallation
oftheParaBody product orany component part; b.shipping,delivery,handling and administrativecharges for returningpartsto ParaBody;
and c. all necessary or incidental costs related to installation of the replacement parts.
6. SHIPPING. Ifshippingby the Ownersis deemednecessary (in solediscretion of ParaBody),partsshouldbe shippedin their originalcarton
orequivalent packaging, fully insured withshipping chargesprepaid. ParaBody willnot assume any responsibility forany lossor damage
incurredin shipping.
7. CLAIMPROCEDURES. If serviceon yourParaBody productis requiredduring thewarranty period,please contactour CustomerService
Departmentat1-800-328-9714forinstructionsregarding returning or replacingparts. Pleasehaveavailablethefollowing information: (i)the
dealer’s name; (ii) the date of purchase; (iii) the serial # (s) of your product (the serial number location is called out on the final assembly
drawingincluded withyour assembly instruction); (iv) a description of the natureof theproblem.
8. OWNER’SRIGHT. This Limited Warrantygivesyou specificlegalrights. You mayalso have otherrights,which vary dependingon local law.
9. LIMITATION OF IMPLIED WARRANTIES. All implied warranties, except to the extent prohibited by applicable law, shall have no greater
duration than the warranty period set forth above. There are no warranties which extend beyond the description inthis Limited Warranty.
Because local laws do not allow limitations on how long an implied warranty lasts, the above limitations may not apply to you.
10. DISCLAIMER. No other express warrantyhas beenmade orwill bemade onbehalf ofParaBody with respect to any ParaBody productor
the operation, repair or replacement of any ParaBody product. ParaBody shall not be responsible for injury, loss of use of the ParaBody
product,inconvenience, lossor damageto personalproperty, whetherdirect orindirect, andincidental orconsequential damages,sothe
above limitation or exclusion may not apply to you.
