ParaBody FACTOR 625 User manual

I:)E}F604
Volume 2
Optional Shroud Kit
S EMB L Y
NSTRUCTIOHS
625
B Y P A R A B OD Y
Our Strength Begins With Listening.

IMPORTANT
KEEPALLFRAMEBOLTCONNECTIONSLOOSEUNTILINSTRUCTEDIN
THEASSEMBLYSTEPSEQUENCESTOSECURELYTIGHTEN.
NOTE:
¯TheParaBodyFactor625baseunitmustbeassembledon
aflat,levelsurfacetoassureitsproperfunction.
¯ParaBodystronglyrecommendsthatthisproductbeassembled
bytwopersonstoavoidpossibleiniury.
!!I llI
.WARNING...
MAKESURESNAPHOOKSAREFASTENEDBEFOREDOINGEXERaSES.
!!!WARNING!!!-
LATBARIS NOTTOBEUSEDFORPULL-UPS.
NOTE:Werecommendcleaningyourproduct(padsandtheframemembers)onaregular
basis,usingwarmsoapywater.Also,touch-uppaintcanbepurchasedfromyour
ParaBodyCustomerServiceRepresentativent1-800-328-9)’14.
WELDMENTS/PARTS:
ITEM NAME/DESCRIPTION QTY.
1OptionnlShroud (PB3179-01) 5
2 ShroudRod (PB3189-01) 10
3Dbl.SidedFoamTape3/4"x72"(Cl196-01) 10
4 Poly-Lock3/4"x4"(20piecesinBag) 1
1.Laytheshroudonadean/flat/firmsurface.
2.Adhereonerollofthedoublesidedfoamtape
3/4"x72"tooneoftheshroudrods.Securetwo(2)
ofthe3/4"x4"Poly-lockstotheshroudrod(oneon
eachendofthesideoppositethedoublesidedfoam
tape).Dothisfortheremaining(1)shroudrod.
3. Usingatemplateortapemeasure,scribethe21/2
"
locationfortheshroudrodsonthesmooth/non
screenedsideoftheshrouds.
4.Removethebackingpaperfromthedoublesided
foamtapeononeoftheshroudrodsandcarefully
fastentheshroudrodtotheshroudusshown.Repeat
thisforthesecondshroudrod.Theshroudrodshould
beappliedtothesmoothornonscreenedsideofeach
shroud.
SHROUD
DOUBLESIDEDFOAMTAPE
3/4"X72"ROLLS
2 ROLLS/SHROUD
SHROUDROD
POLY-LOCK
3/4.X4"
--L POLY-LOCK
~ 3/4. X4.
4/SHROUD
LEGPRESS/2STACKSHROUD
NOHAIRCELLTEXTUREONTHISSIDE
SHROUDROD
2/SHROUD
If youhaveanyquestionsontheproperassemblyofequipment,
donothesitatetocalltheParaBodyCustomerServiceDepartmentat
T -800-328-97 T 4

Donotmarkthis box! Document:11000199

PARAB6DY INC.
FACTOR625 D-RING RETROKIT
607/608
PRODUCT ASSEMBLY
INSTRUCTION SHEETS
TOOLS REQUIRED FOR ASSEMBLY
RATCHET
9/16 INCH SOCKET
7/16 INCH WRENCH
ADJUSTABLE WRENCH
REVISION: A
If youexperience any problemwith the assemblyof this product, please contact yo~ar dealer
or your PARABODYCustomer Service Representative at:
1-800-328-9714

607/608 FACTOR 625 D-RING RETRO KIT ASSEMBLY PARTS LIST
HARDWARE/PARTS:
ITEM NAME/DESCRIPTION QT~(
2.
3.
4.
5.
6.
7
8.
9.
D-RINGWLDMNT........................................................ (6352301)........................ ~...............1
ROTARYCABLE.......................................................... (6406001)........................................ I
LEGPRESS/ROTARYCABLE..................................... (6405701)....................................... 1
PEC/D-RINGCABLE........... ~........
.~................................
(6406101)....................................... 1
MULTIPRESSCABLE.......... ..X......................................(6405801)........... =....~.~,.~................ 1
LATCABLE................................................... (6405901)
"’’!’’~""’~’"
...... :"~............... 1
SWIVEL.......................................................................... (3201501)....................................... 4
D-RINGCABLECLIP................................................... (3200501)....................................... 4
¯ VINYLCAP.................................................................... (3201402)....................................... 1

607/608 FACTOR 625 D-RING RETRO KIT ASSEMBLY INSTRUCTIONS
STEP 1: D-RING’INSTALLATION
1. Toassemble the newD-RINGto the FACTOR625, use the following steps:
¯Removeall the CABLESfrom the old D-RING.
¯Loosen, and removethe two (2) 1/4-20 NUTS,and the 1/4 IN. WASHERfrom the end of the
RING CABLE.
¯Slide one (1) VINYLCAPover the end of the newD-RING.
¯Removeand discard old D-RING,and replace with the newD-RING.
¯LOOSELYattach the 1/4 IN. WASHER,and the two (2) 1/4 IN. NUTSto the end of the D..RING
CABLE. (POSITION THE 1/4-28 NUTS HALF WAYUP ON THE THREADSOF TIlE D-
RING CABLEUNTIL CABLEINSTALLATION IS COMPLETE.DO NOT TIGI-][TEN NUTS
AT THIS TIME)
STEP: 2 CABLE INSTALLATION
NOTE: FOR EASE OF CABLE REPLACEMENTTHE D-RING END OF THE OLD CABLES MAYBE
CUT OFF. IF THIS IS NOT POSSIBLE SOMEPULLEYS WILL NEED TO BE LOOSENEDAND
REMOVED TEMPORALLY IN ORDER TO REMOVEOLD CABLES.
To replace the ROTARYCABLE(6406001), or (depending on which RETROKIT being assembled)
the LEGPRESS/ROTARYCABLE(6405701), see the drawing, and use the following steps:
¯Removethe SHOCKCORDfrom the BASEof the 625, then remove it from the end of the old
ROTARY CABLE.
¯ Removeand discard the old ROTARYCABLE,and replace it with the new ROTARYCABLE.
(THE CABLE MUST BE ROUTEDTHE SAME WAYIT WASREMOVED).
¯Run the ROTARYCABLEthrough the hole of the D-RINGshown in (DETAILA )on drawing, and
attach one (1) D-RINGCABLECLIP around the ball end of the ROTARYCABLE.
¯ Attach one (1) SHOCKCORDto the D-RINGCABLECLIP on the end of the ROTARYCABLE
as shown in (DETAILA).
¯Route the SHOCKCORDthe same waythat it was removed. Attach one (I) SWIVELto the end
the SHOCKCORD,and slide the swivel over the BARon the BASEas shown in (VIEWB-B).
Replace the SHOCKCORDto its original position on the BAR
¯ IMPORTANT: MAKESURE THAT THE D-RING CABLE CLIP IS POSITIONED
VERTICALLY ABOVETHE D-RING.

607/608 FACTOR625 D-RING RETRO KIT ASSEMBLY INSTRUCTIONS
3. Replace the remaining CABLESin the following’or~er using the steps outlined in STEP2: (PLEASE
REPLACE ONE CABLE AT A TIME, REPLACING IN A CLOCKWISE DIRECTION AROUND
THE D-RING. SEE DRAWING)
¯PEC/D-RING CABLE(6406101)
¯MULTI PRESS CABLE(6405801)
¯LAT CABLE(6405901)
Whenall of the CABLEShave been replaced, adjust the height of the D-RINGon the D-RINGCABLE
by raising or lowering the two (2) 1/4-28 IN. NUTS.(THE D-RINGSHOULDRESTJUSTBELOW
THED-RINGCABLECLIPS ONTHECABLEENDS). Whenthe correct height is obtained.
SECURELYtighten the two (2) 1/4-28 nuts together.
